Extron electronics Digital Video Scalers DVS 204 Series User manual

Specifications — DVS 204 Series Digital Video Scalers
Video input
Number/signal type .................. 1 (RGBHV, RGBS, RGsB) pass-through, RGBS, RGBcvS
1 composite video, S-video, component video (Y, R-Y, B-Y)
1 S-video, 1 SDI (optional, DVS 204D only)
1 composite video
Connectors ................................... (1) 15-pin HD female .............. RGB pass-through, RGBS, RGBcvS
3 BNC female .......................... component video, S-video, composite video
1 BNC female .......................... SDI (DVS 204D, DVS 204D 12 V only)
(1) 4-pin mini DIN female ..... S-video
1 BNC female .......................... composite video
Nominal level............................... 1 Vp-p for Y of component video and S-video, and for composite video
0.7 Vp-p for RGB and for R-Y and B-Y of component video
0.3 Vp-p for C of S-video
Minimum/maximum levels ..... Analog: 0.0 V to 1.0 Vp-p with no offset
Impedance ................................... 75 ohms
Horizontal frequency .................. NTSC 3.58, NTSC 4.43, PAL, SECAM
Vertical frequency ....................... NTSC 3.58, NTSC 4.43, PAL, SECAM
Resolution range .......................... NTSC 3.58, NTSC 4.43, PAL, SECAM
Return loss .................................... <-25 dB @ 5 MHz
DC offset (max. allowable) ......... 1.5 V
Video processing
Decoder ......................................... 9 bit digital
Digital sampling .......................... 24 bit, 8 bits per color; 13.5 MHz standard
Colors ............................................ 16.78 million
Video output
Number/signal type .................. 1 scaled or pass-through RGBHV, RGBS, RGsB;
or scaled component video (Y, R-Y, B-Y)
Connectors ................................... 6 female BNC
1 female 15-pin HD
Nominal level............................... 1 Vp-p for Y of component video
0.7 Vp-p for RGB and for R-Y and B-Y of component video
Minimum/maximum levels ..... 0.0 V to 0.7 Vp-p
Impedance .................................... 75 ohms
Scaled resolutions ........................ 640x4801,3,4,5,6, 800x6001,3,4,5,6, 848x4801,3,4,5,6, 852x4801,3,4,5,6, 1024x7681,3,4,5,6, 1280x7682,5,6,
1280x10241,3,4,5,6, 1360x7651,3,4,5,6, 1365x10241,3,4,5,6, 1400x10501,3,4,5,6, HDTV 480p3,5,
576p1,5, 720p3,5, 1080p3,5, and 1080i1,3,5
1= at 50 Hz 2= at 56 Hz 3= at 60 Hz 4= at 75 Hz
5 = locked to the current input’s vertical refresh rate (Accu-RATE Frame Lock)
6= True Rate
Sync
Input type ..................................... (RGBHV, RGBS, RGsB) pass-through, RGBS, RGBcvS
Output type .................................. RGBHV, RGBS, RGsB
Standards ...................................... NTSC 3.58, NTSC 4.43, PAL, SECAM
Input level ..................................... 0 V to 1.0 Vp-p
Output level.................................. TTL: 5.0 Vp-p, unterminated
Input impedance.......................... 75 ohms
Output impedance ...................... 75 ohms
Max input voltage ....................... 5 Vp-p
Max. propagation delay.............. 20 ns
Polarity .......................................... Positive or negative (switch-selectable)
1-2 DVS 204, DVS 204D, DVS 20412V, DVS 204D 12V • Specifications

Control/remote — decoder/scaler
Serial control port ........................ RS-232, 9-pin female D connector
Baud rate and protocol ............... 9600 baud, 8 data bits, 1 stop bit, no parity
Serial control pin configurations 1 = input 1 select
2 = TX
3 = RX
4 = input 2 select
5 = GND
6 = input 3 select
7 = input 4 select
8 = n/a
9 = hardwired IR
Contact closure ............................ 9-pin female D connector (same as RS-232 connector)
Contact closure pin configurations See pins 1, 4, 6, and 7 above.
IR controller module ................... Extron IR 901 (optional)
Program control ........................... Extron’s control/configuration program for Windows®
Extron’s Simple Instruction Set (SIS™)
General
Power
DVS 204, DVS 204D ......... 100 VAC to 240 VAC, 50/60 Hz, 30 watts, internal, autoswitchable
DVS 204/204D 12VDC
External power supply 100 VAC to 240 VAC, 50/60 Hz, 36 watts, external, autoswitchable; to 12 VDC,
3 A, regulated
Power input requirements
12 VDC, 2 A.
Temperature/humidity
All models......................... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
DVS 204, DVS 204D ......... Operating: +32 to +113 °F (0 to +45 °C) / 10% to 90%, noncondensing
DVS 204/204D 12VDC.... Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Rack mount ................................... Yes, with optional rack shelf, part #60-190-01
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.75" H x 8.75" W x 9.5" D (1U high, half rack wide)
4.4 cm H x 22.2 cm W x 24.1 cm D
(Depth excludes connectors and knobs. Width excludes rack ears.)
Product weight ............................. 3.3 lbs (1.5 kg)
Shipping weight ........................... 6 lbs (3 kg)
Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
All nominal levels are at ±10%.
Specifications are subject to change without notice.
(7.51-020705-D9)
DVS 204, DVS 204D, DVS 20412V, DVS 204D 12V • Specifications 1-3
