Choose Extreme
More applications, more complexity—telephony, storage, mobility and applications—all required
at a frenzied pace. Higher stakes—downtime and security incidents that can cripple operations and
raise costs. Fewer resources—constrained electrical power and fewer people to manage an increased
workload. More devices—an end-user community that is highly mobile and with high expectations. All
of this with less budget to get it done. How do you solve these issues and still be ready for more?
Extreme Networks®solutions deliver the scalability, agility, and simplicity you need to address
your exciting and yet demanding challenges:
• Scalability to enter new markets, meet the demands of the ‘peaks’ of the business world,
and scale with your organization as it grows and evolves.
• Agility to implement new applications quickly and respond to your business and user
community, without making major investment and change.
• Simplicity that delivers on the vision of an environment that is simpler to install, operate
and maintain.
Prepare for the future—Be Extreme.
Our future-proof designs allow you to avoid forklift upgrades and give you backward and forward solution
compatibility, ultimately protecting your past and future network investments.
Get it Done.
Be
Extreme.

Switching Portfolio

BlackDiamond Family
The exacting demands of IP Telephony deployments, enterprise
aggregation, corporate data centers and network backbones, and
metro Ethernet provider Points of Presence require solutions that
combine consistent performance, carrier-class availability, enhanced
security and simplified management. BlackDiamond®products from
Extreme Networks are designed and purpose-built to meet these
mission-critical requirements.
BlackDiamond 20808
Ideal for the metro Ethernet core where price/performance ratio, high density and resources to support
new service offerings are required.
• Lowest cost per 10 Gigabit Ethernet port provides the most affordable per-bit transport
• Unparalleled per-slot and system capacity in its class
• Designed to support residential, business and wireless backhaul services on the same platform
• ExtremeXOS®modular high availability and extensible operating system
• Redundant, hot-swappable management and switching modules, power supplies and I/O modules
BlackDiamond 12800R Series
Ideal for metro aggregation where high service density with carrier-class scalability and availability
are required.
• ExtremeXOS modular high availability and extensible operating system
• Ingress and egress hierarchical Quality of Service (QoS) on gigabit and 10 Gigabit Ethernet ports
to handle thousands of subscribers
• High-performance multicast, MAC-in-MAC and MPLS for network scaling
• Advanced vMAN service multiplexing, cross-connect and network-peering features for Carrier
Ethernet deployments
• Redundant, hot-swappable management
BlackDiamond 12804C
Ideal for small to medium network cores where availability and security are crucial.
• ExtremeXOS modular high availability and extensible operating system
• Hardware support for IPv6 and NAT
• CLEAR-Flow Security Rules Engine
• Redundant, hot-swappable management and switching modules, power supplies and I/O modules
BlackDiamond 20808 BlackDiamond 12804CBlackDiamond 12800R Series

BlackDiamond 10808
Ideal for network core and data centers where high Gigabit Ethernet density, availability and security
are crucial.
•ExtremeXOS modular high availability and extensible operating system
•Hardware support for IPv6, MPLS, MAC-in-MAC and NAT
•CLEAR-Flow Security Rules Engine
•Redundant, hot-swappable management and switching modules, power supplies and I/O modules
BlackDiamond 8800 Series
Ideal for high density gigabit network edge, mid-sized network cores and data centers.
•ExtremeXOS modular high availability and extensible operating system
•Policy-based QoS and routing capability
•CLEAR-Flow Security Rules Engine (c series)
•High-performance gigabit and 10 Gigabit Ethernet connectivity with low power consumption
•Redundant, hot-swappable management and switching modules, power supplies and I/O modules
•High density 10/100/1000 Power over Ethernet (PoE)
Speeds.
Speed your feeds.
Feed your
BlackDiamond 10808 BlackDiamond 8800

