Extron • System 8/10 PLUS • User’s Manual • P/N 68-403-01 Rev. C
Eiki Installation Configuration and Connections
Page 1
SYSTEM 8/10 Plus
PROJECTOR COMMUNICATIONS KIT
ATTENTION!
PLEASE READ THIS DOCUMENT FOR IMPORTANT
INSTALLATION INSTRUCTIONS
THIS KIT HAS BEEN SHIPPED WITH THE FOLLOWING COMPONENTS:
Kit Type: EIKI
Included Communications Adapter(s):
Quantity Part Number Description
1 26-467-01 ADP, UNV, “A”
1 26-474-01 ADP, UNV, “F”
THE TABLE BELOW LISTS THE POSSIBLE CONFIGURATION(S)AND CORRESPONDING
COMMUNICATIONSADAPTER(S) FOR YOUR PROJECTOR MANUFACTURER’S VARIOUS
MODELS. PLEASE NOTE THAT YOUR SWITCHER HAS BEEN CONFIGURED AS
INDICATED BY THE “✔”IN THE “Config as” COLUMN. IF YOUR PROJECTOR MODEL
DIFFERS FROM THIS CONFIGURATION, YOU MUST RECONFIGURE YOUR SWITCHER
WITH THE CORRECT SETTINGS.
PLEASE REFER TO THE FOLLOWING PAGES FOR COMPLETE CONFIGURATIONAND
SIGNAL CONNECTION INSTRUCTIONS.
THIS SWITCHER HAS BEEN CONFIGURED FOR: EIKI LC-X1, LC-XGA 970
Config Model Rotary Switches Cable SW15 Settings Comm
as RS1 RS2 RS3 RS4 J2/J3 12345678910Adapter
✔Eiki LC-X1 0 0 F B J2 ¯¯¯¯¯ ¯¯26-467-01
✔Eiki XGA 970 0 0 F B J2 ¯¯¯¯¯ ¯¯26-474-01
Eiki Powerhouse Two 2 0 F B J2 ¯¯¯¯¯ ¯¯26-467-01

Extron • System 8/10 PLUS • User’s Manual • P/N 68-403-01 Rev. C
Eiki Installation Configuration and Connections
Page 2
Eiki LC-X1/XGA 970 Projector Configuration
Verify that the System 8/10 PLUS is already configured for the Eiki LC-X1/XGA
970 projector. The general setup is explained on page 3-4 and the switch
settings for the projector are repeated below.
1. Use a small screwdriver to remove the access cover from the System 8/10 PLUS
front panel. See bottom of page 3-3. The label on the back of the access cover
also has the configuration information.
__________ Before changing anything, remove the AC power cord to the System 8/10 PLUS
to verify that the main power is OFF; also turn the projector power OFF.
2. Set the switches as follows:
Config Model Rotary Switches Cable SW15 Settings Comm
as RS1 RS2 RS3 RS4 J2/J3 1 2 3 4 5 6 7 8 9 10 Adapter
✔Eiki LC-X1/XGA970 0 0 F B J2 ¯¯¯¯ ¯¯¯ 26-467-01
or 26-474-01
_ RS5 is for RGB switching
delay. See page 3-4 for
more information on switch
functions.
3. Use a grease pencil (or other rub-off marker) to mark the space on the label next
to “Eiki LC-X1/XGA970”.
4. Locate the switcher’s Address DIP switches on the rear panel, lower right.
Unless this is part of a host/peripheral system, set #3 and #5 to the up position
and the others down. See illustration to the left.
Use the illustration on the facing page to do the following steps.
5. Connect the Comm Adapter’s 9-pin male connector to the 9-pin female serial
port connector on the rear panel of the projector.
6. Connect the CC-50' (or CC-100') cable from the 9-pin male connector of the
Comm Adapter to the 15-pin HD “Projector Control” port located on the rear
panel of the System 8/10 PLUS.
______ Secure the screws on all D connectors.
7. Connect the BNC (RGBS) cables from the System 8/10 PLUS outputs to the Eiki
projector inputs according to the application requirements.
8. Apply Main Power to the System 8/10 PLUS by connecting the power cord. The
Main Power LED should light. Apply power to the projector.
9. Return System 8/10 PLUS and projector to normal operation.
Configured For:
RS-232
3456 7891012
SW15 DIP Switch
ON
RS5 RS2
RS2
RS1
RS3
RS4
RS1
RS3 RS4

