User Guide
DSC 401 and
DSC 401 A
Scalers
4K/60 HDMI to HDMI Scalers
68-3539-01 Rev. A
04 21


Copyright
© 2021 Extron. All rights reserved. www.extron.com
Trademarks
All trademarks mentioned in this guide are the properties of their respective owners.
The following registered trademarks (®), registered service marks (SM), and trademarks (TM) are the property of RGBSystems, Inc. or Extron (see the
current list of trademarks on the Terms of Use page at www.extron.com):
Registered Trademarks (®)
Extron, Cable Cubby, ControlScript, CrossPoint, DTP, eBUS, EDID Manager, EDID Minder, eLink, Flat Field, FlexOS, Glitch Free, GlobalConfigurator,
GlobalScripter, GlobalViewer, Hideaway, HyperLane, IPIntercom, IPLink, KeyMinder, LinkLicense, LockIt, MediaLink, MediaPort, NAV,
NetPA, PlenumVault, PoleVault, PowerCage, PURE3, Quantum, ShareLink, Show Me, SoundField, SpeedMount, SpeedSwitch, StudioStation,
SystemINTEGRATOR, TeamWork, TouchLink, V-Lock, VideoLounge, VN-Matrix, VoiceLift, WallVault, WindoWall, XPA, XTP, XTPSystems, and ZipClip
Registered Service Mark(SM) : S3 Service Support Solutions
Trademarks (™)
AAP, AFL (Accu-RATEFrameLock), ADSP(Advanced Digital Sync Processing), AVEdge, CableCover, CDRS(ClassD Ripple Suppression),
CodecConnect, DDSP(Digital Display Sync Processing), DMI (DynamicMotionInterpolation), DriverConfigurator, DSPConfigurator, DSVP(Digital
Sync Validation Processing), EQIP, Everlast, FastBite, Flex55, FOX, FOXBOX, IP Intercom HelpDesk, MAAP, MicroDigital, Opti-Torque,
PendantConnect, ProDSP, QS-FPC(QuickSwitch Front Panel Controller), RoomAgent, Scope-Trigger, SIS, SimpleInstructionSet, Skew-Free,
SpeedNav, Triple-Action Switching, True4K, True8K, Vector™ 4K, WebShare, XTRA, and ZipCaddy

FCC Class A Notice
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part15 of the FCC rules. The ClassA limits provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause interference. This interference must be corrected at the expense of the user.
NOTE: For more information on safety guidelines, regulatory compliances, EMI/EMF
compatibility, accessibility, and related topics, see the Extron Safety and Regulatory
Compliance Guide on the Extron website.
VCCI-A Notice

Conventions Used in this Guide
Notifications
The following notifications are used in this guide:
CAUTION: Risk of minor personal injury.
ATTENTION : Risque de blessuremineure.
ATTENTION:
• Risk of property damage.
• Risque de dommages matériels.
NOTE: A note draws attention to important information.
Software Commands
Commands are written in the fonts shown here:
^AR Merge Scene,,0p1 scene 1,1 ^B 51 ^W^C.0
[01]R000400300 0040000800 00600[02] 35[17] [03]
E X! *X1&*X2)*X2#*X2! CE}
NOTE: For commands and examples of computer or device responses used in this
guide, the character “0” is the number zero and “O” is the capital letter “o.”
Computer responses and directory paths that do not have variables are written in the font
shown here:
Reply from 208.132.180.48: bytes=32 times=2ms TTL=32
C:\Program Files\Extron
Variables are written in slanted form as shown here:
ping xxx.xxx.xxx.xxx —t
SOH R Data STX Command ETB ETX
Selectable items, such as menu names, menu options, buttons, tabs, and field names are
written in the font shown here:
From the File menu, select New.
Click the OK button.
Specifications Availability
Product specifications are available on the Extron website, www.extron.com.
Extron Glossary of Terms
A glossary of terms is available at http://www.extron.com/technology/glossary.aspx.

Contents
Introduction............................................................ 1
About this Guide................................................. 1
Features ............................................................. 2
DSC 401 A Only Features............................... 4
Application Diagrams.......................................... 5
Installation.............................................................. 6
Installation Overview ........................................... 6
Rear Panel Features ........................................... 7
Wiring the Power Supply .................................... 9
Securing the HDMI Connector Using the
LockIt Cable Lacing Bracket ........................... 11
Operation.............................................................. 12
Front Panel Features......................................... 12
Powering On .................................................... 13
On-screen Display (OSD) Menu ........................ 13
Menu Overview............................................. 13
Using the OSD Menu.................................... 14
Device Info Screen........................................ 16
Quick Setup Submenu.................................. 17
Picture Controls Submenu (DSC 401 A
Only)............................................................ 18
Input Submenu............................................. 20
Output Submenu.......................................... 23
Audio Submenu............................................ 27
Advanced Submenu ..................................... 29
Communications Submenu .......................... 31
Image Reset (DSC 401 A Only)......................... 32
Changing the Output Resolution and Refresh
Rate ................................................................ 33
Custom Rates .............................................. 33
Resetting the Output Rate ........................... 33
Power Save Mode ............................................ 34
Switching Transitions ........................................ 34
CEC Control (DSC 401 A Only)......................... 34
Presets............................................................. 35
Locking the Front Panel (Executive Mode) ........ 35
Resetting.......................................................... 36
Remote Configuration and Control................ 37
SIS Commands ................................................ 37
Connecting the DSC to the Host .................. 37
Initial Power Up Messages............................ 38
Password Messages .................................... 38
DSC-initiated Messages ............................... 39
Error Responses........................................... 39
Using the Command and Response Table .... 40
Symbol Definitions ........................................ 41
Command and Response Table for SIS
Commands ..................................................... 48
CEC Commands — DSC 401 A Only ............... 67
Symbol Definitions for CEC
Communications Commands ...................... 67
Product Configuration Software (PCS)
Program .......................................................... 70
Downloading PCS from the Website ............. 70
Starting the Configuration Program............... 72
Updating Firmware ........................................... 75
Internal Web Page.............................................. 76
Web Page Components ................................... 77
Device Info Panel .......................................... 78
Input Panel .................................................. 78
Roles and Permissions Panel........................ 78
Device Status Panel...................................... 79
Output Panel ............................................... 81
Network Settings Panel (DSC 401 A Only) .... 81
Firmware Panel............................................. 82
Reference Information ...................................... 84
Mounting the DSC............................................ 84
Downloading Firmware ..................................... 85
DSC 401 and 401 A User Guide • Contents vii

