Extron electronics Quantum Ultra Series User manual

User Guide
Quantum Ultra Series
Videowall Processors
Videowall Processing Systems
68-2760-01 Rev. H
01 22


Copyright
© 2017-2022 Extron. All rights reserved. www.extron.com
Trademarks
All trademarks mentioned in this guide are the properties of their respective owners.
The following registered trademarks (®), registered service marks (SM), and trademarks (TM) are the property of RGBSystems, Inc. or Extron (see the
current list of trademarks on the Terms of Use page at www.extron.com):
Registered Trademarks (®)
Extron, Cable Cubby, ControlScript, CrossPoint, DTP, eBUS, EDID Manager, EDID Minder, eLink, Flat Field, FlexOS, Glitch Free, GlobalConfigurator,
GlobalScripter, GlobalViewer, Hideaway, HyperLane, IPIntercom, IPLink, KeyMinder, LinkLicense, LockIt, MediaLink, MediaPort, NAV,
NetPA, PlenumVault, PoleVault, PowerCage, PURE3, Quantum, ShareLink, Show Me, SoundField, SpeedMount, SpeedSwitch, StudioStation,
SystemINTEGRATOR, TeamWork, TouchLink, V-Lock, VN-Matrix, VoiceLift, WallVault, WindoWall, XPA, XTP, XTPSystems, and ZipClip
Registered Service Mark(SM) : S3 Service Support Solutions
Trademarks (™)
AAP, AFL (Accu-RATEFrameLock), ADSP(Advanced Digital Sync Processing), AVEdge, CableCover, CDRS(ClassD Ripple Suppression),
CodecConnect, DDSP(Digital Display Sync Processing), DMI (DynamicMotionInterpolation), DriverConfigurator, DSPConfigurator, DSVP(Digital
Sync Validation Processing), EQIP, Everlast, FastBite, Flex55, FOX, FOXBOX, IP Intercom HelpDesk, MAAP, MicroDigital, Opti-Torque,
PendantConnect, ProDSP, QS-FPC(QuickSwitch Front Panel Controller), RoomAgent, Scope-Trigger, SIS, SimpleInstructionSet, Skew-Free,
SpeedNav, Triple-Action Switching, True4K, True8K, Vector™ 4K, WebShare, XTRA, and ZipCaddy

FCC Class A Notice
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part15 of the FCC rules. The ClassA limits provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause interference. This interference must be corrected at the expense of the user.
ATTENTION:
• The Twisted Pair Extension technology works with unshielded twisted pair (UTP)
or shielded twisted pair (STP) cables; but to ensure FCC Class A and CE
compliance, STP cables and STP Connectors are required.
• La technologie extension paires torsadées fonctionne avec les câbles paires
torsadées blindées(UTP) ou non blindées(STP). Afin de s’assurer de la
compatibilité entre FCC ClasseA et CE, les câbles STP et les connecteurs STP
sont nécessaires.
NOTES:
• This unit was tested with shielded I/O cables on the peripheral devices. Shielded
cables must be used to ensure compliance with FCC emissions limits.
• For more information on safety guidelines, regulatory compliances, EMI/EMF
compatibility, accessibility, and related topics, see the Extron Safety and
Regulatory Compliance Guide on the Extron website.
VCCI-A Notice
Battery Notice
This product contains a battery. Do not open the unit to replace the battery. If the
battery needs replacing, return the entire unit to Extron (for the correct address, see the
Extron Warranty section on the last page of this guide).
CAUTION: Risk of explosion. Do not replace the battery with an incorrect type. Dispose
of used batteries according to the instructions.
ATTENTION : Risque d’explosion. Ne pas remplacer la pile par le mauvais type de
pile. Débarrassez-vous des piles usagées selon le mode d’emploi.

Conventions Used in this Guide
Notifications
The following notifications are used in this guide:
WARNING: Potential risk of severe injury or death.
AVERTISSEMENT : Risque potentiel de blessure grave ou de mort.
CAUTION: Risk of minor personal injury.
ATTENTION : Risque de blessuremineure.
ATTENTION:
• Risk of property damage.
• Risque de dommages matériels.
NOTE: A note draws attention to important information.
Software Commands
Commands are written in the fonts shown here:
^AR Merge Scene,,0p1 scene 1,1 ^B 51 ^W^C.0
[01]R000400300004000080000600[02]35 [17] [03]
E X! *X1&*X2)*X2#*X2! CE}
NOTE: For commands and examples of computer or device responses used in this
guide, the character “0” is the number zero and “O” is the capital letter “o.”
Computer responses and directory paths that do not have variables are written in the font
shown here:
Reply from 208.132.180.48: bytes=32 times=2ms TTL=32
C:\Program Files\Extron
Variables are written in slanted form as shown here:
ping xxx.xxx.xxx.xxx —t
SOH R Data STX Command ETB ETX
Selectable items, such as menu names, menu options, buttons, tabs, and field names are
written in the font shown here:
From the File menu, select New.
Click the OK button.
Specifications Availability
Product specifications are available on the Extron website, www.extron.com.
Extron Glossary of Terms
A glossary of terms is available at https://www.extron.com/technology/glossary.aspx.

