extronics iSCAN2012D User manual

Extronics Limited
1 Dalton Way, Midpoint 18, Middlewich, Cheshire, UK. CW10 0HU
Tel: [phone] Fax: [phone] E-mail: [e-mail] Web: www.extronics.com 1
Operating Instructions
Bluetooth Handheld Scanner
iSCAN2012D
iSCAN211
iSCAN211PDF
Revision date: 18.3.2016

Extronics Limited
1 Dalton Way, Midpoint 18, Middlewich, Cheshire, UK. CW10 0HU
Tel: [phone] Fax: [phone] E-mail: [e-mail] Web: www.extronics.com 2
Contents
1. iSCAN2x1 product range overview .................................................................................................3
2. Important notes on the operating instructions ..............................................................................4
2.1 Safety information .................................................................................................................. 4
2.2 Notes on the operating instructions....................................................................................... 4
2.3 General notes of caution ........................................................................................................ 5
3. Product Information ....................................................................................................................... 7
3.1 Manufacturer.......................................................................................................................... 7
3.2 Certification.............................................................................................................................7
3.3 Serial numbers ........................................................................................................................ 7
3.4 Technical data for base/charging station................................................................................8
4 System assembly.............................................................................................................................9
4.1 Assembly 1 description ................................................................................................................. 9
4.2 Cable range in assembly 1...........................................................................................................10
4.3 Assembly 2 description ...............................................................................................................10
4.4 Cable range in assembly 2...........................................................................................................11
5 Step by step guide to installation and operation..........................................................................12
5.1 General connection of handheld scanner.............................................................................12
5.2 Using the base station in hazardous areas (assembly 1) ......................................................13
5.3 Using the base station in non-hazardous areas (assembly 2)...............................................14
5.4 Connection of RS232 iSCANPS power supply .......................................................................15
5.5 Connection of USB iSCANPS power supply...........................................................................17
Revision control
Document Number 416238, revision 2.0
© This document is copyright Extronics Limited 2016.
Extronics reserve the right to change this document and its content without notice. The latest
version applies.

Extronics Limited
1 Dalton Way, Midpoint 18, Middlewich, Cheshire, UK. CW10 0HU
Tel: [phone] Fax: [phone] E-mail: [e-mail] Web: www.extronics.com 3
1. iSCAN2x1 product range overview
Bluetooth handheld
scanner
Standard 1D
iSCAN211
Standard and stacked
PDF iSCAN211PDF
iSCAN211EXB
iSCAN2XXCAB5
iSCAN2XXCAB6
iSCAN2XXCAB7
iSCAN2XXCAB8
iSCAN2XXCAB9
iSCAN2XXCAB10
iSCANPS1
iSCANPS2
iSCANPS3
iSCANPS4
iSCAN211B
iSCAN211BNOBT
iSCAN2XXCAB1
iSCAN2XXCAB2
iSCAN2XXBLP
iSCAN2XXCAB3
iSCAN2XXCAB4
Standard 1D, stacked
PDF, and 2D
ISCAN2012D
iSCAN201EXB2D
iSCAN2XXCAB5
iSCAN2XXCAB6
iSCAN2XXCAB7
iSCAN2XXCAB8
iSCAN2XXCAB9
iSCAN2XXCAB10
iSCANPS1
iSCANPS2
iSCANPS3
iSCANPS4
iSCAN201B2D
iSCAN201BNOBT2D
iSCAN2XXCAB1
iSCAN2XXCAB2
iSCAN2XXBLP
iSCAN2XXCAB3
iSCAN2XXCAB4

Extronics Limited
1 Dalton Way, Midpoint 18, Middlewich, Cheshire, UK. CW10 0HU
Tel: [phone] Fax: [phone] E-mail: [email protected] Web: www.extronics.com 4
2. Important notes on the operating instructions
2.1 Safety information
Warnings are highlighted by a special symbol and a different font colour:
Danger
Non-compliance may result in life-threatening situations.
This warning must be heeded.
Warning
This type of warning concerns dangerous situations that may result in minor injuries.
Info
Important and helpful notes and information.
2.2 Notes on the operating instructions
Before starting up the equipment please read the Manual thoroughly.
The Operating Instructions contain important information on functionality as well as safety rules.
If these are not heeded, normal operations within hazardous areas cannot be guaranteed.
The notes contained in this manual are important for starting up and operating the product.
These instructions may be updated at any time. Extronics Limited reserves the right to make changes
to this document. Before they use the product, users must ensure that they have the most up-to-
date version of the operating instructions. To make sure this is the case, please check Extronics’
website, www.extronics.com, or contact one of the company's staff.
The drawings contained in these operating instructions are for illustration purposes only and may
differ somewhat from the actual design.
No changes may be made to the device that were not intended or approved
by Extronics Limited.

