Extron electronics RGB 202 Rxi VTG User manual

User’s Manual
Extron Electronics, USA
1230 South Lewis Street
Anaheim, CA 92805
USA
714.491.1500
Fax [phone]
Extron Electronics, Europe
Beeldschermweg 6C
3821 AH Amersfoort
The Netherlands
+31.33.453.4040
Fax [phone]
Extron Electronics, Asia
135 Joo Seng Road, #04-01
PM Industrial Building
Singapore 368363
+65.6383.4400
Fax [phone]
Extron Electronics, Japan
Daisan DMJ Building 6F
3-9-1 Kudan Minami
Chiyoda-ku, Tokyo 102-0074 Japan
+81.3.3511.7655
Fax [phone]
www.extron.com
© 2002 Extron Electronics. All rights reserved.
Universal Interfaces with Stereo Audio and ADSP™
68-500-01
Printed in the USA
RGB 202 R
xixi
xixi
xi , RGB 202 R
xixi
xixi
xi VTG

Precautions
Thissymbolisintendedtoalert the user of important
operating and maintenance (servicing) instructions
in the literature provided with the equipment.
This symbol is intended to alert the user of the
presence of uninsulated dangerous voltage within
the product's enclosure that may present a risk of
electric shock.
Caution
Read Instructions • Read and understand all safety and operating
instructions before using the equipment.
Retain Instructions • The safety instructions should be kept for future
reference.
Follow Warnings • Follow all warnings and instructions marked on the
equipment or in the user information.
Avoid Attachments • Do not use tools or attachments that are not
recommended by the equipment manufacturer because they may be
hazardous.
Warning
Power sources • This equipment should be operated only from the power source
indicated on the product. This equipment is intended to be used with a main
power system with a grounded (neutral) conductor. The third (grounding) pin is
a safety feature, do not attempt to bypass or disable it.
Power disconnection • To remove power from the equipment safely, remove all
power cords from the rear of the equipment, or the desktop power module (if
detachable), or from the power source receptacle (wall plug).
Power cord protection • Power cords should be routed so that they are not likely to
be stepped on or pinched by items placed upon or against them.
Servicing • Refer all servicing to qualified service personnel. There are no user-
serviceable parts inside. To prevent the risk of shock, do not attempt to service
this equipment yourself because opening or removing covers may expose you to
dangerous voltage or other hazards.
Slots and openings • If the equipment has slots or holes in the enclosure, these are
provided to prevent overheating of sensitive components inside. These openings
must never be blocked by other objects.
Lithium battery • There is a danger of explosion if battery is incorrectly replaced.
Replace it only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the manufacturer's
instructions.
Ce symbole sert à avertir l’utilisateur que la
documentation fournie avec le matériel contient des
instructions importantes concernant l’exploitation
et la maintenance (réparation).
Ce symbole sert à avertir l’utilisateur de la présence
dansleboîtierdel’appareilde tensions dangereuses
non isolées posant des risques d’électrocution.
Attention
Lire les instructions• Prendre connaissance de toutes les consignes de
sécurité et d’exploitation avant d’utiliser le matériel.
Conserver les instructions• Ranger les consignes de sécurité afin de
pouvoir les consulter à l’avenir.
Respecter les avertissements • Observer tous les avertissements et
consignes marqués sur le matériel ou présentés dans la documentation
utilisateur.
Eviter les pièces de fixation • Ne pas utiliser de pièces de fixation ni
d’outils non recommandés par le fabricant du matériel car cela
risquerait de poser certains dangers.
Avertissement
Alimentations• Ne faire fonctionner ce matériel qu’avec la source d’alimentation
indiquée sur l’appareil. Ce matériel doit être utilisé avec une alimentation
principale comportant un fil de terre (neutre). Le troisième contact (de mise à la
terre) constitue un dispositif de sécurité : n’essayez pas de la contourner ni de la
désactiver.
Déconnexion de l’alimentation• Pour mettre le matériel hors tension sans danger,
déconnectez tous les cordons d’alimentation de l’arrière de l’appareil ou du
module d’alimentation de bureau (s’il est amovible) ou encore de la prise secteur.
Protection du cordon d’alimentation • Acheminer les cordons d’alimentation de
manière à ce que personne ne risque de marcher dessus et à ce qu’ils ne soient
pas écrasés ou pincés par des objets.
Réparation-maintenance • Faire exécuter toutes les interventions de réparation-
maintenance par un technicien qualifié. Aucun des éléments internes ne peut être
réparé par l’utilisateur. Afin d’éviter tout danger d’électrocution, l’utilisateur ne
doit pas essayer de procéder lui-même à ces opérations car l’ouverture ou le
retrait des couvercles risquent de l’exposer à de hautes tensions et autres dangers.
Fentes et orifices • Si le boîtier de l’appareil comporte des fentes ou des orifices,
ceux-ci servent à empêcher les composants internes sensibles de surchauffer. Ces
ouvertures ne doivent jamais être bloquées par des objets.
Lithium Batterie • Il a danger d'explosion s'll y a remplacment incorrect de la
batterie. Remplacer uniquement avec une batterie du meme type ou d'un ype
equivalent recommande par le constructeur. Mettre au reut les batteries usagees
conformement aux instructions du fabricant.
Safety Instructions • English
Consignes de Sécurité • Français
Sicherheitsanleitungen • Deutsch
Dieses Symbol soll dem Benutzer in der im
Lieferumfang enthaltenen Dokumentation
besonders wichtige Hinweise zur Bedienung und
Wartung (Instandhaltung) geben.
DiesesSymbolsolldenBenutzerdaraufaufmerksam
machen, daß im Inneren des Gehäuses dieses
ProduktesgefährlicheSpannungen,dienichtisoliert
sind und die einen elektrischen Schock verursachen
können, herrschen.
Achtung
Lesen der Anleitungen • Bevor Sie das Gerät zum ersten Mal verwenden,
sollten Sie alle Sicherheits-und Bedienungsanleitungen genau
durchlesen und verstehen.
Aufbewahren der Anleitungen • Die Hinweise zur elektrischen Sicherheit
des Produktes sollten Sie aufbewahren, damit Sie im Bedarfsfall darauf
zurückgreifen können.
Befolgen der Warnhinweise • Befolgen Sie alle Warnhinweise und
Anleitungen auf dem Gerät oder in der Benutzerdokumentation.
Keine Zusatzgeräte • Verwenden Sie keine Werkzeuge oder Zusatzgeräte,
die nicht ausdrücklich vom Hersteller empfohlen wurden, da diese eine
Gefahrenquelle darstellen können.
Vorsicht
Stromquellen • Dieses Gerät sollte nur über die auf dem Produkt angegebene
Stromquelle betrieben werden. Dieses Gerät wurde für eine Verwendung mit
einer Hauptstromleitung mit einem geerdeten (neutralen) Leiter konzipiert. Der
dritte Kontakt ist für einen Erdanschluß, und stellt eine Sicherheitsfunktion dar.
Diese sollte nicht umgangen oder außer Betrieb gesetzt werden.
Stromunterbrechung • Um das Gerät auf sichere Weise vom Netz zu trennen,
sollten Sie alle Netzkabel aus der Rückseite des Gerätes, aus der externen
Stomversorgung (falls dies möglich ist) oder aus der Wandsteckdose ziehen.
Schutz des Netzkabels • Netzkabel sollten stets so verlegt werden, daß sie nicht
im Weg liegen und niemand darauf treten kann oder Objekte darauf- oder
unmittelbar dagegengestellt werden können.
Wartung • Alle Wartungsmaßnahmen sollten nur von qualifiziertem
Servicepersonal durchgeführt werden. Die internen Komponenten des Gerätes
sind wartungsfrei. Zur Vermeidung eines elektrischen Schocks versuchen Sie in
keinem Fall, dieses Gerät selbst öffnen, da beim Entfernen der Abdeckungen die
Gefahr eines elektrischen Schlags und/oder andere Gefahren bestehen.
Schlitze und Öffnungen • Wenn das Gerät Schlitze oder Löcher im Gehäuse
aufweist, dienen diese zur Vermeidung einer Überhitzung der empfindlichen
Teile im Inneren. Diese Öffnungen dürfen niemals von anderen Objekten
blockiert werden.
Litium-Batterie • Explosionsgefahr, falls die Batterie nicht richtig ersetzt wird.
Ersetzen Sie verbrauchte Batterien nur durch den gleichen oder einen
vergleichbaren Batterietyp, der auch vom Hersteller empfohlen wird. Entsorgen
Sie verbrauchte Batterien bitte gemäß den Herstelleranweisungen.
Este símbolo se utiliza para advertir al usuario sobre
instrucciones importantes de operación y
mantenimiento (o cambio de partes) que se desean
destacar en el contenido de la documentación
suministrada con los equipos.
Este símbolo se utiliza para advertir al usuario sobre
la presencia de elementos con voltaje peligroso sin
protección aislante, que puedan encontrarse dentro
de la caja o alojamiento del producto, y que puedan
representar riesgo de electrocución.
Precaucion
Leer las instrucciones • Leer y analizar todas las instrucciones de
operación y seguridad, antes de usar el equipo.
Conservar las instrucciones • Conservar las instrucciones de seguridad
para futura consulta.
Obedecer las advertencias • Todas las advertencias e instrucciones
marcadas en el equipo o en la documentación del usuario, deben ser
obedecidas.
Evitar el uso de accesorios • No usar herramientas o accesorios que no
sean especificamente recomendados por el fabricante, ya que podrian
implicar riesgos.
Advertencia
Alimentación eléctrica • Este equipo debe conectarse únicamente a la fuente/tipo
de alimentación eléctrica indicada en el mismo. La alimentación eléctrica de este
equipo debe provenir de un sistema de distribución general con conductor
neutro a tierra. La tercera pata (puesta a tierra) es una medida de seguridad, no
puentearia ni eliminaria.
Desconexión de alimentación eléctrica • Para desconectar con seguridad la
acometida de alimentación eléctrica al equipo, desenchufar todos los cables de
alimentación en el panel trasero del equipo, o desenchufar el módulo de
alimentación (si fuera independiente), o desenchufar el cable del receptáculo de
la pared.
Protección del cables de alimentación • Los cables de alimentación eléctrica se
deben instalar en lugares donde no sean pisados ni apretados por objetos que se
puedan apoyar sobre ellos.
Reparaciones/mantenimiento • Solicitar siempre los servicios técnicos de personal
calificado. En el interior no hay partes a las que el usuario deba acceder. Para
evitar riesgo de electrocución, no intentar personalmente la reparación/
mantenimiento de este equipo, ya que al abrir o extraer las tapas puede quedar
expuesto a voltajes peligrosos u otros riesgos.
Ranuras y aberturas • Si el equipo posee ranuras o orificios en su caja/alojamiento,
es para evitar el sobrecalientamiento de componentes internos sensibles. Estas
aberturas nunca se deben obstruir con otros objetos.
Batería de litio • Existe riesgo de explosión si esta batería se coloca en la posición
incorrecta. Cambiar esta batería únicamente con el mismo tipo (o su equivalente)
recomendado por el fabricante. Desachar las baterías usadas siguiendo las
instrucciones del fabricante.
Instrucciones de seguridad • Español
FCC Class A Notice
Note: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at his
own expense.
Note: This unit was tested with shielded cables on the peripheral devices. Shielded
cables must be used with the unit to ensure compliance.
Extron’s Warranty
Extron Electronics warrants this product against defects in materials and
workmanship for a period of three years from the date of purchase. In the event of
malfunction during the warranty period attributable directly to faulty workmanship
and/or materials, Extron Electronics will, at its option, repair or replace said products
or components, to whatever extent it shall deem necessary to restore said product to
proper operating condition, provided that it is returned within the warranty period,
with proof of purchase and description of malfunction to:
USA, Canada, Europe, Africa, and
South America, and the Middle East: Asia:
Central America:
Extron Electronics, Europe Extron Electronics, Asia
Extron Electronics Beeldschermweg 6C 135 Joo Seng Road, #04-01
1230 South Lewis Street 3821 AH Amersfoort PM Industrial Bldg.
Anaheim, CA 92805, USA The Netherlands Singapore 368363
This Limited Warranty does not apply if the fault has been caused by misuse,
improper handling care, electrical or mechanical abuse, abnormal operating conditions
or non-Extron authorized modification to the product.
If it has been determined that the product is defective, please call Extron and ask for an
Applications Engineer at [phone] (USA), 31.33.453.4040 (Europe), or 65.6383.4400
(Asia) to receive an RA# (Return Authorization number). This will begin the repair
process as quickly as possible.
Units must be returned insured, with shipping charges prepaid. If not insured, you
assume the risk of loss or damage during shipment. Returned units must include the
serial number and a description of the problem, as well as the name of the person to
contact in case there are any questions.
Extron Electronics makes no further warranties either expressed or implied with
respect to the product and its quality, performance, merchantability, or fitness for any
particular use. In no event will Extron Electronics be liable for direct, indirect, or
consequential damages resulting from any defect in this product even if Extron
Electronics has been advised of such damage.
Please note that laws vary from state to state and country to country, and that some
provisions of this warranty may not apply to you.

iRGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Table of Contents
Chapter 1 • Introduction .......................................................... 1-1
About this Manual ................................................................ 1-2
About the RGB 202 Rxx
xx
xii
ii
iand RGB 202 Rxx
xx
xii
ii
i VTG............ 1-2
Features ...................................................................................... 1-2
Features of both models ....................................................... 1-2
Additional RGB 202 Rxi
VTG feature .................................... 1-4
Chapter 2 • Installation and Operation ......................... 2-1
Installation and Operation Overview ......................... 2-2
Mounting the Interfaces.................................................... 2-2
Tabletop/desktop placement ................................................ 2-3
Under-desk mounting ........................................................... 2-3
Through-desk mounting ....................................................... 2-4
Rack mounting ....................................................................... 2-5
Front Panel ................................................................................ 2-6
Rear Panel.................................................................................. 2-9
Cabling ...................................................................................... 2-11
LCD Display ............................................................................. 2-14
LCD screen backlight ........................................................... 2-14
Scan rate indication ............................................................. 2-14
Centering ............................................................................. 2-14
Operating the VTG (RGB 202 Rxixi
xixi
xi VTG only) ............ 2-15
Troubleshooting ................................................................... 2-16
Chapter 3 • Remote Control .................................................. 3-1
RS-232 Programmer’s Guide ............................................ 3-2
Host-to-interface communications ....................................... 3-2
Interface-initiated messages ................................................. 3-2
Error responses ...................................................................... 3-3
Using the command/response table ..................................... 3-3
Command/response table ..................................................... 3-4
Control Software for Windows ...................................... 3-5
Installing the software .......................................................... 3-5
Using the software ................................................................ 3-5
Contact Closure Remote Control................................... 3-6
Table of Contents

ii RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i
VTG • Table of Contents
Table of Contents, cont’d
RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG
1
Chapter One
Introduction
About this Manual
About the RGB 202 Rxi and RGB 202 Rxi VTG
Features
Appendix • Specifications, Accessories and
Part Numbers................................................................................... A-1
Specifications ......................................................................... A-2
Included Parts......................................................................... A-5
Optional Accessories........................................................... A-5
Cables ......................................................................................... A-5
68-500-01 Rev. C
Printed in the USA
03 02

RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Introduction
RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Introduction
Introduction, cont’d
Thirty memory presets — Thirty spaces are reserved in the
interface’s memory for storing user-defined combinations
of horizontal and vertical position settings based upon
input signal scan rates. The interface automatically
recalls the position settings when it detects an input
signal with a matching scan rate.
LCD scan rate indicator — This backlit liquid crystal display
(LCD) indicates the horizontal and vertical sync rates, and
the minimum and maximum centering limits. A DIP
switch is provided for turning off the backlight.
MBC power jacks — These jacks provide power to buffered
monitor breakout cables.
75 ohm video termination switches — Rear panel DIP switches
provide a way to switch between high Z and 75 ohm
video input termination for systems where a local
computer monitor is not used.
RGBHV, RGBS, or RGsB outputs — Select the output format
via cabling setup and rear panel DIP switch.
Serration pulse switch — This DIP switch-selectable feature
adds or strips the serration pulses from the output signal
to make it compatible with digital display devices. Use
the serration pulse switch if flagging or bending occurs at
the top of the video display.
Sync polarity adjustment — Horizontal and vertical sync
output can either follow input sync polarity, or outgoing
sync can be forced to negative via a rear panel DIP switch.
Vertical sync pulse width adjustment — Vertical sync pulse
width can be adjusted via a rear panel DIP switch.
Remote control input selection — Connect a remote contact
closure keypad, an RS-232 control system, or a computer
to the rear panel RS-232 port to remotely control the
interface.
Vented metal enclosure — Vents in the enclosure keep the
interface cool and ready for use 24 hours a day, 7 days per
week.
Automatic sync stripping — Sync signals are automatically
stripped from the red, green and blue video input signals.
The interfaces output sync simultaneously as separate
horizontal and vertical sync and as composite sync, but
sync on green (SOG) can be selected via a rear panel DIP
switch.
Introduction
About this Manual
This manual contains information about the Extron
RGB 202 Rxi and RGB 202 Rxi VTG universal interfaces and on
how to operate and configure them.
About the RGB 202 Rxixi
xixi
xi and RGB 202 Rxixi
xixi
xi VTG
The RGB 202 Rxi is an analog computer-video interface with
300 MHz (-3dB) video bandwidth and Advanced Digital Sync
Processing™. It accepts two computer-video and two
unbalanced computer stereo audio inputs. It also features one
RGBHV, RGBS or RGsB output and one balanced, line level
stereo audio output. The RGB 202 Rxi VTG is identical to the
RGB 202 Rxi except that it also contains a built-in video test
generator (VTG).
Front panel controls, remote contact closure, or an RS-232
remote control system or computer can be used to select
between inputs.
Features
Features of both models
Flexible mounting options — The RGB 202 Rxi and
RGB 202 Rxi VTG can be rack mounted, mounted under a
desk or podium, or mounted through a desk or other
furniture with optional mounting kits.
Stereo audio — Unbalanced PC stereo audio inputs are output
as line level, balanced stereo audio.
Level (boost) and peaking controls — Separate front panel
controls compensate for signal losses from long cable
runs.
Horizontal and vertical centering controls — These front panel
controls allow separate horizontal and vertical centering
adjustments.
Digital sync processing — Using regular sync processing to
allow centering control (H-shift or V-shift) can create
problems with some digital display devices as a result of
the sync delay. Extron’s ADSP™ (Advanced Digital Sync
Processing™) maintains a stable sync signal while
allowing centering control. These interfaces also provide
another option, DDSP™ (Digital Display Sync
Processing™), to ensure proper displays without altering
sync pulse timing or width. The sync processing type is
selected via a rear panel DIP switch.
1-2 1-3

RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Introduction
Introduction, cont’d
RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG
2
Chapter Two
Installation and Operation
Installation and Operation Overview
Mounting the Interfaces
Front Panel
Rear Panel
Cabling
LCD Display
Operating the VTG (RGB 202 Rxi VTG only)
Troubleshooting
Additional RGB 202 Rxixi
xixi
xi VTG feature
Video test generator — The RGB 202 Rxi VTG includes a
4-resolution, 4-pattern video test generator to simplify
system setup and testing.
1-4

RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Installation and Operation
RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Installation and Operation
Installation and Operation, cont’d
2-3
Tabletop/desktop placement
For tabletop or desktop placement only, install the self-adhesive
rubber feet/pads (provided) onto the four corners of the bottom
of the interface enclosure.
Under-desk mounting
1. Attach the optional under-desk mounting brackets
(part #70-077-01) to the interface with the six machine
screws (provided in the mounting kit), as shown below.
2. Hold the interface with attached brackets against the
underside of the desk or other furniture. Mark the location
of holes for screws on the desk.
3. Drill 1/4” (6.4 mm) deep, 3/32” (2.38 mm) diameter pilot
holes in the table or desk at the marked screw locations
from the underside/inside (concealed side) of the
furniture, where the interface will be located.
4. Insert the four wood screws into the pilot holes. Fasten
each screw into the installation surface until just less than
1/4” of the screw protrudes.
5. Align the installed screws with the slots in the mounting
brackets, and place the interface against the surface, with
the screws through the bracket slots.
6. Slide the interface slightly forward or back, then tighten all
four screws to fasten it in place.
RGB 202
RVTG
BOOST
LEVEL
CONTROL
PEAK INPUT
1
2
WITH ADSP
TM
MINIVTG
CENTERING
SXGA
SVGA
VGA202
VTG
XGA
Under-desk mounting
Installation and Operation
Installation and Operation Overview
This is an overview of the installation process. You will find
detailed installation and operation instructions in this chapter.
To install and set up the RGB 202 Rxi and RGB 202 Rxi VTG
interfaces, follow these basic steps:
1
Turn all of the equipment (computers, remote controls,
interface, projector/monitor, local monitor, and speakers
or other audio device) off. Disconnect the power cords
from the power source.
2
Install the rubber feet for tabletop use, or install the
appropriate brackets and furniture or rack mount the
interface. See “Mounting the Interfaces” in this chapter.
3
Attach the input (computers), output (display, local
monitor and audio), and remote control cables. See
“Cabling” in this chapter.
4
Set the rear DIP switches. Use the “Rear Panel” section of
this chapter as a guide.
5
Connect power cords and turn on the devices: output
devices (projector, monitors, speakers), remote control
device, interface, and source computers.
6
Select an input from the front panel toggle switch or the
remote control (keypad, system, or PC).
7
The image should now appear on screen, and sound
should be audible. If not, ensure that all devices are
plugged in and receiving power. Check the cabling and
switch settings, and make adjustments as needed. Select a
different input (or the VTG) to check for a picture and
sound.
If problems persist, see “Troubleshooting” in this chapter,
then call Extron’s customer support hotline, if needed.
8
Adjust horizontal and vertical centering, and also level
and peaking to obtain the best picture.
9
For the RGB 202 Rxi VTG, set up and test the VTG. See
“Operating the VTG” in this chapter.
2-2
Mounting the Interfaces
Select an installation option: tabletop/desktop placement, or
under-desk, through-desk or rack mounting. Follow the
appropriate installation guide on the next three pages.

RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Installation and Operation
RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Installation and Operation
Installation and Operation, cont’d
RGB 202 VTG
BOOST
LEVEL
CONTROL
PEAKINPUT
1
2
WITH ADSP
TM
MINIVTG
CENTERING
Rxi
SXGA
SVGA
VGA202
VTG
XGA
2-52-4
Through-desk mounting
1. If rubber feet were installed on the interface, remove them.
2. Insert the machine screws (provided in the mounting kit)
through the slots in the optional through-desk mounting
brackets (part #70-077-02), and loosely attach the brackets
to the interface.
3. Hold the interface with attached brackets against the
underside of the desk/table. With a soft pencil mark the
location of holes for screws on the desk. Mark the
opening, approximately 1.8” x 8.9” ( 4.6 cm x 22.6 cm).
4. Cut out the material from the installation area with a
jigsaw. Check the opening size by inserting the interface
part way through the hole. If needed, use a saw, file or
sandpaper to enlarge the hole. Smooth the edges of the
hole with sandpaper.
5. Drill 1/4” (6.4 mm) deep, 3/32” (2.38 mm) diameter pilot
holes in the desk or table at the marked screw locations.
The holes should be drilled from the underside or inside
(concealed side) of the furniture, where the interface will
be located.
6. Attach the interface to the desk with the provided wood
screws, as shown in
this illustration.
Through-desk mounting
7. To adjust the height of the interface within the desk, slide
the interface up or down to the desired position, then
tighten the screws that attach the brackets to the interface.
Rack mounting
1. If feet were installed on the bottom of the interface, remove
them.
2. Place the interface on one half of the 1U (one unit high,
19” wide) optional rack shelf (part #60-190-01). Align the
front of the interface with the front of the shelf, and align
the threaded holes on the bottom of the interface with the
holes in the rack shelf.
3. Attach the interface to the rack shelf with the two provided
4-40 x 1/8” machine screws. Insert the screws from the
underside of the shelf, and securely fasten them through
diagonally opposite corners as shown in the illustration
below.
(2) 4-40 x 1/8" screws
Use 2 mounting holes on
opposite corners
False front panel
uses 2 front holes
RGB 202 R VTG
BOOST
LEVEL
CONTROL
PEAKINPUT
1
2
WITHADSP
TM
MINIVTG
CENTERING
xi
SXGA
SVGA
VGA202
VTG
XGA
Rack mounting
4. Attach the false front panel (provided with the rack shelf)
to the unoccupied side of the rack (as shown above), or
install a second half-rack-width device in that side by
repeating steps 1 – 3.
5. Attach the rack shelf to the rack using four 10-32 x ¾” bolts.
Insert the bolts through #10 beveled washers, then through
the holes in the rack ears and rack, as shown above.

RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Installation and Operation
RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Installation and Operation
Installation and Operation, cont’d
2-6
Front Panel
The features described in this section apply to both models
unless otherwise noted.
RGB 202 R
BOOST
LEVEL
CONTROL
PEAK INPUT
1
2
WITH ADSP TM
CENTERING
RGB 202 R VTG
BOOST
LEVEL
CONTROL
PEAK INPUT
1
2
WITH ADSP
TM
MINI VTG
CENTERING
SXGA
SVGA
VGA 202
VTG
XGA
1 2 3 4 6 7 85
counterclockwise limit) provides no peaking. The maximum
setting (at the clockwise limit) provides 100% peaking. Adjust
this control while viewing the displayed image to obtain the
optimum picture sharpness.
3
Vertical centering ( )— While viewing the displayed image,
rotate this control to move the image up or down on the screen.
During centering adjustment, the LCD displays V-SHIFT, and it
indicates the vertical shift minimum or maximum limit when
the centering limit has been reached. See the notes below.
4
Horizontal centering ( )— While viewing the displayed
image, rotate this control to move the image to the right or left
on the screen. During centering adjustment, the LCD displays
H-SHIFT, and it indicates the horizontal shift minimum or
maximum limit when the centering limit has been reached.
DDSP disables the interface’s vertical and horizontal
centering controls. If DDSP is set to On and either
centering control is rotated, N/A DDSP ON appears on
the LCD display.
To use the display device’s centering controls instead of
the interface’s centering, set the DDSP DIP switch to On.
The centering controls have no mechanical limits to
rotation. When the minimum or maximum limit of the
control is reached, the picture stops moving on screen.
Many projectors store centering information in their own
memories based on signal frequency. When a projector displays
video from input sources that have the same frequency, one
source’s images may not be centered. Using the interface’s
centering controls eliminates that problem.
Turning the centering control knobs not only moves the images,
but it also stores the horizontal and vertical centering settings in
separate memories for each selected input. The interface recalls
the centering settings each time an input is selected. Centering
adjustments only need to be set once for an application because
the settings are saved even when the power is off.
5
VTG output resolution and pattern selection switch
(RGB 202 Rxi VTG only) — Select a combination of display
resolution and video test pattern using this 16-position rotary
switch. Four different video test patterns are available for each
of the four resolutions offered by the RGB 202 Rxi VTG’s built-in
mini video test generator. See “Operating the VTG” in this
chapter for more information.
1
Level/boost control — This alters the video output voltage to
affect the brightness of the displayed
image. Adjust the level/boost control
while viewing the displayed image to set
the level/boost that provides best picture
quality.
If the interface receives a typical (0.7 volts p-p) analog computer
video input, the output will be as follows:
• At the minimum level setting (the counterclockwise limit of
this control), the interface will output video at 0.5 volts p-p.
• Unity level is 0.7 volts p-p, the same as the input signal.
Set the control to just before the boost area (indicated by
the red line) to output unity level video.
• At the maximum level setting (the clockwise limit of this
control), the interface will output video at 1.45 volts p-p.
Select a setting in the boost range (0.7 volts and above),
indicated by the red line, to compensate for the decrease in
signal level that occurs when the signal passes through long
cables.
Set the boost at 100% (the maximum level) for cable lengths over
500 feet for all computer signals of 15 kHz to 135 kHz.
2
Peaking (Peak) control — Peaking affects the sharpness of a
picture. Increased peaking can compensate for detail (mid- and
high-frequency) loss from low bandwidth system components
or capacitance in long cables. The minimum setting (at the
LEVEL
BOOST
Unity:
0.70V p-p
Maximum:
1.45V p-p
Minimum:
0.50V p-p
2-7

RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Installation and Operation
RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Installation and Operation
Installation and Operation, cont’d
6
202 (interface)/VTG selection switch
(RGB 202 Rxi VTG only) — Use this switch to select the output
signal’s source
202 = The image from the interface (from input 1 or
input 2) will be displayed.
VTG = A test pattern generated by the VTG (video test
generator) will be displayed.
When this switch is set to VTG, signals from input1 and
input 2 are ignored; the interface’s internal VTG
provides a test pattern in place of the computer video
input. Input selection (selection of input 1 or input 2)
cannot be performed until the 202/VTG selection switch
is set to 202.
7
LCD display — This backlit LCD shows the horizontal and
vertical scanning frequencies. While centering adjustments are
being made, the LCD displays H-SHIFT or V-SHIFT, and it
indicates the horizontal or vertical shift minimum or maximum
limit when a centering limit has been reached. If DDSP is on
and the horizontal or vertical centering control is rotated, the
LCD displays N/A DDSP ON.
While the VTG is active (RGB 202 Rxi VTG only), the LCD
displays the current format, resolution and scan rate settings.
See the “LCD Display” section for details.
The backlight turns on at power-up, and it remains on for
15 seconds if a signal is not present at the selected input. If a
signal is present, the backlight will remain on at all times.
However, if the rear panel No Backlight DIP switch is set to On,
the backlight will turn on for only three seconds at power-up,
then it will remain dark even when an active signal is present.
8
Input selection switch and LEDs — Use this toggle switch to
select between input 1 and input 2. The LED corresponding to
the selected input lights, and the switch returns to the center
position automatically.
A remote contact closure switch, a computer, or an RS-232
control system connected via the rear panel 9-pin D port can be
used instead of this switch.
Rear Panel
The features described in this section apply to both models.
DDSP SOG SERR NEG SYNC V SYNC WIDTH 75 OHM 1 75 OHM 2 NO BACKLIGHT
AUDIO
INPUT
POWER
MBC
REMOTE
1
12
2
ANALOG
100-240 0.2A
50/60 Hz
OUTPUTSINPUTS
R
H
G
V
B
S
ANALOG
OUTPUT
9VDC
1 2 3 4 6 7 85
1
AC power connector — Connect a standard IEC AC power
cord here for power input (100VAC to 240VAC, 50/60 Hz) to the
internal, autoswitching power supply.
2
MBC power connectors — These 2.5 mm mini jacks supply
9VDC power for buffered monitor breakout cables (MBCs).
Connect the MBCs’ power plugs here.
3
Analog computer-video inputs 1 (top) and 2 (bottom) —
Connect the source computers to these 9-pin D male connectors.
Adapters and monitor breakout cables are available from Extron
for use with SGI, Sun, and Macintosh computers.
4
Audio inputs 1 and 2 — Connect audio cables from the source
computers to these 3.5mm mini stereo jacks for unbalanced
audio input. See “Cabling” in this chapter for a wiring diagram.
5
DIP switches — This bank of DIP switches controls DDSP
(Digital Display Sync Processing), SOG (sync on green) output,
serration pulse output, sync polarity, vertical sync width, video
termination (high Z/75 ohm), and backlight illumination.
The default for all DIP switches is Off (down).
1 — DDSP (Digital Display Sync Processing)
This feature may be necessary for digital display devices
such as LCD, DLP (digital light processing) and plasma
displays. Use this option if the image is not displayed
properly after other options, such as serration pulse and
video termination changes, have been explored.
On — The interface uses DDSP instead of ADSP.
DDSP does not process the sync signal.
DDSP disables horizontal and vertical centering
controls.
Off — The interface performs sync processing operations,
such as centering, with ADSP.
2-8 2-9

RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Installation and Operation
RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Installation and Operation
Installation and Operation, cont’d
2 — SOG (sync on green)
On — The interface outputs sync on green.
Off — The interface outputs both separate horizontal and
vertical sync (on the H and V connectors) and
composite sync (on the S connector) for RGBHV or
RGBS, respectively.
3 — Serr (serration pulse) — Many LCD and DLP projectors
and plasma displays, must have serration pulses removed
from the sync signal in order to be displayed properly.
Flagging or bending at the top of the video image is a sign
that the serration pulses should be removed.
On — The interface outputs serration pulses in the vertical
sync interval.
Off — The interface does not output serration pulses.
4 — Neg Sync — This switch controls sync polarity.
On — Both the horizontal and the vertical sync signals
are forced to negative polarity on output.
Off — Output sync polarity follows (is the same as) input
polarity.
5 — V Sync Width (vertical sync pulse width) — For some
digital display devices, if no picture appears, the picture
cuts in and out, or it is scrambled, try adjusting the output
vertical sync pulse width or switching from ADSP to DDSP.
On — The vertical sync pulse is narrow.
Off — The vertical sync pulse is wide.
6 & 7 — 75 Ohm (video input termination) — DIP switches
6 and 7 provide termination for video inputs 1 and 2,
respectively. Video termination can be accomplished by
using a laptop breakout cable, by connecting a termination
adapter or a local monitor to a monitor breakout cable
(MBC), by using an MBC buffer cable, or by setting a
termination switch on the interface.
DIP switches 6 and 7 provide a termination method to
prevent blooming when a monitor breakout cable is used
but no local monitor or termination adapter is connected.
On — The interface provides 75 ohm video input
termination.
Off — The interface provides high Z (high impedance)
video input termination.
8 — No Backlight — This switch controls illumination of the
LCD backlight.
On — The LCD backlight is off, except for three seconds
at power-up.
Off — The LCD backlight is on while a signal is present at
the selected input.
6
BNC output connectors — These female BNC connectors are for
red (R), green (G), and blue (B) video output, and
horizontal (H), vertical (V). and composite (S) sync output.
7
Remote control connector — Connect a contact closure remote
control device or an RS-232 device (control system or PC
computer) to this 9-pin D female connector for remote switching
between inputs.
Software for RS-232 control is included with the interface. See
chapter 3, “Remote Control” for details.
8
Stereo audio output connector — This 3.5 mm, 5-pole captive
screw connector is for balanced audio output. See “Cabling” for
a wiring guide.
Cabling
The application diagram in this section shows how the system
looks when cabling is completed. Attach cables to the interface
as follows:
1. Connect the computers’ video outputs to the interface’s
analog input male 9-pin D connectors on the
rear panel. These inputs have the following
pin configuration:
Pin Signal
1 Ground
2 No connection
3 Red video
4 Green video/sync
5 Blue video
6 No connection
7 No connection
8 Horiz. sync/composite sync
9 Vertical sync
If the computers provide the audio input, laptop breakout
cables (LBCs) with audio can be used, or monitor breakout
cables (MBCs) with audio can be used to allow local
monitor output.
DB9 Pin Locations
Male
15
69
2-10 2-11

RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Installation and Operation
RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Installation and Operation
Installation and Operation, cont’d
Most laptop or notebook computers have an external
video port, but they require special commands to output
the video to that connector. Also, laptops’ screens shut
off once that port is activated. See the computer’s user’s
guide for details, or contact Extron for a list of laptop
keyboard commands.
2. Connect the unbalanced stereo audio sources (computer or
other devices such as a CD player) to
the front panel.
Wire the audio jack as shown here.
3. Connect the display device’s (projector’s, monitor’s)
coaxial BNC cable to the rear panel BNC connectors.
For RGBHV (separate H and V sync) output,
connect the cables as shown at left.
For composite sync (RGBS), connect the sync
cable to the connector labeled “S”.
For sync on green (SOG, RGsB), connect the
cables as shown here, and also select the SOG
option on the rear panel DIP switch.
4. Connect the local monitors to the monitor breakout cables
if they were used in step 1 to connect the computers to the
interface. Set the 75 ohm DIP switches to On if no local
monitor is used with a connected MBC cable.
5. Connect an audio device, such as powered speakers, to the
rear panel stereo audio output connector for balanced or
unbalanced audio output. Following the wiring guide
shown below, insert the wires into the appropriate
openings in the captive screw connector. Tighten the
screws on top to fasten the wires, then insert the wired
audio connector into the audio output connector on the
interface rear panel.
For unbalanced output, connect the sleeve to
ground (GND). Connecting the sleeve to a negative
(-) terminal will damage the audio output circuits.
Unbalanced Output
AUDIO AUDIO
Tip
See Warning
Sleeve (s)
Tip
See Warning
Balanced Output
Tip
Ring
Sleeve (s)
Tip
Ring
LR LR
Wiring the audio output connector
RGB 202 R
RS-232 Control
System or
Computer
Laptop Computer
Sun Workstation
MBC Buffer
CRT Projector
Stereo Audio
HiCarol
HiCarol
DDSP
SOG
SERR
NEGSYNC
VSYNCWIDTH
75OHM1
75OHM2
NOBACKLIGHT
AUDIO
INPUT
POWER
MBC
REMOTE
1
12
2
ANALOG
100-2400.2A
50/60Hz
OUTPUTS
INPUTS
R
H
G
V
B
S
ANALOG
OUTPUT
9VDC
RGB 202 R
xixi
xixi
xi / RGB 202 R
xixi
xixi
xi VTG application diagram
6. Set the interface’s DIP and toggle switches. Use the “Rear
Panel” section of this chapter as a guide.
7. Connect an RS-232 control device, if one will be used.
8. Connect power cords and turn on the display and audio
output devices (projectors, monitors, speakers), interface,
and input devices (computers). The system is ready for
operation.
2-132-12
RGBHV
R
H
G
V
B
S
RGBS
R
H
G
V
B
S
RGsB
R
H
G
V
B
S
(
L) Sleeve (GND)
Tip (L)
Ring (R)
Sleeve (
G

RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Installation and Operation
RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Installation and Operation
Installation and Operation, cont’d
2-14 2-15
LCD Display
The RGB 202 Rxi and RGB 202 Rxi VTG’s front panel LCD
display serves two main functions: to display the scanning rates
of the input signal, and to indicate the horizontal and vertical
centering limits. During VTG operation, the RGB 202 Rxi VTG’s
LCD displays the VTG format, resolution and refresh rates.
LCD screen backlight
The LCD screen lights for 15 seconds at power-up, and it stays
backlit as long as an input signal is present at the selected input.
To force the backlight to remain off at all times except at power-
up, set the rear panel No Backlight DIP switch to On.
See page 2-11 for details.
Scan rate indication
When the interface is powered on, the LCD lights for 15 seconds
while it determines whether an input sync signal is present. If
the No Backlight DIP switch is set to On, the LCD lights for
three seconds only.
• If the interface does not detect an input sync signal, the
LCD goes dark and displays “NO SIGNAL” until the
interface receives an active sync signal.
• If the interface detects an input sync signal, the LCD
displays the horizontal and vertical scan rates (sync
frequencies) in the following format:
Hxxx.xxk
Vxxx.xHz
The first line shows the horizontal rate in kilohertz, and
the second line shows the vertical rate in Hertz.
Centering
While the vertical ( ) or horizontal ( ) centering (shift)
controls are being adjusted, the LCD displays “H-SHIFT” or
“V-SHIFT”, respectively. That message remains on the LCD (in
place of the scan rates) until the centering control has been
inactive for 3 seconds. When a centering control reaches its
minimum or maximum limit, the LCD displays “MIN” or
“MAX” on the line below “H-SHIFT” or “V-SHIFT”.
If the centering controls are no longer active, the centering
settings are saved, and the LCD displays the current scan rates.
If the DDSP DIP switch is set to On and a centering control is
rotated, the LCD displays N/A DDSP ON, and the image does
not shift on screen.
Operating the VTG (RGB 202 Rxixi
xixi
xi VTG only)
The RGB 202 Rxi VTG includes a limited video test generator.
The VTG creates and outputs standard test patterns at fixed
formats and resolutions so that a system can be set up and
tested even when an input computer is not available.
To use the VTG, follow these steps:
1. Set the front panel 202/VTG selection switch to VTG.
2. Select an appropriate combination of output resolution
and test pattern using the 16-position rotary switch on the
front panel. Four different video test patterns are available
for each of the four resolutions. Select the test patterns by
rotating the switch within the appropriate resolution
quadrant. The LCD displays the selected VTG format, the
resolution, and then the scan rates.
The test patterns are shown below.
Left to right: crosshatch, H-pattern, 8 split-level
grayscale, and 8 color bar test patterns
The four available resolutions are shown below.
hctiwS tnardauq tamroF noituloseR
)senilxslexip(
.ziroH etar )zHk( .treV etar )zH(
13AGV084x0465.1306
2AGVS006x0089.7306
33ASEV867x42014.8406
4IGS4201x08210.4606

RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Installation and Operation
RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Installation and Operation
Installation and Operation, cont’d
2-16 2-17
6. If the image appears and is stable, but it has ghosting or
blooming, check the high Z/75 ohm video input
termination. If changing the termination doesn’t solve the
problem, try using a different input cable.
7. If the picture is faint or cuts out and the signal is weak, the
video input may be double-terminated. If a local monitor
or a termination adapter is attached to the input’s monitor
breakout cable, or if a laptop breakout cable is used, make
sure that the 75 ohm video input termination DIP switches
are set to Off (for high Z termination).
8. If the picture from a new source computer does not seem
correctly centered, the input position memory presets
might require resetting. To reset the input position
memories, do the following:
a. Unplug the interface’s AC power cord.
b. Hold the input selection switch up (toward input 1)
while reconnecting the power cord to the interface
and the power source
c. Select the appropriate input, and adjust the
horizontal and vertical centering.
9. If the image still does not display correctly, call Extron’s
customer support hotline.
If the interface does not respond to controls
1. If the picture does not move on screen when the horizontal
and vertical centering controls are rotated, DDSP is in use.
Set the DDSP DIP switch to Off.
2. If the RGB 202 Rxi VTG does not switch between inputs
when a remote control is used, the front panel 202/VTG
toggle switch might be set to VTG. Use the switch to select
202 in order to use a remote control.
When the 202/VTG switch is set to VTG, signals from
input1 and input 2 are ignored; the interface’s internal
video test generator provides a test pattern in place of the
computer video input. Input selection (selection of
input 1 or input 2) cannot be performed until the
202/VTG selection switch is set to 202.
Troubleshooting
Turn on the input devices (computer, audio device) and output
device(s) (projector, monitors, speakers). The image should now
appear on the screen, and sound should be audible.
If the image does not appear or there is no sound
1. Ensure that all devices are plugged in.
2. Make sure that each device is receiving power. The
interface’s front panel LED lights if the interface is
receiving power and an active sync signal.
3. Check the cabling and the audio connector wiring and
grounding, and make adjustments as needed.
4. Verify that the 75 ohm video input termination DIP
switches have been set correctly.
5. For digital display devices (including LCD, DLP and
plasma devices), try turning DDSP on or off using the rear
panel DIP switch.
6. To test the system setup and output, substitute a video test
generator for one of the computer inputs. Use the VTG
that is built into the RGB 202 Rxi VTG, or use a stand-alone
VTG with the RGB 202 Rxi. To use a stand-alone VTG,
unplug the input/output devices’ and interface’s power
cords, replace the video source with a VTG, then reconnect
power cords to restore AC power.
7. Call Extron’s customer support hotline if needed.
If the image is not displayed correctly
1. If the output image looks too green, the sync on green
(SOG) DIP switch may be set to On, and the display device
may not be configured to handle SOG signals.
Set SOG to Off.
2. If the picture bends or flags at the top of the screen, set the
serration pulse DIP switch to Off.
3. For a display device that experiences intermittent glitches,
try turning DDSP on or off using the rear panel DIP
switch.
4. If the picture “hangs off” the edges of the screen, adjust the
centering controls ( , ).
5. If the edges of the image seem to exceed their boundaries
or if thin lines and sharp edges look thick and fuzzy, try
changing the Level/Boost or Peak Control settings. If the
image is too bright, decrease the boost or peaking level.

RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Installation and Operation
Installation and Operation, cont’d
RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG
3
Chapter Three
Remote Control
RS-232 Programmer’s Guide
Contact Closure Control
2-18

RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Remote Control
RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Remote Control
Remote Control, cont’d
Remote Control
3-2
RECONFIG
When a change is made via a front panel control or another
operation occurs that must be written to a new memory block,
the interface sends the reconfiguration message. No response is
required from the RS-232 host, but the host may request a new
status listing via the request information command (I/i). See
the command/response table in this chapter for details.
Chn
X2
The input number has been changed or,
for the RGB 202 Rxi VTG, the VTG has been turned on or off.
Error responses
When the interface receives a valid SIS command, it executes the
command and sends a response to the host device. If the
interface is unable to execute the command because the
command is invalid or it contains invalid parameters, it returns
an error response to the host.
The error response codes and their descriptions are as follows:
E01 – Invalid input number (the number is too large or small;
occurs when attempting to select VTG mode via RS-232)
E06 – Invalid input selection (occurs when selecting an input when
the RGB 202 Rxi VTG is set to VTG mode)
E10 – Invalid command
E13 – Invalid value (the number is out of range/too large)
Using the command/response table
The command/response table lists valid command ASCII codes,
the interface’s responses to the host, and a description of the
command’s function or the results of executing the command.
Lower case characters are acceptable in the command field only
where indicated. The ASCII to HEX conversion table below is
for use with the command/response table.
ASCII to HEX Conversion Table
•
There are three ways to control input selection and centering
features of an RGB 202 Rxi /RGB 202 Rxi VTG interface: by using
the front panel controls, by using an RS-232 remote control
device, and by using a contact closure keypad.
RS-232 Programmer’s Guide
The interface can be remotely controlled via a host computer or
other device (such as a control system) attached to the rear panel
9-pin D RS-232 connector. The protocol is 9600 baud, 1 stop bit,
no parity, and no flow control.
The control device (host) can use either Extron’s Simple Instruc-
tion Set (SIS) commands or the graphical control program for
Windows. RS-232 control software is included with the interface.
The rear panel RS-232 9-pin D female
connector has the following pin assignments:
Pin RS-232 function Contact closure Description
1 – Input 1 Select input #1
2 Tx – Transmit data
3 Rx – Receive data
4 – Input 2 Select input #2
5 Gnd Gnd Signal ground
6 – – Not used
7 – – Not used
8 – – Not used
9 – – Not used
Host-to-interface communications
SIS commands consist of one or more characters per field. No
special characters are required to begin or end a command
sequence. When a command is valid, the interface executes the
command and sends a response to the host device. All respon-
ses from the interface to the host end with a carriage return and
a line feed (CR/LF = ), which signals the end of the response
character string. A string is one or more characters.
Interface-initiated messages
When a local event such as a front panel or contact closure
selection or adjustment takes place, the interface sends a
message to the host. No response is required from the host. The
interface-initiated messages are listed here (underlined).
(C) Copyright 2000, Extron Electronics, RGB 202 Rxi, Vx.xx
The interface displays the copyright message when it first
powers on. Vx.xx is the firmware version number.
DB9 Pin Locations
Female
51
96
3-3

RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Remote Control
RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Remote Control
Remote Control, cont’d
3-53-4
The command/response table page uses symbols (defined below) to represent variables.
Symbol definitions
= CR/LF
(carriage return/line feed) (hex 0D 0A)
• = Space
X1
= Input number (1 or 2)
X2
= Active input/VTG (1 = input 1, 2 = input 2, 3 = VTG)
X3
= Shift control range (-255 to +255)
X4
= Controller firmware version (listed to two decimal places
e.g.: x.xx)
X5
= Frequency in Hz or kHz (listed as xxx.xx)
Command/response table Command description Command Response Additional
ASCII Hex to host description
Input selection Select input
X1
! 30 +
X1
21 Chn
X1
Select input 1 or 2
Horizontal shift Specify horizontal shift
X3
H
X3
48 Hph
X3
Set horizontal shift value
Shift right one step { H 7B 48 Hph
X3
Increment up
Shift left one step } H 7D 48 Hph
X3
Increment down
Vertical shift Specify vertical shift
X3
/
X3
2F Vph
X3
Set vertical shift value
Shift up one step { / 7B 2F Vph
X3
Increment up
Shift down one step } / 7D 2F Vph
X3
Increment down
Firmware version, part number & information requests, and reset Query firmware version number Q/q 51/71
X4
Display version (Ver x.xx)
Request part number N/n 4E/6E N60-32_-01 Display interface’s part # Request information Command = I/i 49/69 (see below) Display status
Response = Chn
X2
•Hph
X3
•Vph
X3
•Hrt
X5
•Vrt
X5
Control Software for Windows
The included graphical control software for Windows offers
another way to control the interface via RS-232 in addition to the
Simple Instruction Set commands listed on page 3-4. The
control software is compatible with Windows 3.1x, Windows 95/
98, and Windows NT. The RGB 202 Rxi and RGB 202 Rxi VTG
use version 2.0 or higher of Extron’s RGB 302/304/202 Control
Program, which is included with these interfaces.
Installing the software
The control program is contained on a 3.5-inch diskette, and it
can run from the floppy drive. However, it is more convenient
to run the program from the hard drive.
To install the software onto the hard drive, run SETUP.EXE from
the floppy disk, and follow the instructions that appear on the
screen. The program requires approximately 1 MB (megabyte)
of hard disk space.
By default the installation creates a C:\RGB302 directory, and it
places two icons (RGB 302+304+202 Control Pgm and RGB 302+
304+202 Help) into a group or folder named “Extron Electronics”.
Using the software
To run the control program, follow these steps:
1. Double-click on the RGB 302 + 304 + 202 Control Pgm icon
in the Extron Electronics group or folder,
or on the Rgb302.exe icon in the
C:\RGB302 directory. The Comm menu
will appear on the screen.
2. Click on the comm port that is connected to the interface’s
RS-232 port. The control software will
“look for” the interface at that port and
read its configuration.
The control program window (shown
at left) will appear and display current
settings.
For information on program features, press the F1 computer key
or click on the Help menu from within the
control program, or double-click on the RGB
302+304+202 Help icon in the Extron Electronics
group or folder.

RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Remote Control
Remote Control, cont’d
RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG
A
Appendix
Specifications, Accessories and
Part Numbers
Specifications
Included Parts
Optional Accessories
Cables
Contact Closure Remote Control
For remote control of input selection only, connect a contact
closure remote control device to the rear panel 9-pin D female
Remote connector. See the pin assignment table on page 3-2.
3-6

RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Specifications
RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Specifications
Specifications, cont’d
A-3
Specifications, Accessories, Part Numbers
A-2
Video
Routing .......................................... 2 x 1 router
Gain ............................................... 0.5V to 1.45V p-p
Bandwidth .................................... 300 MHz (-3dB)
Rise time ........................................ 1.5 nS
Video input
Number/signal type ................... 2 analog RGBHV, RGBS, RGsB, RsGsBs
Connectors .................................... 2 9-pin D male for MBC/LBC cable or
buffer
Minimum/maximum levels ...... Analog ....... 0.3V to 1.45V p-p with no
offset at unity gain
Impedance .................................... 75 ohms or high Z, switchable (set to
75 ohms if no local monitor is connected)
Horizontal frequency .................. 15 kHz to 150 kHz
Vertical frequency ....................... 40 Hz to 140 Hz
Return loss .................................... -30dB @ 5 MHz
Maximum DC offset .................... 4V
Video signal characteristics — RGB 202 Rxixi
xixi
xi VTG only
Dot clock ....................................... VGA 25.18 MHz, Mac 30.04 MHz, SVGA
65.04 MHz, SGI 107.4 MHz ..
Pixel clock accuracy..................... > 99.02%
Scan rate accuracy ....................... > 99.03%
Frequency range .......................... VGA ..... 31.475 kHz x 60 Hz,
SVGA ... 37.879 kHz x 60 Hz,
XGA ..... 48.392 kHz x 60 Hz,
SGI........ 63.928 kHz x 60 Hz
Rise/fall time ............................... 2.5 nS / 2.0 nS, measured
Video output
Number/signal type ................... 1 analog RGBHV, RGBS, RGsB
Connectors .................................... 6 BNC female
Minimum/maximum levels ...... 0.3V to 1.30V p-p with 0.7V p-p nominal
input level
Impedance .................................... 75 ohms
Return loss .................................... -30dB @ 5 MHz
DC offset ....................................... ±5mV maximum with input at 0 offset
Sync
Input type ..................................... RGBHV, RGBS, RGsB, RsGsBs
Output type .................................. RGBHV, RGBS, RGsB
Input level ..................................... 2V to 5.5V p-p with ±0.2VDC offset max.
Output level.................................. TTL ............. 4V to 5V p-p
Input impedance .......................... 10 kohms
Output impedance ...................... 75 ohms
Max. propagation delay.............. 85 nS
Max. rise/fall time ....................... 2 nS
Polarity .......................................... RGBHV...................... tracks polarity (or
force negative sync
via DIP switch)
RGBS, RGsB .............. negative
Audio
Routing .......................................... 2 x 1 stereo router
Gain ............................................... Unbalanced 0dB, balanced +6dB
Frequency response ..................... 20 Hz to 20 kHz, ±0.05dB
THD + Noise ................................ 0.03% @ 1 kHz, 0.3% @ 20 kHz at rated
maximum output drive
S/N ................................................ >90dB at rated maximum output drive
(17dBu), balanced
Crosstalk ....................................... <-90dB @ 1 kHz, fully loaded
Stereo channel separation .......... >90dB @ 1 kHz to 20 kHz
Audio input
Number/signal type ................... 2 PC level stereo, unbalanced
Connectors .................................... 2 3.5 mm stereo jacks (female) (2
channel); tip (L), ring (R), sleeve (ground)
Impedance .................................... >10 kohms, unbalanced, DC coupled
Maximum level ............................ +8.5dBu, (balanced or unbalanced) at
stated %THD+N
Audio output
Number/signal type ................... 1 buffered stereo (2 channel), balanced/
unbalanced
Connectors .................................... 1 3.5 mm, captive screw connector, 5-pole
Impedance .................................... 50 ohms unbalanced, 100 ohms balanced
Gain error...................................... ±0.1dB channel to channel
Maximum level (Hi-Z) ................ >+14dBu, balanced at stated %THD+N
Maximum level (600 ohm) ......... >+8.5dBm, balanced at stated %THD+N
0dBu = 0.775 volts (RMS).

RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Specifications
Specifications, cont’d
RGB 202 Rxx
xx
xii
ii
i, RGB 202 Rxx
xx
xii
ii
i VTG • Accessories and Part NumbersA-4 A-5
Included Parts
These items are included in each order for a RGB 202 Rxi or a
RGB 202 Rxi VTG:
Included parts Part number
RGB 202 Rxi/RGB 202 Rxi VTG 60-327-01/60-328-01
3.5 mm, 5-pole captive screw connector 10-319-10
RGB 202 Rxi/202 Rxi VTG User’s Manual 68-500-01
Rubber feet
IEC power cord
Windows-based control software 29-035-01
Tweeker
Optional Accessories
Accessories Part number
Under-desk mounting bracket kit 70-077-01
Through-desk mounting bracket kit 70-077-02
1U rack shelf 60-190-01
3.5 mm stereo plug 10-306-01
Installation cable
(bulk 14-conductor, non-plenum) 22-120-02
Installation cable
(bulk 17-conductor, plenum) 22-111-03
Cables
Monitor breakout cables Part number
MBC VGA/XGA HR 26-162-01
MBC Mac/Quadra 26-018-01
MBC Sun Sparc HR 26-424-01
MBC SGI/13W3 HR 26-425-01
Control/remote — interface
Serial control port ........................ RS-232, 9-pin female D connector (also
used for contact closure)
Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity
Serial control pin configuration .. 2 = TX, 3 = RX, 5 = GND
Contact closure ............................ 1 9-pin female D connector (also used for
RS-232)
Contact closure pin configuration. 1 = input #1, 4 = input #2, 5 = GND
Program control ........................... Extron’s control program for Windows
Extron’s Simple Instruction Set™– SIS™
General
Input power .................................. 100VAC to 240VAC, 50/60 Hz, 18 watts,
internal, auto-switchable
MBC power jacks ......................... 9.0VDC, 0.15A
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /
10% to 90%, non-condensing
Operating +32° to +113°F (0° to +45°C) /
10% to 90%, non-condensing
Rack mount................................... Yes, with an optional rack shelf (part
#60-190-01)
Furniture mount .......................... Yes, with an optional under-desk
mounting kit (part #70-077-01) or
through-desk mounting kit (part #70-077-
02)
Enclosure type.............................. Metal, vented
Enclosure dimensions ................. 1.75" H x 8.75" W x 8.0" D (1U high, half
rack width)
4.4 cm H x 22.2 cm W x 20.3 cm D
with rear BNCs ........ D = 8.4" (21.3 cm)
(Depth excludes knobs.)
Product weight............................. RGB 202 Rxi ................. 2.2 lbs (1.0 kg)
RGB 202 Rxi VTG ..... 2.3 lbs (1.0 kg)
Shipping weight ........................... 5 lbs (2.3 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International
Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