Contents
Introduction ............................................... 1
About this Guide.................................................. 1
About the Quantum Ultra Series Videowall
Processors ......................................................... 1
Quantum Ultra 610 and 305 ............................ 2
Quantum Ultra II 610 and 305.......................... 2
Quantum Ultra Connect 128 and 84 ................ 2
Features .............................................................. 2
All Models........................................................ 2
Quantum Ultra and Ultra II 610 and 305........... 5
Quantum Ultra II 610 and 305 Only.................. 7
Quantum Ultra Connect 128 and 84 ................ 7
HyperLane Bus for Source Transfer ..................... 8
Virtual Network Computing (VNC)........................ 8
Application Examples .......................................... 9
Installation and Configuration ................. 13
Installation Steps ............................................... 13
Front Panel Features.......................................... 15
Quantum Ultra and Ultra II 305,
Connect 128, and Connect 84 ..................... 15
Quantum Ultra and Ultra II 610 Front Panel
Door ............................................................. 15
Rear Panel Features .......................................... 16
HDMI LockIt Cable Lacing Brackets .............. 19
Input and Output Cards..................................... 19
Card Locations — Quantum Ultra and
Ultra II 610 and 305...................................... 20
Inputs ............................................................ 21
Outputs ......................................................... 31
Adjusting for Edge Blending and Mullion
Compensation.................................................. 41
Connecting to a Network................................... 42
RS-232 Insertion — DTP Outputs Only.............. 43
Ethernet to RS-232 Insertion ......................... 43
Captive Screw Signal Insertion....................... 44
Selecting the Insertion Method and RS-232
Protocol........................................................ 45
Expansion Cards ............................................... 46
Expansion Card Locations............................. 47
Connecting the Expansion Cards................... 48
Operation................................................. 49
Starting the Control Panel.................................. 49
Buttons on the Control Panel............................. 51
Loading Image Files........................................... 51
Updating the Password ..................................... 53
Updating Firmware ............................................ 54
Downloading a Firmware File ......................... 54
Uploading a Firmware File.............................. 55
Modifying Network Settings from the Control
Panel................................................................ 58
Resetting the Device from the Control Panel ...... 59
Service Mode .................................................... 60
Disabling and Enabling Write Protection............. 61
Shutting Down the Device ................................. 61
Remote Configuration and Control .......... 62
SIS Commands ................................................. 62
Copyright Information .................................... 62
Processor-initiated Messages ........................ 63
Error Codes ................................................... 63
Using the Command and Response Table ..... 63
Symbol Definitions ......................................... 64
Command and Response Table for SIS
Commands ..................................................... 68
Videowall Configuration Software (VCS)
Program ........................................................... 81
Downloading VCS from the Website .............. 81
Starting the Configuration Program ............... 83
Starting the VCS Program with Expansion
Cards ........................................................... 86
viiQuantum Ultra Series Videowall Processing Systems • Contents

Maintenance ............................................ 91
Front Panel — Quantum Ultra and Ultra II 610 ... 91
Accessing the Quantum Ultra and
Ultra II 610 Front Panel ................................. 91
Front Panel Contents..................................... 93
Replacing Input and Output Cards..................... 94
Replacing a Power Supply — Quantum Ultra
and Ultra II 610................................................. 96
Replacing the Primary Power Supply ............. 96
Replacing the Redundant Power Supply...... 101
Replacing the Power Supply Front Fan —
Quantum Ultra 610 Only ................................. 102
Replacing a Disk Drive — Quantum Ultra
and Ultra II 610............................................... 106
Replacing the System Board Computer
(SBC) Assembly —
Quantum Ultra 610 and Ultra II 610 ................ 109
Removing the SBC Assembly ...................... 109
Installing a New SBC Assembly ................... 111
Reference .............................................. 112
Best Practices for Cleaning Your Extron
Products ........................................................ 112
Cleaning Fiber Optic Connectors and
Cables........................................................ 113
Mounting the Quantum Ultra Series ................. 114
UL Guidelines for Rack Mounting................. 114
Rack Mounting Requirements...................... 115
Rack Mounting Procedure ........................... 115
Quantum Ultra Series Videowall Processing Systems • Contents viii

Quantum Ultra Series Videowall Processing Systems • Introduction 1
Introduction
This section gives an overview of the Extron Quantum Ultra Series Videowall Processing
Systems, describes their significant features, and provides sample application diagrams.
The following topics are covered:
• About this Guide
• About the Quantum Ultra Series Videowall Processors
• Features
• HyperLane Bus for Source Transfer
• Virtual Network Computing (VNC)
• Application Examples
About this Guide
This guide discusses how to install, configure, and operate the Quantum Ultra Series,
consisting of Quantum Ultra 610 and 305, the Quantum Ultra II 610 and 305, and the
Quantum Ultra Connect 128 and 84 Videowall Processors. Throughout this guide, the
following terms are used:
• “Quantum Ultra Series,” and “processor” refer to all Quantum Ultra, Quantum Ultra II,
and Quantum Ultra Connect models.
• “Quantum Ultra” refers to only the Quantum Ultra 610 and 305.
• “Quantum Ultra II” refers to only the Quantum Ultra II 610 and 305.
• “Quantum Ultra Connect” refers to only the Quantum Ultra Connect 128 or 84.
About the Quantum Ultra Series Videowall Processors
The Extron Quantum Ultra Series Videowall Processors are modular 4K video processors
that support ultra-high resolutions up to 2560x1600 and 4096x2160 (4K) @ 60 Hz
on inputs and outputs. They also provide customizable output resolutions, input and
output image rotation, and mullion compensation for compatibility with most display
technologies. USB, RS-232, and Ethernet interfaces provide direct connections for control
systems.
Control methods for all models include Extron Videowall Configuration Software (VCS),
which can be downloaded from the Extron website and provides a means of configuring
videowall displays and saving window presets. Control is also available through Simple
Instruction Set (SIS) commands and by using the Express Mobile Software (EMS) for
Quantum Ultra and Ultra II on an iOS, Android, or Microsoft tablet device.

