Extraflame DIADEMA ACS Series User manual

MADE IN ITALY
design & production
DIADEMA ACS
004276529 - Rev 010
UK THeRMO PRODUCTS USeR MANUAL

2

ENGLISH
ENGLISH........................................................................................................................................................................................................................................ 4
WarNINGS.................................................................................................................................................................................................................................... 4
SafEty.......................................................................................................................................................................................................................................... 4
routINE MaINtENaNcE............................................................................................................................................................................................................ 6
HyDrauLIc SyStEM.................................................................................................................................................................................................................... 7
INSTALLATION AND SAFETY DEVICES.................................................................................................................................................................................................................................7
aNtI-coNDENSatIoN DEVIcE (MaNDatory) ........................................................................................................................................................................ 8
STOVE pOSITIONINg...................................................................................................................................................................................................................................................................9
rEarMS......................................................................................................................................................................................................................................... 9
DIaDEMa acS IDro fEaturES.................................................................................................................................................................................................. 9
INStaLLatIoN............................................................................................................................................................................................................................ 10
pREpARATIONS FOR MAINTENANCE..................................................................................................................................................................................................................................10
PELLEtS aND fEEDING ............................................................................................................................................................................................................. 12
cHEcKS aND PrEcautIoNS for fIrSt IGNItIoN................................................................................................................................................................ 12
THE pELLET LOADINg MOTOR DOES NOT WORK:.................................................................................................................................................................................................12
coNtroL PaNEL........................................................................................................................................................................................................................ 13
DISpLAY ICONS KEY...................................................................................................................................................................................................................................................................13
GENEraL MENu ......................................................................................................................................................................................................................... 14
gENERAL WARNINgS................................................................................................................................................................................................................................................................14
tHE rEMotE coNtroL............................................................................................................................................................................................................. 15
ENAbLE DELAYED SWITCH-OFF...........................................................................................................................................................................................................................................15
TYpE AND REpLACEMENT OF bATTERIES ........................................................................................................................................................................................................................15
coMMISSIoNING SEttINGS..................................................................................................................................................................................................... 16
ADjuSTINg TIME, DAY, MONTH AND YEAR.....................................................................................................................................................................................................................16
ADjuSTINg LANguAgE ..........................................................................................................................................................................................................................................................16
otHEr fuNctIoNS.................................................................................................................................................................................................................... 16
AIR DISCHARgE...........................................................................................................................................................................................................................................................................16
FIRST LOAD...................................................................................................................................................................................................................................................................................16
oPEratIoN aND LoGIc ............................................................................................................................................................................................................ 17
INStaNt DoMEStIc Hot WatEr ProDuctIoN KIt ............................................................................................................................................................. 18
MODES............................................................................................................................................................................................................................................................................................18
DHW ................................................................................................................................................................................................................................................................................................18
HEATINg.........................................................................................................................................................................................................................................................................................18
puFFER ..........................................................................................................................................................................................................................................................................................18
aDDItIoNaL tHErMoStat...................................................................................................................................................................................................... 19
ADDITIONAL THERMOSTAT FuNCTIONINg WITH STbY ACTIVE.............................................................................................................................................................................19
ADDITIONAL THERMOSTAT FuNCTIONINg WITH STbY DEACTIVATED...............................................................................................................................................................19
ADDITIONAL THERMOSTAT INSTALLATION ....................................................................................................................................................................................................................19
SEt PoWEr ................................................................................................................................................................................................................................. 20
tEMPEraturE SEt .................................................................................................................................................................................................................... 20
SET bOILER TEMpERATuRE ....................................................................................................................................................................................................................................................20
SET puFFER TEMpERATuRE....................................................................................................................................................................................................................................................20
uSEr MENu................................................................................................................................................................................................................................. 20
buRN pOT CLEANINg...............................................................................................................................................................................................................................................................20
RESET...............................................................................................................................................................................................................................................................................................21
LOW .................................................................................................................................................................................................................................................................................................21
SEt cHroNo .............................................................................................................................................................................................................................. 21
StatuS ........................................................................................................................................................................................................................................ 22
SEttINGS .................................................................................................................................................................................................................................... 22
SET CLOCK ....................................................................................................................................................................................................................................................................................22
ADjuSTINg LANguAgE ..........................................................................................................................................................................................................................................................22
DISpLAY..........................................................................................................................................................................................................................................................................................22
STAND - bY....................................................................................................................................................................................................................................................................................23
aux .............................................................................................................................................................................................................................................. 23
SEASON..........................................................................................................................................................................................................................................................................................24
SET bOILER....................................................................................................................................................................................................................................................................................24
ENAbLE bOILER TIMER ............................................................................................................................................................................................................................................................24
bOILER CHRONO ........................................................................................................................................................................................................................................................................24
cLEaNING aND MaINtENaNcE............................................................................................................................................................................................... 25
MaINtENaNcE........................................................................................................................................................................................................................... 25
CLEANINg AND MAINTENANCE bY THE uSER...............................................................................................................................................................................................................25
routINE MaINtENaNcE PErforMED by quaLIfIED tEcHNIcIaNS ................................................................................................................................ 27
DECOMMISSIONINg (END OF SEASON)...........................................................................................................................................................................................................................27
DISPLayS .................................................................................................................................................................................................................................... 29
aLarMS ...................................................................................................................................................................................................................................... 29
GuaraNtEE tErMS .................................................................................................................................................................................................................. 31
DISPoSaL.................................................................................................................................................................................................................................... 32
attENtIoN
SurfacES caN bEcoME VEry Hot!
aLWayS uSE ProtEctIVE GLoVES!
During combustion, thermal energy is released that signicantly increases the heat of surfaces, doors, handles, controls, glass, exhaust
pipes, and even the front of the appliance. Avoid contact with those elements if not wearing protective clothing (protective gloves
included). Make sure children are aware of the danger and keep them away from the stove during operation.
3