BLACKDIAMOND
BLACKDIAMOND
F E A T U R E S
20808 10808 12804R 12802R 12804C 8810 8806
Max Auto-Negotiating
10/100/1000BASE-T
Ports
— 480 80 40 80 432 240
Max 1 Gigabit
Ethernet Ports (SFP) 320 480 80 40 80 440 248
Max 10 Gigabit
Ethernet Ports 64 48 8 4 8 72 40
Form Factor/
Footprint
Chassis/
14.5RU
Chassis/
22RU
Chassis/
10RU
Chassis/
3RU
Chassis/
10RU
Chassis/
14RU
Chassis/
10RU
Total Switching Capacity 2 Tbps 1.28 Tbps 160 Gbps 80 Gbps 160 Gbps 1.45 Tbps 816 Gbps
Programmable ASICs Yes Yes Yes Yes Yes No No
Redundant Power Yes Yes Yes Yes Yes Yes Yes
Power over Ethernet
(802.3af) No No No No No Yes Yes
Wire-Speed Layer 2/
Layer 3 Switching Yes Yes Yes Yes Yes Yes Yes
Routing - IPv4
BGP4, IS-IS,
OSPF, RIP
v1/v2, PIM,
MSDP
BGP4, IS-IS,
OSPF, RIP
v1/v2, PIM,
MSDP
BGP4, IS-IS,
OSPF, RIP
v1/v2, PIM,
MSDP
BGP4, IS-IS,
OSPF, RIP
v1/v2, PIM,
MSDP
BGP4, IS-IS,
OSPF, RIP
v1/v2, PIM,
MSDP
BGP4, IS-IS,
OSPF, RIP
v1/v2, PIM,
MSDP
BGP4, IS-IS,
OSPF, RIP
v1/v2, PIM,
MSDP
Routing - IPv6
RIPng,
OSPFv3,
IS-IS
RIPng,
OSPFv3,
IS-IS
RIPng,
OSPFv3,
IS-IS
RIPng,
OSPFv3,
IS-IS
RIPng,
OSPFv3,
IS-IS
RIPng,
OSPFv3,
IS-IS
RIPng,
OSPFv3,
IS-IS
Policy-Based
Routing/Switching Yes Yes Yes Yes Yes Yes Yes
Policy-Based Quality of
Service (QoS)
Yes/ Three
Tier Yes Yes/Three
Tier
Yes/Three
Tier Yes Yes Yes
Network Login — Yes Yes Yes Yes Yes Yes
Access Control Lists Yes Yes Yes Yes Yes Yes Yes
Universal Port Yes Yes Yes Yes Yes Yes Yes
CLI Scripting Yes Yes Yes Yes Yes Yes Yes
Widgets Yes Yes Yes Yes Yes Yes Yes
Layer 3 Virtual Switching Yes Yes Yes Yes Yes No No
vMANs (802.1ad) Yes Yes Yes Yes Yes Yes Yes
MAC-in-MAC (802.1ah) — Yes Yes Yes Yes No No
CLEAR-Flow Yes Yes Yes Yes Yes Yes
(c series)
Yes
(c series)
sFlow® — Yes Yes Yes Yes Yes Yes
EAPS Yes Yes Yes Yes Yes Yes Yes
Advanced Spanning Tree
(802.1w, 802.1s, PVST+) Yes Yes Yes Yes Yes Yes Yes
Link Aggregation Yes Yes Yes Yes Yes Yes Yes
Switch Management
Capabilities
SNMP, XML,
Web, CLI,
4 RMON
groups
SNMP, XML,
Web, CLI,
4 RMON
groups
SNMP, XML,
Web, CLI,
4 RMON
groups
SNMP, XML,
Web, CLI,
4 RMON
groups
SNMP, XML,
Web, CLI,
4 RMON
groups
SNMP, XML,
Web, CLI,
4 RMON
groups
SNMP, XML,
Web, CLI,
4 RMON
groups
License - Upgrades MPLS,
H-QoS
MPLS
H-QoS
MPLS,
H-QoS — MPLS Core Core
License - Default Core Core Core Core Core Advanced
Edge
Advanced
Edge

