Extreme Networks Summit X430 Series Quick start guide

Part Number: 120882-00 Rev. 02
1
Summit X430 Series Switches
Installation Note
Pre-installation Requirements
Before you install the Summit X430 series switch, read the information in “Safety Information” on
page 2.
The following items are provide with the Summit X430 series switch:
●Mounting brackets
●Eight M3 screws to secure the mounting brackets to the switch
To install the switch in a rack, you need the following additional tools and equipment:
●Four rack mounting screws to match your equipment rack
●Screwdriver to fit the rack mounting screws
●AC power cord that is suitable for the current rating of this product (See “Selecting AC Power
Supply Cords” on page 4.
Required Tools
The following items are provided with the Summit X430 series switch:
●Two rack mounting brackets adaptable for either a front-mount or mid-mount installation
●Twelve screws for attaching the brackets to the switch enclosure
●For DC models, spade terminal and M4 screw with captive washer for grounding the switch
You need the following additional tools and materials to install the switch in a rack:
●#1 Phillips screwdriver
●Four rack mounting screws to match your equipment rack
●Screwdriver to fit the rack mounting screws
●#14 AWG stranded copper cable for grounding the switch (DC powered models)
●ESD-preventive wrist strap for installing optional ports at the back of the switch

Installing the Switch
Summit X430 Series Switches Installation Note
2
Installing the Switch
1On each side of the switch, place a mounting bracket over the mounting holes.
2Insert the provided screws and tighten them securely (Figure 1).
Figure 1: Attaching a Mounting Bracket
3Slide the switch into the rack (Figure 2).
Figure 2: Installing the Switch in the Rack
4Insert and tighten rack-mounting screws to secure the switch to the rack.
5Connect the power cable to the AC input power connector on the back of the switch.
6Connect the other end of the power cable to an AC power socket.
Safety Information
WARNING!
Read the safety information in this section before you install Extreme Networks products. Failure to follow
this safety information can lead to personal injury or damage to the equipment.
SH
SH_262

Maintenance Safety
Summit X430 Series Switches Installation Note
3
Only trained service personnel should perform service to Extreme Networks switches and components.
Trained service personnel have read all related installation manuals, have the technical training and
experience necessary to be aware of the hazards to which they are exposed in performing a task, and
are aware of measures to minimize the danger to themselves or other persons.
WARNING!
This is a Class A product. In a residential environment this product may cause radio interference, in which
case the user may be required to take adequate measures.
Considerations Before Installing
●The system is designed to operate in a typical Telco environment that is environmentally controlled.
Choose an indoor area that has the following characteristics:
- Temperature-controlled and humidity-controlled, to ensure that the maximum ambient room
temperature shall not exceed the temperature specified in the product data sheet
- Clean and free from airborne materials that can conduct electricity
- Well ventilated and away from sources of heat, including direct sunlight
- Away from sources of vibration or physical shock
- Isolated from strong electromagnetic fields produced by electrical devices
- Secured, enclosed, and restricted-access, ensuring that only trained and qualified service
personnel have access to the equipment
●Establish at least 3 inches clearance on all sides for effective ventilation. Do not obstruct air intake
vents or ventilation grills on the front, side, or rear panel. Locate the system away from heat sources.
●Make sure that your equipment is placed in an area that accommodates the product specifications
for power consumption and component heat dissipation.
●Make sure that your power supplies meet the site power or AC power requirements of all network
equipment.
Maintenance Safety
●Use only original accessories or components that are approved for use with this system.
Failure to follow these instructions may damage the equipment or violate required safety and
EMC regulations.
●The chassis cover should be removed only by Extreme Networks personnel. This system contains no
customer-serviceable components. Repairs to the system must be performed by an Extreme
Networks factory service technician.
●Disconnect all power cords before working near power supplies, unless a maintenance procedure
instructs you to do otherwise.
●Replace a power cord immediately if it shows any signs of damage.
●When you work with optical devices or other modular accessories, wear an ESD-preventive wrist
strap to reduce the risk of electronic damage to the equipment. Connect the other end of the strap to
an appropriate grounding point on the equipment rack. Leave the ESD-preventive wrist strap