Extron • System 8/10 PLUS • User’s Manual • P/N 68-403-01 Rev. C
Eiki Installation Configuration and Connections
Page 3
Eiki LC-X1/XGA 970 Projector Connections
Use the illustration below when connecting the System 8/10 PLUS to an Eiki LC-
X1/XGA 970 projector. Refer to Eiki documentation to continue the installation.
_ If the installation includes looping (host/peripheral) switchers, see Chapter 5.
If Video Loop Back is part of the installation, see pages 2-10 and 2-11.
R
AUDIO 1
ANALOG RGB
ANALOG RGB
CONTROL PORT 1USB 1
GBHV
RL
AUDIO 1VIDEO/Y C/Cb(B-Y) Cr(R-Y) S-VIDEO
S-VIDEO
S-VIDEO
RL
AUDIO 2
CONTROL PORT 2
SERIAL PORTAC JACK
USB 2
RL
AUDIO OUT
RL
AUDIO 1VIDEO/Y C/Cb(B-Y) Cr(R-Y)
RL
AUDIO 1VIDEO/Y C/Cb(B-Y) Cr(R-Y)
RL
RGBHV 5 BNC
15-Pin Male
S-Video
Composite
Video 9-Pin Female
9-Pin Male
9-Pin Male
ComAdapter
26-467-01 "A"
or 26-474-01 "F" A

Extron • System 8/10 PLUS • User’s Manual • P/N 68-403-01 Rev. C
Eiki Installation Configuration and Connections
Page 4
Eiki Powerhouse Two Projector Configuration
Verify that the System 8/10 PLUS is already configured for the Eiki Powerhouse
Two projector. The general setup is explained on page 3-4 and the switch
settings for the projector are repeated below.
1. Use a small screwdriver to remove the access cover from the System 8/10 PLUS
front panel. See bottom of page 3-3. The label on the back of the access cover
also has the configuration information.
__________ Before changing anything, remove the AC power cord to the System 8/10 PLUS
to verify that the main power is OFF; also turn the projector power OFF.
2. Set the switches as follows:
Config Model Rotary Switches Cable SW15 Settings Comm
as RS1 RS2 RS3 RS4 J2/J3 1 2 3 4 5 6 7 8 9 10 Adapter
Eiki Powerhouse Two 2 0 F B J2 ¯¯¯¯ ¯¯¯ 26-467-01
_ RS5 is for RGB switching
delay. See page 3-4 for
more information on switch
functions.
3. Use a grease pencil (or other rub-off marker) to mark the space on the label next
to “Eiki Powerhouse Two”.
4. Locate the switcher’s Address DIP switches on the rear panel, lower right.
Unless this is part of a host/peripheral system, set #3 and #5 to the up position
and the others down. See illustration to the left.
Use the illustration on the facing page to do the following steps.
5. Connect the Comm Adapter’s 9-pin male connector to the 9-pin female serial
port connector on the rear panel of the projector.
6. Connect the CC-50' (or CC-100') cable from the 9-pin male connector of the
Comm Adapter to the 15-pin HD “Projector Control”port located on the rear
panel of the System 8/10 PLUS.
______ Secure the screws on all D connectors.
7. Connect the BNC (RGBS) cables from the System 8/10 PLUS outputs to the Eiki
projector inputs according to the application requirements.
8. Apply Main Power to the System 8/10 PLUS by connecting the power cord. The
Main Power LED should light. Apply power to the projector.
9. Return System 8/10 PLUS and projector to normal operation.
Configured For:
RS-232
3456 7891012
SW15 DIP Switch
ON
RS5 RS2
RS2
RS1
RS3
RS4
RS1
RS3 RS4

Extron • System 8/10 PLUS • User’s Manual • P/N 68-403-01 Rev. C
Eiki Installation Configuration and Connections
Page 5
Eiki Powerhouse Two Projector Connections
Use the illustration below when connecting the System 8/10 PLUS to an Eiki
Powerhouse Two projector. Refer to Eiki documentation to continue the
installation.
_ If the installation includes looping (host/peripheral) switchers, see Chapter 5.
If Video Loop Back is part of the installation, see pages 2-10 and 2-11.
R
AUDIO 1 ANALOG RGB
ANALOG RGB
CONTROL PORT 1USB 1
GBHV
RL
AUDIO 1VIDEO/Y C/Cb(B-Y) Cr(R-Y) S-VIDEO
S-VIDEO
S-VIDEO
RL
AUDIO 2
CONTROL PORT 2
SERIAL PORTAC JACK
USB 2
RL
AUDIO OUT
RL
AUDIO 1VIDEO/Y C/Cb(B-Y) Cr(R-Y)
RL
AUDIO 1VIDEO/Y C/Cb(B-Y) Cr(R-Y)
RL
DIGITAL
RGBHV 5 BNC
15-Pin Male
S-Video
Composite
Video 9-Pin Female
9-Pin Male
9-Pin Male
Comm Adapter
26-467-01 "A" A
