Extreme Networks ExtremeSwitching SLX 9540 Manual

ExtremeSwitching SLX 9540 Hardware
Installation Guide
9036306-00 Rev AB
March 2020

Copyright © 2020 Extreme Networks, Inc. All Rights Reserved.
Legal Notice
Extreme Networks, Inc. reserves the right to make changes in specications and other information contained in this document and its
website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such
changes have been made.
The hardware, rmware, software or any specications described or referred to in this document are subject to change without notice.
Trademarks
Extreme Networks and the Extreme Networks logo are trademarks or registered trademarks of Extreme Networks, Inc. in the United
States and/or other countries.
All other names (including any product names) mentioned in this document are the property of their respective owners and may be
trademarks or registered trademarks of their respective companies/owners.
For additional information on Extreme Networks trademarks, please see: www.extremenetworks.com/company/legal/trademarks
Open Source Declarations
Some software les have been licensed under certain open source or third-party licenses. End-user license agreements and open source
declarations can be found at: www.extremenetworks.com/support/policies/software-licensing
ExtremeSwitching SLX 9540 Hardware Installation Guide
2 9036360-00 Rev AB

Contents
Preface...................................................................................................................................................................................................................................7
Conventions..................................................................................................................................................................................................................................................7
Notes, cautions, and warnings.....................................................................................................................................................................................................7
Text formatting conventions.........................................................................................................................................................................................................7
Command syntax conventions....................................................................................................................................................................................................8
Documentation and Training.................................................................................................................................................................................................................8
Training..................................................................................................................................................................................................................................................8
Getting Help................................................................................................................................................................................................................................................. 8
Subscribing to Service Notications.........................................................................................................................................................................................9
Providing Feedback to Us...................................................................................................................................................................................................................... 9
About this Document.......................................................................................................................................................................................................11
Supported hardware and software................................................................................................................................................................................................... 11
What is new in this document............................................................................................................................................................................................................12
Device Overview............................................................................................................................................................................................................... 13
Hardware features...................................................................................................................................................................................................................................13
Port-side view of the SLX 9540 Switch ......................................................................................................................................................................................15
Nonport-side view of the SLX 9540 Switch ............................................................................................................................................................................. 15
Device management options.............................................................................................................................................................................................................16
Preparing for the Installation..........................................................................................................................................................................................17
Safety precautions.................................................................................................................................................................................................................................. 17
General precautions......................................................................................................................................................................................................................17
ESD precautions............................................................................................................................................................................................................................ 18
Power precautions.........................................................................................................................................................................................................................18
Lifting precautions.........................................................................................................................................................................................................................19
Laser precautions.......................................................................................................................................................................................................................... 19
Facility requirements..............................................................................................................................................................................................................................19
Electrical considerations............................................................................................................................................................................................................. 19
Environmental considerations.................................................................................................................................................................................................. 20
Location considerations..............................................................................................................................................................................................................20
Cable management recommendations................................................................................................................................................................................20
Quick installation checklist.................................................................................................................................................................................................................. 21
Shipping carton contents.....................................................................................................................................................................................................................22
Mounting the Device........................................................................................................................................................................................................23
Mounting options....................................................................................................................................................................................................................................23
Mounting precautions............................................................................................................................................................................................................................23
Standalone installation.......................................................................................................................................................................................................................... 24
Installing the device in a rack..............................................................................................................................................................................................................24
Four-post rack mount kit installation (XBR-R000297)......................................................................................................................................................... 25
Time and items required.............................................................................................................................................................................................................25
Parts list............................................................................................................................................................................................................................................. 25
Flush-front mounting...................................................................................................................................................................................................................26
Installing the Universal Two-Post Rack Kit (XEN-R000294)..............................................................................................................................................29
Installation requirements.............................................................................................................................................................................................................30
Time and items required.............................................................................................................................................................................................................30
ExtremeSwitching SLX 9540 Hardware Installation Guide
9036360-00 Rev AB 3