4ENGLISH
Warnings
This instructions manual is an integral part of the product: make sure that
it always accompanies the appliance, even if transferred to another owner
or user, or if transferred to another place. If it is damaged or lost, request
another copy from the area technician. This product is intended for the use
for which it has been expressly designed. The manufacturer is exempt from
any liability, contractual and extracontractual, for injury/damage caused to
persons/animals and objects, due to installation, adjustment and mainte-
nance errors and improper use.
Installation must be performed by qualied sta, which assumes com-
plete responsibility for the denitive installation and consequent good
functioning of the product installed. One must also bear in mind all laws
and national, regional, provincial and town council Standards present
in the country in which the appliance has been installed, as well as the
instructions contained in this manual.
The Manufacturer cannot be held responsible for the failure to comply
with such precautions.
After removing the packaging, ensure that the content is intact and com-
plete. Otherwise, contact the dealer where the appliance was purchased.
All electric components that make up the product must be replaced with
original spare parts exclusively by an authorised after-sales centre, thus
guaranteeing correct functioning.
safety
THE APPLIANCE MAY BE USED BY CHILDREN 8 YEARS OF AGE OR
OLDER AND INDIVIDUALS WITH REDUCED PHYSICAL, SENSORY, OR
MENTAL CAPACITIES OR WITHOUT EXPERIENCE OR THE NECESSARY
KNOWLEDGE, PROVIDED THAT THEY ARE SUPERVISED OR HAVE
RECEIVED INSTRUCTIONS ON SAFE USE OF THE APPLIANCE AND THAT
THEY UNDERSTAND THE INHERENT DANGERS.
THE GENERATOR MUST NOT BE USED BY PERSONS INCLUDING
We thank you for having chosen our company; our product is a great heating solution developed from the
most advanced technology with top quality machining and modern design, aimed at making you enjoy the
fantastic sensation that the heat of a ame gives, in complete safety.

5ENGLISH
CHILDREN WITH REDUCED PHYSICAL, SENSORY AND MENTAL
CAPACITIES OR WHO ARE UNSKILLED PERSONS, UNLESS THEY ARE
SUPERVISED AND TRAINED REGARDING USE OF THE APPLIANCE BY A
PERSON RESPONSIBLE FOR THEIR SAFETY.
THE CLEANING AND MAINTENANCE REQUIRED BY THE USER MUST
NOT BE PERFORMED BY CHILDREN WITHOUT SUPERVISION.
CHILDREN MUST BE CHECKED TO ENSURE THAT THEY DO NOT PLAY
WITH THE APPLIANCE.
DO NOT TOUCH THE GENERATOR WHEN YOU ARE BAREFOOT OR
WHEN PARTS OF THE BODY ARE WET OR DAMP.
THE SAFETY AND ADJUSTMENT DEVICES MUST NOT BE
MODIFIED WITHOUT THE AUTHORISATION OR INDICATIONS OF THE
MANUFACTURER.
DO NOT PULL, REMOVE, TWIST THE ELECTRICAL CABLES COMING
OUT OFTHE PRODUCT EVEN IF IT IS DISCONNECTED FROMTHE MAINS.
IT IS ADVISED TO POSITION THE POWER SUPPLY CABLE SO THAT IT
DOES NOT COME INTO CONTACT WITH HOT PARTS OF THE APPLIANCE.
THE POWER SUPPLY PLUG MUST BE ACCESSIBLE AFTER
INSTALLATION.
DO NOT CLOSE OR REDUCE THE DIMENSIONS OFTHE AIRING VENTS
IN THE PLACE OF INSTALLATION. THE AIRING VENTS ARE ESSENTIAL
FOR CORRECT COMBUSTION.
DO NOT LEAVE THE PACKAGING ELEMENTS WITHIN REACH OF
CHILDREN OR UNASSISTED DISABLED PERSONS.
THE HEARTH DOOR MUST ALWAYS BE CLOSED DURING NORMAL
FUNCTIONING OF THE PRODUCT.
WHEN THE APPLIANCE IS FUNCTIONING AND HOT TO THE TOUCH,
ESPECIALLY ALL EXTERNAL SURFACES, ATTENTION MUST BE PAID
CHECK FOR THE PRESENCE OF ANY OBSTRUCTIONS BEFORE
SWITCHING THE APPLIANCE ON FOLLOWING A PROLONGED PERIOD
OF INACTIVITY.
THE GENERATOR HAS BEEN DESIGNED TO FUNCTION IN ANY
CLIMATIC CONDITION. IN PARTICULARLY ADVERSE CONDITIONS
STRONG WIND, FREEZING SAFETY SYSTEMS MAY INTERVENE
THAT SWITCH THE GENERATOR OFF. IF THIS OCCURS, CONTACT THE
TECHNICAL AFTERSALES SERVICE AND ALWAYS DISABLE THE SAFETY

6ENGLISH
SYSTEMS.
IN THE EVENT THE FLUE CATCHES FIRE, USE SUITABLE SYSTEMS
FOR SUFFOCATING THE FLAMES OR REQUEST HELP FROM THE FIRE
BRIGADE.
THIS APPLIANCE MUST NOT BE USED TO BURN WASTE
DO NOT USE ANY FLAMMABLE LIQUIDS FOR IGNITION
DURING THE FILLING PHASE DO NOT PUT THE BAG OF PELLETS TO
INTO CONTACT WITH THE PRODUCT
THE MAJOLICAS ARE TOP QUALITY ARTISAN PRODUCTS AND
AS SUCH CAN HAVE MICRODOTS, CRACKLES AND CHROMATIC
IMPERFECTIONS. THESE FEATURES HIGHLIGHT THEIR VALUABLE
NATURE. DUE TO THEIR DIFFERENT DILATION COEFFICIENT, THEY
PRODUCE CRACKLING, WHICH DEMONSTRATE THEIR EFFECTIVE
AUTHENTICITY. TO CLEAN THE MAJOLICAS, IT IS RECOMMENDED TO
USE A SOFT, DRY CLOTH. IF A DETERGENT OR LIQUID IS USED, THE
LATTER COULD PENETRATE INSIDE THE CRACKLES, HIGHLIGHTING
THEM.
SINCE THE PRODUCT CAN TURN ON AUTOMATICALLY THANKS TO
THE TIMER, OR REMOTELY USING THE DEDICATED APPLICATIONS, IT IS
STRICTLY FORBIDDEN TO LEAVE ANY COMBUSTIBLE OBJECT WITHIN
THE SAFETY DISTANCES INDICATED ON THE TECHNICAL DATA PLATE.
INTERNAL COMBUSTION CHAMBER PARTS CAN BE SUBJECT TO
EXTETICAL WARN, IT DOESN'T AFFECT THE FUNCTIONALITY
routine Maintenance
Based on Decree 22 January 2008 n°37 art.2, routine maintenance means
interventions aimed at reducing degradation due to normal use, as well
as dealing with accidental events entailing the need of rst interventions,
which however do not modify the structure of the system upon which one
is intervening or its intended use according to the requirements laid down
by the technical standards in force and by the manufacturer's use and main-
tenance manual.