Maintenance Safety
Summit X430 Series Switches Installation Note
4
permanently attached to the equipment rack so that it is always available when you need to handle
ESD-sensitive components.
●Install all cables in a manner that avoids strain. Use tie wraps or other strain relief devices.
General Safety Precautions
●Do not try to lift objects that you think are too heavy for you.
●When you install equipment in a rack, load heavier devices in the lower half of the rack first to
avoid making the rack top-heavy.
●For Summit desktop equipment installations, do not place a monitor or other heavy objects on top of
the equipment. The chassis cover is not designed to support weight.
●Use only tools and equipment that are in perfect condition. Do not use equipment with
visible damage.
●Route cables in a manner that prevents possible damage to the cables and avoids causing accidents,
such as tripping.
Selecting AC Power Supply Cords
Extreme Networks does not include AC power input cords in the product box. To purchase a power
cord for your product and for your specific country, contact your local Extreme Networks Channel
Account Manager or Sales Manager, or purchase a cord from your local supplier.
To locate a Sales Manager or Partner in your region visit:
http://www.extremenetworks.com/how-to-buy/how-to-buy.aspx
Power cords that are used with AC-powered Summit X430 series switches must meet the
following requirements:
●The power cord must be agency-certified for the country of use.
●The power cord must have an IEC320-C13 connector for connection to the switch or external power
supply.
●The power cord must have an appropriately rated and approved wall plug applicable to the country
of installation.
●For cords up to 6 feet (2 m) long, the wire size must be 18 AWG (.75 mm2) minimum; over 6 feet, the
minimum wire size is 16 AWG (1.0 mm2).
Connecting Power
For the specific ratings and input power requirements of each switch model, see the data sheet for the
Summit X430 series switches at http://www.extremenetworks.com.
WARNING!
Be sure to satisfy the requirements listed in this section when you connect all Extreme Networks
equipment to power.

Maintenance Safety
Summit X430 Series Switches Installation Note
5
AC powered Summit X430 switches
When you connect equipment to power:
●Plug power cords only into properly grounded electrical outlets to help prevent electrical shock and
to comply with international safety standards.
●Use only power cords that are certified for use within the country of use. Do not attempt to modify
AC power cords.
●Make sure the voltage and frequency of your power outlet match the system electrical ratings for the
equipment. The building and/or power source must provide overload protection.
●Use a surge suppressor, line conditioner, or uninterruptible power supply to protect the system from
momentary increases or decreases in electrical power.
●Summit X430 series switches do not have switches for turning the unit on and off. Remove the wall
plug from the electrical outlet to disconnect the power from a Summit X430 series switch. Make sure
that this connection is near the equipment and is easily accessible for quick disconnect.
WARNING!
Make sure that the source outlet is properly grounded according to the country’s local electrical
requirements before plugging the AC supply power cord into a power supply.
Cable Routing for LAN Systems
The Summit X430 series switches meet the requirements for LAN system equipment. LAN systems are
designed only for intra-building installations; that is, cable runs between devices must be in the same
building as the connected units.
Fiber Optic Ports—Optical Safety
The following safety warnings apply to all optical devices used in Extreme Networks equipment that
are removable or directly installed in an I/O module or chassis system. Such devices include but are
not limited to gigabit interface converters (GBICs), small form factor pluggable (SFP) modules (or
mini-GBICs), XENPAK transceivers, and XFP laser optic modules.
WARNING!
Laser optic modules become very hot after prolonged use. Be careful when you remove a laser optic
module from the chassis or option card. If the laser optic module is too hot to touch, disengage the laser optic
module and allow it to cool before removing it completely.
WARNING!
When you work with laser optic modules, always take the precautions listed below to avoid exposure to
hazardous radiation.

Battery Replacement and Disposal
Summit X430 Series Switches Installation Note
6
●Never look at the transmit LED/laser through a magnifying device while the laser is powered on.
●Never look directly at a fiber port on the switch or at the ends of a fiber cable when they are
powered on.
●Invisible laser radiation can occur when the connectors are open. Avoid direct eye exposure to the
beam when optical connections are unplugged.
●Never alter, modify, or change an optical device in any way other than suggested in this
document.
Battery Replacement and Disposal
Batteries included with Extreme products are encapsulated and must be replaced only by qualified
Extreme Service personnel. Contact your Extreme Networks Service personnel for product replacement.
Do not attempt to replace the battery. If these instructions are disregarded and replacement of these
batteries is attempted, the following guidelines must be followed to avoid danger of explosion:
●Replace with the same or equivalent battery type as recommended by the battery manufacturer.
●Dispose of the battery in accordance with the battery manufacturer’s recommendation.
Battery Warning — Taiwan
WARNING!
Fiber Optic Ports and Optical Safety
The following safety warnings apply to all optical devices used in Extreme Networks equipment that
are removable or directly installed in an I/O module or chassis system. Such devices include but are not
limited to gigabit interface converters (GBICs), small form factor pluggable (SFP) modules (or
mini-GBICs), QSFP+ modules, XENPAK transceivers, and XFP laser optic modules.