Parts list ............................................................................................................................................................................................................................................ 30
Flush-front mounting...................................................................................................................................................................................................................31
Mid-mounting................................................................................................................................................................................................................................. 35
Installing the Universal Four-Post Rack Kit (XEN-R000296).............................................................................................................................................39
Installation requirements.............................................................................................................................................................................................................40
Time and items required.............................................................................................................................................................................................................40
Parts list............................................................................................................................................................................................................................................. 40
Flush-front mounting...................................................................................................................................................................................................................42
Flush-rear (recessed) mounting...............................................................................................................................................................................................47
Initial Setup and Verication.......................................................................................................................................................................................... 53
Initial setup and conguration checklist......................................................................................................................................................................................... 53
Items required...........................................................................................................................................................................................................................................54
Providing power to the device........................................................................................................................................................................................................... 54
Establishing a serial connection .......................................................................................................................................................................................................55
Conguring a static IP address..........................................................................................................................................................................................................57
Establishing an Ethernet connection...............................................................................................................................................................................................57
Customizing the chassis and host names....................................................................................................................................................................................58
Conguring the DNS service............................................................................................................................................................................................................. 59
Setting the date and time.....................................................................................................................................................................................................................59
Verifying correct operation.................................................................................................................................................................................................................. 59
Backing up the conguration............................................................................................................................................................................................................. 60
Installing cable management kit........................................................................................................................................................................................................60
Transceivers and Cables................................................................................................................................................................................................. 61
Supported transceivers and cables................................................................................................................................................................................................. 61
Time and items required...................................................................................................................................................................................................................... 61
Precautions specic to transceivers and cables.........................................................................................................................................................................62
Cleaning the ber-optic connectors................................................................................................................................................................................................62
Managing cables..................................................................................................................................................................................................................................... 63
Installing an SFP+ transceiver............................................................................................................................................................................................................63
Replacing an SFP+ transceiver..........................................................................................................................................................................................................65
Installing a QSFP28 transceiver.......................................................................................................................................................................................................67
Replacing a QSFP28 transceiver.................................................................................................................................................................................................... 69
Breakout cables....................................................................................................................................................................................................................................... 70
Verifying transceiver operation..........................................................................................................................................................................................................71
Monitoring the Device..................................................................................................................................................................................................... 73
Monitoring Overview............................................................................................................................................................................................................................. 73
LED activity interpretation................................................................................................................................................................................................................... 73
LED indications........................................................................................................................................................................................................................................74
Power Supplies................................................................................................................................................................................................................. 77
Power supply overview.........................................................................................................................................................................................................................77
Precautions specic to power supplies..........................................................................................................................................................................................79
Identifying the airow direction..........................................................................................................................................................................................................80
Time and items required...................................................................................................................................................................................................................... 80
Replacing a power supply....................................................................................................................................................................................................................80
Inserting a new AC power supply ....................................................................................................................................................................................................81
Inserting a new DC power supply.................................................................................................................................................................................................... 82
Grounding the SLX 9540 device.....................................................................................................................................................................................................83
Fan Assemblies.................................................................................................................................................................................................................85
ExtremeSwitching SLX 9540 Hardware Installation Guide
4 9036360-00 Rev AB