7ENGLISH
HYDRAULIC SYSTEM
Certain concepts referring to the Italian Standard UNI 10412-2 (2009) are described in this chapter.
As previously described, when installing, all national, regional, provincial and council Standards in force provided by the country in which the
appliance has been installed must be complied with.
During installation of the generator it is MANDATORY to adjust the system with a manometer in order to display the water pressure.
TABLE OF SAFETY DEVICES FOR CLOSED VESSEL SYSTEM AND NOT PRESENT IN THE PRODUCT
Safety valve p
Pump control thermostat (it is managed by the water probe and the board program) p
Water temperature indicator (display) p
Pressure transducer with display p
Automatic circuit breaker adjustment switch (managed by board program) p
Pressure transducer with minimum and maximum pressure switch alarm p
Water overheating automatic circuit breaker switch (block thermostat) p
Circulation system (pump) p
Expansion system p
INSTALLATION AND SAFETY DEVICES
The installation, relative system connections, commissioning and inspection of correct functioning must be carried out perfectly, in full
compliance with Standards in force, national, regional and municipal, as well as these instructions. For Italy, installation must be carried out by
professionally qualied sta (Ministerial Decree dated 22.01.08 n°37).
Extraame S.p.A. declines all responsibility for damage to objects and/or persons caused by the system.
TYPE OF SYSTEM
There are 2 dierent types of system:
Open vessel system and closed vessel system.
The product has been designed and made to work with closed vessel systems.
CHECK THAT THE PRELOAD OF THE EXPANSION VESSEL IS SET TO 1.5 BAR.
SAFETY DEVICES FOR CLOSED VESSEL SYSTEM
In accordance with the UNI 10412-2 (2009) regulation in force in Italy, all the closed systems must be tted with: safety valve, pump control
thermostat, temperature indicator, pressure indicator, automatic circuit breaker block switch (block thermostat), circulation system,
expansion system, and safety dissipation built-in to the generator with thermal safety valve (self-activated), if the appliance does not have a
temperature self-adjustment system.
Pay attention to the correct sizing of the system:
generator power compared to the thermal requirement
possible need for a buer tank

8ENGLISH
DISTANCES OF SAFETY DEVICES ACCORDING TO THE STANDARD
The temperature safety sensors must be in place on the machine at a distance no greater than 30 cm from the ow connection. Whenever the
generators lack a device, those missing can be installed on the generator ow pipe, within a distance no greater than 1 m from the machine.
COMMISSIONING CHECKS
Before connecting the boiler:
a) wash all system piping thoroughly in order to remove any residues which might compromise the correct functioning of certain system
components (pumps, valves, etc.).
b) The company recommends installing a magnetic lter in the generator return, to increase the operational life of the boiler, make it easier
to remove impurities and increase the overall eciency of the system.
It is also advisable to perform an inspection using appropriate instruments, to check for any stray currents that may cause corrosion.
c) check to verify that the ue has adequate draught, that it is not narrowed and that other appliances do not discharge into the ue. This is to
prevent unexpected power increases.The ue tting can be mounted between the boiler and the ue only after this inspection. An inspection
of the connections with pre-existing ues is recommended.
ANTICONDENSATION DEVICE MANDATORY
Make sure a suitable anti-condensate circuit has been realised, which guarantees an appliance return temperature of at least 55°C. The
automatic thermostatic valve, for instance, is used in solid fuel boilers as it prevents cold water from returning into the exchanger. A high
return temperature allows eciency improvement, reduces formation of smoke condensation and prolongs the generator’s life span. The
manufacturer recommends using the 55°C model with 1”hydraulic connections.
For the products with the *PWM pump control thermostat, installation is considered equivalent to the realisation of a suitable anti-condensate
circuit in the case where::
- the heat generator pump is the only one in the installation, or
- there is a plate heat exchanger between the heat generator and the installation, or
- there is a hydraulic compensator or an inertial storage tank (buer) between the heat generator and the installation
*Check technical data sheet on website.
Valve on sale as an accessory (optional)

100°C
85°C
TA
0
1
2
3
4
5
6
7
00,5 1 1,5 2 2,5 3 3,5
ENGLISH
Stove poSitioning
For correct product functioning, it is recommended to position it so that it is perfectly level, using a spirit level.
The diagram to the side illustrates the behaviour of the pump used on
our thermo-products at the speeds that can be set.
Flow rate (m3/h)
Head (m)
DiaDema acS iDro FeatUreS
DiaDema acS iDro
Water content of the thermo-product heat exchanger (l) 21
Volume of expansion vessel integrated in the thermo-product (l) 8
3 bar safety valve integrated in the thermo-product SI
Minimum and maximum pressure switch integrated into the thermo-product SI
Pump integrated into the thermo-product SI
Pump max. head (m) 6
* Envision a possiblE additional Expansion vEssEl dEpEnding on thE systEm watEr contEnt.
rearmS
The gures below illustrate the positions of the tank (85°C) and H2O (100°C) rearms. Contact the qualied technician if one of the rearms
should be triggered, so as to verify the cause.
*
9