Quantum Ultra Series Videowall Processing Systems • Introduction 2
Quantum Ultra 610 and 305
The Quantum Ultra 610 is a 6U, 10-slot card frame, while the Quantum Ultra 305
is a 3U frame with 5 card slots. These models support multiple videowalls with mixed
resolutions and screen orientations. They also support edge blend compensation, window
border styles, and a variety of source types including picture, RSS, Text, Clock, and VNC.
The optional IN SMD 100 input card decodes and displays multiple simultaneous MPEG2,
Motion JPEG, and H.264 video streams at up to 60 frames per second. Each input card
contains four HDMI or two LAN connectors. The output cards contain either four HDMI
or four DTP connectors. Both chassis support any combination of input and output
cards. Additional inputs and outputs can be added to a system with use of one or more
additional chassis and expansion cards.
Quantum Ultra II 610 and 305
The Quantum Ultra II models have the same features as the Quantum Ultra 610 and 305,
with the following additions:
• HDMI 4K PLUS input and output cards that support 4K @ 60 Hz resolution and
refresh rates (the existing HDMI input and output cards continue to be supported as
well)
• 500 Gbps Hyperlane video bus (instead of the 400 Gbps Hyperlane bus of the
other models)
• IEC C20 power connectors on the rear panel instead of the standard IEC
connectors of the Quantum Ultra 610 (Quantum Ultra II 610 only)
• 1500 watt primary and redundant power supplies with non-user replaceable
internal fans (Quantum Ultra II 610 only)
Quantum Ultra Connect 128 and 84
The Quantum Ultra Connect 128 and 84 have fixed configurations. The Quantum Ultra
Connect 128 has three HDMI input cards and two HDMI output cards, while the Quantum
Ultra Connect 84 has two HDMI input cards and one HDMI output card. This card
configuration is fixed and cannot be modified by the user. In addition, multiple chassis are
not supported with these models.
Features
All Models
• Extron Vector 4K scaling engine — The Vector 4K scaling engine is specifically
designed for critical-quality 4K imagery, with best-in-class image upscaling and
downscaling.
• Supports 4K on one, two, or four connections — The Quantum Ultra Series
provides management of 4K video as a single, dual, or quad-path signal, for flexibility
when working with 4K sources, peripherals, and displays.
• Direct control via RS-232, USB, and Ethernet — Locally-stored configuration file
allows direct connection between the control system and the Quantum Ultra Series.
• Designed for 24/7, mission-critical environments — The Quantum Ultra Series
provides a high performance, high reliability display processing solution for monitoring
valuable infrastructure and assets with maximum uptime.

Quantum Ultra Series Videowall Processing Systems • Introduction 3
• Integrates into a diverse array of 4K environments such as lobbies,
auditoriums, and simulations — The Quantum Ultra Series is optimized for use
with 4K displays, windowing large numbers of high-resolution sources across multiple
displays with resolutions up to 3840x2160 or greater.
• Full-featured control protocol — Allows access to preset selection, window source
selection, window size, position, and visibility, and many more presentation options.
• Reliable connectivity for HDMI cables — Extron LockIt®cable lacing brackets
provide secure, reliable cable connections for Quantum HDMI inputs and outputs.
• Powerful window management and source scaling capabilities — Sources can
be windowed, layered, and positioned anywhere on the video display, from 1/100 of
the native source resolution to 1000 times the output resolution.
• Supports portrait or landscape screen orientation
• Source rotation — Source images can be rotated in 90-degree increments,
providing flexible and creative presentation options for live content.
• Mullion (bezel) compensation for flat-panel displays — Adjustable
compensation extends the displayed image “behind” screen bezels, accurately
presenting sources which span multiple displays.
• HDCP compliant — Ensures display of content-protected media and interoperability
with other HDCP-compliant devices.
• Custom output resolutions — Maximize compatibility with evolving display
technology, non-standard displays, and LED systems.
• JITC Certified — Successfully completed interoperability and information assurance
testing for use in government applications and other mission-critical environments.
• Key Minder continuously verifies HDCP compliance for quick, reliable
switching — Key Minder authenticates and maintains continuous HDCP encryption
between input and output devices to ensure quick and reliable switching in
professional AV environments, while enabling simultaneous distribution of a single
source signal to one or more displays.
• SpeedSwitch Technology delivers virtually instantaneous switching speeds
for HDCP-encrypted content
• User-selectable HDCP authorization — Allows individual inputs to appear HDCP
compliant or non-HDCP compliant to the connected source, which is beneficial if the
source automatically encrypts all content when connected to an HDCP-compliant
device. Protected material is not passed in non-HDCP mode.
• HDCP Visual Confirmation — When HDCP-encrypted content is transmitted to a
non-HDCP compliant display, a green window with an alert message is sent to the
display for immediate visual confirmation that protected content cannot be viewed on
that display.
• Picture controls for brightness and contrast, as well as horizontal and
vertical sizing, positioning, and zoom
• Internal video test patterns for calibration and setup — The Quantum Ultra
Series offers several dynamically-generated video test patterns to facilitate proper
system setup and calibration of display devices.
• Digitally signed, secure firmware upgrades — Firmware updates are digitally
signed and transferred across an encrypted connection for secure system upgrade.
• Event logging — A system event log is maintained as a locally stored file with a user-
definable maximum size.
• Direct downloading of log files from the Quantum Ultra Series