Fan assemby overview......................................................................................................................................................................................................................... 85
Precautions specic to fan assemblies..........................................................................................................................................................................................86
Identifying the airow direction..........................................................................................................................................................................................................87
Times and items required....................................................................................................................................................................................................................87
Replacing a fan assembly....................................................................................................................................................................................................................87
Inserting a new fan assembly.............................................................................................................................................................................................................87
ExtremeSwitching SLX 9540 Technical Specications.......................................................................................................................................... 91
System specications............................................................................................................................................................................................................................91
Ethernet.......................................................................................................................................................................................................................................................91
LEDs.............................................................................................................................................................................................................................................................91
Other............................................................................................................................................................................................................................................................ 92
Weight and physical dimensions...................................................................................................................................................................................................... 92
Environmental requirements.............................................................................................................................................................................................................. 92
Power supply specications (per PSU)..........................................................................................................................................................................................93
Power consumption (typical conguration).................................................................................................................................................................................. 93
Power consumption (maximum conguration)...........................................................................................................................................................................93
Data port specications (Ethernet)...................................................................................................................................................................................................93
Serial port specications (pinout RJ-45).......................................................................................................................................................................................94
Serial port specications (pinout - mini-USB)............................................................................................................................................................................ 94
Serial port specications (protocol)..................................................................................................................................................................................................94
Memory specications ........................................................................................................................................................................................................................ 94
Regulatory compliance (EMC)...........................................................................................................................................................................................................95
Regulatory compliance (safety)..........................................................................................................................................................................................................95
Regulatory compliance (environmental).........................................................................................................................................................................................95
Regulatory Statements....................................................................................................................................................................................................97
CE statement............................................................................................................................................................................................................................................ 97
China ROHS............................................................................................................................................................................................................................................. 97
BSMI statement (Taiwan)..................................................................................................................................................................................................................... 97
Canadian requirements.........................................................................................................................................................................................................................98
China CCC statement............................................................................................................................................................................................................................98
Europe and Australia (CISPR 32 Class A Warning)..................................................................................................................................................................99
FCC warning (US only)..........................................................................................................................................................................................................................99
Germany statement................................................................................................................................................................................................................................99
KCC statement (Republic of Korea)................................................................................................................................................................................................. 99
VCCI statement.....................................................................................................................................................................................................................................100
Japan power cord ................................................................................................................................................................................................................................100
Cautions and Danger Notices..................................................................................................................................................................................... 101
Cautions...................................................................................................................................................................................................................................................101
General cautions......................................................................................................................................................................................................................... 101
Danger Notices..................................................................................................................................................................................................................................... 104
General dangers..........................................................................................................................................................................................................................104
ExtremeSwitching SLX 9540 Hardware Installation Guide
9036360-00 Rev AB 5

ExtremeSwitching SLX 9540 Hardware Installation Guide
6 9036360-00 Rev AB

Preface
• Conventions............................................................................................................................................................................................................ 7
• Documentation and Training............................................................................................................................................................................8
• Getting Help............................................................................................................................................................................................................8
• Providing Feedback to Us.................................................................................................................................................................................9
This section discusses the conventions used in this guide, ways to provide feedback, additional help, and other Extreme Networks®
publications.
Conventions
This section discusses the conventions used in this guide.
Notes, cautions, and warnings
Notes, cautions, and warning statements may be used in this document. They are listed in the order of increasing severity of potential
hazards.
NOTE
A Note provides a tip, guidance, or advice, emphasizes important information, or provides a reference to related information.
ATTENTION
An Attention statement indicates a stronger note, for example, to alert you when trac might be interrupted or the device might
reboot.
CAUTION
A Caution statement alerts you to situations that can be potentially hazardous to you or cause damage to hardware,
rmware, software, or data.
DANGER
A Danger statement indicates conditions or situations that can be potentially lethal or extremely hazardous to you. Safety
labels are also attached directly to products to warn of these conditions or situations.
Text formatting conventions
Text formatting conventions such as boldface, italic, or Courier font may be used to highlight specic words or phrases.
Format Description
bold text Identies command names.
Identies keywords and operands.
Identies the names of GUI elements.
Identies text to enter in the GUI.
italic text Identies emphasis.
Identies variables.
Identies document titles.
ExtremeSwitching SLX 9540 Hardware Installation Guide
9036360-00 Rev AB 7

