The Extron RGB 302/304 is a digitally controlled
UniversalAnalog/ECLComputer-VideoInterface.It
can connect most computers to a video presentation
device, such as a large screen projector or data
monitor. The RGB 302/304’s SmartSave™ feature
automatically selects sync settings and other
parameters for a quick and easy setup.
AmongtheRGB302/304features are RGB input/
outputconnectors,an MBC power jack, audio input/
outputconnectors,an RS-232 connector, and rear
panel DIP switches.
TheRGB304isidentical in performance and features
as the RGB 302 with the exception being that, unlike
the RGB 302, the RGB 304 has its 9-pin Analog/ECL
input,Audioinput,andMBCpowerjacklocatedonthe
frontpanel of the unit, as shown below. This difference
allows the RGB 304 to be installed in situations where
front panel access to such connectors may be
necessary, such as the mounting of the unit in a rack
mountenvironment.
RGB302/304 Features
The RGB 302/304 features allow video output to be
controlled in several ways:
• Automaticsync output detection and setup for quick
installation
• CustomsetupandadjustmentsmadefromtheFront
Panel(shownbelow)
• RGB 302/304 Windows® software, through an RS-232
interface
• User-writtenprogramsthroughtheRS-232port
Page 1-1
Chapter 1 • Introduction to the RGB 302/304
MENU NEXT
RGB 302
MENU NEXT
RGB 304
MBC
POWER
ANALOG/ECL
AUDIO IN
INPUT
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

Extron RGB 302/304 Universal Interface • User’s Manual
SmartSave ™
Thisunique featuregreatlysimplifiesthevideo
configurationsetupoftheRGB302/304. The
RGB 302/304 comes preset with various video
configurationstomatchmostcomputer video
requirements.Theproperconfigurationis
automaticallyselectedandimplementedfortheuser.
Inaddition,theRGB302/304will automaticallysave
anyusermodificationstothe videoconfigurationand
willrecallthecorrectconfigurationwithout needfor
userintervention.
LCD Menu Driven Controls
The RGB 302/304 does not have front panel “knobs”
or “switches” to control its operation. Instead, the
“controls”aredisplayedand adjusted using theFront
Panel LCD display and the six front panel buttons.
The Front Panel display can be used in any of four
languages:English,French,SpanishandGerman.
The display serves two purposes:
1. The RGB 302/304 automatically detects and
displaysvitaltroubleshootinginformation,suchas
thehorizontalandverticalscanfrequencies.
2. The user can step through and display any of the
controlsorfeaturesin the interface.
___ Chapter 3has detailsonusingtheFrontPanel.
Memory Blocks and Memory Cycling
There are 15 preset memory blocks which store video
format information, such as video, sync and control
settings. Each block is preloaded by Extron and
definesonevideoconfiguration(e.g.VESA3,MAC16",
etc.). These preset memory blocks define most video
requirements.Inaddition,thereare25user-definable
memoryblocksavailable.
The RGB 302/304 automatically cycles through
(MemoryCycling)the user-definedmemoryblocks
and loads the video format that most closely matches
thecomputer’svideooutput.Should a match notbe
found, the 15 preset memory blocks are searched
next (refer to
the section “Memory Cycling Feature” in
Chapter2).
Level Control (picture)
This feature is similar to the brightness control on a
datamonitor and is used toadjust the intensity of the
videolevelontheprojector/monitorscreenbyusing
the cursor keys. There are 255 levels for this control.
Page 1-2
Chapter 1 • Introduction to the RGB 302/304
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

