Purpose
Conventions
Documentation and Training
Getting Help
Providing Feedback
This section discusses the purpose of this document, the conventions used, ways to provide feedback,
additional help, and information regarding other Extreme Networks publications.
Purpose
This guide provides information and instructions to install the Extreme Networks Virtual Services
Platform 8000 Series (VSP 8000 Series) switches. The VSP 8000 Series includes the VSP 8200 Series
and the VSP 8400 Series.
Conventions
This section discusses the conventions used in this guide.
Text Conventions
The following tables list text conventions that can be used throughout this document.
Table 1: Notes and warnings
Icon Notice type Alerts you to...
Tip Helpful tips and notices for using the product.
Note Useful information or instructions.
Important Important features or instructions.
Installing the Virtual Services Platform 8000 Series 5

Table 1: Notes and warnings (continued)
Icon Notice type Alerts you to...
Caution Risk of personal injury, system damage, or loss of data.
Warning Risk of severe personal injury.
Table 2: Text Conventions
Convention Description
Angle brackets ( < > ) Angle brackets ( < > ) indicate that you choose the text
to enter based on the description inside the brackets.
Do not type the brackets when you enter the command.
If the command syntax is cfm maintenance-
domain maintenance-level <0-7> , you
can enter cfm maintenance-domain
maintenance-level 4.
Bold text Bold text indicates the GUI object name you must act
upon.
Examples:
•Click OK.
•On the Tools menu, choose Options.
Braces ( { } ) Braces ( { } ) indicate required elements in syntax
descriptions. Do not type the braces when you enter the
command.
For example, if the command syntax is ip address
{A.B.C.D}, you must enter the IP address in dotted,
decimal notation.
Brackets ( [ ] ) Brackets ( [ ] ) indicate optional elements in syntax
descriptions. Do not type the brackets when you enter
the command.
For example, if the command syntax is show clock
[detail], you can enter either show clock or
show clock detail.
Ellipses ( … ) An ellipsis ( … ) indicates that you repeat the last
element of the command as needed.
For example, if the command syntax is
ethernet/2/1 [ <parameter>
<value> ]..., you enter ethernet/2/1 and
as many parameter-value pairs as you need.
Italic Text Italics emphasize a point or denote new terms at the
place where they are defined in the text. Italics are also
used when referring to publication titles that are not
active links.
About this Document
Installing the Virtual Services Platform 8000 Series 6

Table 2: Text Conventions (continued)
Convention Description
Plain Courier Text Plain Courier text indicates command names, options,
and text that you must enter. Plain Courier text also
indicates command syntax and system output, for
example, prompts and system messages.
Examples:
•show ip route
•Error: Invalid command syntax
[Failed][2013-03-22 13:37:03.303
-04:00]
Separator ( > ) A greater than sign ( > ) shows separation in menu
paths.
For example, in the Navigation tree, expand the
Configuration > Edit folders.
Vertical Line ( | ) A vertical line ( | ) separates choices for command
keywords and arguments. Enter only one choice. Do not
type the vertical line when you enter the command.
For example, if the command syntax is access-
policy by-mac action { allow |
deny } , you enter either access-policy by-
mac action allow or access-policy by-
mac action deny, but not both.
Documentation and Training
Find Extreme Networks product information at the following locations:
Current Product Documentation
Release Notes
Hardware/software compatibility matrices for Campus and Edge products
Supported transceivers and cables for Data Center products
Other resources, like white papers, data sheets, and case studies
Extreme Networks oers product training courses, both online and in person, as well as specialized
certifications. For details, visit www.extremenetworks.com/education/.
Getting Help
If you require assistance, contact Extreme Networks using one of the following methods:
Extreme
Portal
Search the GTAC (Global Technical Assistance Center) knowledge base; manage support cases
and service contracts; download software; and obtain product licensing, training, and
certifications.
The Hub A forum for Extreme Networks customers to connect with one another, answer questions, and
share ideas and feedback. This community is monitored by Extreme Networks employees, but is
not intended to replace specific guidance from GTAC.
About this Document
Installing the Virtual Services Platform 8000 Series 7

