Extreme Networks BlackDiamond 10808 Manual

Extreme Networks, Inc.
3585 Monroe Street
Santa Clara, California 95051
[phone]
[phone]
http://www.extremenetworks.com
BlackDiamond 10808 Switch
Hardware Installation Guide
Published: April 2008
Part number: 100285-00 Rev. 01

BlackDiamond 10808 Switch Hardware Installation Guide
2
AccessAdapt, Alpine, Altitude, BlackDiamond, EPICenter, ESRP, Ethernet Everywhere, Extreme Enabled, Extreme
Ethernet Everywhere, Extreme Networks, Extreme Standby Router Protocol, Extreme Turbodrive, Extreme Velocity,
ExtremeWare, ExtremeWorks, Essentials, ExtremeXOS, the Go Purple Extreme Solution, ScreenPlay, Sentriant,
ServiceWatch, Summit, SummitStack, Triumph, Unified Access Architecture, Unified Access RF Manager, UniStack,
the Extreme Networks logo, the Alpine logo, the BlackDiamond logo, the Extreme Turbodrive logo, the Summit
logos, the Powered by ExtremeXOS logo, and the Color Purple, among others, are trademarks or registered
trademarks of Extreme Networks, Inc. or its subsidiaries in the United States and/or other countries.
Adobe, Flash, and Macromedia are registered trademarks of Adobe Systems Incorporated in the U.S. and/or other
countries. AutoCell is a trademark of AutoCell. Avaya is a trademark of Avaya, Inc. Internet Explorer is a registered
trademark of Microsoft Corporation. Mozilla Firefox is a registered trademark of the Mozilla Foundation. sFlow is a
registered trademark of sFlow.org. Solaris and Java are trademarks of Sun Microsystems, Inc. in the U.S. and other
countries.
Specifications are subject to change without notice.
All other registered trademarks, trademarks, and service marks are property of their respective owners.
© 2008 Extreme Networks, Inc. All Rights Reserved.
For safety compliance information, see Appendix A, “Safety Information.”

BlackDiamond 10808 Switch Hardware Installation Guide 3
Table of Contents
Preface........................................................................................................................................... 7
Introduction ...............................................................................................................................7
Conventions................................................................................................................................8
Related Publications ...................................................................................................................8
Part 1: About the BlackDiamond 10808 Switch
Chapter 1: Overview of the BlackDiamond 10808 Switch................................................................. 13
Overview of the BlackDiamond 10808 Switch..............................................................................13
Full-Duplex Support ..................................................................................................................13
Management Ports ....................................................................................................................14
External Compact Flash Memory Card .........................................................................................14
BlackDiamond 10808 Switch Chassis.........................................................................................14
Chapter 2: BlackDiamond 10808 Series Modules ........................................................................... 17
Overview of the BlackDiamond 10808 Modules ...........................................................................17
Management Switch Modules (MSMs).........................................................................................17
Redundant MSM Activity .....................................................................................................18
MSM Physical Features........................................................................................................18
MSM LEDs .........................................................................................................................19
I/O Modules..............................................................................................................................20
G60T Module .....................................................................................................................21
G60T LEDs...................................................................................................................21
G60X Module .....................................................................................................................22
SFP (Mini-GBIC) Ports ...................................................................................................22
G60X LEDs...................................................................................................................23
G20X Module .....................................................................................................................23
SFP Ports .....................................................................................................................24
G20X LEDs...................................................................................................................24
10G6X Module ...................................................................................................................24
XENPAK Ports ..............................................................................................................25
10G6X LEDs.................................................................................................................25
10G2X Module ...................................................................................................................26
XENPAK Ports ..............................................................................................................26
10G2X LEDs.................................................................................................................27
10G2H Module ...................................................................................................................27
XENPAK Ports ..............................................................................................................28
SFP Ports .....................................................................................................................28
10G2H LEDs ................................................................................................................28
I/O Module LEDs.................................................................................................................29
Chapter 3: Power Supply Units for the BlackDiamond 10808 Switch ................................................ 31
Overview of BlackDiamond 10808 Power Supplies .......................................................................31
Extreme Networks 700/1200 W AC PSU .....................................................................................31