Extron RGB 302/304 Universal Interface • User’s Manual
Peaking Control (sharpness)
This control is similar to the sharpness control on a
datamonitor. It is also used to compensate for long
cable runs. There are eight Peaking levels which are
selected by using the cursor keys.
Horizontal Shift Control (centering)
Thisfeatureshifts the displayed image to the leftor
rightontheprojector/monitorscreenbyusingthe
cursor keys. There are 255 positions for this control.
Vertical Shift Control (centering)
Thisfeature shifts the displayed imageup or down on
the projector/monitor screen by using the cursor keys.
Thereare 255 positions for thiscontrol.
Automatic Sync Output Detection
The RGB 302/304 automatically detects which cables
are connected and sends either Sync On Green,
CompositeSyncorSeparateHorizontalandVertical
sync signals to the correct output cables. This
functioncan beoverriddenthroughmenucontrols.
Automatic Sync Stripping
The RGB 302/304 automatically strips all incoming
sync from the red, green, and blue channels for clean,
crisp signal processing. Sync may be recombined with
the green channel if necessary.
Keyboard Lockout
The RGB 302/304 features a Keyboard Lockout
function which allows the user to “lock out” the front
panel controls by using “hot keys”. This feature
disablesfrontpaneloperationaftersetup.
Auto-switching Power Supply
The RGB 302/304 is equipped with an internal auto-
switchingpower supply that operates fromany input
voltage in the 100 to 240 VAC, 50/60 Hz range. No
equipmentchangesare necessary.
Audio InterfaceThe RGB 302/304 includes a PC/computer audio (600
ohm)toline-levelaudio(balanced)converter.For
computers which have a sound card, the audio
interfacewillprocesstheaudiosignal along with the
video(audio follow).Theaudiooutputcanbe
connected to an external stereo system.
Page 1-3
Chapter 1 • Introduction to the RGB 302/304
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

Extron RGB 302/304 Universal Interface • User’s Manual Page 1-4
Chapter 1 • Introduction to the RGB 302/304
DIP Switch Settings
The RGB 302/304 includes a rear panel DIP switch
bank which will activate Digital Display Sync
Processing, remove/pass serration pulses, and set 75
Ohm/highimpedancevideoinputtermination.
RS-232 Control Interface for Remote Control
The RGB 302/304 has a built-in RS-232 interface to
allowtheunittobecontrolledremotelyineitheroftwo
ways:
1. Use the Windows® RGB 302/304 Control Panel
software provided by Extron (see next section).
2. The user may write software to control the RGB 302/
304 from a PC or control system. See the
Programmer’s Guide inAppendix A.
The RS-232 protocol is fixed at 9600 baud, no parity, 8
data bits and 1 stop bit.
Benefits of Windows® RGB 302/304 Software
UsingtheWindows® software provided with the
RGB 302/304 adds several advantages over Front
Paneloperation.
• All of the controls are quick and easy to use with
theon-screencontrolpanel.
• Application setups can be stored as disk files,
therefore,anunlimited numberofsetupscanbe
stored and reloaded from the PC’s hard drive or
floppydisk.
Refer to Chapter 4 for details on using this software.
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

Extron RGB 302/304 Universal Interface • User’s ManualPage1-5
FrontPanel Controls
The Front Panel buttons (as shown below) have many
functions, depending on which menu is accessed at
anyparticular time. For example, the usercan display
andadjust controls to modify the video display. The
specific functions for these buttons are described
below.
The LCD panel cycles through 3 default menus when
the RGB 302/304 is first powered on. Refer to Chapter
3 for instructions on using the RGB 302/304 menus.
___ There isa built-intime-outfunction which willreturnto
the default menu cycle if no buttons are pressed for
approximately 8seconds.By default, anychanges
whichweremadewillbeautomaticallysaved uponthe
time-out.
Menu button TheMenu button is used to select and step through
thefourdifferentmenuclasses(tobeexplainedin
Chapter3).
Next button The Next button is used to advance to the next
submenuof a menu class orto return to the beginning
of the menu class (seethe menuflowchartonpage 3-1).
Cursor buttonsThe cursor buttons are typically used to step through
themenuoptions before makingachoice.These
optionscouldbealphacharactersornumericsettings.
The user may also want to change the value of the
current setting (i.e., increase or decrease level, shift,
peaking, etc.). These buttons also serve as
convenient “hot keys” to various functions.
LCD Display Besidesdisplaying the menus, the LCD display
providessomehelpfulinformation,suchaswhich
buttons to use when making choices.
MENU NEXT
RGB 302
MENU NEXT
RGB 304
MBC
POWER
ANALOG/ECL
AUDIO IN
INPUT
MENU
NEXT
Chapter 1 • Introduction to the RGB 302/304
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