Call GTAC For immediate support: [phone] (toll-free in U.S. and Canada) or 1 [phone]. For the
support phone number in your country, visit: www.extremenetworks.com/support/contact
Before contacting Extreme Networks for technical support, have the following information ready:
•Your Extreme Networks service contract number, or serial numbers for all involved Extreme
Networks products
•A description of the failure
•A description of any actions already taken to resolve the problem
•A description of your network environment (such as layout, cable type, other relevant environmental
information)
•Network load at the time of trouble (if known)
•The device history (for example, if you have returned the device before, or if this is a recurring
problem)
•Any related RMA (Return Material Authorization) numbers
Subscribe to Service Notifications
You can subscribe to email notifications for product and software release announcements, Vulnerability
Notices, and Service Notifications.
1 Go to www.extremenetworks.com/support/service-notification-form.
2 Complete the form (all fields are required).
3 Select the products for which you would like to receive notifications.
Note
You can modify your product selections or unsubscribe at any time.
4 Select Submit.
Providing Feedback
The Information Development team at Extreme Networks has made every eort to ensure the accuracy
and completeness of this document. We are always striving to improve our documentation and help
you work better, so we want to hear from you. We welcome all feedback, but we especially want to
know about:
•Content errors, or confusing or conflicting information.
•Improvements that would help you find relevant information in the document.
•Broken links or usability issues.
If you would like to provide feedback, you can do so in three ways:
•In a web browser, select the feedback icon and complete the online feedback form.
•Access the feedback form at https://www.extremenetworks.com/documentation-feedback/.
•Email us at [e-mail].
Provide the publication title, part number, and as much detail as possible, including the topic heading
and page number if applicable, as well as your suggestions for improvement.
About this Document
Installing the Virtual Services Platform 8000 Series 8

2New in this document
Temperature Sensors
The following section details what is new in this document.
Warning and critical threshold values are updated in the document. For more information, see Install a
Fan Module on page 79.
Installing the Virtual Services Platform 8000 Series 9

3Hardware models for VSP 8000
Series
Power cord types and order codes
This section lists the VSP 8000 Series hardware.
VSP 8200 Series Hardware
Power cords must be ordered separately. Ensure you order the correct power cord for your region. For
more information, see Power cord types and order codes.
Table 3: VSP 8284XSQ Hardware
VSP 8284XSQ Description Part number
VSP 8284XSQ-AC
This model number ships with one
field-replaceable 800 watt AC
power supply.
•80 ports of 10GBASE-SFP+
•4 ports of 40GBASE-QSFP+
•one 10/100/1000BASE-T Out-Of-Band
Management Port
•one RJ-45 Console Port
•one USB 2.0 port
•Base Software License
•four field-replaceable fan modules
EC8200A01-E6
VSP 8284XSQ-DC
This model number ships with one
field-replaceable 800 watt DC
power supply.
Includes all of the above features. —
Eective 12-Jun-2017,
the DC version of the
VSP 8284XSQ switch
is no longer being
sold.
VSP 8284XSQ AC PS No PC GSA
This model number is compliant
with the Trade Agreements Act
(TAA). It ships with one field-
replaceable 800 watt AC power
supply but no power cord.
Includes all of the above features. EC8200A01-E6GS
Redundant power supplies
800 watt AC redundant power
supply •The VSP 8284XSQ comes with one 800 W
AC PSU.
•For full power redundancy, you can install a
second 800 W AC PSU.
EC8005A01-E6
800 watt DC redundant power
supply •The VSP 8284XSQ comes with one 800 W
DC PSU.
•For full power redundancy, you can install a
second 800 W DC PSU.
EC8005001-E6
Installing the Virtual Services Platform 8000 Series 10

Table 3: VSP 8284XSQ Hardware (continued)
VSP 8284XSQ Description Part number
Redundant fan modules
12 volt redundant fan module The VSP 8284XSQ comes with all four 12–V fan
modules installed.
EC8011004-E6
Universal Slide Rack Mount Kit (300mm-900mm)
Slide Rack Mount Kit
(300mm-900mm)
The optional rack mount kit allows a switch to be
installed in a four post rack with depths between
300mm and 900mm. It is designed for use on the VSP
7200 Series, VSP 8200 Series and VSP 8400 Series.
EC8011002-E6
Note:
The universal slide rack mount kit is optional and must be ordered separately. VSP 7200 Series, VSP 8200 Series
and VSP 8400 Series ship with rack mount brackets. When using rack mount brackets on the VSP 8200 Series
and VSP 8400 Series, we recommend the use of a shelf to provide additional support.
VSP 8400 Series hardware
The following tables describe the VSP 8400 Series hardware.
Table 4: VSP 8404 Hardware
VSP 8404 Description Part number
VSP 8404 AC
This model number ships with one
field-replaceable 800 watt AC
power supply.
•one 10/100/1000BASE-T Out-Of-Band
Management Port
•one RJ-45 Console Port
•one USB 2.0 port
•Base Software License
•four field-replaceable fan modules
EC8400A01-E6
VSP 8404 AC PS No PC GSA
This model number is compliant
with the Trade Agreements Act
(TAA). It ships with one field-
replaceable 800 watt AC power
supply but no power cord.
Includes all of the above components. EC8400A01-E6GS
VSP 8404C AC
This model number ships with one
field-replaceable 800 watt AC
power supply.
Includes all of the above components. EC8400A02-E6
VSP 8404C-AC No PC GSA
This model is TAA compliant. It
ships with an AC power supply
but no power cord.
Includes all of the above components. EC8400A02-E6GS
VSP 8404–DC
This model number ships with one
field-replaceable 800 watt DC
power supply.
Includes all of the above components. EC8400001-E6
Hardware models for VSP 8000 Series
Installing the Virtual Services Platform 8000 Series 11