Summit Advanced Series
Summit®Advanced Series switches are designed to provide solutions for data
centers and enterprise aggregation/edge and Carrier Ethernet edge networks,
with their exceptional Quality of Service, low latency, resiliency, line-rate
performance and Power over Ethernet (PoE).
Summit Advanced Series switches offer various critical capabilities, such as
processing packets between core and edge switches, high availability and
control, and simplified management of your entire network with our ExtremeXOS
operating system. With one operating system from edge to core, these switches
provide high-density gigabit PoE to the desktop and in the data center, including
10/100 Layer 2/Layer 3 intelligent switching for advanced IP/Ethernet services.
Summit Advanced Series switches commonly support stacking with
SummitStack™ technology, Universal Port dynamic port configuration and
Layer 3 IPv4/IPv6 routing to meet the demanding requirements of your network.
Summit X650 Summit X450a
Summit X450e
Summit Advanced Switch Common Features
•Universal Port dynamic port configuration for IP Telephony and security
•40 gigabit full-duplex SummitStack stacking for mix-and-match stacking
•IPv4/IPv6 unicast and multicast routing
Summit X650
The ultimate Top of Rack switch for service virtualization and 10 gigabit aggregation.
• High-density 24-port 10 Gigabit Ethernet with 10GBASE-T or SFP+ support in 1 rack unit with
additional 8-port 10 Gigabit Ethernet option module
•AC or DC dual and hot-swappable power supply
Summit X450a Series
Ideal for Gigabit Ethernet Layer 2/Layer 3 aggregation and small network cores.
•Flexible fiber and copper Gigabit Ethernet with optional 10 Gigabit Ethernet
•AC or DC power supply with external redundancy options
Summit X450e Series
Ideal for Gigabit PoE Layer 2/Layer 3 intelligent switching for advanced IP services at the edge.
•Flexible 10/100/1000 PoE with optional 10 Gigabit Ethernet
•AC power supply with external redundancy options
Summit X250e Series
Ideal for 10/100 Layer 2/Layer 3 intelligent switching for advanced IP services at the edge.
•Flexible fiber and copper Fast Ethernet connectivity with PoE and gigabit uplinks
•AC or DC power supply with external redundancy options
Summit X250e

Summit X350 Series
Ideal for 10/100/1000 Layer 2 switching for simple enterprise edge solution.
•ExtremeXOS operating system
•ExtremeXOS scripting capability to automate switch configuration
•External redundant AC power supply options
•Flexible 10/100/1000BASE-T standalone switches
Summit X150 Series
Ideal for 10/100 Layer 2 switching for simple enterprise edge solution.
•ExtremeXOS operating system
•ExtremeXOS scripting capability to automate switch configuration
•External redundant AC power supply options
•10/100BASE-TX with and without PoE standalone switches
Summit X350 Summit X150
Summit X250e Summit X450e
Summit X450a Summit X650
Summit X150 Summit X350
10/100 Gigabit 10 Gigabit
Advanced Edge
Aggregation/Data Center
Value Edge
Summit
Value Series
Summit Value Series switches are designed to provide solutions for enterprise
edge applications with the industry-leading modular ExtremeXOS operating
system. Summit Value Series switches offer simplicity and intelligence at an
affordable price for the edge of the network by providing a unified switch
operating system environment—ExtremeXOS. They are designed for the
simple Gigabit Ethernet- or Fast Ethernet-to-the-desktop applications with
outstanding manageability, resiliency and performance.
With Summit Value Series switches, we can offer an end-to-end synchronized
and consistent operational experience from the core to edge through the
modularity of the ExtremeXOS operating system. The ExtremeXOS operating
system helps to increase network uptime and availability for mission-critical
applications in the enterprise environment to significantly reduce the complexity
of managing the network.
To further simplify the operation, Summit Value Series switches commonly
support the CLI scripting capability which automates the deployment of the
network to help reduce the network operating expenditure.

