1-2 RGB 500 Series • Specifications
Specifications — RGB 500 Series Interfaces
Video
Gain ............................................... Unity (0.70V p-p), (0.725V p-p) 50% peaking, (0.75V p-p) 100% peaking
Bandwidth .................................... 300 MHz (-3dB)
Video input
Number/signal type ................... 1 analog RGBHV, RGBS, RGsB, RsGsBs
Connectors
RGB 500, RGB 500 Dual, RGB 508
1 9-pin D male, MBC/LBC cable or buffer
RGB 560, RGB 560 Dual, RGB 568, RGB 560 AKM
1 15-pin HD female
Minimum/maximum levels ...... Analog ....... 0.3V to 1.5V p-p with no offset
Impedance .................................... 75 ohms or High Z, switchable (set to 75 ohms if no local monitor is connected)
Horizontal frequency .................. Autoscan 15 kHz to 130 kHz
Vertical frequency ....................... Autoscan 30 Hz to 120 Hz
Return loss .................................... -30dB @ 5 MHz
Maximum DC offset .................... 4.0V
Video output
Number/signal type ................... 1 analog RGBHV, RGBS, RGsB
Connectors
All models......................... 5 BNC female
RGB 560, RGB 560 Dual, RGB 568, RGB 560 AKM
1 15-pin HD female for buffered local monitor output
Minimum/maximum levels ...... 0.70V to 0.75V p-p with no offset and 0.7V p-p input
Impedance .................................... 75 ohms
Return loss .................................... -30dB @ 5 MHz
Sync
Input type ..................................... RGBHV TTL (±), RGBS TTL (-), RGsB 0.3V (-), RsGsBs 1.3V (-)
Output type .................................. RGBHV (±), RGBS(-), RGsB (-)
Input level ..................................... 2V to 5.5V p-p with ±0.3VDC offset (max.)
Output level.................................. 4V to 5V p-p
Input impedance.......................... 10 kohms
Output impedance ...................... 75 ohms
Max. input voltage ...................... 5.7V p-p
Max. propagation delay.............. 48 nS
Max. rise/fall time ....................... 3.5 nS
Polarity
RGB 560 AKM .................... RGBHV...................... Polarity follows input when RGBHV is input and the sync
polarity switch is set to Off. Sync polarity is negative if the
sync polarity switch is set to On.
RGBS, RGsB .............. Negative
All other models ................ RGBHV ...................... Polarity follows input when RGBHV is input and the bottom
panel sync polarity jumper is set to follow (pin 1 jumpered to
pin 2). Sync polarity is negative if the sync polarity jumper is
set to negative (pin 2 jumpered to pin 3).
RGBS, RGsB .............. Negative
Audio
Gain ............................................... Unbalanced 0dB, balanced +6dB
Frequency response..................... 20 Hz to 20 kHz, ±0.05dB
THD + Noise ................................ 0.03% @1 kHz, 0.3% @ 20 kHz at rated maximum output drive
S/N ................................................ >90dB at rated maximum output (14dBm), balanced
Stereo channel separation .......... >95dB @ 1 kHz to 20 kHz

1-3RGB 500 Series • Specifications
Audio input
Number/signal type ................... 1 PC level stereo, unbalanced
Connectors .................................... 1 3.5 mm stereo jack, 2 channel; tip (L), ring (R), sleeve (ground)
Impedance .................................... 10 kohms, DC coupled
Maximum level ............................ +8.5dBu,(unbalanced) at stated %THD+N
Audio output
Number/signal type ................... 1 stereo (2 channel), balanced/unbalanced
Connectors .................................... 1 3.5 mm captive screw connector, 5 pole
Impedance .................................... 50 ohms unbalanced, 100 ohms balanced
Gain error ...................................... ±0.1dB channel to channel
Maximum level (600 ohm) ......... >+14dBm, balanced at stated %THD+N
General
Power............................................. 100VAC to 240VAC, 50/60 Hz, 5 watts, external, auto-switchable;
to 12 to 24VAC or VDC, 0.20 A power supply. Product requires 0.20 A (minimum).
(Order the power supply separately, part #70-055-01.)
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) / 10% to 90%, non-condensing
Rack mount ................................... No
Furniture mount .......................... Yes, or wall mount, with included hardware
Enclosure type .............................. Metal
Enclosure dimensions — RGB 500, RGB 560
Faceplate ........................... 4.5" H x 4.6" W x 0.1” D (2-gang)
(11.4 cm H x 11.7 cm W x 0.3 cm D)
Interface enclosure .......... 2.5" H x 3.7" W x 1.75" D
(6.4 cm H x 9.4 cm W x 4.4 cm D)
(Depth excludes connectors and knobs.)
Enclosure dimensions — RGB 500 Dual, RGB 508, RGB 560 Dual, RGB 568
Faceplate ........................... 4.5” H x 8.3” W x 0.1” D (4-gang)
(11.4 cm H x 21.1 cm W x 0.3 cm D)
Interface enclosure .......... 2.5" H x 3.7" W x 1.75" D
(6.4 cm H x 9.4 cm W x 4.4 cm D)
(Depth excludes connectors and knobs.)
Enclosure dimensions — RGB 560 AKM
Interface............................. 3.0" H x 8.2" W x 1.5" D
(7.62 cm H x 20.8 cm W x 3.8 cm D)
(Depth excludes connectors and knobs.)
Product weight
RGB 500, RGB 508, RGB 560 0.7 lbs (0.3 kg)
RGB 568, RGB 560 AKM . 0.9 lbs (0.4 kg)
Shipping weight ........................... RGB 500, RGB 560.... 2 lbs (0.9 kg)
All other models ...... 3 lbs (1.4 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International Safe Transit Association)
Listings .......................................... UL
Compliances ................................. RGB 560 AKM .......... CE
All other models ...... CE, FCC Class A
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