10 ENGLISH
INSTALLING INSERTS
When installing inserts, access must be prevented to the internal parts of the appliance and it must not be possible to access live parts during
extraction operations.
Any wiring, for example the power cable or room probe, must be positioned so as not to be damaged during movement of the insert and must
not come into contact with hot parts. If a cavity made of combustible material is installed, we recommend taking all the safety precautions
indicated by the installation standards.
VENTILATION AND AERATION OF INSTALLATION ROOMS
In case of non-airtight heater and/or installation, the ventilation must respect the minimum area indicated below (considering the highest value
among those provided):
Appliance categories Reference standard
Percentage of the
net opening section with respect to the
appliance fumes outlet section
Minimum net opening value of the
ventilation duct
Pellet stoves UNI EN 14785 - 80 cm²
Boilers UNI EN 303-5 50% 100 cm²
INSTALLATION
GENERAL
The ue gas exhaust and hydraulic connections must be carried out by qualied personnel who must issue installation conformity
documentation compliant with national standards.
The installer must provide the owner or person acting for him, according to the legislation in force, with the declaration of conformity,
supplied with:
1) the use and maintenance manual of the appliance and of the system components (such as for example, the smoke ducts, chimney, etc.);
2) photocopy or photograph of the chimney plaque;
3) system booklet (where applicable).
The installer must ask to be issued with a receipt stating that the documentation has been provided, and must keep it with a copy of the technical
documentation relating to the installation.
For installation in a condominium, prior approval from the condominium's administrator must be requested.
Where required, check the exhaust gas emissions after installation. Should a sampling point be installed, it must be airtight.
COMPATIBILITY
Do not install in rooms with a re hazard. It is also forbidden to install it in living areas with the following characteristics:
1. where there are liquid fuel appliances with continuous or discontinuous operation that draw the combustion air into the room in which they
are installed.
2. wherethereare typeB gasappliancesintendedforheating,with or withoutdomestic hotwaterproduction andinadjacentand communicating
rooms.
3. where the depression measured in situ between the external and internal environment is greater than 4 Pa.
N.B.: Watertight appliances can also be installed in the cases indicated in points 1, 2 and 3 of this paragraph.
INSTALLATIONS IN BATHROOMS, BEDROOMS AND STUDIO FLATS
Installation in bathrooms, bedrooms and studio ats is only allowed for sealed or closed hearth appliances with ducted combustion air taken
from the outside.
oor protection
POSITIONING AND SAFETY DISTANCES
The support surfaces and/or points must have a suitable capacity to bear the overall weight
of the appliance, accessories and coverings. If the oor is made of a combustible material,
we recommend using a non-combustible material to protect the front part from any burnt
material which might fall during routine cleaning operations. The generator must be level
to function properly. The side walls, the rear walls and the oor support surface should be
made of non-combustible material.
One must also bear in mind all laws and national,
regional, provincial and town council regulations in force
in the country in which the appliance has been installed,
as well as the instructions contained in this manual.
Air inlet
Under any condition, including in the presence of extractor hoods and/or of controlled forced ventilation systems, the pressure dierence
between the generator installation rooms and the outside must always be equal to or less than 4 Pa.
MINIMUM DISTANCES PELLET STOVES
Installation next to ammable or heat-sensitive materials is permitted only if the special
safety distances specied on the label at the beginning of the manual (pag.2) are
observed. If the materials are not ammable, you must keep a side and rear distance of at
least 100 mm (without the inserts). For products equipped with rear spacers, wall-mounting
installation is permitted exclusively for the rear side.
PREPARATIONS FOR MAINTENANCE
To carry out extraordinary maintenance operations on the product, it may be necessary to move it away from the adjacent walls. This must be
done by a technician authorised to disconnect the combustion product evacuation ducts and then reconnect them. For heaters connected to the
hydraulic system, the connection between the system itself and the product must be made in such a way that, when an authorised technician is
about to carry out extraordinary maintenance operations, it is possible to move the heater at least 1 metre away from the adjacent walls.

3 - 5%
Max 3 mt
11ENGLISH
EXAMPLES OF CORRECT CONNECTION TO THE CHIMNEY
In the presence of type B gas appliances with intermittent operation not intended for heating, they must have their own aeration and/or
ventilation opening.
The air inlets must meet the following requirements:
they must be protected with grids, metal mesh, etc., but without reducing the net useful section;
they must be made so as to make the maintenance operations possible;
positioned so that they cannot be obstructed;
The clean and non-contaminated air ow can also be obtained from a room adjacent to that of installation (indirect aeration and
ventilation), as long as the ow takes place freely through permanent openings communicating with the outside.
The adjacent room cannot be used as a garage, or to store combustible material or for any other activity with a re hazard, bathroom,
bedroom or common room of the building.
FLUE GAS EXHAUST
The heat generator works in depression and is equipped with an outlet fan for ue gas extraction. There must be a single exhaust system for
the generator. Using a ue that is shared with other devices is not allowed.
The components of the ue gas exhaust system must be chosen in relation to the type of appliance to be installed in compliance with:
UNI/ TS 11278 in the event of metal chimneys, with particular attention to that stated in the specication;
UNI EN 13063-1 and UNI EN 13063-2, UNI EN 1457, UNI EN 1806 in the event of non-metallic chimneys.
The length of the horizontal section must be minimal and, in any case, no longer than 3 metres, with a minimum upward slope of 3%
There must not be more than 4 direction changes including the one due to the use of the "T" element.
A“T”tting with a condensation collection cap must be provided at the base of the vertical section.
If the exhaust is not inserted in an existing ue, a vertical section with a windproof end piece is required (UNI 10683).
The vertical duct can be inside or outside the building. If the smoke duct is inserted in an existing ue, it must be certied for solid fuel.
If the smoke duct is outside the building, it must always be insulated.
The smoke ducts must have at least one airtight inlet for ue gas sampling.
All the sections of the ue gas duct must be accessible to inspection.
Inspection openings must be provided for cleaning.
If the generator has a fume temperature lower than 160°C+ ambient temperature caused by the high yield (contact technicians) it
MUST be resistant to humidity.
A ue system that does not respect the previous points or, in general, that does not comply with the regulations, may cause condensation
phenomena inside it.
CHIMNEY CAP
The chimney caps must meet the following requirements:
they must have a useful outlet section no less than double that of the chimney/ducted system on which it is installed;
they must be adapted in order to prevent the penetration of rain and snow in the chimney/ducted system;
they must be built so that, in the event of winds coming from all directions and from any angle, the expulsion of combustion products
is in any case ensured;
Protection from rain
and wind
Condensation-proof
"T" tting with
inspection plug
Insulated ue
Insulated "T"
tting with
inspection plug
Protection from rain and wind
"T" tting with
inspection
plug
CONNECTION TO THE MAINS ELECTRIC SUPPLY
The generator is supplied with an electric power cable to be plugged into a 230V 50 Hz socket, possibly with a circuit breaker switch. The
socket must be easily accessible.
The electrical system must be compliant with standards. The eciency of the earthing circuit must be checked. Unsuitable earthing of the
system can cause malfunctioning for which the manufacturer will not be held liable.
Power supply variations beyond 10% can cause faulty operation of the product.