Format Description
Courier font Identies CLI output.
Identies command syntax examples.
Command syntax conventions
Bold and italic text identify command syntax components. Delimiters and operators dene groupings of parameters and their logical
relationships.
Convention Description
bold text Identies command names, keywords, and command options.
italic text Identies a variable.
[ ] Syntax components displayed within square brackets are optional.
Default responses to system prompts are enclosed in square brackets.
{ x | y | z } A choice of required parameters is enclosed in curly brackets separated by vertical bars. You must select
one of the options.
x | yA vertical bar separates mutually exclusive elements.
< > Nonprinting characters, for example, passwords, are enclosed in angle brackets.
... Repeat the previous element, for example, member[member...].
\ Indicates a “soft” line break in command examples. If a backslash separates two lines of a command
input, enter the entire command at the prompt without the backslash.
Documentation and Training
To nd Extreme Networks product guides, visit our documentation pages at:
Current Product Documentation www.extremenetworks.com/documentation/
Archived Documentation (for earlier versions and
legacy products)
www.extremenetworks.com/support/documentation-archives/
Release Notes www.extremenetworks.com/support/release-notes
Hardware/Software Compatibility Matrices https://www.extremenetworks.com/support/compatibility-matrices/
White papers, data sheets, case studies, and other
product resources
https://www.extremenetworks.com/resources/
Training
Extreme Networks oers product training courses, both online and in person, as well as specialized certications. For more information,
visit www.extremenetworks.com/education/.
Getting Help
If you require assistance, contact Extreme Networks using one of the following methods:
Documentation and Training
ExtremeSwitching SLX 9540 Hardware Installation Guide
8 9036360-00 Rev AB

Extreme Portal Search the GTAC (Global Technical Assistance Center) knowledge base, manage support cases and service
contracts, download software, and obtain product licensing, training, and certications.
The Hub A forum for Extreme Networks customers to connect with one another, answer questions, and share ideas and
feedback. This community is monitored by Extreme Networks employees, but is not intended to replace specic
guidance from GTAC.
Call GTAC For immediate support: 1-800-998-2408 (toll-free in U.S. and Canada) or [phone]. For the support
phone number in your country, visit: www.extremenetworks.com/support/contact
Before contacting Extreme Networks for technical support, have the following information ready:
• Your Extreme Networks service contract number and/or serial numbers for all involved Extreme Networks products
• A description of the failure
• A description of any action(s) already taken to resolve the problem
• A description of your network environment (such as layout, cable type, other relevant environmental information)
• Network load at the time of trouble (if known)
• The device history (for example, if you have returned the device before, or if this is a recurring problem)
• Any related RMA (Return Material Authorization) numbers
Subscribing to Service Notications
You can subscribe to email notications for product and software release announcements, Vulnerability Notices, and Service
Notications.
1. Go to www.extremenetworks.com/support/service-notication-form.
2. Complete the form with your information (all elds are required).
3. Select the products for which you would like to receive notications.
NOTE
You can modify your product selections or unsubscribe at any time.
4. Click Submit.
Providing Feedback to Us
Quality is our rst concern at Extreme Networks, and we have made every eort to ensure the accuracy and completeness of this
document. We are always striving to improve our documentation and help you work better, so we want to hear from you! We welcome all
feedback but especially want to know about:
• Content errors or confusing or conicting information.
• Ideas for improvements to our documentation so you can nd the information you need faster.
• Broken links or usability issues.
If you would like to provide feedback to the Extreme Networks Information Development team, you can do so in two ways:
• Use our short online feedback form at https://www.extremenetworks.com/documentation-feedback/.
• Email us at [e-mail].
Please provide the publication title, part number, and as much detail as possible, including the topic heading and page number if
applicable, as well as your suggestions for improvement.
Providing Feedback to Us
ExtremeSwitching SLX 9540 Hardware Installation Guide
9036360-00 Rev AB 9

