PVT HD RGB • Installation Guide
The Extron®PVT HD RGB is a
2-gang AV wallplate for PoleVault®, PlenumVault®, and
WallVault®Systems that support the PVS 407D switcher.
It passes HDMI/DVI, high-resolution computer video, and
analog stereo audio signals to a PoleVault digital switcher
up to 150 feet away over shielded twisted pair (XTP DTP 24)
cable.
The PVT has one HDMI connector and an audio input jack
on the left front panel, and on the right front panel it has one
audio input jack and one 15-pin HD VGA connector for RGB
input signals.
NOTE: This device is compatible only with the PVS 407D, running rmware version
4.00 or above. It is not compatible with the PVS 405D or other XTP/DTP devices.
VGA IN
HDMI IN
AUDIO IN
AUDIO IN
Installation
ATTENTION:
• Installation and service must be performed by authorized personnel.
• L’installation et l’entretien doivent être effectuéspar le personnel autorisé
uniquement.
• The unit must be installed in accordance with the National Electrical Code and with
local electrical and safety codes.
• L’unité doit être installée conformément au National Electric Code.
NOTES:
• Install the wallplate directly into the wall using the supplied mud ring or a UL
Listed 2-gang junction box (not supplied) such as a RACO 232, following the
steps below.
• If installing a junction box, allow enough depth for the wallplate and cables. Take
into consideration the bend radius of the cable, providing suitable strain relief
and maintaining the cable bend. Do not bend the cables 90 degrees.
• Conduits and conduit adapters should be used.
• Use a wall box with a depth of at least 3.0 inches (7.6 cm). Alternatively, the
included mud ring (MR 200) can be used.
1. Using the mud ring or a junction box
as a guide, mark the edges and cut out
the material within the marked area of
the mounting location.
2. Either:
• Insert the mud ring into the opening,
rotate the locking arms, and secure it
with the supplied screws,
or
• Insert the wall box and secure it with
nails or screws.
VGA IN
HDMI IN
AUDIO IN AUDIO IN
Faceplate
Wall
Mud Ring
Extron®
PVT HD RGB
STP cable
from PoleVault®Switcher

PVT HD RGB • Installation Guide (Continued)
68-3182-01
Rev A
11 17
© 2017 Extron Electronics, All Rights Reserved. All trademarks mentioned are the property of their respective owners.
www.extron.com
3. Run the XTP DTP 24 cable from the PoleVault
switcher location, going behind the wall and to the
PVT location, then thread the cables through the mud
ring or wall box.
Provide strain relief and maintain optimum cable bend
radius (see Notes on rst page)..
NOTES:
• Extron highly recommends shielded twisted
pair (STP) cabling with shielded RJ-45 plugs.
• The XTP DTP 24 cables supplied are
terminated to TIA 568B standard.
4. Plug the XTP DTP 24 cable from the PoleVault switcher into the RJ-45 connector
labeled PVT Out on the rear of the wallplate
NOTE: The two LEDs (Signal and Link) located between
the left and right front panels, mirror the Signal and
Link LEDs on the rear panel RJ-45 connector (see
image at right). These are useful for troubleshooting
the device without removing it from the wall.
5. Mount the PVT wallplate into the mud ring or wall box
and attach the supplied decorator-style faceplate.
6. Connect an HDMI source to the front panel HDMI input connector.
7. Connect an RGB high resolution source device to the front panel VGA IN
connector.
8. Connect an audio source to the audio input tip-ring-
sleeve jack. Wire the plug as shown at right.
NOTE: To complete system installation, see the Digital PoleVault System Installation Guide
(featuring the PVS 407D switcher), available online at www.extron.com.
5
Pin
1
2
3
6
7
8
4
Wire Color
568B
White-green
Green
White-orange
White-blue
Orange
White-brown
Brown
Blue
12345678
RJ-45
Connector
Insert Twisted
Pair Wires
Pins:
SIGNAL
SERVICE
MI IN
DIO IN
LINK
AUDI
VGA
Sleeve (Gnd)
Ring (R)
Tip (L)
3.5 mm Stereo Plug
(unbalanced)