12 ENGLISH
PELLETS AND FEEDING
Pellets are made by applying high pressure to sawdust, or wood waste products (not containing paint) from sawmills, carpentry and other
activities related to processing and working with wood.
Given that it does not use any glue to hold it together this type of fuel is completely environmentally friendly. In fact the compactness of the
pellets over time is guaranteed by a natural substance found in the wood itself: wood coal. In addition to being an environmentally friendly
fuel in that it pushes wood residues to the limits pellets also have technical advantages.
While wood has a caloric value of 4.4kWh/kg. (with 15% humidity after around 18 months of seasoning) the caloric value of pellets is 5 kWh/
kg.
Pellet density is 650kg/m3 and the water content is equal to 8% of its weight. For this reason they do not require seasoning in order to arrive
at a suciently adequate degree of heat yield.
THE USE OF EXPIRED PELLETS OR ANY OTHER MATERIAL WILL AFFECT THE FUNCTIONALITY OF YOUR
GENERATOR AND MAY LEAD TO THE TERMINATION OF THE WARRANTY AND CESSATION OF ANY ACCOMPANYING
RESPONSIBILITY ON THE PART OF THE MANUFACTURER
The pellets used must comply with the characteristics described by the
following standards:
EN PLUS class A1, ISO 17225-2 class A1
and
UNI EN 3035 with the following characteristics: water content ≤ 12%,
ash content ≤ 0.5% and lower caloric value >17 MJ/kg (in the case of
boilers).
The manufacturer always recommended using pellets with a diameter
of 6 mm with its products.
PELLET STORAGE
In order to ensure problem-free combustion pellets must be stored in
a dry place.
Open the tank lid and load the pellets using a scoop.
CHECKS AND PRECAUTIONS FOR FIRST IGNITION
IMPORTANT!
IN ORDER FOR THE GENERATOR TO WORK PROPERLY, THE HYDRAULIC SYSTEM’S PRESSURE MUST BE BETWEEN
0.6 AND 2.5 BAR.
If the pressure detected by the digital pressure switch is below 0.6 or above 2.5 bar, it triggers a boiler alarm.
Bringing the water pressure within the standard values, it is possible to reset the alarm by pressing the button /1 for 3 seconds
(The alarm can be reset only if the fumes motor has stopped and 15 minutes have elapsed from the display of the alarm)
THE PELLET LOADING MOTOR DOES NOT WORK:
Due to the lling of the system, it is normal that there is air inside the circuit.
During the 1st ignition cycle, water movement causes the displacement of air bubbles and their out-ow from the automatic vents out of the
system. This can cause the pressure to drop and activate the minimum pressure switch, which stops the motor that transports the pellets and,
therefore, the heat generator.
Vent out the system, if necessary even multiple times, to remove the air, and reload it if the pressure is too low.
It is not a malfunction, but a normal occurrence due to its lling. After lling, the plumber must always thoroughly vent the system, using the
special vents in the circuit and running the "air breather" function on the machine. (After the rst ignition and with a cold machine, re-activate
the function "air breather" - see chapter "OTHER FUNCTIONS”)
BULB THERMOSTATS  RESET:
Check by pressing the reset buttons (85 - 100°C) located on the back of the appliance, before contacting a technician (see section RESET).

OFF
13ENGLISH
CONTROL PANEL
BUTTON
ON/OFF
DISPLAY OF VARIOUS
TEXT MESSAGES
TO ACCESS
THE MENU
SETTING
TEMPERATURE
OPERATION POWER
ADJUSTMENT
DISPLAY ICONS KEY
Indicates the receipt of the radio signal
On = during radio communication
O = no radio communication
Flashing = serial port excluded
Indicates the stove modulation
On = the stove is working at the set power
Flashing = the power at which the stove is working is dierent to
the power set, the stove is modulating (for various reasons)
Indicates the presence of an alarm.
On: indicates the presence of an alarm
O: indicates the absence of alarms
Flashing: indicates the deactivation of the depression sensor.
It indicates weekly programming functioning
Indicator on = weekly programming active
Indicator o = weekly programming disabled
Indicates the water temperature status
O = the T° read by the probe is above the set temperature
On = the T° read by the probe is below the set temperature
Indicates the contact of the external additional thermostat
Contact closed: the contact of the external additional thermostat is
closed and the STBY function is disabled.
Contact open: the contact of the external additional thermostat is
open and the STBY function is disabled.
Flashing with contact closed: the contact of the external additional
thermostat is closed and the STBY function is activated
Flashing with contact open: the contact of the external additional
thermostat is open and the STBY function is activated
It indicates fumes motor operation.
O = fumes motor disabled
On = fumes motor active
Flashing = breakdown (contact technical after-sales service)
It indicates the summer / winter function
O: Activates the winter function
On: Activates the summer function
Not used
Indicates the DHW request
O: DHW satised, pump o
Flashing : the DHW request exists but the work conditions are not
satised, pump o
On : the DHW is in request mode and the work conditions are
satised, pump on
It indicates pellet feed motor operation
O = pellet feed motor disabled
On = pellet feed motor active
Indicates the heating request
O : heating satised, pump o
Flashing : the heating request exists but the work conditions are
not satised, pump o
On : the heating is in request mode and the work conditions are
satised, pump on
It indicates pump operation
O = pump deactivated
On = pump active
Flashing = the safety device is active (H2O temperature > 85°C)
Indicates the puer request, if active.
O : puer satised, pump o
Flashing : the puer request exists but the work conditions are not
satised, pump o
On : the puer is in request mode and the work conditions are
satised, pump on