Extron RGB 302/304 Universal Interface • User’s Manual
RGB 302/304 Specifications
Part Number ..60-243-01(RGB302)
..60-244-01(RGB304)
User’sManual ..68-354-01
Dimensions ..8.75" W x 9.5" D x 1.75" H
ShippingWeight ..5 lbs
Input Power ..100 - 240 VAC, 50/60 Hz,
auto-switchable, internal
PowerConsumption ..17 watts
OperatingTemperature ..0° C to 50° C
Control Baud Rate ..9600baud
InputSignal: Video ..2V p-p max
VideoImpedance ..75 Ωterminated,7.5kΩuntermin.
Sync ..Separate H & V Sync TTL (±)
..Composite H & V TTL (±)
..Sync on Green (-).3V
..Sync on Red, Green & Blue (-).3V
SyncImpedance ..10 kΩ
Audio ..Connector: 3.5 mm jack
AudioImpedance ..High Z
Output Signal: Video ...35V to 1V p-p with .7V applied
VideoImpedance ..75 Ω
Sync ..Sync on Green (-)
..Composite Sync (-)
..Separate H & V (±)
SyncImpedance ..75 kΩ
Audio ..Connector: 3.5 mm jack
AudioImpedance ..600 Ω
FrequencyCompatability:
Horizontal ..15 - 125 kHz (automatically)
Vertical ..30 - 170 Hz (automatically)
RGBVideoBandwidth ..220 MHz (2 ns rise time)
LCD Scan Rate Range:
Horizontal ..15 - 150 kHz
Vertical ..30 - 170 Hz
LCD Menu (Front Panel): ..Back-litalphanumericdisplay
(English, German, Spanish or
French)
Warranty ..Two years, parts and labor
Chapter 1 • Introduction to the RGB 302/304
Page1-6
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

Extron RGB 302/304 Universal Interface • User’s Manual
Chapter 1 • Introduction to the RGB 302/304
Page1-7
____
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

Extron RGB 302/304 Universal Interface • User’s Manual
2
Chapter Two
Installing the RGB 302/304
Easy Setup Procedure
DIP Switch Settings
AudioConnections
Installation Check
Memory Cycling Feature
RS-232Specifications
RGB 302/304 Universal Digital Interface
User’s manual
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

Extron RGB 302/304 Universal Interface • User’s ManualPage 2-1
Chapter 2 • Installing the RGB 302/304
____ The diagrams above showthe front and rear panels of
theRGB 302 (top pair) and RGB 304 (bottompair).
EasySetup Procedure
Theseeasy-to-followstepsdescribethegeneralsetup
oftheRGB302/304. Refer to theexample
Application
Diagrams
at the end of this chapter.
1.Turnthecomputer and monitorpowerOff.
Do not connect the RGB 302/304 power cable yet
(there is no power switch).
2.Disconnectand removethecomputer’slocalmonitor
videocablefromthecomputervideo port.
3. Connect BNC output cables from the RGB 302/304
tothedatamonitor/projector —allBNCoutputsare
RGB analog. The BNC connectors are marked R, B,
G, H/V and V. They may be connected in any of
three ways:
• Red, Green/sync and Blue, for RGB with sync on
Green.(3-cablehookup)
• Red, Green, Blue and H/HV, for RGB with Composite
sync signals. (4-cablehookup)
• Red, Green, Blue, H/HV and V, for RGB with separate
HorizontalandVerticalsyncsignals.(5-cablehookup)
MENU NEXT
RGB 304
OUTPUT
R
50/60 Hz
100-240V 0.5A
G B H/HV V
LR
OUT
MBC
POWER
RS-232
ANALOG/ECL
AUDIO IN
AUDIO
DDSP SER REM 75 OHM
INPUT
MENU NEXT
RGB 302
OUTPUT
R
50/60 Hz
100-240V 0.5A
G B H/HV V
LR
OUT IN
MBC
POWER
RS-232
ANALOG/ECL
INPUT
AUDIO
DDSP SER REM 75 OHM
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