ExtremeSwitching SLX 9540 Hardware Installation Guide
10 9036360-00 Rev AB

About this Document
• Supported hardware and software..............................................................................................................................................................11
• What is new in this document.......................................................................................................................................................................12
Supported hardware and software
The following table describes the ExtremeSwitching SLX 9540 Switch Models .
TABLE 1 SLX 9540 Switch Models
Part number Description Introduced OS Currently
supported
BR-SLX-9540-24S-AC-F SLX 9540-24S Switch AC with Front to Back airow.
Supports 24×10 GbE/1 GbE + 24×1 GbE ports.
SLX-OS 17r.1.00 Yes
BR-SLX-9540-24S-DC-F SLX 9540-24S Switch DC with Front to Back airow.
Supports 24×10 GbE/1 GbE + 24×1 GbE ports.
SLX-OS 17r.1.00 Yes
BR-SLX-9540-24S-AC-R SLX 9540-24S Switch AC with Back to Front airow.
Supports 24×10 GbE/1 GbE + 24×1 GbE ports.
SLX-OS 17r.1.00 Yes
BR-SLX-9540-24S-DC-R SLX 9540-24S Switch DC with Back to Front airow.
Supports 24×10 GbE/1 GbE + 24×1 GbE ports.
SLX-OS 17r.1.00 Yes
BR-SLX-9540-48S-AC-F SLX 9540-48S Switch AC with Front to Back airow.
Supports 48×10 GbE/1 GbE + 6×100 GbE/40 GbE
ports.
SLX-OS 17r.1.00 Yes
BR-SLX-9540-48S-DC-F SLX 9540-48S Switch DC with Front to Back airow.
Supports 48×10 GbE/1 GbE + 6×100 GbE/40 GbE
ports.
SLX-OS 17r.1.00 Yes
BR-SLX-9540-48S-AC-R SLX 9540-48S Switch AC with Back to Front airow.
Supports 48×10 GbE/1 GbE + 6×100 GbE/40 GbE
ports.
SLX-OS 17r.1.00 Yes
BR-SLX-9540-48S-DC-R SLX 9540-48S Switch DC with Back to Front airow.
Supports 48×10 GbE/1 GbE + 6×100 GbE/40 GbE
ports.
SLX-OS 17r.1.00 Yes
The following table describes the SLX 9540 Switch Upgrade Licenses.
TABLE 2 SLX 9540 Switch Upgrade Licenses
Part number Description Introduced OS Currently
supported
BR-SLX-9540-24S-COD-P Upgrade 24 x 1 GbE ports to 24×10 GbE/1 GbE ports.
(SLX 9540-24S)
SLX-OS 17r.1.00 Yes
BR-SLX-9540-2C-POD-P Ports on Demand to enable 2×100 GbE/40 GbE ports. (SLX
9540-24S)
SLX-OS 17r.1.00 Yes
BR-SLX-9540-ADV-LIC-P Advanced Feature License for MPLS, BGP-EVPN, CE2.0,
NSX (SLX 9540-24S, SLX 9540-48S)
SLX-OS 17r.1.00 Yes
The following table list the SLX 9540 Switch supported power supplies FRU.
ExtremeSwitching SLX 9540 Hardware Installation Guide
9036360-00 Rev AB 11

TABLE 3 Supported SLX 9540 Switch Power Supplies
Part number Description Introduced OS Currently
supported
XBR-ACPWR-650-F SLX FIXED AC 650W POWER SUPPLY F2B AIRFL SLX-OS 17r.1.00 Yes
XBR-ACPWR-650-R SLX FIXED AC 650W POWER SUPPLY B2F AIRFL SLX-OS 17r.1.00 Yes
XBR-DCPWR-650-F SLX FIXED DC 650W POWER SUPPLY F2B AIRFL SLX-OS 17r.1.00 Yes
XBR-DCPWR-650-R SLX FIXED DC 650W POWER SUPPLY B2F AIRFL SLX-OS 17r.1.00 Yes
The following table list the SLX 9540 Switch supported Fan assemblies.
TABLE 4 Supported SLX 9540 Switch Fan Assemblies
Part number Description Introduced OS Currently
supported
XBR-3250CFM-FAN-F SLX FIXED FAN AC F2B AIRFLOW SLX-OS 17r.1.00 Yes
XBR-3250CFM-FAN-R SLX FIXED FAN AC B2F AIRFLOW SLX-OS 17r.1.00 Yes
The following table list the SLX 9540 Switch supported Rack Mount Kits.
NOTE
XEN-R000296 and XEN-R000294 can also be used with SLX xed, however, the box includes XBR-R000297 at
shipment.
TABLE 5 Supported SLX 9540 Switch Rack Mount Kits
Part number Description
XEN-R000294 Universal two-post mid-mount or ush-mount rack kit
XEN-R000296 Universal four-post xed rack mount kit
XBR-R000297 SLX Fixed rack mount kit
What is new in this document
This is a new document.
What is new in this document
ExtremeSwitching SLX 9540 Hardware Installation Guide
12 9036360-00 Rev AB

