Extron electronics RGB 138xi User manual

User’s Guide
Extron Electronics, USA
1230 South Lewis Street
Anaheim, CA 92805
USA
714.491.1500
Fax [phone]
Extron Electronics, Europe
Beeldschermweg 6C
3821 AH Amersfoort
The Netherlands
+31.33.453.4040
Fax [phone]
Extron Electronics, Asia
135 Joo Seng Road, #04-01
PM Industrial Building
Singapore 368363
+65.6383.4400
Fax [phone]
Extron Electronics, Japan
Daisan DMJ Building 6F
3-9-1 Kudan Minami
Chiyoda-ku, Tokyo 102-0074 Japan
+81.3.3511.7655
Fax [phone]
www.extron.com
© 2001 Extron Electronics. All rights reserved.
Active Audio AAP Installation Kit
68-640-01 Rev. A
Printed in the USA
12 01
RGB 138
xixi
xixi
xi and 168
xixi
xixi
xi
5Route the audio cables through the rear cable clamp
openings of the interface, as shown below.
Connect powered speakers or another audio device to the
included captive screw connectors. Insert the audio device
wires into the captive screw connector and tighten the
captive screws to fasten the wires, then insert the wired
audio connector into the audio output connector of the
Active Audio AAP plate before installing the AAP plate into
the interface.
Connect the sleeve to ground (GND).
Connecting the sleeve to a negative (-)
terminal will damage the audio output circuits.
6Install the Active Audio AAP adapter into the interface using
the four nuts and replace the interface’s top cover. Mount
the interface in a rack or furniture and connect the power
cords and turn on the devices in the following order: display
and audio output devices, the interface, and input device
(computer).
Unbalanced Output
Tip
See Warning
Sleeve (s)
Tip
See Warning
Balanced Output
Tip
Ring
Sleeve (s)
Tip
Ring
HIGHVOLTAGE
CAUTION
RGB 138 xi
INPUTS
AUDIOANALOG
UNSWITCHED
600WATTS MAX.
MIN/MAX
MBC
POWER
UNIVERSALINTERFACEW/ADSP
Cable Routing
Audio cables are routed through
the rear cable clamp openings
Active Audio AAP Kit Part number
Active Audio Buffering Unbalanced to
Balanced Stereo Audio Kit 70-110-04

RGB 138xixi
xixi
xi and 168xixi
xixi
xi Active Audio AAP • InstallationRGB 138xixi
xixi
xi and 168xixi
xixi
xi Active Audio AAP • Installation
Installation
32
Extron’s Active Audio Buffering Unbalanced to Balanced Stereo
Audio AAP Installation kit (part #70-110-04) offers Active Audio
AAP connections for Extron’s RGB 138xi and RGB 168xi universal
analog interfaces.
Active Audio AAP Installation Kit Instructions
These instructions refer to both the RGB 138xi and the RGB 168xi
models.
To install the Active Audio AAP Installation kit, refer to the steps
below, the RGB 138xi, RGB 168xi User’s Manual, and the Active
Audio AAP label wiring instructions.
1Disconnect the power from the interface, remove the
interface from its rack mount or furniture mount position,
and remove the top cover.
2Remove the blank AAP plate(s) from the interface to
accommodate the double-space Active Audio AAP plate.
RGB138xi
INPUTS
AUDIO ANALOG
UNSWITCHED
600WATTSMAX.
MIN/MAX
MBC
POWER
UNIVERSALINTERFACE W /ADSP
Remove #8 Screws
(4 Places) Each Side
and Bracket, if Present
Remove (12)
Screws
Lift Cover
Straight Up
Active Audio AAP power cable
connected to AAP power connector
Active Audio
outputs
The Active Audio AAP plate’s power and audio connections
must be wired before mounting the AAP plate in the
interface. Both the provided Active Audio AAP power cable
and the included captive screw audio connectors are keyed
to prevent incorrect connections.
3Route the Active Audio power cable under the interface’s
power cable.
4Connect the interface end of the power cable to the power
connector on the interface’s main board. The connectors are
keyed to prevent an incorrect connection.
Route the Active Audio AAP power cable
under the interface's power supply cable
Connect this power connector to the
interface's power connector
Connect the Active Audio AAP power cable
to the interface's power connector
