AV RCA
RCA Male to Male Composite Video and Stereo Audio Cables
Former Model Name: IN8906, IN8920
DesCrIPtIoN
The AV RCA Cables are deluxe interconnect cables for composite video and stereo audio. The
thicker conductor is a 75 ohm 20 AWG coax cable specially designed to carry a composite
video signal. The two thinner conductors are designed to carry stereo audio line level signals.
These cables are terminated on each end with three high quality RCA male connectors, which
are color coded yellow, red, and white.
HDTV RCA
RCA Male to Male HDTV/Component Video Cable
Former Model Name: IN9720
DesCrIPtIoN
Component video cable, three RCA male to three RCA male.
RCA Audio Cables
RCA Male to Male Stereo Audio Cables
Former Model Name: IN8706, IN8710, IN8725
DesCrIPtIoN
The RCA Audio Cables are designed to interconnect line level audio signals between A/V
equipment inputs and outputs. These cables feature separate conductors to carry the left and
right audio signals and are terminated on each end with red and white RCA male connectors.
Video, S-Video & Audio Cables (continued)
VIdeo, s-VIdeo & audIo Cables
MoDel VersIoN DesCrIPtIoN Part #
AV RCA/6 6' (1.8 m).................................................................................................. 26-643-06
AV RCA/20 20' (6.0 m) ................................................................................................ 26-643-20
MoDel VersIoN DesCrIPtIoN Part #
HDTV RCA/6 6' (1.8 m).................................................................................................. 26-645-06
MoDel VersIoN DesCrIPtIoN Part #
A RCA/6 6' (1.8 m).................................................................................................. 26-641-06
A RCA/10 10' (3.0 m) ................................................................................................ 26-641-10
A RCA/25 25' (7.6 m) ................................................................................................ 26-641-25