Quantum Ultra Series Videowall Processing Systems • Introduction 4
• Password protected operating system — Access to the The Quantum Ultra
Series operating system is protected with a user-definable password.
NOTE: The factory configured passwords for all accounts on this device have
been set to the device serial number. In the event of an absolute system reset,
the passwords convert to the default, which is extron.
• Service maintenance alerts — System administrators can be notified of fan or
power supply failure or when recommended operating temperature is exceeded.
• Power save mode — Places the Quantum Ultra Series processor in a low-power
state and turns off input and output cards to conserve energy when not in use.
• Easy-to-use configuration and control software — Videowall Configuration
Software - VCS reduces configuration and preset programming time with a task-
oriented, intuitive interface.
• Integrates easily into a diverse array of 4K environments such as lobbies,
auditoriums, and simulation environments — The Quantum Ultra Series is
optimized for use with 4K displays, windowing high-resolution sources across multiple
displays with resolutions up to 3840x2160 or greater.
• Advanced 4:4:4 signal processing — 4:4:4 signal processing maintains color
accuracy and fine picture detail.
• Seamless transitions — Seamless cut and fade through black transition effects
are available when switching between presets, delivering fast, glitch-free, and
professional-looking presentations for any application.
• Solid-state storage — Ensures long-term operation and fast boot times.
• Write-protected operating system — Prevents any permanent modification to the
file system without administrator password verification and eliminates the possibility of
viruses or unauthorized file updates from being retained across a power cycle.
• Extron Everlast Power Supply — Provides worldwide power compatibility, with
high-demonstrated reliability and low power consumption for reduced operating cost.
• Front panel LED indicates power supply status
• Auto Input Memory — When activated, the unit automatically stores size, position,
and picture settings based on the incoming signal. When the same signal is detected
again, these image settings are automatically recalled from memory.
• Custom output resolutions — Optimizes compatibility with evolving display
technology, non-standard displays, and LED systems.
• Encrypted data connection between the Quantum Ultra Series processor
and configuration PC — SSL encryption provides a secure connection between
the Quantum Ultra Series and the PC running the Extron Videowall Configuration
Software.
• Selectable HDMI to DVI Interface Format Correction — Enables or disables
InfoFrames and sets the correct color space for proper connection to HDMI and DVI
displays.
• Up to 64 video and graphic windows per output card — The Quantum Ultra
Series offers extensive windowing capabilities, with the ability to display up to 64
video, image, and clock windows from each output card.

Quantum Ultra Series Videowall Processing Systems • Introduction 5
Quantum Ultra and Ultra II 610 and 305
• Scalable 4K @ 60 Hz videowall processing for display systems of any
size — Quantum Ultra and Ultra II support videowalls up to 36 screens in size from a
single processor. Additional processors can be configured and operated as a single
system to accommodate larger videowalls.
• 400 Gbps HyperLane video bus delivers real-time performance — The Extron
HyperLane video bus has a total throughput of 400 Gbps, accommodating the
high-bandwidth demands of large videowalls displaying many simultaneous HD and
4K sources.
• Modular architecture accommodates a variety of input and output
arrangements — The Quantum Ultra and Ultra II card frame can be populated
with input and output cards selected to match source and display requirements for
efficient system design.
• Manage multiple videowalls with varying resolutions and screen
arrangements from a single Quantum Ultra or Ultra II device — Videowalls of
varying output resolutions and orientation can all be supported with a single chassis.
• Display locally stored images — Image file types, including JPEG, PNG, and
bitmaps can be uploaded to the Quantum Ultra or Ultra II for use as backgrounds or
displayed as source windows.
• Keying and Alpha channel support for image files — User-definable level or
color keying for image files allows transparent backgrounds for pictures, logos, and
messages. Alpha channel and transparency are also supported.
• 6U, 10-slot Card Frame — The 6U, 10-slot Quantum Ultra and Ultra II 610 card
frames support any combination of input and output cards for I/O sizes from 36x4 to
4x36, or anything in-between.
3U, 5-slot Card Frame — The 3U, 5-slot Quantum Ultra and Ultra II 305 card
frames support any combination of input and output cards for I/O sizes from 16x4 to
4x16, or anything in-between.
• Removable storage drives (Quantum Ultra and Ultra II 610) — The
Quantum Ultra and Ultra II 610 feature operating system and data storage drives that
are easily removable to accommodate security management procedures.
• Hot-swappable, dual-redundant power supplies (Quantum Ultra and
Ultra II 610) — The Quantum Ultra and Ultra II 610 feature hot swappable,
dual-redundant power supplies with two AC power inputs as standard equipment for
reliable operation and maximum up-time.
• Indicator LEDs — Front panel LEDs indicate fan and power supply status.
• HDMI and DTP output cards support signals up to 4K @ 60 Hz — The
OUT4HDMI and OUT4DTP four-channel output cards deliver signals from 1024x768
to 2048x1080 and 1920x1200 at 60 Hz. Dual-channel mode supports two
single-path 4K @ 30 Hz signals, while single-channel mode supports one dual-path or
quad- path 4K @ 60 Hz signal.
• Decodes and displays multiple streamed VNC sources — The Quantum Ultra
Series can display streamed content sourced from PCs running a Virtual Network
Computing – VNC server application. Multiple VNC streams can be presented
simultaneously on the videowall for collaborative desktop sharing from local or remote
PCs.