Table of Contents
BlackDiamond 10808 Switch Hardware Installation Guide
4
LEDs..................................................................................................................................32
Power Supply Cords.............................................................................................................32
Fuse ..................................................................................................................................33
Specifications.....................................................................................................................33
Extreme Networks 1200 W DC PSU ............................................................................................33
Minimum Software Required ................................................................................................35
LEDs..................................................................................................................................35
Part 2: Installing BlackDiamond 10808 Switches and Modules
Chapter 4: Site Preparation............................................................................................................ 39
Planning Your Site ....................................................................................................................39
Meeting Site Requirements ........................................................................................................40
Operating Environment Requirements ...................................................................................40
Building and Electrical Codes.........................................................................................40
Wiring Closet Considerations ..........................................................................................41
Temperature .................................................................................................................41
Humidity ......................................................................................................................42
Chassis Spacing Requirements .......................................................................................42
Chassis Airflow Requirements.........................................................................................42
Electrostatic Discharge ..................................................................................................43
Rack Specifications and Recommendations ...........................................................................44
Mechanical Recommendations for the Rack .....................................................................44
Protective Grounding for the Rack...................................................................................44
Space Requirements for the Rack ...................................................................................45
Securing the Rack .........................................................................................................45
Evaluating and Meeting Cable Requirements ...............................................................................46
Cabling Standards ...............................................................................................................46
Cable Labeling and Record Keeping......................................................................................46
Installing Cable...................................................................................................................47
Fiber Optic Cable ..........................................................................................................48
Cable Distances ............................................................................................................49
RJ-45 Connector Jackets .....................................................................................................50
Radio Frequency Interference...............................................................................................51
Meeting Power Requirements .....................................................................................................51
PoE Devices .......................................................................................................................51
Power Supply Requirements.................................................................................................51
AC Power Cable Requirements..............................................................................................52
Replacing the Power Cable.............................................................................................52
Uninterruptible Power Supply Requirements ..........................................................................53
Selecting a UPS ............................................................................................................53
Calculating Volt-Amperage Requirements.........................................................................53
UPS Transition Time .....................................................................................................54
Applicable Industry Standards....................................................................................................54
Chapter 5: Installing a BlackDiamond 10808 Chassis ..................................................................... 55
Required Tools and Resources....................................................................................................56
Unpacking the Chassis ..............................................................................................................56
Checking the Shipping Status Indicators ...............................................................................56
Removing the Accessories Box..............................................................................................58
Removing the Carton from the Chassis ..................................................................................60

Table of Contents
BlackDiamond 10808 Switch Hardware Installation Guide 5
Installing the Chassis ................................................................................................................62
Standard Rack Installation ...................................................................................................63
Mid-Mount Rack Installation ................................................................................................66
Grounding the Chassis ...............................................................................................................68
Initial Management Access ........................................................................................................69
Chapter 6: Installing Power Supply Units in the BlackDiamond10808 Switch ................................... 71
Safety ......................................................................................................................................71
BlackDiamond PSU Compatibility ...............................................................................................72
Minimum Software Requirements .........................................................................................72
Installing an Extreme Networks 700/1200 W AC PSU ..................................................................72
Required Tools and Equipment.............................................................................................73
Installing the 700/1200 W AC PSU ......................................................................................73
Removing or Replacing an Extreme Networks 700/1200 W AC PSU .........................................74
LEDs on the 700/1200 W AC PSU........................................................................................75
Power Supply Cords.............................................................................................................75
Installing an Extreme Networks 1200 W DC PSU .........................................................................76
Minimum Software Required ................................................................................................77
Pre-Installation Requirements ..............................................................................................77
Installing the DC Wiring .......................................................................................................77
Installing a 1200 W DC PSU................................................................................................78
Removing an Extreme Networks 1200 W DC PSU...................................................................81
LEDs on the 1200 W DC PSU ..............................................................................................82
Chapter 7: Installing BlackDiamond 10808 Modules....................................................................... 83
Module Slot Assignments...........................................................................................................83
Installing a BlackDiamond 10808 Series Module .........................................................................83
Making Network Interface Cable Connections...............................................................................86
Initial Management Access ........................................................................................................86
Connecting Equipment to the Console Port ............................................................................86
Logging In for the First Time ................................................................................................87
Installing a Backup MSM...........................................................................................................88
Verifying the Module Installation ................................................................................................88
Displaying Slot Status Information ........................................................................................88
Removing a BlackDiamond 10808 Series Module ........................................................................89
Blank Front Panels....................................................................................................................89
Installing a Blank Front Panel ..............................................................................................90
Removing a Blank Front Panel..............................................................................................91
Installing or Removing an External Compact Flash Memory Card....................................................91
Part 3: Installing BlackDiamond Switch Accessories
Chapter 8: BlackDiamond Cable Management ................................................................................. 95
About BlackDiamond Cable Management ....................................................................................95
Installing the BlackDiamond 10808 Cable Manager .....................................................................95
Using the Cable Holders and Cable Clips...................................................................................100
Connecting Cable Holders ..................................................................................................101
Connecting Cable Clips ......................................................................................................102