SUMMIT
F E A T U R E S
SUMMIT
X650 X450a X450e X250e X350 X150
Max Auto-Negotiating
10/100BASE-TX
Ports
— — —
24 (SFP
available)
or 48
— 24 or 48
Max Auto-Negotiating
10/100/1000BASE-T
Ports
— 24 or 48 24 or 48 (both
with PoE) 2 24 or 48 2
Max 1 Gigabit
Ethernet Ports (SFP) 4 4 4 2 4 2
Max 10 Gigabit
Ethernet Ports (XFP,
XENPAK, SFP+)
24 (default),
32 (with VIM1-
10G8X)
2 2 — 2 —
Form Factor/
Footprint
Fixed/
1RU
Fixed/
1RU
Fixed/
1RU
Fixed/
1RU
Fixed/
1RU
Fixed/
1RU
Stacking Support Yes,
SummitStack
Yes,
SummitStack
Yes,
SummitStack
Yes,
SummitStack No No
Total Switching
Capacity
488-680
Gbps
128-256
Gbps
128-256
Gbps
48.8-97.6
Gbps
88-176
Gbps
8.8-13.6
Gbps
Redundant Power Yes/
Hot Swappable
Yes/
External
Yes/
External
Yes/
External
Yes/
External
Yes/
External
Power over Ethernet
(802.3af) No No Yes Yes No Summit
X150-24p
Wire-Speed Layer 2/
Layer 3 Switching Yes Yes Yes Yes Yes Yes
Routing - IPv4
BGP4, IS-IS,
OSPF, RIP
v1/v2, PIM,
MSDP
BGP4, IS-IS,
OSPF, RIP
v1/v2, PIM,
MSDP
OSPF, RIP v1/
v2, PIM
OSPF, RIP v1/
v2, PIM No No
Routing - IPv6 RIPng,
OSPFv3, IS-IS
RIPng,
OSPFv3, IS-IS RIPng RIPng No No
Policy-Based
Routing/Switching Yes Yes Yes Yes
Yes/
Policy-Based
Switching
Yes/
Policy-Based
Switching
Policy-Based Quality
of Service (QoS) Yes Yes Yes Yes Yes Yes
Network Login Yes Yes Yes Yes Yes Yes
Access Control Lists Yes Yes Yes Yes Yes Yes
Universal Port Yes Yes Yes Yes No No
CLI Scripting Yes Yes Yes Yes Yes Yes
Widgets Yes Yes Yes Yes Yes Yes
vMANs (802.1ad) Yes Yes Yes Yes Yes Yes
CLEAR-Flow Yes Yes No No No No
sFlow Yes Yes Yes Yes Yes Yes
EAPS Yes Yes Yes Yes Yes Yes
Advanced Spanning
Tree (802.1w,
802.1s, PVST+)
Yes Yes Yes Yes Yes Yes
Link Aggregation Yes Yes Yes Yes Yes Yes
Switch Management
Capabilities
SNMP, XML,
Web, CLI, 4
RMON groups
SNMP, XML,
Web, CLI, 4
RMON groups
SNMP, XML,
Web, CLI, 4
RMON groups
SNMP, XML,
Web, CLI, 4
RMON groups
SNMP, XML,
Web, CLI, 4
RMON groups
SNMP, XML,
Web, CLI, 4
RMON groups
License - Upgrades Core Core Advanced Edge Advanced Edge — —
License - Default Advanced Edge Advanced Edge Edge Edge Layer 2-Edge Layer 2-Edge

Wireless Products
Extreme Networks offers a complete suite of wireless LAN products pro-
viding a highly scalable, secure, and robust wireless solution for the enter-
prise mobile workforce. The solution is designed to be flexible to meet the
needs of small- to medium-sized businesses, large corporate campuses,
and distributed enterprises with many branch offices. Extreme Networks
wireless solution seamlessly integrates with the wired infrastructure to
enable fast and easy deployment of unified voice and data services as well
as common security and QoS policies across the entire network.
Summit WM3000 Series
WLAN Controllers
Altitude™ 3500/4600 Series
Access Points
Summit WM3000 Series WLAN Controllers
•Small site to large multi-site deployment
•Comprehensive wired/wireless security features
•Seamless mobility
•Toll-quality voice service
•Scalability and high availability with clustering
Altitude 3500/4600 Series Access Points
•Dual radio/dual band access points
•Plug-n-play deployment
•Indoor and outdoor models for campus-wide mobility
•802.11n performance for high speed wireless access
•Remote site deployment with site survivability
•Mesh networking and bridging for extending wireless service
•Virtual AP services with 16 SSIDs/radio
Wireless Management Suite
•Life cycle management
•Import floor plans and LAN Planner designs
•Site survey and modeling
•Configuration management
•Multi-site dashboard view
•RF Visualization with heat maps
•Wizard-based diagnostic tools
Wireless Management
Suite