Quantum Ultra Series Videowall Processing Systems • Introduction 6
• User-definable window borders and text labels enhance presentation and
simplify source identification — Custom color borders with rounded corners, drop
shadows, and transparency can be applied to any window type. A border can be set
to flash to draw attention to the source window. Border titles and overlay text can be
applied to a window and dynamically updated from the control system to indicate a
change in the source’s name, type, status, or classification level.
• Output overlap for edge-blended applications — Output overlap feature supports
edge-blended applications by providing redundant image data for the projection
system’s blended regions.
• Supports direct decoding of H.264 streams for presentation on the videowall
(IN SMD 100 card) — Eliminates the need for external decoders, reducing system
cost and complexity.
• Compatible with common industry streaming formats,including H.264,
MPEG-2, MPEG-4, and Motion JPEG (IN SMD 100 card).
• Decodes a wide range of streamed resolutions up to 1080p/60 (IN SMD 100
card) — Users can opt to decode more streams at lower resolutions or fewer
streams at higher resolutions, allowing efficient use of network and processing
bandwidth.
• Supports the video sections of ONVIF Profile S (IN SMD 100 card) —
Compatible with a wide variety of H.264 encoders, IP cameras, media encoders, and
other streaming devices that also support ONVIF Profile S.
• Independently-configurable network connections (IN SMD 100 card) — This
allows decoding resources to be shared within the same subnet or split across
multiple subnets, providing increased flexibility when designing complex streaming
networks.
• Transmits up to four outputs at distances up to 330 feet (100 meters) over
a shielded CATx cable (OUT4DTP card) — Reduces system complexity when
output extension is required for driving videowall displays up to 330’ (100 m) away
from the Quantum Ultra Series processor.
• Quantum Expansion IN and Quantum Expansion OUT cards link multiple
Quantum Ultra Series processors together to create a single large system.
• Selectable DTP, XTP matrix, and HDBaseT output modes (OUT4DTP card) —
Allows selection of the type of twisted pair technology best suited for the application.
• Power insertion enables remote powering of DTP receivers (OUT4DTP
card) — 12 V DC insertion at the OUT4DTP output card enables the DTP receivers
to be powered over the twisted pair connections, eliminating the need for separate
power supplies at the remote units. Requires one PS 124 per OUT4DTP card.
• Bidirectional RS-232 and IR insertion for AV device control (OUT4DTP card)
— Bidirectional RS 232 control and IR signals can be transmitted alongside the video
signal over DTP connections, allowing the remote device to be controlled without
the need for additional cabling. Bidirectional control insertion eliminates the need for
control system wiring to remote devices.
• RS-232 insertion from the Ethernet control port (OUT4DTP card) — System
level device control to all remote locations via the Quantum Ultra control port,
providing comprehensive control of endpoints and attached devices without needing
additional equipment.