1
23
45
6
OFF
1 4
3
2
5
6
6
14 ENGLISH
GENERAL MENU
Go back - exit
Parameter scrolling: next (2) ; previous (3)
Modify settings data: increase (4); decrease (5)
Conrm - access Menu
SET POWER POWER
SET TEMPERATURE SET H2O
USER MENU BURN POT CLEANING
RESET
SET CHRONO ENABLE CHRONO PELLETS
ENABLE PRG1
ENABLE PRG2
STATUS *STOVE STATUS ENABLE PRG3
ENABLE PRG4
SETTINGS SET CLOCK START PRG1
LANGUAGE STOP PRG1
DISPLAY MONDAY PRG1...
STANDBY
...SUNDAY PRG1
SEASON SET PRG1
SET BOILER REPEAT THE SAME
STEPS FOR THE
OTHER 3 TIME SLOTS
ENABLE CHRONO
BOILER
* MENU
TECHNICIAN
BOILER CHRONO * RESERVED TO THE
TECHNICIAN
GENERAL WARNINGS
Advice to follow for the rst start-ups of the product:
During the rst hours of operation, there may be some smoke or
odours, but they are due to the normal“thermal break-in” process.
During this process, the duration of which changes depending on
the product, it is recommended to:
Ventilate the room well
If present, remove any majolica parts from the top of the
product
Activate the product at the maximum power and temperature
Avoid remaining in the room for a long time
Do not touch the surfaces of the product
Notes:
The process is completed after a few heating/cooling cycles.
Do not use for the combustion of elements or substances other than
those indicated in the manual.
Before turning on the product, it is necessary to perform the
following checks:
If it is intended to be connected to a hydraulic system, it must
be complete and fully functional and in compliance with the
instructions given in the product manual and with the relevant
regulations in force.
The pellet hopper must be completed loaded
The combustion chamber and the burn pot must be clean
Make sure that the re holder, the ash pan and the pellet
hopper close hermetically (if present in the hermetic version); they
must be closed and there must be no foreign bodies in the sealing
elements and gaskets.
Check that the power cord is properly connected
The bipolar switch (if present) must be set to position“1”.

15ENGLISH
THE REMOTE CONTROL
All that can normally be implemented through the LCD can be adjusted using the remote control.
The table below provides a detailed description of the various functions:
INFO
1
2
3
4
5
6
7
8
9
10
11 12 13
14 15 16
1ON / OFF Pressing the key for three seconds, the stove will switch on or o
2POWER INCREASE Pressing the key will increase the operating power
3POWER DECREASE Pressing the key will decrease the operating power
4T° INCREASE The temperature setting can be increased by pressing this key
5T° DECREASE The set temperature can be decreased by pressing this key
6ENABLE / DISABLE
CHRONO Pressing the key once will enable or disable the chrono
7ENABLE DELAYED
SWITCHOFF
The delayed switch-o can be set by pressing this key.
For example, if the stove is set to switch-o in an hour, it shall switch-o
automatically once the set time elapses, displaying the countdown every
minute for delayed automatic shutdown.
8MENU This key allows the user to access the user and technical menu (the
technical menu is reserved for assistance)
9INCREASE The temperature setting can be increased by pressing this key
10 ESC KEY The key allows the user to exit any program or display and returns to the
main menu without saving the data
11 BACK The key returns to the display of the various menus
12 CONFIRMATION KEY This key conrms the adjustments made during the user menu
programming phase
13 FORWARD The key allows the user to go forward in the various menus
14 ENABLE FUNCTION F1 Pre-set key for future applications
15 DECREASE The key decreases the value to be set
16 STOVE STATUS Pressing this key will display the general status of the stove
TYPE AND REPLACEMENT OF BATTERIES
The batteries are housed in the lower part of the remote control.
To replace it, you need to take out the battery holder, remove or insert the battery following the symbols on the remote control and on the
battery.
For operation, 1 CR2025, 3V lithium buer battery is required.
The batteries used contain metals harmful for the environment. They must therefore be disposed of separately in appropriate containers.
Important note: the numbers shown on the remote control are purely indicative and are not present on the remote control supplied with the product.
IF THE REMOTE CONTROL IS OFF BECAUSE IT HAS NO BATTERIES, THE STOVE CAN BE CONTROLLED FROM THE CONTROL
PANEL ON TOP OF IT. WHILE REPLACING THE BATTERY, PAY ATTENTION TO THE POLARITY BY OBSERVING THE SYMBOL ON
THE INSIDE COMPARTMENT OF THE REMOTE CONTROL.
J
ALL CLEAN CHECK UP
SHOULD THE "ALL CLEAN CHECK UP" ALARM BE TRIGGERED, MAKE SURE
THAT THE BOTTOM OF THE BURN POT IS FREE OF RESIDUES OR SCALES.
THE HOLES AT THE BOTTOM MUST BE COMPLETELY FREE TO GUARANTEE
CORRECT COMBUSTION. ONE CAN USE THE FUNCTION TO ADJUST
COMBUSTION BASED ON THE DESCRIBED REQUIREMENTS. IF THE ALARM
PERSISTS AND THE ABOVE LISTED CONDITIONS HAVE BEEN CHECKED,
CONTACT THE QUALIFIED AFTERSALES ASSISTANCE CENTRE.
BURN POT HOLES

16 ENGLISH
ADJUSTING TIME, DAY, MONTH AND YEAR
Set clock allows the user to adjust the time and date
CONTROLS PROCEDURE
Press key 6.
Proceed by pressing key 2 until the word SETTINGS is displayed.
Conrm using key 6.
Proceed by pressing key 2 until LANGUAGE is displayed.
Conrm using key 6.
Use keys 4 or 5 to set the language.
Press key 1 several times to conrm and exit the menu.
SET LANGUAGE
LANGUAGE
ITALIAN
ENGLISH
GERMAN
FRENCH
SPANISH
COMMISSIONING SETTINGS
Once the power cable at the back of the stove has been connected, move the switch, also located on the back, to (I).
The switch at the back of the stove powers the stove board.
The stove remains o and a rst screen appears on the panel reading OFF.
OTHER FUNCTIONS
AIR DISCHARGE
This function allows the user to bleed any air in the stove. Once the function has been activated, the pump indicator light is activated on the
display (for 15 minutes 30 seconds the pumps will be powered, alternating with 30 seconds of downtime).
To activate the function:
With the stove "OFF" press keys 1 and 4 at the same time, enter the password "77" using keys 4 and 5 and conrm with key 6.
Cut the power to interrupt.
FIRST LOAD
This function allows the user to activate the pellet feeding motor reducer for continuous functioning.
To activate the function:
When the stove is cold and ''OFF'' press keys 2 and 5 at the same time for a couple of seconds, the scrolling message “first load” will
appear on the display.
To interrupt continuous loading simply press key 1.
CONTROLS PROCEDURE
Press key 6.
Proceed by pressing key 2 until the word SETTINGS is displayed.
Conrm using key 6.
Conrm SET CLOCK with key 6.
Use keys 4or 5 to set and key 2 to move forward, to adjust the hours, minutes,
day, month and year.
Press key 1 several times to conrm and exit the menu.
SET CLOCK
DAY MON, TUE, WED, ...SUN
HOURS 0...23
MINUTES 00...59
DATE 1...31
MONTH 1...12
YEAR 00...99
ADJUSTING LANGUAGE
It is possible to select the preferred language to display the various messages.