DSC 401 and 401 A User Guide • Contents viii

Introduction
This section provides an overview of the DSC 401 and DSC 401 A scalers, covering the
following topics:
• About this Guide
• About the DSC 401 and DSC 401 A
• Features
• Application Diagrams
About this Guide
The DSC 401 and DSC 401 A User Guide describes the Extron DSC HDMI-to-HDMI Digital
Scaling Converters and provides instructions for experienced installers to install, configure,
and operate them.
In this guide, the terms “scaler” and “DSC” are used interchangeably to refer to either of the
DSC 401 and 401 A models.
About the DSC 401 and DSC 401 A
The Extron DSC 401 and DSC 401 A are high-performance scalers capable of converting
between HDMI resolutions up to 4K @ 60 Hz with full 4:4:4 color sampling. They
support data rates up to 18 Gbps and incorporate the Extron-exclusive Vector™ 4K
scaling technology, which is engineered for critical-quality 4K applications. Both HDCP
2.3-compliant models support 4K @ 60 Hz signals on a single connection.
The scalers feature on-screen displays, internal test patterns, and status LEDs. The
DSC 401 A model also features audio embedding and de-embedding, logo image keying
and display, input presets, audio file playback, and Ethernet control with PoE. The DSC 401
and DSC 401 A scalers are ideal for locations such as conference rooms, auditoriums, or
anywhere high-quality 4K scaling of HDMI signals is required.
Both scalers feature front panel controls for quick access to functions. Additionally, LED
indicators on the front panel provide visual confirmation of video input signals, the presence
of HDCP encryption, reset levels, and power. Remote configuration is available via USB-C
on both models. The DSC 401 A can be configured or controlled externally over Ethernet.
Each scaler is housed in a compact, 1-inch, quarter-rack wide metal enclosure.
DSC 401 and DSC 401 A User Guide • Introduction 1

Features
• 4K @ 60 Hz HDMI to HDMI scaling — The DSC 401 and DSC 401 A scalers provide
high quality scaling of HDMI video resolutions and frame rates.
• Connectors —
• Input — One female HDMI Type A
• Audio Input (DSC 401 A only) — One 3.5 mm stereo mini jack
• Output — One female HDMI Type A
• Audio Output (DSC 401 A only) — One balanced and unbalanced stereo audio
on 5-pole captive screw
• Advanced Extron Vector 4K scaling engine — The Vector 4K scaling engine is
specifically designed for critical-quality 4K imagery, with best-in-class image upscaling
and downscaling.
• HDCP 2.3 compliant — Ensures display of content-protected media and
interoperability with other HDCP-compliant devices.
• Advanced 4:4:4 signal processing — 4:4:4 signal processing maintains color
accuracy and fine picture detail.
• Input resolutions — Accepts HDMI video from 480i up to 4096x2160 @ 4:4:4.
• Selectable output rates from 640x480 up to 4096x2160 @ 4:4:4.
• Supported HDMI specification features include data rates up to 18 Gbps, Deep
Color, and HD lossless audio formats
• Motion-adaptive deinterlacing — Advanced deinterlacing for all interlaced signals up
to 1080i delivers optimized image quality.
• Seamless transitions — Automatically applies a seamless fade or cut when a new
source is detected.
• Automatic 3:2 and 2:2 pulldown detection — Advanced film mode processing
techniques instantaneously detect and maximize image quality for NTSC, PAL, and
1080i sources that originated from film.
• User-selectable HDCP authorization — Allows the unit to appear HDCP compliant
or non-HDCP compliant to the connected source, which is beneficial if the source
automatically encrypts all content when connected to an HDCP-compliant device.
Protected material is not passed in non-HDCP mode.
• EDID Minder — EDID Minder ensures that the source powers up properly and reliably
outputs content for display. It manages EDID communication between connected
devices.
• Custom EDID and output resolutions — User-defined output resolutions up to
600 MHz pixel clock can be supported by uploading custom EDID files or capturing
EDID from a display or other destination device.
• Aspect ratio control — The aspect ratio of the video output can be controlled by
selecting a FILL mode, which provides a full-screen output, or a FOLLOW mode, which
preserves the original aspect ratio of the input signal.
• Scaler Bypass Mode — Allows scaling to be bypassed to support unprocessed
transmission of 3D, HDR, and other formats.
• HDCP authentication and signal presence confirmation — Provides real-time
verification of HDCP status for each digital video input and output. This allows for quick
and easy signal and HDCP verification through USB or Ethernet, providing feedback to
a system operator or helpdesk support staff.
DSC 401 and DSC 401 A User Guide • Introduction 2