Table 4: VSP 8404 Hardware (continued)
VSP 8404 Description Part number
VSP 8404C–DC
This model number ships with one
field-replaceable 800 watt DC
power supply.
Includes all of the above components. EC8400002-E6
Redundant power supplies
800 watt AC redundant power
supply •The VSP 8400 Series comes with one
800 W AC PSU.
•For full power redundancy, you can
install a second 8001-AC-PSU.
•No power cord.
EC8005A01-E6
800 watt DC redundant power
supply •The VSP 8400 Series comes with one
800 W DC PSU.
•For full power redundancy, you can
install a second 800 W DC PSU.
EC8005001-E6
Spare fan modules
Spare fan module The VSP 8404 comes with all four 12–V fan
modules installed. This part can be purchased if a
spare fan module is desired.
EC8011005-E6
Universal Slide Rack Mount Kit (300mm-900mm)
Slide Rack Mount Kit
(300mm-900mm)
The optional rack mount kit allows a switch to be
installed in a four post rack with depths between
300mm and 900mm. It is designed for use on
the VSP 7200 Series, VSP 8200 Series and VSP
8400 Series.
EC8011002-E6
Note:
The universal slide rack mount kit is optional and must be ordered separately. The VSP 7200 Series, VSP 8200
Series and VSP 8400 Series ship with rack mount brackets. When using rack mount brackets on the VSP 8200
Series and VSP 8400 Series, we recommend the use of a shelf to provide additional support.
Table 5: VSP 8400 Series Ethernet switch modules (ESMs)
Model Name Description Part Number
8424XS 24 port 10GBASE-SFP+ Ethernet Switch Module EC8404001-E6
8424XS (TAA-compliant) 24 port 10GBASE-SFP+ Ethernet Switch Module EC8404001-E6GS
8424XT 24 port 10GBASE-T Ethernet Switch Module EC8404002-E6
8424XT (TAA-compliant) 24 port 10GBASE-T Ethernet Switch Module EC8404002-E6GS
8408QQ
Note:
Two ports are reserved for future
use.
8 port 40GBASE-QSFP+ Ethernet Switch Module EC8404003-E6
Hardware models for VSP 8000 Series
Installing the Virtual Services Platform 8000 Series 12

Table 5: VSP 8400 Series Ethernet switch modules (ESMs) (continued)
Model Name Description Part Number
8408QQ (TAA-compliant)
Note:
Two ports are reserved for future
use.
8 port 40GBASE-QSFP+ Ethernet Switch Module EC8404003-E6GS
8418XSQ 16 port 10GBASE-SFP+ and 2 port 40GBASE-QSFP
+ Combination Ethernet Switch Module
EC8404005-E6
8418XSQ (TAA-compliant) 16 port 10GBASE-SFP+ and 2 port 40GBASE-QSFP
+ Combination Ethernet Switch Module
EC8404005-E6GS
8418XTQ 16 port 10GBASE-T and 2 port 40GBASE-QSFP+
Combination Ethernet Switch Module
EC8404006-E6
8418XTQ (TAA-compliant) 16 port 10GBASE-T and 2 port 40GBASE-QSFP+
Combination Ethernet Switch Module
EC8404006-E6GS
8424GS 24 port 100/1000BASE-X Ethernet Switch Module EC8404007-E6
8424GS (TAA-compliant) 24 port 100/1000BASE-X Ethernet Switch Module EC8404007-E6GS
8424GT 24 port 10/100/1000BASE-T Ethernet Switch
Module
EC8404008-E6
8424GT (TAA-compliant) 24 port 10/100/1000BASE-T Ethernet Switch
Module
EC8404008-E6GS
8402CQ
Important:
This ESM operates only with the
VSP 8404C model.
2 port 100G QSFP28 Ethernet Switch Module EC8404009-E6
8402CQ (TAA-compliant)
Important:
This ESM operates only with the
VSP 8404C model.
2 port 100G QSFP28 Ethernet Switch Module EC8404009-E6GS
Hardware models for VSP 8000 Series
Installing the Virtual Services Platform 8000 Series 13