Extronics Limited
1 Dalton Way, Midpoint 18, Middlewich, Cheshire, UK. CW10 0HU
Tel: [phone] Fax: [phone] E-mail: [email protected] Web: www.extronics.com 5
If the handheld scanner is not used properly, the operating permission for hazardous areas may lapse
for the device in question.
Non-adherence to the instructions will void any warranty.
For the full commission of the handheld scanner, the programming information contained
in the manual issued by SICK AG (www.SICK.com) is also required.
2.3 General notes of caution
Caution / Notes
The devices may only be operated when fully assembled.
In hazardous areas, the devices must not be wiped or cleaned with a dry
cloth.
The device must be switched off immediately if it is likely that it can no
longer be operated safely as a result of damaging impact or general
peculiarities (such as ingress of water or other fluids, temperatures outside
of the specified range, etc.).
General statutory requirements or health and safety rules and accident
prevention guidelines and environmental laws must be adhered to (e.g.
the German Occupational Health and Safety regulation).
Users must not open the device.
Users must not make any changes to the device. Components may not be
exchanged or replaced. If non-specified components are used, explosion
protection is no longer guaranteed.
Ensure safe handling with firm footing and sufficient room for movement.
If the enclosure is in any way damaged the device must be removed from
the hazardous area immediately.
In accordance with IEC 60079-19 and IEC 60079-17, operators of electrical
installation in hazardous areas are obliged to have them serviced by
qualified electricians.
Do not insert any sharp objects into the enclosure or any other openings of
the handheld barcode scanner. Any openings at the device may not be
covered or blocked.
The device and any accessories must be properly disposed of, i.e. as legally
specified, for example by a certified company.

Extronics Limited
1 Dalton Way, Midpoint 18, Middlewich, Cheshire, UK. CW10 0HU
Tel: [phone] Fax: [phone] E-mail: [email protected] Web: www.extronics.com 6
Notes on
installation
Electrical plants are subject to certain regulations concerning installation
and operation (e.g. RL 99/92/EG, RL 94/9EG, or the national rules such as
IEC 60 079-14 and VDE 0100).
In the hazardous area it is the operator's responsibility to carry out any
repair and maintenance in compliance with applicable rules.
Caution
on laser devices
Devices fitted with laser fall under standards US 21 CFR 1040.10 and EN 60825-
1. The laser's classification is stated on a plate affixed to the device. Class 1
lasers are deemed inherently safe during normal use, but users must not look
directly into the light source. The following declaration is required by American
and international laws:
Usage of control elements, adaptations or the use of procedures that differ
from these instructions may result in a dangerous exposure to laser beams.
Class 2 lasers use a visible low-voltage LED. As with any source of bright light,
such as the sun, the user should avoid looking directly into the light. Brief
exposure to a class 2 laser is deemed not dangerous.
Maintenance
Provided the device is operated and assembled according to instructions and
the ambient requirements are being met continuous maintenance is not
necessary.
Servicing
Operators of electric equipment in hazardous areas are obliged to have them
serviced by qualified electricians (IEC 60079-19 and IEC 60079-17).
Repairs
Repairs may only be carried out by the manufacturer or by persons trained and
commissioned for this purpose by the manufacturer.
The device is closed ex-factory. It may only be opened in the factory by specifically trained
personnel.
Software
installation
For instructions on how to install the software at the PC please refer to the
manual issued by SICK.
Operation
Before operating the device you must ensure that all necessary components
are available.