Table of Contents
BlackDiamond 10808 Switch Hardware Installation Guide
6
Part 4: BlackDiamond Maintenance Procedures
Chapter 9: Replacing BlackDiamond 10808 Switch Chassis Components ....................................... 107
Replacing a BlackDiamond 10808 Switch Fan Tray ...................................................................107
Removing the Fan Tray ......................................................................................................107
Installing the Replacement Fan Tray ...................................................................................108
Replacing the BlackDiamond 10808 Air Filter ...........................................................................109
Replacing a BlackDiamond 10808 Power Supply Controller ........................................................110
Pre-Installation Requirements ............................................................................................111
Removing a Power Supply Controller ...................................................................................111
Installing a Power Supply Controller ....................................................................................112
Verifying a Successful Installation.......................................................................................112
Chapter 10: Repacking a BlackDiamond 10808 Chassis................................................................ 113
Safety Information ..................................................................................................................113
Required Tools and Equipment.................................................................................................114
Repacking the BlackDiamond 10808 Chassis ............................................................................114
Part 5: Appendixes
Appendix A: Safety Information .................................................................................................... 121
Considerations Before Installing ...............................................................................................121
Installing Power Supply Units...................................................................................................121
Maintenance Safety.................................................................................................................122
General Safety Precautions ......................................................................................................123
Cable Routing for LAN Systems ..........................................................................................123
PoE Devices .....................................................................................................................124
Selecting Power Supply Cords ..................................................................................................124
Battery Replacement and Disposal............................................................................................125
Fiber Optic Ports—Optical Safety .............................................................................................125
GBIC, SFP (Mini-GBIC), XENPAK, and XFP Regulatory Compliance .......................................126
Appendix B: Technical Specifications .......................................................................................... 133
BlackDiamond 10808 Switch...................................................................................................133
Power Supplies for the BlackDiamond 10808 Switch .................................................................135
Connector Pinouts...................................................................................................................136
Index .......................................................................................................................................... 139

BlackDiamond 10808 Switch Hardware Installation Guide 7
Preface
This preface provides an overview of this guide, describes guide conventions, and lists other
publications that might be useful.
NOTE
Service to all equipment should be performed by trained and qualified service personnel only. Before installing or
removing any components of the system, or before carrying out any maintenance procedures, you must thoroughly
read the safety information provided in Appendix A of this guide. Failure to follow this safety information can lead to
personal injury or damage to the equipment.
Introduction
This guide describes how to install the Extreme Networks® BlackDiamond®10808 switch. This guide
also contains information about site preparation, switch functionality, and switch operation.
This guide is intended for use by network administrators responsible for installing and setting up
network equipment. It assumes a basic working knowledge of:
●Local area networks (LANs)
●Ethernet concepts
●Ethernet switching and bridging concepts
●Routing concepts
●Simple Network Management Protocol (SNMP)
See the ExtremeXOS 12.1 Concepts Guide and the ExtremeXOS 12.1 Command Reference Guide for
information about configuring Extreme Networks BlackDiamond 10808 switches.
NOTE
If the information in the installation note or release note shipped with your Extreme Networks switch differs from the
information in this guide, follow the installation or release note.

Preface
BlackDiamond 10808 Switch Hardware Installation Guide
8
Conventions
Table 1 and Table 2 list conventions used throughout this guide.
Related Publications
The Extreme Networks ExtremeXOS™ switch documentation set includes:
● ExtremeXOS 12.1 Concepts Guide
● ExtremeXOS 12.1 Command Reference Guide
● ExtremeXOS 12.1 Release Notes
● BlackDiamond 8800 Series Switch Hardware Installation Guide
● BlackDiamond 12800 Series Switch Hardware Installation Guide
● Summit Family of Switches Hardware Installation Guide
● Extreme Networks Pluggable Interface Modules Installation Guide
Table 1: Notice Icons
Icon Notice Type Alerts you to...
Note Important features or instructions.
Caution Risk of personal injury, system damage, or loss of data.
Warning Risk of severe personal injury.
Table 2: Text Conventions
Convention Description
Screen displays This typeface represents information as it appears on the screen, or command
syntax.
The words “enter”
and “type”
When you see the word “enter” in this guide, you must type something, and then
press the Return or Enter key. Do not press the Return or Enter key when an
instruction simply says “type.”
[Key] names Key names appear in text in one of two ways:
• Referenced by their labels, such as “the Return key” or “the Escape key”
• Written with brackets, such as [Return] or [Esc]
If you must press two or more keys simultaneously, the key names are linked with a
plus sign (+). Example:
Press [Ctrl]+[Alt]+[Del].
Words in italicized type Italics emphasize a point of information or denote new terms at the place where
they are defined in the text.

