Specifications
In-Circuit Power Adapter
68-739-01 Rev. B
Printed in the USA
09 03
IPA T IPA
Data rate ........................................ 10/100Base-T, half/full duplex with
autodetect
Power
Input .................................. 100VAC to 240VAC, 50/60 Hz, 15 watts,
external, autoswitchable; to 48VDC, 0.3 A
power supply
Output ............................... IEEE 802.3af compliant
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /
10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, non-condensing
Rack mount .................................. Yes, with optional 1U rack shelf, part
#60-190-01, or the VersaTools rack shelf,
part #60-190-20;
also under-furniture mountable with
optional brackets #70-212-01
or projector mountable with optional
brackets #70-217-01/70-077-04
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.7" H x 2.2" W x 3.0" D (1U high, one-
eighth rack width)
4.3 cm H x 5.6 cm W x 7.6 cm D
(Depth excludes connectors.)
Product weight ............................. 0.5 lbs (0.2 kg)
Shipping weight ........................... 1 lbs (1 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International
Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. FCC Class A
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
Included Parts
Part Description Part Number
IPA T IPA In-Circuit Power Adapter 60-545-01
User’s guide

IPA T IPA • InstallationIPA T IPA • Installation
Installation
32
The Extron IPA T IPA In-Circuit Power Adapter (IPA) is an IPL™
Accessory product in the IP Tools series. Power for network
devices is not always available or nearby. The IPA supplies Power
over Ethernet (PoE) and is IEEE 802.3af compliant. PoE allows
power to be supplied to network devices using the existing
Ethernet cable. The IPA has the added flexibility of being able to
first detect whether a device on the network has PoE capability
before supplying power. This detection feature prevents damage to
network devices that are not compliant with the current IEEE
802.3af standard for PoE.
LANIN
10/100Mps
ETHERNETONLY
POWEREDLAN
OUT
PWR
NOTE:
COM1
LAN
UID#093012052
POWER
12V
.5AMAX
COM1
TXRXTXRX
COM2
COM2
LAN
POWER
12V
.5AMAX
LANLANLANLAN
Extron
IPL T S2
Ethernet Control
Interface
Extron
IPA T IPA
In-Circuit Power
Adapter
Ethernet Switch
Powered
LAN Out
LAN/WAN
Network/
Internet
Projector
RS-232
Extron
48V Power Supply
External
Power Supply
Example IPA T IPA Application
Front and Rear Panels Features
IPAT IPA
LAN IN
10/100Mbps
ETHERNET ONLY
POWERED LAN
OUT
PWR
NOTE:
1
Front Panel
2 3 4
Rear Panel
1
Power indicator — The LED lights green when power is
input to the IPA T IPA.
2
LAN input — This female RJ-45 connector links the In-
Circuit Power Adapter either directly to the Ethernet LAN
or through a network switcher, hub, or router. Use a
straight-through cable when connecting to a switcher, hub,
or router.
3
Power over Ethernet indicator — The LED lights green if
the connected network device is IEEE 802.3af compliant.
If +12VDC is already being supplied to the IPL T device,
the IPA T IPA’s powered LAN output port will not supply
power until the +12VDC is removed. Under this
condition, if the +12VDC is removed while the PoE
connection is present, the IPL T device will power off and
then back on causing a complete restart of all running
scripts. The green LED will light, indicating power is
being sent from the IPA T IPA to the IPL T device.
4
LAN output — This female RJ-45 connector links to the
network device, and the IPA determines if the network
device is able to accept PoE. If it is PoE capable, the
supplied power will be IEEE 802.3af compatible.
Mounting Options
VersaTools
Rack Shelf
Quarter Rack Width
False Front Face Plate
(2) 4-40 x 3/16"
Screws
Eighth Rack Width
False Front Face Plate
IPATIPAIPATIPAIPATIPAIPATIPA
IPATIPA
Mounting in a
VersaTools
Rack Shelf
IPAT IPA
Mounting Under a
Desk orTabletop
Specifications
General
Connectors ................................... 1 RJ-45 female connector for pass-through
input
1 RJ-45 female connector for power and
pass-through output