Extronics Limited
1 Dalton Way, Midpoint 18, Middlewich, Cheshire, UK. CW10 0HU
Tel: [phone] Fax: [phone] E-mail: [email protected] Web: www.extronics.com 7
3. Product Information
3.1 Manufacturer
Extronics Limited
1 Dalton Way
Midpoint 18
Middlewich
CW10 0HU
3.2 Certification
3.3 Serial numbers
Serial key:
Year of manufacture
(2 numbers)
Serial number
(4 numbers)
Example:
16001
iSCAN211 and
iSCAN211PDF:
II 2 G Ex ib IIC T4
II 2 G Ex ib IIC T4 Gb
II 2 D Ex ib IIIC T135C
II 2 D Ex ib IIIC T135C Db
iSCAN2012D:
II 2G Ex ib IIB T4
II 2G Ex ib IIB T4 Gb
II 2D Ex ib IIIC T135°C
II 2D Ex ib IIIC T135°C Db
Test certificate
IBExU15ATEX1084
IECEx IBE 15.0024
Protection rating
IP65

Extronics Limited
1 Dalton Way, Midpoint 18, Middlewich, Cheshire, UK. CW10 0HU
Tel: [phone] Fax: [phone] E-mail: [email protected] Web: www.extronics.com 8
3.4 Technical data for base/charging station
Ambient temperature for
base station:
-20°C to +50°C
Bluetooth:
iSCAN211 and iSCAN211PDF:
Bluetooth V2.1 EDR, Class 2
2.4…2.4835 GHZ (ISM band)
iSCAN2012D:
Bluetooth V4.0 EDR, Class 1
2.4…2.4835 GHZ (ISM band)
Terminal assignment
(Handheld scanner)
USB cable
RS232 cable
USB/D+ green
USB/D- white
GND black
+UB brown
RS232-TXD white
GND brown
+UB yellow
Nominal values of
hazardous area base
station:
maximum input voltage
Ui
4.9 V
maximum input current
li
480 mA
maximum input power
Pi
1.25 W
maximum internal inductance
Li
negligible
maximum internal capacitance
Ci
112.4 µF
If using a power supply other than iSCANPSx:
maximum input voltage
Ui
5.6 V
maximum input current
li
480 mA
maximum input power
Pi
1.25 W
maximum internal inductance
Li
negligible
maximum internal capacitance
Ci
46 µF
Note: The input voltage in to the handheld scanner itself is reduced by the
associated connection cable ISCAN2XXCAB7 or 8 to 4.9V.
Nominal values of safe
area base station:
operating voltage
U
5V
power requirement
I
85 mA in standby mode

Extronics Limited
1 Dalton Way, Midpoint 18, Middlewich, Cheshire, UK. CW10 0HU
Tel: [phone] Fax: [phone] E-mail: [email protected] Web: www.extronics.com 9
4System assembly
4.1 Assembly 1 description
The Bluetooth handheld scanner was designed for use in hazardous areas. Normal operation requires
a base station, a connection cable between base station and power supply, power supply, and
connection cable(s) between power supply and a PC.
External connection cables:
Data cable:
USB 0.2 - 2.5 mm², 4-wire
RS232 0.2 - 2.5 mm², 3-wire
Power cable:
0.2 - 2.5 mm², 3-wire
The handheld scanner and the power supply can be connected and operated in the hazardous area.
For safe installation please refer to the manual issued by SICK AG (www.SICK.com)
The warnings and notes of caution contained in these operating instructions and in the
manual issued by SICK AG (www.SICK.com) must be adhered to.
For the professional use of the power supply iSCANPS the operating instructions of the
manual of the power supply are necessary.

Extronics Limited
1 Dalton Way, Midpoint 18, Middlewich, Cheshire, UK. CW10 0HU
Tel: [phone] Fax: [phone] E-mail: [email protected] Web: www.extronics.com 10
4.2 Cable range in assembly 1
4.3 Assembly 2 description
The Bluetooth handheld scanner can also be used separately in the hazardous area. The base or
charging station is then operated in the non-hazardous area.
Use an RS232 cable (iSCAN2XXCAB1 or 2) or a USB cable (iSCAN2XXCAB3 or 4) to connect the station
directly to a power supply and a PC.
The warnings and notes of caution contained in these operating instructions and in the
manual issued by SICK AG (www.SICK.com) must be adhered to.
RS232
iSCAN211EXB
iSCAN201EXB2D
1.8 or 3.8m
or optional with
4.5m or 6m
extension
iSCANPS
Up to 20m
Host
USB
iSCAN211EXB
iSCAN201EXB2D
1.8 or 3.8 m
iSCANPS
Up to 5m
Host