Device Overview
• Hardware features..............................................................................................................................................................................................13
• Port-side view of the SLX 9540 Switch ................................................................................................................................................ 15
• Nonport-side view of the SLX 9540 Switch ........................................................................................................................................15
• Device management options........................................................................................................................................................................16
Hardware features
TABLE 6 ExtremeSwitching SLX 9540 Features
SLX 9540 Switch Features Description
Maximum 100 GbE/40 GbE ports 6
Maximum 10 GbE/1 GbE ports 48
Switch fabric capacity 1.08 Tbps
Forwarding capacity 720 Mpps
Airow Front to back or back to front (orderable option)
Fan module slots 6, shipped with 5 Fan FRUs (4+1 redundancy)
Maximum AC power supply rating 650 W
Power supply module slots 2 (1+1 redundancy)
Height 1.72 in/4.37 cm/1 RU
Width 17.32 in/44.00 cm
Depth chassis only without cable management or fan
handles
17.51 in/44.47 cm
Weight chassis only 19.84 lb/9.00 kg
The following illustration shows the front view of the SLX 9540 Switch .
ExtremeSwitching SLX 9540 Hardware Installation Guide
9036360-00 Rev AB 13

FIGURE 1 SLX 9540 Switch front view
The following illustration shows the front view of the SLX 9540 Switch .
FIGURE 2 SLX 9540 Switch rear view with power supply and fan assemblies
For more device details, refer to ExtremeSwitching SLX 9540 Technical Specications on page 91.
Hardware features
ExtremeSwitching SLX 9540 Hardware Installation Guide
14 9036360-00 Rev AB

Port-side view of the SLX 9540 Switch
The following illustration shows the port-side view of the SLX 9540 Switch.
FIGURE 3 Port-side view of the SLX 9540 Switch
1. 10/100/1000Base-T RJ-45 management Ethernet port
2. SFP ports 1-48
3. QSFP28 ports 49-54
4. RS-232 port
5. USB port
The following illustration shows magnied view of the port-side of the SLX 9540 Switch showing the LEDs
FIGURE 4 Port-side view of the SLX 9540 Switch
1. Management port link LED
2. Management port speed LED
3. Upper LEDs 0-3 for QSFP ports 49, 51, 53
4. Lower LEDs 0-3 for QSFP ports 50, 52, 54
5. SFP Port LEDs for ports 1-48
6. Status LED
7. Power LED
Nonport-side view of the SLX 9540 Switch
The following illustration shows the rear-view or nonport-side of the SLX 9540 Switch.
Nonport-side view of the SLX 9540 Switch
ExtremeSwitching SLX 9540 Hardware Installation Guide
9036360-00 Rev AB 15

FIGURE 5 Nonport-side view
1. Power supply unit 1
2. Fans 1-5
3. Fan 6 (empty slot)
4. Power supply unit 2
Device management options
You can use the management functions built into the device to monitor the port status, physical status, and other information to help you
analyze device performance and to accelerate system debugging. The device automatically performs a power-on self-test (POST) each
time it is turned on.
You can manage the device using any of the management options listed in the following table.
TABLE 7 Management options for the device
Management tool Out-of-band support In-band support Reference documents
Command line interface (CLI) Ethernet or serial connection N/A ExtremeSwitching SLX-OS Management
Conguration Guide
REST or NETCONF/YANG APIs. Ethernet connection Yes ExtremeSwitching SLX-OS Management
Conguration Guide
Standard SNMP applications Ethernet or serial connection N/A ExtremeSwitching SLX-OS Management
Conguration Guide
Device management options
ExtremeSwitching SLX 9540 Hardware Installation Guide
16 9036360-00 Rev AB