Extron RGB 302/304 Universal Interface • User’s Manual Page2-2
Chapter 2 • Installing the RGB 302/304
____ The Extron RGB 302/304 automatically detects which
cables are connected and sends sync signals to the
correctoutput.
4.ConnecttheAnalog/ECLMBCvideo cable from the
computer (Power PC, PC, Mac, or workstation) to
theAnalog/ECLInputconnector on the RGB302/
304and tothelocalmonitor.Seenotebelow.
____ If a Laptop Breakout Cable (LBC) is being used, set
DIP Switch 3 to Off. Refer to “Rear Panel DIP Switch
Settings”in the next section.
4a. MBC Power Connector — If an MBC buffer is
beingused,plugthephone jack into theMBC
powerfemaleconnectoroftheRGB 302/304.
5. RS-232 Control (optional) — If using a PC or other
system to control the RGB 302/304, connect the
cablehere(pinoutsandinterfacespecificationsare
givenunderthesection
“InstallationCheck” laterin
thischapter).
6.Turn power On at the local computermonitor. Next,
turnpowerOn atthecomputersupplyingthe video
input — (Power PC, PC, Mac or workstation).
6a.Turn powerOnatthedatamonitor/projector.
6b.ConnectpowertotheRGB302/304.
7. Observe that the RGB 302/304 LCD display lights up
andcyclesthrough thethreedefaultmenus(below).
7a. The ID or Title Menu - Displays the name of
theunit.Tochangethisdisplay, see
“Editing
the ID Screen”
in Chapter 3.
7b.TheScan RateMenu-Fromthemonitor
breakout cable, the RGB 302/304 detects
the scan rate frequencies and displays
them. The scan rate display on the left is an
example.
7c.TheSync Output-Memory Cycling Menu-
As an example, if the RGB 302/304 has
detected an output with sync on Green and
Memory Cycling is turned On, the first line
will display “Sync Out: Green” and the
second line will display “Mem Cycling: On” .
Refertothe
“MemoryCyclingFeature”
sectioninthischapterforadetailed
explanationofMemoryCycling.
ANALOG/ECL
INPUT
RS-232
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

Extron RGB 302/304 Universal Interface • User’s ManualPage2-3
____ Memory Cycling can be On or Off. Sync Output can be
Green,Comp(Composite),H&V(SeparateHorizontal
&Vertical), or Auto (Automatic).
AutomaticSync
means the RGB 302/304 detects which output
connectors are currently active and will set and display
the output sync as either Green, RGBS or RGBHV,
dependingontheconnections.
Rear Panel DIP Switch Settings
The RGB 302/304 has three DIP switch settings:
Switch 1: On = Digital Display Sync Processing
Off = Processed sync (normal)
Switch 2: On = Remove serration pulses
Off = Pass serration pulses (normal)
Switch 3: On=75-Ohminputtermination
Off=Highimpedanceinputtermination
AudioConnections
TheRGB302/304provides audio interfacing tothe
audiooutput which is connected to the user’s audio
equipment.Theusersuppliestheaudiocables.
OntheRGB 302, the audio input and outputare both
locatedonthe rear panel, as shown in thediagram to
theleft.
The RGB 304 has the audio output
locatedontherear panel, butthe
audioinputis situated onthefront
panel,asshown to the right.
Theaudio interface is a PC/computer audio (600 Ω)to
line-levelaudio(balanced)converter.Ifthecomputer
has a sound card, the RGB 302/304 will distribute the
audiowiththevideo(audiofollow).
Althoughtheinputandoutputaudioconnectorsare
physically the same, they are used differently. See the
illustrationandthefollowingdescriptionsforthe
correctwiringofaudioinputsandoutputs.
Audio Input — Connect the stereo audio sources to
Audio In. Input cables should be wired as follows:
• Stereo left to Tip (+) contact
• Stereo right to Ring (-) contact
• Both commons to Sleeve (Gnd) contact
Chapter 2 • Installing the RGB 302/304
DDSP SER REM 75 OHM
On
Off 123
LR
OUT IN
AUDIO
RGB 302
AUDIO IN
LR
OUT
AUDIO
RGB 304
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