Quantum Ultra Series Videowall Processing Systems • Introduction 7
Quantum Ultra II 610 and 305 Only
• 500 Gbps HyperLane video bus delivers real-time performance for resolutions
up to 8K — Provides a total throughput of 500 Gbps, accommodating the
high-bandwidth demands of large videowalls displaying many simultaneous 4K
sources.
• HDMI 4K PLUS cards support 4K/60 on each connection — Offers management
of 4K/60 video as a single signal for flexibility when working with 4K/60 sources,
peripherals, and displays.
• Supports multi-path 8K/60 signals — The IN4HDMI 4K PLUS card supports
8K @ 60 Hz video as a four channel, multi-path signal. One 8K @ 60 Hz source is
supported per card.
• HDMI embedded audio switching — Embedded audio can be switched between
the Quantum IN4HDMI 4K PLUS input cards and Quantum OUT4HDMI 4K PLUS
output cards for assignment to each canvas.
• 8K-ready design ensures compatibility with existing as well as next generation input
and output cards
• HDCP 2.3 compliant
Quantum Ultra Connect 128 and 84
• Cost effective 4K/60 HDMI videowall processors for videowalls with up to
eight screens
• 400 Gbps HyperLane video bus delivers real-time performance — The Extron
HyperLane video bus has a total throughput of 400 Gbps, easily accommodating the
high-bandwidth demands of large videowalls displaying many simultaneous HD and
4K sources.
• 3U, 5-slot card frame
• IN4HDMI input card supports signals up to 4K/60 — The IN4HDMI four-channel
input card accepts four signals from 1024x768 to 2048x1080 and 1920x1200 at
60 Hz. Dual-channel mode supports two single-path 4K/30 signals, while single-
channel mode supports one dual-path or quad-path 4K/60 signal. When used with
HDCP-compliant displays, HDCP 1.4-encrypted sources can be displayed on the
videowall.
• OUT4HDMI output cards support signals up to 4K/60 — The OUT4HDMI
four-channel output cards delivers signals from 1024x768 to 2048x1080 and
1920x1200 at 60 Hz. Dual-channel mode supports two single-path 4K/30 signals,
while single-channel mode supports one dual-path or quad-path 4K/60 signal.
• Up to 64 video and graphic windows per output card — Quantum Ultra Connect
offers extensive windowing capabilities, with the ability to display up to 64 video
windows from each output card.

Quantum Ultra Series Videowall Processing Systems • Introduction 8
HyperLane Bus for Source Transfer
The HyperLane bus carries video source data between the input and output cards. It
allows the passage of up to 400 Gbps (500 Gbps for the Quantum Ultra II models) of
video information, which translates to a maximum of 96 native 1080p inputs at 60 Hz, or
24 4K sources at 60 Hz, all at 30 bits per pixel.
The HyperLane bus delivers data in real time. This means that it is able to display a
source at its full temporal resolution, maintaining the same scan rate as the original source
without dropping any fields or frames. The HyperLane bus remains operational if an
operating system crash occurs, allowing crucial source content to be maintained on the
target display.
The following table gives a breakdown of common resolutions and the number of sources
at that native resolution that can be passed down a 500 Gbps HyperLane bus:
Width Height Frame Rate Bandwidth (Gbps) Number of Native Sources
1024 768 60 1.42 318
1280 720 60 1.66 272
1920 1080 60 3.73 120
1920 1200 60 4.15 108
1600 1200 60 3.46 130
2560 1600 60 7.37 61
3840 2160 30 7.46 60
4096 2160 30 7.96 56
3840 2160 60 14.93 30
4096 2160 60 15.93 28
4096 2400 60 17.69 25
NOTE: Bandwidth values do not include overhead data required for bus management.
The bandwidth per signal is slightly higher.
Virtual Network Computing (VNC)
The Quantum Ultra Series can decode multiple VNC streams from servers loaded on
remote desktops. The VNC streams can originate on the same network used for control
or on a separate network and accessed using the second LAN port available on the
Quantum Ultra Series.
Desktop resolutions up to 3840x2160 are supported, but the refresh speed of the
desktop content depends on the amount of content moving or changing on the remote
desktop. The size of the VNC window on the Quantum Ultra Series output and the
number of VNC sources simultaneously displayed also influence the refresh rate of the
content.

Quantum Ultra Series Videowall Processing Systems • Introduction 9
The following table shows expected frame rates of a 1920x1080 desktop at various sizes,
quantity, and amount of content in motion:
VNC
Desktop
Window
Size
Number of
Windows
Amount of
Motion
Average Frame
Rate (ftbs)
Network
Usage (Mbps)
1920x1080
3840x2160 1 Full screen 4 18
3840x2160 1 1/9 desktop 15 18
1920x1080 1 Full screen 4 18
1920x1080 1 1/9 desktop 20 22
1920x1080 16 Full screen 1 100
1920x1080 16 1/9 desktop 10 100
960x540 64 1/9 desktop 1 120
Application Examples
The following application diagrams show examples of how the Quantum Ultra 610 and
305, Quantum Ultra II 610 and the Quantum Ultra Connect 128 can be connected.
QUANTUM ULTRACONNECT
Tx Rx G
CONFIG
RS-232
HDMIOUTUSB
1
2
3
AB
100-240V ~ --A MAX 50-60 Hz
POWER LAN
SYSTEM REMOTE
SLOT 5 SLOT 4SLOT 2
SLOT 3 SLOT1
DISCONNECTPOWER
CORDBEFORE
SERVICING
INPUTS QUANTUMIN4HDMI
INPUTS QUANTUMIN4HDMI
INPUTS QUANTUMIN4HDMI
OUTPUTS QUANTUMOUT4HDM I
OUTPUTS QUANTUMOUT4HDM I
POWER
12V
1AMAX
G
Tx Rx RTSCTS
COM1
G
Tx Rx
COM2
VCG
VOL RELAYS
12C
1 2 3 4G
DIGITALI/O
PWROUT =6W
eBUS
+V+S -S G
LAN
IPCP PRO250
IR/S
SG
MODEL80
FLATPANEL
WiFi1234
MODEL80
FLATPANEL
WiFi1234
PUSH PUSH
POWERGUIDE MENU RES480 480p 720p 1080i 1080p DIRECTV HD
SELECT
DIRECTV
Extr
on
I
PCP Pro 250
IP
Link Pro
Contro
l Processor
Extr
on
TL
P Pro 1520TG
15
" Tabletop
To
uchLink Pro
To
uchpanel
Extron
Quantum Ultra Connect 12
8
Ultra-high Bandwidth
4K Videowall Processor
Control
VLAN
4K Desktop PC
Satellite Receiver
4K Media Player
Camera
Ethernet
Ethernet
Ethernet
IR
HDMI
HDMI
HDMI
HDMI
HDMI HDMI
HDMIHDMIHDMI
4K Desktop PC
Figure 1. Quantum Ultra Connect 128 Application
1