Fiber Optic Ports and Optical Safety
Summit X430 Series Switches Installation Note
7
WARNING!
Laser optic modules become very hot after prolonged use. Take care when removing a laser optic module
from the module or option card. If the laser optic module is too hot to touch, disengage the laser optic module and
allow it to cool before removing it completely.
WARNING!
When working with laser optic modules, always take the precautions listed below to avoid exposure to
hazardous radiation.
●Never look at the transmit LED/laser through a magnifying device while the transmit LED is
powered on.
●Never look directly at a fiber port on the switch or at the ends of a fiber cable when they are
powered on.
●Invisible laser radiation can occur when the connectors are open. Avoid direct eye exposure to the
beam when optical connections are unplugged.
●Never alter, modify, or change an optical device in any way other than suggested in this
document.
GBIC, SFP (Mini-GBIC), QSFP+, XENPAK, and XFP Regulatory
Compliance
Extreme Networks pluggable optical modules and direct-attach cables meet the following regulatory
requirements:
●Class 1 or Class 1M Laser Product
●EN60825-1:2007 2nd Ed. or later, European standard
●FCC 21 CFR Chapter 1, Subchapter J in accordance with FDA & CDRH requirements
●Application of CE Mark in accordance with 2004/108/EEC EMC Directive and the 2006/95/EC Low
Voltage Directives
●UL and/or CSA registered component for North America
●47 CFR Part 15, Class A when installed into Extreme products
Summit X430-8p Switch I/O Ports
The front panel of the Summit X430-8p switch includes:
●Eight fixed autosensing 10/100/1000BASE-T ports (ports 1–8) that provide 8 Gbps of high-density
copper connectivity. In addition, all of these ports (ports 1-8) also support the POE protocol
IEEE802.af and POE+ protocol IEEE 802.at standard and can provide 15.4 Watts of power on a single
port up to a total power budget of 60 Watts.
●Two unpopulated 1000BASE-X unpopulated SFP ports (ports 9–10) that provide 2 Gbps of fiber
connectivity.
●Ethernet management port.
●Serial console port implemented as an RJ-45 connector, used to connect a terminal and perform local
management.

Fiber Optic Ports and Optical Safety
Summit X430 Series Switches Installation Note
8
Summit X430-24t Switch I/O Ports
The front panel of the Summit X430-24t switch includes:
●Twenty-four fixed autosensing 10/100/1000BASE-T ports (ports 1–24) that provide 24 Gbps of
high-density copper connectivity
●Four unpopulated 1000BASE-X unpopulated SFP ports (ports 25–28) that provide 4 Gbps of fiber
connectivity.
Ports 21 through 24 are implemented as shared ports that pair a copper port with a fiber port. For
information about SFPs, see the Extreme Networks Pluggable Interface Modules Installation Guide.
●Ethernet management port.
●Serial console port implemented as an RJ-45 connector, used to connect a terminal and perform local
management.
Summit X430-24p Switch I/O Ports
The front panel of the Summit X430-24p switch includes:
●Twenty-four fixed autosensing 10/100/1000BASE-T ports (ports 1–24) that provide 24 Gbps of
high-density copper connectivity. In addition, all of these ports (ports 1-24) also support the POE
protocol IEEE802.af and POE+ protocol IEEE 802.at standard and can provide 15.4 Watts of power on
a single port up to a total power budget of 370 Watts.
●Four unpopulated 1000BASE-X unpopulated SFP ports (ports 25–28) that provide 4 Gbps of fiber
connectivity.
●Ethernet management port.
●Serial console port implemented as an RJ-45 connector, used to connect a terminal and perform local
management.