17ENGLISH
OPERATION AND LOGIC
IGNITION
Once the points listed previously have been checked, press key 1 for three seconds to ignite the stove.
15 minutes are available for the ignition phase. After ignition and having reached the control temperature, the stove interrupts the ignition
phase and passes to STARTING.
STARTING
During the start-up phase, the stove stabilises combustion, increasing it progressively, to then start ventilation and pass on to WORK.
WORK
During the work phase, the stove reaches the set power; see following item.
SET POWER ADJUSTMENT
Set the operating power (from 1 to 5).
Power 1 = minimum level - Power 5 = maximum level.
SET H2O TEMPERATURE ADJUSTMENT
Set the boiler temperature between 65 - 80°C .
PUMP OPERATION
The pump activates water circulation when the temperature of the water inside the stove reaches 60°C. As the pump always functions above
60°, an always open heating area is recommended to make product functioning homogenous, preventing overheating blocks. Normally this
area is dened“Safety zone”.
BURN POT CLEANING
At pre-set intervals the stove performs burn pot cleaning, switching the machine o.
When the cleaning phase is nished, the stove will re-start automatically and continue its work going back to the power level selected.
MODULATION and HOFF
As the water temperature approaches the set point, the boiler starts to modulate automatically bringing itself to the minimum power.
If the temperature increases beyond the set point, it will automatically switch o indicating HOFF and will automatically go back on when
the temperature drops below the set point.
SWITCHOFF
Press key 1 for three seconds.
When the operation has been performed, the appliance automatically enters the switch-o phase, blocking the supply of pellets.
The ue gas exhaust motor will remain on until the stove temperature has dropped below the factory parameters.
REIGNITION
The stove can only be re-ignited automatically or manually when the cooling cycle conditions and the preset timer have been satised.
J
NO IGNITION
FIRST IGNITION COULD EVEN FAIL AS THE AUGER IS EMPTY AND IS NOT ALWAYS ABLE TO LOAD THE BURN POT
WITH THE REQUIRED AMOUNT OF PELLETS ON TIME TO REGULARLY START THE FLAME.
IF THE PROBLEM OCCURS AFTER ONLY A FEW MONTHS WORKING, CHECK THAT ROUTINE CLEANING STATED IN
THE STOVE BOOKLET, HAS BEEN CARRIED OUT CORRECTLY.
DO NOT USE ANY INFLAMMABLE LIQUIDS FOR IGNITION!
DO NOT ALLOW THE BAG OF PELLETS TO COME INTO CONTACT WITH THE BOILING HOT STOVE DURING THE FILLING PHASE!
IN THE EVENT OF CONTINUOUS NO IGNITION, CONTACT AN AUTHORISED TECHNICIAN.
IT IS FORBIDDEN TO USE THE APPLIANCE WITHOUT THE DIVIDER SEE THE
FIGURE TO THE SIDE. ITS REMOVAL JEOPARDISES THE SAFETY OF THE
PRODUCT AND IMMEDIATELY VOIDS THE WARRANTY PERIOD. IN THE CASE
OF WEAR OR DETERIORATION REQUEST AFTERSALES ASSISTANCE FOR
REPLACEMENTOFTHE PART REPLACEMENTTHAT IS NOTUNDER GUARANTEE
AS THE COMPONENT IS SUBJECT TO WEAR.
BURN POT UPPER DIVIDER

I4B
I4A
I4A I6
I5
I4B I7
18 ENGLISH
The thermo-stove is equipped with a kit for the production of
domestic hot water consisting of a plate heat exchanger, a motorised
diverter valve and a ow switch.
Domestic water production = 11 l/ min (t 30°C)
In absence of a request for domestic water, the heat generator heats
the system water. In the event of a request for domestic water, the
power of the generator is all used to produce domestic hot water
(heat is not supplied to the heating system).
In order to ensure proper operation in the domestic mode, the
thermo-stove must be switched on, in steady state conditions and
in operation.
If the heat generator is in the HOFF, TOFF, STANDBY, FINAL
CLEANING and OFF conditions, it cannot supply heat for the
production of hot water.
In the HOFF, TOFF conditions, the stove is switched o because
it has satised all heat requests, in this case a request for domestic
water will make the stove switch on again but one must wait for
the time required for it to reach steady state conditions.
In the event of STANDBY, the stove is switched o because it has
satised the additional thermostat (STBY clamp), in this case a
request for domestic water will not make the stove switch on again
until the additional thermostat is in request conditions because
the contact has priority over any request. Even in this case one
must wait for the time required for steady state conditions.
Avoid sampling hot water with very limited ow rates. Flow rates
below 3 litres per minute can make the thermo-stove switch from
the OPERANT state to the HOFFstate with consequent appliance
shutdown.
It is recommended to always leave a heating zone open in order to
ensure the dissipation of any excess heat produced by the thermo-
stove.
In order to prevent burns, one must t a thermostatic mixing valve,
in order to limit the temperature of the domestic water sent to the
utilities.
One must provide a suitable water ltration and softening system
according to the specic hardness of the water in the place where
the heat exchanger is installed.
The excessive deposit of limescale, as well as reducing the eciency
of the plate heat exchange, can compromise its operation.
Replacement of the plate heat exchanger in the event of excessive
fouling it not covered by the warranty.
The kit for the production of domestic hot water (plate heat
exchanger, motorised diverter valve and ow switch) is controlled by
a board integrated in the stove (system expansion board kit), which
allows various hydraulic congurations up to a maximum of four
heating zones, a puer and an auxiliary boiler.
NF Neutral and phase
OUT1/N 230 V 50 Hz output heating area 1 (max. 5A)
OUT2/N 230 V 50 Hz output heating area 2 (max. 5A)
OUT3/N 230 V 50 Hz output heating area 3 (max. 5A)
OUT4/N 230 V 50 Hz output heating area 4 or puer pump (max 5 A)
05NC/N 230 V 50 Hz output (max. 5A) normally closed for domestic storage tank
05NO/N 230 V 50 Hz output (max. 5A) normally open for domestic storage tank
O6 NO/O6C auxiliary output normally open
O6 NC/O6C auxiliary output normally closed
I1/GND area 1 input (dry contact)
I2/GND area 2 input (dry contact)
I3/GND area 3 input (dry contact)
I4A/GND area 4 input (dry contact)
I4B/GND Future preparation
I5/GND boiler / heat exchanger probe inlet
I6/GND upper puer probe inlet
I7/GND lower puer probe inlet
OC power line connection (+ = red, - = black)
MODES
SUMMER - WINTER: the mode allows setting SUMMER or WINTER
operation.
In the SUMMER mode the room thermostats relating to the heating
system and the puer are always satised; the thermo-stove works to
satisfy the DHW.
In WINTER mode, all requests are considered (DHW, heating system
and puer).
DHW
DHW is controlled via the integrated instantaneous DHW exchanger
(PH11=ON) and always has priority over all other requests.
HEATING
The activation of the outputs relating to heating is aected by the
operating modes (Summer/Winter) and by the presence or absence
of the puer.
With the puer deactivated, the outputs are activated when there is a
request and the temperature of the water in the boiler is hot enough.
With the puer activated, the outputs are activated when there is a
request and the temperature of the puer is hot enough.
One can enable the 4th Heating Zone. By setting parameter PH13
on “1”.
To activate the puer contact the dealer.
(Default setting PH13=0 = disabled).
PUFFER
With the puer active (set PH12=ON) the thermo-stove operates to
satisfy the requests of the puer and DHW (always priority). Default
setting: PH12= OFF - disabled.
To activate the puer contact the dealer.
INSTANT DOMESTIC HOT WATER PRODUCTION KIT