Sentriant Family
The Sentriant®family of security products provides organizations with
cost-effective, easy-to-deploy solutions to today’s tough network security
challenges. These high-performance, highly scalable appliances make it
easy to verify that devices connecting to the network are in compliance
with security policies established by the IT department and mitigate
rapidly propagating network threats in seconds.
Working in combination with other Extreme Networks products, the
Sentriant family provides a variety of capabilities for detecting security
policy violations and enforcing policy. Leveraging the capabilities within
the network elements allow our security products to scale with your
infrastructure and reduce the number of appliances that you need to
achieve the required level of security. The reduction in the number of
appliances improves the availability of the network and reduces the total
cost of ownership.
Sentriant NG300 Sentriant AG200
Sentriant NG300
Ideal for detecting and mitigating rapidly propagating security threats from inside the network.
•Defends against security threats without interfering with network traffic
•Unique behavioral defense mechanism complements traditional signature-based IPS systems
•Integration with Extreme Networks switches for network-wide coverage
•Standalone mode for broad network compatibility
Sentriant AG200
Ideal for endpoint compliance testing and Network Access Control.
•Flexible deployment options (802.1X, DHCP, in-line) for broad infrastructure compatibility
•Fast, pre-connect testing of required security software and settings (PC and MAC)
•Quarantines and facilitates remediation of non-compliant endpoints
•Enterprise-class endpoint testing scale, management and administration

Widgets
Extreme Networks Widgets are designed to ease deployment,
monitoring, operations and optimization across the spectrum of
Extreme Networks switches, access points and security appliances.
What is a widget? Simply put, a widget is a published script, rule set or
other aid that helps you address your network challenges.
Widgets are organized into four categories. In each category you will
find a collection of modules that address your various needs from
switch deployment to automating power conservation practices. Each
module contains one or more widgets and associated documentation to
help you deploy and enhance your network.
Visit Widget Central where you can download free widgets, discover
information about widgets and related product documentation, as well
as contribute new widgets or ideas for widgets.
http://www.extremenetworks.com/solutions/widget-central/
Deploy—Widgets that help you quickly deploy your network devices
Monitor—Widgets that monitor the health of your network
Operate—Widgets that help you handle ongoing network events automatically
Optimize—Widgets that help you tune the performance of your network

Management Tools
Network management tools from Extreme Networks automate Layers 2 – 7 application
infrastructure management.
EPICenter
EPICenter®management platform provides fault configuration, accounting, performance and
security functions to manage Extreme’s multi-layer switching equipment in a converged network.
Universal Port Manager and Policy Manager add more detailed control and monitoring of edge
policies. EPICenter also makes it easy for you to monitor and validate EAPS rings.
ServiceWatch
ServiceWatch®management and monitoring software provides powerful, Layers 4 – 7 monitoring
and management for mission-critical network services.
ExtremeWorks Maintenance and Support
Extreme Networks offers comprehensive service solutions that help you optimize your network 24x7.
ExtremeWorks®maintenance programs give you the support you need to operate and manage your
network on a day-to-day basis, and provide you the safety net you need when the unexpected occurs.
Extreme Innovation
ExtremeXOS
The ExtremeXOS network operating system provides insight and control for
mission-critical applications and offers access to new types of configuration and
management technologies that enable more innovative, creative, and extensible
solutions. The ExtremeXOS operating system stands out as a real alternative to
closed, proprietary products that limit choice and compromise performance.
The open, secure XML interfaces in the ExtremeXOS operating system allow
applications to effectively control the network without limiting flexibility and
forcing system-wide upgrade cycles. Modularity enhances availability, minimizing
the impact of changes, attacks or instabilities. Wire-rate instrumentation
provides deep insight into critical network activities to build sophisticated
security and voice applications. The innovative Universal Port infrastructure in
the ExtremeXOS operating system provides dynamic security policies for users
and devices as well as auto-configuration of ports
and VoIP phones.
The ExtremeXOS operating system from edge to
core simplifies the administration of your network,
which can result in lower costs and streamlined
resource management, saving your team time and
hassle during routine maintenance and upgrades.