Related Publications
BlackDiamond 10808 Switch Hardware Installation Guide 9
Documentation for Extreme Networks products is available from the Extreme Networks website at the
following location:
http://www.extremenetworks.com/services/documentation
You can select and download the following Extreme Networks documentation from the Documentation
Overview page:
●Software User Guides
●Hardware User Guides
You can find archived user guides for software at:
http://www.extremenetworks.com/services/documentation/swuserguides.asp
You can also find archived installation guides for hardware at:
http://www.extremenetworks.com/services/documentation/hwuserguides.asp

Preface
BlackDiamond 10808 Switch Hardware Installation Guide
10

1About the BlackDiamond 10808 Switch

BlackDiamond 10808 Switch Hardware Installation Guide 13
1Overview of the BlackDiamond 10808 Switch
This chapter describes the Extreme Networks BlackDiamond 10808 switch and includes the following
sections:
●Overview of the BlackDiamond 10808 Switch on page 13
●Full-Duplex Support on page 13
●Management Ports on page 14
●External Compact Flash Memory Card on page 14
●BlackDiamond 10808 Switch Chassis on page 14
For information about the I/O modules and management modules (MSMs) for the BlackDiamond 10808
switch, see Chapter 3, “BlackDiamond 10808 Series Modules.”.
For information about installing the BlackDiamond 10808 switch, see Chapter 2.
Overview of the BlackDiamond 10808 Switch
The BlackDiamond 10808 switch is a chassis-based, Ethernet service core switch designed for core
applications.
The features of this switch include:
●Hot-swappable I/O modules that include Gigabit Ethernet copper ports (10/100/1000) and Gigabit
Ethernet fiber ports (SFP), or 10 Gigabit Ethernet ports (XFP)
●Management Switch Fabric Modules (MSMs) that provide the active switching fabric and CPU
control subsystem
●Redundant, load-sharing, hot-swappable power supplies
●Field-replaceable, hot-swappable fan trays
●Auto-negotiation for half-duplex or full-duplex operation on 10/100/1000 Mbps ports
●Load sharing on multiple ports
For more information about configuring a BlackDiamond switch, see the ExtremeXOS 12.1 Concepts
Guide and the ExtremeXOS 12.1 Command Reference Guide.
Full-Duplex Support
Extreme Networks switches provide full-duplex support for all ports. Full-duplex support means that
frames can be transmitted and received simultaneously, which, in effect, doubles the bandwidth
available on a link. Most ports on an Extreme Networks switch will auto-negotiate duplex in the default
configuration. Gigabit Ethernet fiber ports and 10-gigabit Ethernet ports operate only in full-duplex
mode in accordance with technical standards.

Overview of the BlackDiamond 10808 Switch
BlackDiamond 10808 Switch Hardware Installation Guide
14
Management Ports
Each BlackDiamond series Management Switch Fabric Module (MSM) has a 10/100BASE-TX Ethernet
management port. This port allows you to communicate directly with the central processing unit (CPU)
of the switch. You can plug an Ethernet cable directly from your laptop into the management port, for
direct access into the switch. This access allows you to view and locally manage the switch
configurations.
External Compact Flash Memory Card
All MSMs in the BlackDiamond family include a compact flash slot next to the console port on the
MSM. This slot accepts a compact flash memory card, which can be used to download a new version of
ExtremeXOS and for other functions, including capturing debug information and core dump files. See
the ExtremeXOS 12.1 Concepts Guide for more information regarding the use of the external compact
flash memory card.
The external compact flash slot supports third-party compact flash cards.
NOTE
You must use an industrial-grade compact flash card in the external compact flash slot of the MSM.
BlackDiamond 10808 Switch Chassis
The BlackDiamond 10808 switch chassis includes the following components:
●One 10-slot chassis with backplane
●Eight I/O module slots, labeled 1 through 8
●Two MSM slots, labeled A and B
●Up to six power supplies, accessed from the front of the unit)
●Two hot-swappable fan trays, accessed from the back of the unit. Each fan tray contains two fans.
●One connector for an ESD-preventive wrist strap
Software monitors the fan trays in the BlackDiamond 10808 switch for overheating. All
over-temperature events cause the switch to send alerts to the network management station or to the
switch log. See the ExtremeXOS 12.1 Concepts Guide for more information about switch monitoring.
CAUTION
Do not cover or obstruct the fan ventilation holes at the rear of the unit. Doing so can result in overheating and
possible damage to the BlackDiamond 10808 switch. Thermal sensors will shut down the BlackDiamond 10808
switch if the internal temperature exceeds 60 degrees Celsius.
The BlackDiamond 10808 switch includes two power supply controllers, located in the back of the
chassis, that collect data from the installed power supplies and report the results to the MSM modules.
The power supply controllers provide primary/backup redundancy in case one of the controllers fails
or is removed. At least one power supply controller must be installed.