Preparing for the Installation
• Safety precautions.............................................................................................................................................................................................17
• Facility requirements.........................................................................................................................................................................................19
• Quick installation checklist.............................................................................................................................................................................21
• Shipping carton contents................................................................................................................................................................................22
Safety precautions
When using this product, observe all danger, caution, and attention notices in this manual. The safety notices are accompanied by
symbols that represent the severity of the safety condition
When using this product, observe all danger, caution, and attention notices in this manual. The safety notices are accompanied by
symbols that represent the severity of the safety condition.
Refer to Cautions and Danger Notices at the end of this guide for translations of safety notices for this product.
General precautions
DANGER
The procedures in this manual are for qualied service personnel.
DANGER
Before beginning the installation, see the precautions in “Power precautions.”
DANGER
Be careful not to accidently insert your ngers into the fan tray while removing it from the chassis. The fan may still be
spinning at a high speed.
CAUTION
Changes or modications made to this device that are not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
CAUTION
Disassembling any part of the power supply and fan assembly voids the warranty and regulatory certications. There are no
user-serviceable parts inside the power supply and fan assembly.
CAUTION
Make sure the airow around the front, and back of the device is not
restricted.
CAUTION
Ensure that the airow direction of the power supply unit matches that of the installed fan tray. The power supplies and fan
trays are clearly labeled with either a green arrow with an "E", or an orange arrow with an "I."
CAUTION
To protect the serial port from damage, keep the cover on the port when not in use.
ExtremeSwitching SLX 9540 Hardware Installation Guide
9036360-00 Rev AB 17

CAUTION
Never leave tools inside the chassis.
CAUTION
If you do not install a module or a power supply in a slot, you must keep the slot ller panel in place. If you run the chassis
with an uncovered slot, the system will overheat.
CAUTION
Use the screws specied in the procedure. Using longer screws can damage the
device.
CAUTION
Do not install the device in an environment where the operating ambient temperature might exceed 50°C (122°F).
DANGER
Batteries used for RTC/NVRAM backup are not located in operator-access areas. There is a risk of explosion if a battery
is replace by an incorrect type. Dispose of used components with batteries according to local ordinance and regulations.
ESD precautions
DANGER
For safety reasons, the ESD wrist strap should contain a series 1 megaohm resistor.
CAUTION
Static electricity can damage the chassis and other electronic devices. To avoid damage, keep static-sensitive devices in
their static-protective packages until you are ready to install them.
CAUTION
Before plugging a cable into any port, be sure to discharge the voltage stored on the cable by touching the electrical
contacts to ground surface.
Power precautions
DANGER
If the installation requires a dierent power cord than the one supplied with the device, make sure you use a power cord
displaying the mark of the safety agency that denes the regulations for power cords in your country. The mark is your
assurance that the power cord can be used safely with the device.
DANGER
Disconnect the power cord from all power sources to completely remove power from the device.
DANGER
This device might have more than one power cord. To reduce the risk of electric shock, disconnect all power cords before
servicing.
DANGER
To avoid high voltage shock, do not open the device while the power is on.
Safety precautions
ExtremeSwitching SLX 9540 Hardware Installation Guide
18 9036360-00 Rev AB