Fiber Optic Ports and Optical Safety
Summit X430 Series Switches Installation Note
9
Summit X430-48t Switch I/O Ports
The front panel of the Summit X430-48t switch includes:
●Forty-eight fixed autosensing 10/100/1000BASE-T ports (ports 1–48) that provide 48 Gbps of
high-density copper connectivity
●Four 1000BASE-X unpopulated SFP ports (ports 49–52) that provide 4 Gbps of fiber connectivity.
Ports 49 through 52 are implemented as shared ports that pair a copper port with a fiber port.
●Ethernet management port
●Serial console port implemented as an RJ-45 connector, used to connect a terminal and perform local
management

X430 Series Switches
Summit X430 Series Switches Installation Note
10
X430 Series Switches
The Summit X430 series includes the following switches:
●Summit X430-8p
●Summit X430-24t
●Summit X430-24p
●Summit X430-48t
Table 1: Summit X430 Series Switch Technical Specifications
Physical Dimensions
Summit X430-8p switch Height: 1.73 inches (4.4 cm)
Width: 8.7 inches (22.1 cm)
Depth: 10.0 inches (25.4 cm)
Summit X430-24t switch
Summit X430-24p switch
Summit X430-48t switch
Height: 1.73 inches (4.4 cm)
Width: 17.4 inches (44.1 cm)
Depth: 10.0 inches (25.4 cm)
Weight
Summit X430-8p switch 5.0 lb (2.27 kg)
Summit X430-24t switch 8.4 lb (3.83 kg)
Summit X430-24p switch 10.0 lb (4.54 kg)
Summit X430-48t switch 9.1 lb (4.13 kg)
Packaged Dimensions
Summit X430-8p switch
Summit X430-24p switch
Summit X430-24t switch
Summit X430-48t switch
Height: 5.12 inches (13.2 cm)
Width: 22.13 inches (56.2 cm)
Depth: 15.16 inches (38.5 cm)
Packaged Weight
Summit X430-8p switch 7.0 lb (3.18 kg)
Summit X430-24t switch 11.1 lb (5.05 kg)
Summit X430-24p switch 13.0 lb (5.90 kg)
Summit X430-48t switch 11.7 lb (5.31 kg)
Acoustic Sound
Summit X430-8p switch 0 dB(A) (no fan)
Summit X430-24t switch
Summit X430-48t switch
55 dB(A)
Summit X430-24p switch 46 dB(A)
Power: Summit X430-8p
Nominal input ratings 100 to 240 V , 50-60 Hz, 1.75 A
Input current 1.14 A @ 110 V (low-line)
0.70 A @ 220 V (high-line)
Heat dissipation 24 W, 82 BTU/hr
Power consumption 24 W, 82 BTU/hr

X430 Series Switches
Summit X430 Series Switches Installation Note
11
Power: Summit X430-24t
Nominal input ratings 100 to 240 V , 50/60 Hz, 0.75 A
Input current 0.40 A @ 110 V (low-line)
0.20 A @ 220 V (high-line)
Heat dissipation 44 W, 150 BTU/hr
Power consumption 44 W, 150 BTU/hr
Power: Summit X430-24p
Nominal input ratings 100 to 240 V , 50/60 Hz, 5.75 A
Input current 4.16 A @ 110 V (low-line)
2.07 A @ 220 V (high-line)
Heat dissipation 55 W, 188 BTU/hr
Power consumption 55 W, 188 BTU/hr
Power: Summit X430-48t
Nominal input ratings 100 to 240 V , 50/60 Hz, 1.0 A
Input current 0.85 A @ 110 V (low-line)
0.50 A @ 220 V (high-line)
Heat dissipation 95 W, 325 BTU/hr
Power consumption 95 W, 325 BTU/hr
Table 1: Summit X430 Series Switch Technical Specifications (Continued)

X430 Series Switches
Summit X430 Series Switches Installation Note
12
AccessAdapt, Alpine, Altitude, BlackDiamond, Direct Attach, EPICenter, ExtremeWorks Essentials, Ethernet
Everywhere, Extreme Enabled, Extreme Ethernet Everywhere, Extreme Networks, Extreme Standby Router
Protocol, Extreme Turbodrive, Extreme Velocity, ExtremeWare, ExtremeWorks, ExtremeXOS, Go Purple Extreme
Solution, ExtremeXOS ScreenPlay, ReachNXT, Ridgeline, Sentriant, ServiceWatch, Summit, SummitStack, Triumph,
Unified Access Architecture, Unified Access RF Manager, UniStack, XNV, the Extreme Networks logo, the Alpine
logo, the BlackDiamond logo, the Extreme Turbodrive logo, the Summit logos, and the Powered by ExtremeXOS
logo are trademarks or registered trademarks of Extreme Networks, Inc. or its subsidiaries in the United States
and/or other countries.
sFlow is the property of InMon Corporation.
Specifications are subject to change without notice.
All other registered trademarks, trademarks, and service marks are property of their respective owners.
© 2013 Extreme Networks, Inc. All Rights Reserved.