BlackDiamond 10808 Switch Chassis
BlackDiamond 10808 Switch Hardware Installation Guide 15
When the BlackDiamond 10808 switch is first powered on, the power supply controllers enable the
power supplies by providing 48V power. The power supply controller also detects and reports
incompatible combinations of power supply types and line voltage feeds and disables the power supply
if an unsafe condition arises.
Figure 1 shows a BlackDiamond 10808 switch equipped with two MSM-1 modules and eight optional
I/O modules.
Figure 1: Front View of the BlackDiamond 10808 Switch
EX_001
I/O module slots I/O module slots
MSM module
slots
ESD wrist strap
connector
Power supplies
behind grill

Overview of the BlackDiamond 10808 Switch
BlackDiamond 10808 Switch Hardware Installation Guide
16
Figure 2 shows the rear panel of the BlackDiamond 10808 switch.
Figure 2: Rear View of the BlackDiamond 10808 Switch
The rear panel of the BlackDiamond 10808 switch provides:
●Access to the fan units
●Chassis serial number
●Ethernet MAC address of the switch
●Symbols of safety certification
●Access to power supply controllers
●Attachment point for optional chassis ground
EX_007A
Fan trays
Grounding
point
Power supply
controllers

BlackDiamond 10808 Switch Hardware Installation Guide 17
2BlackDiamond 10808 Series Modules
This chapter describes the I/O modules and the Management Switch Module (MSM) that are installed
in the BlackDiamond 10808 switch chassis. The chapter includes the following sections:
●Overview of the BlackDiamond 10808 Modules on page 17
●Management Switch Modules (MSMs) on page 17
●I/O Modules on page 20
For instructions on installing the BlackDiamond 10808 modules, see Chapter 4, “Installing
BlackDiamond 10808 Modules.”
Overview of the BlackDiamond 10808 Modules
Modules available for the BlackDiamond 10808 switch include management switch modules (MSMs)
and I/O modules. A BlackDiamond module consists of a printed circuit board mounted on a metal
panel that acts as the insertion vehicle in the BlackDiamond 10808 switch. The module carrier also
includes ejector/injector levers and captive retaining screws at each end of the module front panel.
LEDs on the module front panel provide information about the operating status of the modules.
Management Switch Modules (MSMs)
The BlackDiamond MSM holds the control plane and the switch fabric for the switch. In addition, each
MSM has two CPUs for protocol processing and network management. The BlackDiamond 10808
chassis has two slots for installing MSMs. Although the system will operate with a single MSM,
bandwidth is reduced. Two MSMs are required for full system bandwidth.
The following MSMs are available for the BlackDiamond 10808 switch:
●MSM-1
●MSM-1XL
The MSM-1 and MSM-1XL have different size Ternary Content Addressable Memory (TCAM). The
MSM-1XL has more memory available for routing tables, learned MAC addresses, and access control
lists (ACLs). For specific details about memory allocation, refer to the data sheet for each module.
MSMs are installed in designated lettered slots in the BlackDiamond 10808 chassis.
A compact flash slot allows you to insert an external compact flash memory card. (See “External
Compact Flash Memory Card” on page 14 for more information about Extreme Networks-supported
compact flash cards.).