Quantum Ultra Series Videowall Processing Systems • Introduction 10
QUANTUM ULTRA610
Tx Rx G
CONFIG
RS-232
AB
SLOT 9SLOT 10
DISCONNECTPOWE R
CORDBEFORE
SERVICING
100-240V ~ --A MAX 50-60 Hz100-240V ~ --A MAX 50-60 Hz
POWER LAN
SYSTEM REMOTE
SLOT 8 SLOT 7 SLOT 6 SLOT 5
OUTPUTS
SLOT 4
OUTPUTS
INPUTS
SLOT 3
INPUTS
SLOT 2
INPUTS
SLOT 1
QUANTUM IN4HDMI
QUANTUM IN4HDMI
QUANTUM IN4HDMI
QUANTUM OUT4HDMI
QUANTUM OUT4HDMI
1234
1234
1234
1234
OUTPUTS
1234
1234
POWER
12V
--A MAX
G
Tx Rx RTSCTS
COM 1
G
Tx Rx
COM 2
VCG
VOL RELAYS
1 2 C
1 2 3 4 G
DIGITAL I/O
PWROUT = 6W
eBUS
+V+S -S G
LAN
IPCP PRO 250
IR/S
S G
Extron
Quantum Ultra 610
Ultra-high Bandwidth
4K Videowall Processor
4K PC
4K
Media Player
Extron
IPCP Pro 250
IP Link Control
Processor
Control
LAN
HDMI HDMI
HDMI HDMI
Ethernet
Ethernet Ethernet
Ethernet
WiFi 1234
4K PC
WiFi 1234
1
4K
Media Player
1
4K
Media Player
1
4K
Media Player
1
Extron
TLP Pro 1022
T
10" Tabletop
TouchLink Pro
Touchpanel
Figure 2. Connection Diagram for a Quantum Ultra 610, HDMI Only
2

Quantum Ultra Series Videowall Processing Systems • Introduction 11
QUANTUM ULTRA610
Tx Rx G
CONFIG
RS-232
AB
SLOT 9SLOT 10
DISCONNECTPOWER
CORDBEFORE
SERVICING
100-240V ~ --AMAX 50-60 Hz100-240V ~ --AMAX 50-60 Hz
POWER LAN
SYSTEM REMOTE
SLOT 8 SLOT 7 SLOT 6 SLOT 5
INPUTS
SLOT 3
INPUTS
SLOT 2
INPUTS
SLOT 1
QUANTUM IN4HDMI
QUANTUM IN4HDMI
QUANTUM IN4HDMI
QUANTUM OUT4HDMI
QUANTUM OUT4HDMI
QUANTUM OUT4HDMI
1234
1234
1234
1234
1234
1234
POWER
12V
--AMAX
G
Tx Rx RTSCTS
COM 1
G
Tx Rx
COM 2
VCG
VOL RELAYS
1 2 C
1 2 3 4 G
DIGITALI/O
PWROUT = 6W
eBUS
+V+S -S G
LAN
IPCP PRO 250
IR/S
S G
LR
POWER
12V
0.7A MAX
AUDIO
SIG LINK
DTP IN
OUTPUTS
LR
POWER
12V
0.7A MAX
AUDIO
SIG LINK
DTP IN
OUTPUTS
LR
POWER
12V
0.7A MAX
AUDIO
SIG LINK
DTP IN
OUTPUTS
LR
POWER
12V
0.7A MAX
AUDIO
SIG LINK
DTP IN
OUTPUTS
LR
POWER
12V
0.7A MAX
AUDIO
SIG LINK
DTP IN
OUTPUTS
LR
POWER
12V
0.7A MAX
AUDIO
SIG LINK
DTP IN
OUTPUTS
OUT
HDBT
SIGLINK
4AMAX
DTP POWER
12V
OUT
SIGLINK
QUANTUMOUT4DTP
OUT TxRx RxGTxOUT TxRx RxGTxTxRx RxGTx TxRx RxGTx
SIGLINK
OUT
SIGLINK
OUT DTP
OUT
HDBT
SIGLINK
4AMAX
DTP POWER
12V
OUT
SIGLINK
QUANTUMOUT4DTP
OUT TxRx RxGTxOUT TxRx RxGTxTxRx RxGTx TxRx RxGTx
SIGLINK
OUT
SIGLINK
OUT DTP
OUT
HDBT
SIGLINK
4AMAX
DTP POWER
12V
OUT
SIGLINK
QUANTUMOUT4DTP
OUT TxRx RxGTxOUT TxRx RxGTxTxRx RxGTx TxRx RxGTx
SIGLINK
OUT
SIGLINK
OUT DTP
Extron
Quantum Ultra 610
Ultra-high Bandwidth
4K Videowall Processor
4K PC
4K Media Player
Extron
IPCP Pro 250
IP Link Control
Processor
Control
LAN
CATx Cable
up to 330' (100 m)
CATx Cable
up to 330' (100 m)
HDMI HDMI RS-232RS-232
HDMI HDMI
Ethernet
Ethernet
Ethernet
Ethernet
WiFi 1234
4K PC
WiFi 1234
1
4K Media Player
1
4K Media Player
1
4K Media Player
1
Extron
TLP Pro 1022
T
10" Tabletop
TouchLink Pro
Touchpanel
Extron
PS 124
Multiple Output
12 Volt DC Power Supply
Extron
PS 124
Multiple Output
12 Volt DC Power Supply
Extron
PS 124
Multiple Output
12 Volt DC Power Supply
Extron
DTP HDMI
4K 330 Rx
Long Distance DTP
Receiver for HDMI
Ext
ron
DTP
HDMI
4K
330 Rx
Long
Distance DTP
Receiv
er for HDMI
RED-OVERLOAD
PS 124
12 VDC 4A POWER SUPPLY
RED-OVERLOAD
PS 124
12 VDC 4A POWER SUPPLY
RED-OVERLOAD
PS 124
12 VDC 4A POWER SUPPLY
Figure 3. Quantum Ultra 610 Application Diagram with DTP Outputs
3