CAUTION
Use a separate branch circuit for each power cord, which provides redundancy in case one of the circuits fails.
CAUTION
Ensure that the device does not overload the power circuits, wiring, and over-current protection. To determine the
possibility of overloading the supply circuits, add the ampere (amp) ratings of all devices installed on the same circuit as the
device. Compare this total with the rating limit for the circuit. The maximum ampere ratings are usually printed on the
devices near the input power connectors.
Lifting precautions
DANGER
Use safe lifting practices when moving the product.
DANGER
Mount the devices you install in a rack as low as possible. Place the heaviest device at the bottom and progressively place
lighter devices above.
DANGER
Make sure the rack housing the device is adequately secured to prevent it from becoming unstable or falling over.
CAUTION
To prevent damage to the chassis and components, never attempt to lift the chassis using the fan or power supply handles.
These handles were not designed to support the weight of the chassis.
Laser precautions
DANGER
All ber-optic interfaces use Class 1 lasers.
DANGER
Laser Radiation. Do Not View Directly with Optical Instruments. Class 1M Laser Products.
DANGER
Use only optical transceivers that are qualied by Extreme Networks, Inc. and comply with the FDA Class 1 radiation
performance requirements dened in 21 CFR Subchapter I, and with IEC 60825 and EN60825. Optical products that do
not comply with these standards might emit light that is hazardous to the eyes.
Facility requirements
To install and operate the device successfully, ensure compliance with the following facility requirements.
Electrical considerations
For successful installation and operation of the device, ensure that the following electrical requirements are met:
• The primary outlet is correctly wired, protected by a circuit breaker, and grounded in accordance with local electrical codes.
Facility requirements
ExtremeSwitching SLX 9540 Hardware Installation Guide
9036360-00 Rev AB 19

• The supply circuit, line fusing, and wire size are adequate, as specied by the electrical rating on the device nameplate.
• The power supply standards are met.
Environmental considerations
For successful installation and operation of the device, ensure that the following environmental requirements are met:
• Because the SLX 9540 Switch can be ordered with fans that move air either front to back or back to front, be sure to orient
your switch with the airow pattern of any other devices in the rack. All equipment in the rack should force air in the same
direction to avoid intake of exhaust air.
• Some combinations of intake and exhaust airow may not be compatible with your environment. Consult your fan assembly
and power supply FRU kits to determine the correct conguration.
• The ambient air temperature does not exceed 50°C (122°F) while the switch is operating with front-to-back airow, or 45°C
(113°F) while the switch is operating with back-to-front airow.
Location considerations
Before installing the device, plan its location and orientation relative to other devices and equipment. Devices can be mounted in a
standard 19-inch equipment rack or on a at horizontal surface.
The site should meet the following requirements:
• Maintain the operating environment as specied in “Environmental considerations” ExtremeSwitching SLX 9540 Technical
Specications on page 91.
• For installation on a at horizontal surface, the SLX 9540 Switch should be installed with its top and bottom covers parallel to
the oor. The SLX 9540 Switch should not be installed upside down.
• Allow a minimum of 3 in. of space between the front and the back of the device and walls or other obstructions for proper
airow.
• Allow at least 3 in. of space at the front and back of the device for the twisted-pair, ber-optic, and power cabling.
• Allow access space for installing, cabling, and maintaining the devices.
• Ensure the status LEDs are clearly visible.
• Allow for twisted-pair cables to be routed away from power lines, uorescent lighting xtures, and other sources of electrical
interference, such as radios and transmitters.
• Allow for the unit to be connected to a separate grounded power outlet that provides 100 to 240 VAC, 50 to 60 Hz, is within 2
m (6.6 ft) of each device, and is powered from an independent circuit breaker. As with any equipment, a lter or surge
suppressor is recommended.
Cable management recommendations
Cables can be organized and managed in a variety of ways; for example, use cable channels on the sides of the rack or patch panels to
reduce the potential for tangling the cables. The following list provides some recommendations for cable management:
NOTE
Before plugging a cable to any port, be sure to discharge any static charge stored on the cable by touching the electrical
contacts to ground surface.
• You should not use tie wraps with ber-optic cables because they are easily overtightened and can damage the optical bers.
Velcro-like wraps are recommended.
Facility requirements
ExtremeSwitching SLX 9540 Hardware Installation Guide
20 9036360-00 Rev AB