BlackDiamond 10808 Series Modules
BlackDiamond 10808 Switch Hardware Installation Guide
18
Redundant MSM Activity
The BlackDiamond 10808 switch can operate with a single MSM installed. When you install a second
MSM, one of the MSMs operates as the primary, and the other becomes the backup.
The primary MSM is responsible for upper-layer protocol processing and system management
functions. For example, OSPF computation and SNMP functions are performed by the primary MSM.
Packet handling is distributed among the CPUs of all installed MSMs.
When you save the switch configuration, it is saved to all MSMs. If you download a new ExtremeXOS
image, the image is downloaded to all MSMs.
Selection of the primary MSM occurs automatically. The following examples describe the selection
process:
●When the BlackDiamond 10808 switch boots with two MSMs already installed, the MSM in slot A
becomes the primary MSM.
●When the BlackDiamond 10808 switch boots with a single MSM (regardless of the slot position), it is
selected as the primary MSM.
If a second MSM is added to the switch after it has been powered on, the added MSM becomes the
backup MSM. MSMs that operate as backups can be inserted and removed without disrupting
network services.
●If you remove the primary MSM while the BlackDiamond 10808 switch is operating, the backup
MSM performs a soft reset and then becomes the primary MSM.
For example, in a BlackDiamond 10808 switch with a primary MSM in slot A and a backup MSM in
slot B, if you remove the primary MSM from slot A, the backup MSM in slot B becomes the primary
MSM.
MSM Physical Features
Figure 3 shows the front panel of the BlackDiamond 10808 series MSM.
Figure 3: BlackDiamond 10808 Series MSM
EX_003
Module status LEDs
Module reset button
Console port
Management port
Compact flash

Management Switch Modules (MSMs)
BlackDiamond 10808 Switch Hardware Installation Guide 19
The BlackDiamond 10808 MSMs have the following features on the front panel:
●LEDs to indicate module operating status
●Module reset button—Allows you to reset the MSM without removing the module from the chassis.
●Management port—Used to connect an Ethernet cable directly from your laptop into the
management port to view and locally manage the switch configurations. This port can also be used
to connect the system into a parallel management network for administration.
●Console port—Used to connect a terminal and perform local management.
●Compact flash slot
MSM LEDs
Table 3 describes the LED activity on the BlackDiamond 10808 MSM.
NOTE
To reset the critical software error LED (amber ERR LED), use the clear log static command and reboot the
switch. If you continue to have critical software errors, or the ERR LED is amber after the clear log static
command and a switch reboot, contact Extreme Networks Customer Support.
Table 3: MSM LEDs
LED Color Indicates
SYS Green blinking
Amber blinking
Amber
Off
Module is operating normally.
Diagnostic test is in progress.
Diagnostic failure has occurred.
Switch is not receiving power.
MSTR Green
Amber
Module is operating as primary.
Module is operating as backup.
ENV Green
Amber
Environment (temperature, fan, power supply) is operating properly.
Environmental failure has occurred.
ERR Amber
Off
A critical software error has been logged since power up.
Normal operation is occurring.
Link/Activity Off
Green
Amber
Link is down.
Link is up.
Packet activity is occurring.

BlackDiamond 10808 Series Modules
BlackDiamond 10808 Switch Hardware Installation Guide
20
I/O Modules
The following I/O modules are available for the BlackDiamond 10808 switch:
●G60T Module
●G60X Module
●G20X Module
●10G6X Module
●10G2X Module
●10G2H Module
NOTE
On the BlackDiamond 10808 switch, the 10 Gbps module (10G6X module) must have the serial number 804405-
00-09 or higher to support untagged frames. To display the serial number of the module, use the
show slot <slot_number> command. (All the modules on the Black Diamond 8800 series of switches, as well as the
Summit X450 switch, support tagged and untagged frames.)
No configuration information is stored on the I/O modules; all configuration information is stored on
the MSM(s).
When the BlackDiamond 10808 switch is powered on, the software generates a default configuration for
any slots that contain I/O modules. The default configuration allows the I/O module ports to
participate in the VLAN named default. The default configuration for the I/O module is not preserved
unless you explicitly save the configuration to nonvolatile RAM (NVRAM).
You can configure parameters of the I/O module after it is installed or you can preconfigure a slot for a
certain type of module and configuration. The preconfigured information is applied to the module after
it is inserted. If you preconfigure a slot for a specific module type, and then insert a different type of
module, the inserted module reverts to its default configuration.
NOTE
See the ExtremeXOS 12.1 Concepts Guide and the ExtremeXOS 12.1 Command Reference Guide for more
information about configuring I/O modules.