Quantum Ultra Series Videowall Processing Systems • Introduction 12
CONFIG
HDMIOUT USB
1
2
3
AB
POWER LAN
SYSTEM REMOTE
SLOT 10 SLOT 9SLOT 7SLOT 6
SLOT 8 SLOT 4SLOT 3SLOT 2SLOT 1
SLOT 5
DISCONNECTPOWER
CORDBEFORE
SERVICING
PRIMARYPOWER
100-240V~16.0AMAX 50-60 Hz
REDUNTANT POWER
100-240V~16.0AMAX 50-60 Hz
QUANTUM ULTRAII 610
RS-232
Tx Rx G
INPUTS
1234
QUANTUM IN4HDMI 4K PLUS
INPUTS
1234
QUANTUM IN4HDMI 4K PLUS
OUTPUTS QUANTUM OUT4HDMI 4K PLUS
1234
OUTPUTS QUANTUM OUT4HDMI 4K PLUS
1234
OUTPUTS QUANTUM OUT4HDMI 4K PLUS
1234
POWER
12V
--AMAX
INPUT OUTPUT AUDIO OUTPUTS
S/PDIF
L
ANALOG
R
POWER
12V
--AMAX
INPUT OUTPUT AUDIO OUTPUTS
S/PDIF
L
ANALOG
R
POWER
12V
--AMAX
INPUT OUTPUT AUDIO OUTPUTS
S/PDIF
L
ANALOG
R
POWER
12V
1.0A MAX
IR/S
G
Tx Rx RTSCTS
COM 1
G
Tx Rx
COM 2
VCG
VOL RELAYS
1 2C
1 234 G
DIGITAL I/O
PWROUT =6W
eBUS
+V +S -S G
LAN
AV
LAN
GS
Control
LAN
PUSHPUSH
POWER GUIDE MENU RES 480 480p 720p 1080i 1080p DIRECTV HD
SELECT
DIRECTV
PUSHPUSH
POWER GUIDE MENU RES 480 480p 720p 1080i 1080p DIRECTV HD
SELECT
DIRECTV
PUSH PUSH
POWERGUIDE MENU RES480 480p 720p 1080i1080p DIRECTV HD
SELECT
DIRECTV
PUSH PUSH
POWERGUIDE MENU RES480 480p 720p 1080i1080p DIRECTV HD
SELECT
DIRECTV
PUSH PUSH
POWERGUIDE MENU RES480 480p 720p 1080i1080p DIRECTV HD
SELECT
DIRECTV
1 2
Extron
Quantum Ultra II 610
Ultra-high Bandwidth
4K/60 Videowall Processor
Extron
TLP Pro 1525TG
15" Tabletop
TouchLink Pro
Touchpanel
Extron
HAE 100 4K PLUS
HDMI Audio
De-Embedder
Extron
HAE 100 4K PLUS
HDMI Audio
De-Embedder
Extron
HAE 100 4K PLUS
HDMI Audio
De-Embedder
Extron
IPCP Pro 255Q xi
IPCP Pro xi Quad Core
Control Processor
4K HDMI
4K HDMI
4K HDMI
4K HDMI
Ethernet
Ethernet/PoE+
Ethernet
4K Workstation
To Sound System To Sound System To Sound
System
4K Media Player
Satellite Receiver
HDMI
Satellite Receiver
Satellite Receiver
Satellite Receiver
Satellite Receiver
Blu-ray Player
Figure 4. Quantum Ultra II 610 Application Diagram with HD 4K PLUS Inputs
and Outputs
4