100°C
85°C
TA
100°C
85°C
TA
19ENGLISH
ADDITIONAL THERMOSTAT
N.B. : Installation must be performed by an authorised technician.
There is a possibility to thermostat a room adjacent to the room where the stove is positioned: just connect a thermostat following the procedure
described in the next step (it is recommended to position the optional mechanical thermostat at a height of 1.50 m from the oor) . Stove
functioning with the external thermostat connected in the TA clamp can be dierent on the basis of the activation or disabling of the STBY
function.
The TA clamp leaves the factory jumpered, therefore it is always with closed contact (on request).
ADDITIONAL THERMOSTAT FUNCTIONING WITH STBY ACTIVE
When the STBY function is activated, the LED ashes. When the contact or external thermostat is satised (open contact / temperature
reached), the stove will switch o. As soon as the contact or external thermostat switches to the "not satised" status (closed contact/
temperature to be reached) it will re-ignite.
N.B.: stove operation depends on the temperature of the water inside the stove and relative factory setting restrictions. If the stove
is in H OFF (water temperature reached), any additional contact or thermostat request will be ignored.
ADDITIONAL THERMOSTAT FUNCTIONING WITH STBY DEACTIVATED
When the STBY function is disabled, the LED is xed.
When the contact or external thermostat is satised (open contact / temperature reached), the stove will go to minimum. As soon as the
contact or external thermostat switches to the "not satised" status (closed contact / temperature to be reached) the stove will start to work
again at the pre-set power.
N.B.: stove operation depends on the temperature of the water inside the stove and relative factory setting restrictions. If the stove
is in H OFF (water temperature reached), any additional contact or thermostat request will be ignored.
ADDITIONAL THERMOSTAT INSTALLATION
Switch the appliance o using the master switch positioned on the rear of the stove.
Remove the plug from the socket.
Refer to the electrical layout to connect the two thermostat cables to the relative clamps positioned on the rear of the machine, one is
red and the other black (TA
clamp). Every model can have a dierent position of the relative clamps in the rear of the machine. The
image is given as an example.
J
REFER TO THE ''SETTINGS" CHAPTER TO ACTIVATE STAND BY
ATTENTION:
THE PRODUCTION OF DHW IS ALREADY INTEGRATED IN THE MACHINE.
THE PRODUCTION OF DOMESTIC HOT WATER IS ONLY ENSURED WHEN THE STOVE IS SWITCHED ON OPERATING
OTHERWISE ONE MUST WAIT FOR THE STOVE TO SWITCH ON.
IN THE EVENT THE OPTIONAL INPUTS ARE USED PUFFER OR HEATING OF THE MACHINE IS IN THE FOLLOWING
STATE: TOFF, HOFF OR STBY REQUESTS SATISFIED ONE MUST WAIT FOR THE MACHINE TO SWITCH ON AGAIN!

20 ENGLISH
SET PUFFER TEMPERATURE
N.B.: the screen is not displayed if the puer is disabled.
CONTROLS PROCEDURE
Press key 6
Proceed by pressing key 2 until TEMPERATURE SET is displayed.
Conrm using key 6.
Press key 2 until SET PUFFER MAX is displayed (adjust using keys 4-5).
Press key 2 until SET PUFFER MIN is displayed (adjust using keys 4-5).
Press key 1 several times to conrm and exit the menu.
SET BOILER TEMPERATURE
CANNOT BE ACTIVATED
N.B.: DIADEMA ACS FEATURES AN INSTANTANEOUS HEAT EXCHANGER FOR THE PRODUCTION OF DOMESTIC HOT WATER AND IT IS
NOT POSSIBLE TO SET THE BOILER TEMPERATURE
SET POWER
The following menu allows you to set the generator power Minimum power 1, maximum power 5.
CONTROLS PROCEDURE
Press key 6.
Conrm using key 6 - SET POWER.
Use keys 4 or 5 to set the power.
Press key 1 several times to conrm and exit the menu.
TEMPERATURE SET
The following menu allows you to set:
The boiler temperature from 65 - 80°C.
CONTROLS PROCEDURE
Press key 6.
Proceed by pressing key 2 until TEMPERATURE SET is displayed.
Conrm using key 6.
Use keys 4 or 5 to set the H2O TEMP SET.
Press key 1 several times to conrm and exit the menu.
USER MENU
BURN POT CLEANING
The menu allows the user to increase the frequency of the automatic burn pot cleaning.
CONTROLS PROCEDURE
Press key 6.
Proceed by pressing key 2 until USER MENU is displayed.
Conrm using key 6.
To increase the automatic cleaning frequency press 4.
To go back to standard values (00) decrease by pressing 5.
Press key 1 several times to conrm and exit the menu.