Compatible transceivers
Important
We recommend using the SFP, SFP+, QSFP+, and QSFP28 transceivers as they have been
through extensive qualification and testing. Extreme Networks will not be responsible for
issues related to third party transceivers.
•The VSP 8000 Series operates in forgiving mode for SFP, SFP+, and QSFP+ transceivers,
which means that the switch will bring up the port operationally when using third party
transceivers (SFP, SFP+ or QSFP+). Extreme Networks does not provide support for
operational issues related to these transceivers, but they will operate and the port link will
come up. The switch logs the device as an unsupported or unknown device.
For more information about compatible transceivers, see Extreme Networks Pluggable
Transceivers Installation Guide and Extreme Hardware/Software Compatibility and
Recommendation Matrices.
VSP 8000 Series operational notes
The VSP 8000 Series supports channelization of a 40 Gbps port into four 10 Gbps channelized
interfaces for the following ports:
•The VSP 8200 Series supports channelization on all four 40 Gbps ports.
•The VSP 8400 Series supports channelization on the following ESM ports:
•The two 40 Gbps ports of the 8418XSQ.
•The two 40 Gbps ports of the 8418XTQ.
•The first six 40 Gbps ports of the 8408QQ.
Note
•Channelized port operation is not aected when the same ESM type is hot swapped when
one or more 40 Gbps ports on that ESM are channelized. Swapping a dierent ESM results
in the configuration for that slot being lost, so any channelized ports need to be re-
configured.
•8402CQ 100 Gbps ESM does not support channelization.
Power cord types and order codes
To connect AC power to the switch, you need an appropriate AC power cord as described in the
following table.
Table 6: Power cords for power distribution units
Order Code Length Power supply side
connector
Power source side
connector
Safety Approval
700512239 3 m C13 C14 USA
700512241 3 m C13 C14 International
except Japan and Taiwan
Hardware models for VSP 8000 Series
Installing the Virtual Services Platform 8000 Series 14

Table 7: Power Cords with C14 power supply side connector
Order Code Description Region
AA0020062E6 Power cord 3.05 m IEC C13 to NEMA 5-15P North America
AA0020063E6 Power cord 2.5 m IEC C13 to BS1363 United Kingdom
AA0020064E6 Power cord 2.5 m IEC C13 to CEE 7/7 European Union
AA0020065E6 Power cord 2.5 m IEC C13 to CEI 23-16 Italy
AA0020066E6 Power cord 2.5 m IEC C13 to GB 2099.1-1996 China
AA0020067E6 Power cord 2.5 m IEC C13 to BS-546/SANS164-1 India & South Africa
AA0020068E6 Power cord 2.5 m IEC C13 to AS 3112 Australia
AA0020069E6 Power cord 2.5 m IEC C13 to JIS 8303 Japan
AA0020101-E6 Power cord 2.5 m IEC C13 to NBR 14136 (IEC 60906-1) Brazil
AA0020104-E6 Power cord 2.5 m IEC C13 to SEV 1011 Switzerland
AA0020107-E6 Power cord 2.5 m IEC C13 to SI-32 Israel
Hardware models for VSP 8000 Series
Installing the Virtual Services Platform 8000 Series 15

4Preinstallation checklist
Before you install the VSP 8000 Series, make sure that you complete the tasks in the preinstallation
checklist.
No. Task Description
1. Review the technical specification for the
switch. Make sure that the area where you
install the switch and where it will operate
meet the requirements.
For the physical, electrical, and environmental
specifications, see Technical specifications.
2. Verify the power supply unit (PSU)
specifications. Optionally order a
redundant PSU to provide redundancy
and load sharing.
See AC power supply specifications or DC power
supply specifications.
3. Make sure that you have the following
tools and cables:
•Phillips #2 screwdriver
•RJ-45 console port cable
•ESD cable
See Cable requirements for the VSP 8000 Series
on page 69.
4. Unpack the equipment. Observe ESD precautions when you unpack the
equipment. See Electrostatic discharge.
5. Verify the contents of the shipped
package.
See Package contents for a description of the
components that are provided with the switch. If
any components are missing, contact Extreme
Networks support.
6. Make sure that the power cord has the
correct country-specific termination.
7. Prepare the rack. Ensure that there is enough rack space to
accommodate a 2RU switch (8.8 cm).
Ensure that the rack is bolted to the floor and
braced if necessary.
Ensure that the rack is grounded to the same
grounding electrode used by the power service in
the area. The ground path must be permanent
and must not exceed 1 Ohm of resistance from the
rack to the grounding electrode.
Installing the Virtual Services Platform 8000 Series 16