Legacy Products
These tried and true products deliver the comprehensive security,
intuitive management and robust network service required in today’s
demanding service provider and enterprise networks. These products
have benefited from years of extensive deployment in a wide range of
network topologies and service applications.
Summit 48si Alpine®Series
Alpine 3800 Series
Ideal for use throughout the network where price/performance ratio is the primary objective.
•ExtremeWare®hardened real-time operating system
•Policy-based QoS and routing capability in a modular switch
•Redundant, hot-swappable management modules, power supplies and I/O module
Summit48si
Ideal for 10/100 Layer 3 switching at the edge of the enterprise or metro network.
•ExtremeWare hardened real-time operating system
•Policy-based QoS and routing in a compact form factor
•Redundant, hot-swappable AC and DC power supplies

LEGACY
LEGACY
F E A T U R E S
FEATURES Alpine 3808 Alpine 3804 Summit48si
Max Auto-Negotiating
10/100BASE-TX Ports 256 128 48
Max Auto-Negotiating
10/100/1000BASE-T Ports 128 64 0
Max Gigabit Ethernet Ports
(GBIC or Mini-SFP) 128 64 2
Form Factor/Footprint Chassis/12RU Chassis/6RU Fixed/1RU
Total Switching Capacity 64 Gbps 32 Gbps 17.5 Gbps
Redundant Power Yes Yes Yes
Wire-Speed Layer 2/
Layer 3 Switching Yes Yes Yes
Routing - IPv4
BGP4, DVMRP,
OSPF, RIP v1/
v2, PIM
BGP4, DVMRP,
OSPF, RIP v1/
v2, PIM
BGP4, DVMRP,
OSPF, RIP v1/
v2, PIM
Policy-Based
Routing/Switching Yes Yes Yes
Policy-Based Quality of
Service (QoS) Yes Yes Yes
Network Login Yes Yes Yes
Access Control Lists Yes Yes Yes
vMANs (802.1ad) Yes Yes Yes
sFlow Yes Yes Yes
EAPS Yes Yes Yes
Advanced Spanning Tree
(802.1w, 802.1s, PVST+) Yes Yes Yes
Link Aggregation Yes Yes Yes
Switch Management
Capabilities
SNMP, Web, CLI,
4 RMON groups
SNMP, Web, CLI,
4 RMON groups
SNMP, Web, CLI,
4 RMON groups
License - Upgrades Full Layer 3 Full Layer 3 Full Layer 3
License - Default Basic Layer 3 Basic Layer Basic Layer

Corporate and North America
Extreme Networks
3585 Monroe Street
Santa Clara, CA 95051
United States
Phone [phone]
Asia Pacific
Extreme Networks
2/F Shun On Centre
6-8 Harbour Road
Wanchai, Hong Kong
China
Phone [phone]
Europe, Middle East, Africa
and South America
Extreme Networks
Kernkade 2, 2nd floor
Lage Weide, Utrecht 3542 CH
The Netherlands
Phone [phone]
Japan
Extreme Networks
17F Sumitomo Korakuen Building
1-4-1 Koishikawa
Bunkyo-ku, Tokyo 112-002
Japan
Phone [phone]
email: [email protected]
© 2009 Extreme Networks, Inc. All rights reserved.
Extreme Networks, the Extreme Networks Logo, Alpine, Altitude, BlackDiamond, EPICenter, ExtremeWare, ExtremeXOS,
ExtremeWorks, Sentriant, ServiceWatch, Summit, and SummitStack are either registered trademarks or trademarks of
Extreme Networks, Inc. in the United States and/or other countries. sFlow is the property of InMon Corporation.
Specifications are subject to change without notice. 1002_13w 10/09
Be Extreme.
www.extremenetworks.com
Printed on Recycle Paper. Please Recycle.