Extron RGB 302/304 Universal Interface • User’s Manual Page2-4
Chapter 2 • Installing the RGB 302/304
AudioOutput (Left and Right) — Thereis one audio
outputusingseparateconnectorsforleft and right
channels. Connect the left and right output jacks to the
inputs of an external audio system. The 3-contact
outputscanbewiredforbalancedorunbalanced
audio.
• For unbalanced audio, use Tip (+) and Sleeve (Gnd)
• For balanced audio, use Tip (+) and Ring (-)
____ Observe polarity when making connections tokeep left
andrightchannelsinphase.
InstallationCheck
Toverifythattheinstallationiscomplete,dothe
following:
1. Check that the LCD default menus show the correct
information(aspreviously described in Step 7). Use
themenusasatroubleshootingaid.
If no video input was detected, no memory
block was loaded, and the display will show
zeroes.
The scan rate menu may be used for
troubleshootingasfollows:
• The timing for the RGB 302/304 is derived from
the vertical sync signal. If the vertical sync signal
is notpresent, both the vertical and horizontal
frequencies will be zeroes, even if there is a
horizontalsignalpresent.
• If a vertical sync signal is detected and the
horizontal sync is not detected, the vertical
frequencyisdisplayed,but the horizontal
frequency is zeroes.
2. Recheck the previous Easy Setup Procedure steps
for correct cable connections, etc.
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

Extron RGB 302/304 Universal Interface • User’s Manual
Chapter 2 • Installing the RGB 302/304
MemoryCyclingFeature
The RGB 302/304 is preset at the factory with fifteen
video formats which are stored in memory blocks.
These memory blocks contain video formats which
will match most computers. There are also 25
additionalemptymemoryblockswhichareuser-
defined.
When a video input is connected and the RGB 302/
304ispoweredOn,the25user-defined memory
blocks are scanned (cycled) sequentially for a
configurationwhichmatchesthecomputer’s video
input. If a match is found, that format’s stored settings
areimplemented.Ifamatchis not found, the15preset
video formats are scanned next. If a match is found,
thatformatandanyadjustmentsto the image are
automaticallysavedtoauser-definedmemoryblock(if
Memory Cycling is set On). If a match is not found
amongthepresetformats,a new video format will be
createdand stored (see note below) asa user-defined
memoryblock.
The25user-defined memory blocksarefilled
sequentially (1 to 25). If the last empty memory block
(#25)hasalready been filled and a new videoformat is
added,memoryblock#1willbeoverwritten.Additional
newformatswillsequentiallyoverwritememoryblocks
#2, #3, #4, etc., and start over again at memory block
#1, #2, #3, etc.
The15 preset memory blocks arepermanently stored,
while the 25 user-defined memory blocks can only be
clearedby resetting the RGB 302/304(refer to
SystemResetMenu inthe
“OptionControlsMenus”
section of Chapter 3). Powering Off the RGB 302/304
will not delete any of the memory blocks.
____ If Memory Cycling is disabled (set Off), any changes to
avideoconfigurationwillnotbestoredinamemory
block and no new memory blocks will be saved. Refer
toMemoryCyclingMenu inthe“OptionControls
Menus” section of Chapter 3.
Page2-5
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

Extron RGB 302/304 Universal Interface • User’s Manual Page2-6
Chapter 2 • Installing the RGB 302/304
PresetMemory Blocks
TheMemoryCycling featuresupports25user-defined
memoryblocksforstoringvideo configurations and 15
permanentlydefinedmemory blocks.The15preset
memoryblockvideo configurationsarelistedbelow.
No. Format HorizontalFrequency[kHz] VerticalFrequency [Hz]
1 VGA1 31.5 70
2 VGA2 31.5 70
3 VGA3 31.5 60
4 VESA1 35.2 56
5 VESA2 37.9 72
6 VESA3 48.4 60
7 VESA4 56.4 70
8 VESA5 38.0 60
9 VESA6 48.0 72
10 Mac 13" 35.0 67
11 Mac 16" 49.7 75
12 Mac 21" 68.7 75
13 Sun1 71.7 76
14 Sun2 81.0 76
15 SGI 63.9 60
PowerSupplyThe RGB 302/304 is equipped with an internal auto-
switchingpower supply that operates fromany input
voltage in the 100 to 240 VAC, 50/60 Hz range. No
equipmentchangesare necessary.
RS-232InterfaceSpecifications
9600 baud, no parity, 8 data bits and 1 stop bit.
RS-232 Connector Pins are assigned as follows:
Pin Signal Pin Signal Pin Signal
1 — 4 — 7 —
2 Transmit 5 Ground 8 —
3 Receive 6 — 9 —
RS-232
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]