5Installing the Virtual Services
Platform 8000 Series
Installation checklist
Installation fundamentals
Ethernet Switch Module
Electrostatic discharge
Technical specifications
Package contents
Installing the VSP 8000 Series in an Equipment Rack
Cable requirements for the VSP 8000 Series
Installation and removal of transceivers
Console port pin assignments
AC Power Supply
DC Power Supply
Removing a power supply
Airflow direction
Install a Fan Module
LED state definitions
40GBASE-QSFP+ ports
MACsec operational notes
Viewing hardware information
This section provides the information and procedures to install the VSP 8000 Series.
Installation checklist
Use this checklist to install the VSP 8000 Series.
Installing the Virtual Services Platform 8000 Series 17

No. Task Description
1. Mount the VSP 8000 Series switch in
the equipment rack.
See Installing the VSP 8000 Series in an
Equipment Rack on page 34.
You have two options for installing the switch in
an equipment rack:
•Using the optional slide rack mount kit
•Using the supplied brackets on page 67
2. Install the primary or redundant power
supply.
Important:
A combination of AC-input and DC-
input power supplies in the same
chassis is not supported.
If you have an AC power supply, see Installing an
AC power supply on page 71.
If you have a DC power supply, see Installing a DC
Power Supply on page 75.
3. For the VSP 8400 Series, install an
Ethernet Switch Module.
See Installing an Ethernet Switch Module on page
25.
4. Check the LEDs to verify the
installation.
For a description of the LEDs, see LED state
definitions on page 81.
Installation fundamentals
VSP 8200 Series
The VSP 8200 Series consists of:
•eighty 10GBASE-SFP/SFP+ ports
•four 40GBASE-QSFP+ ports
•one 10/100/1000BASE-T Out-Of-Band Management Port
•one RJ-45 Console Port
•one USB 2.0 port
•Base Software License
•one field-replaceable 800 watt power supply (either AC or DC)
•four field-replaceable 12 volt fan modules
Installing the Virtual Services Platform 8000 Series
Installing the Virtual Services Platform 8000 Series 18

Figure 1: VSP 8284XSQ — Front view
1. SFP+ port LEDs are in between the ports on each slot. The up arrows refer to the port above and the down
arrows refer to the port below. For a description of what the LEDs mean, see SFP, SFP+,QSFP+, and QSFP28 port
LED state indicators on page 83.
2. Eighty SFP+ ports that support 1G SFPs and 10G SFP+s.
•40 ports in Slot 1 on top
•40 ports in Slot 2 on the bottom
3. QSFP+ port LEDs are in between the ports on each slot. The up arrows refer to the port above and the down
arrows refer to the port below. For a description of what the LEDs mean, see SFP, SFP+,QSFP+, and QSFP28 port
LED state indicators on page 83.
4. Four QSFP+ ports: two in Slot 1 and two in Slot 2.
5. USB port
6. Console port
7. Management port — The LEDs are on the bottom of the port. For more information, see Management port
LEDs.
8. LEDs for system power (PWR), switch status (Status), redundant power supply (RPS), and fan modules (Fan).
For more information, see Switch LEDs.
The following figure shows the rear of the chassis with four fan modules and one power supply installed.
The fan modules are numbered 1–4 from left to right, and the power supplies are numbered PSU 1 on
top and PSU 2 on the bottom.
Installing the Virtual Services Platform 8000 Series
Installing the Virtual Services Platform 8000 Series 19

Figure 2: VSP 8284XSQ — Rear view
VSP 8400 Series
The VSP 8400 Series consists of:
•four slots to install ESMs. For more information, see Ethernet Switch Module (ESM).
•one 10/100/1000BASE-T Out-of-Band Management port
•one RJ45 console port
•one USB 2.0 port
•one field replaceable 800 watt power supply (AC or DC)
•four field replaceable 12 volt fan modules
•Base Software License
The following figure shows the front view of the VSP 8404.
Note
•The front view is common for both VSP 8404 and VSP 8404C models.
•When looking at the front of the switch, slot numbering begins at the top row and
increases from left to right. Slot 1 is the top-left slot; slot 2 is the top-right slot. Slot 3 is the
bottom-left slot; slot 4 is the bottom-right slot.
Installing the Virtual Services Platform 8000 Series
Installing the Virtual Services Platform 8000 Series 20
