1Product Overview
Thank You for your interest in AVG Automation’s latest unique offering, the EZ7 Series TouchPLC.
EZ7-TouchPLC is two piece products: Front part consisting of display (and touch screen) housed in metal, and a back
part that has PLC processor. Front part is installed on the front of the control cabinet, while the back part is installed
on the back of the control cabinet door. The two are connected using a cable.
This construction has following benefits:
No large cutouts for the Front and Back PLC, only drill holes for the studs, and a hold for cable
Easily replace worn-out touch screens instead of changing whole unit
If required, upgrade to larger display sizes without need to change the back.
Use the same EZTouch editor that is used for other EZTouch families of TouchPLC
Support for a variety of PLC Protocols including DH+ and Remote I/O
1.1 System Diagram
1.2 Documents for more information
This manual provides information on installation, wiring and getting started with editor software. Editor software
provides help on software. Following documents have more detailed information on the Panel and PLC:
1. EZ Series Touch Panel Software
2. Micro Touch PLC Manual
Serial or Ethernet or USB Connection
for programming and monitoring
PC running
EZTouch Editor
EZ7-TouchPLC

Page 5of 44
EZ7-TouchPLC Micro
2Part Number
EZ7 is available in 7, 8, 10, and 12 inch display sizes:
EZ7DT-TxC-xx-MICROxx-PLC
Programming software and cable
EZTOUCH-EDITOR TouchPLC Editor runs on windows 7 or higher (common to all EZTouchPLC models)
EZ-PGMCBL Serial cable for PC to TOUCHPLC connection
Replacement Part numbers
Back only
EZ7DT-PLC-4BACK EZ7 4 Slot PLC Back (PLC Processor unit)
EZ7DT-PLC-8BACK EZ7 8 Slot PLC Back (PLC Processor unit)
Front (Displays including Touch screen)
EZ7DT-T7C-FR EZ7 7” Inch Display Only
EZ7DT-T8C-FR EZ7 8” Inch Display Only
EZ7DT-T10C-FR EZ7 10” Inch Display Only
EZ7DT-T12C-FR EZ7 12” Inch Display Only
Cable
EZ7DT-CBL-012 Cable between Front and back of EZ7, 12”
Use
For
40
40 I/O ; 24 DC Inputs, 8 DC Outputs, 8 Relay
outputs
44
44 I/O ; 24 DC Inputs, 8 DC Outputs, 8 Relay
outputs, 2 Analog Inputs, 2 Analog outputs
(Voltage)
48
48 I/O ; 24 DC Inputs, 8 DC Outputs, 8 Relay
outputs, 4 Analog Inputs, 4 Analog outputs
(Voltage)
Use
For
E
Ethernet
EH
Ethernet and DH+
Use
For
7
7” TFT Color
8
8” TFT Color
10
10” TFT Color
12
12” TFT Color
Display Sizes
Connectivity
Number of I/O

Page 6of 44
EZ7-TouchPLC Micro
3Specification
EZ7TouchPLC Micro Model Specifications
Part Number
EZ7DT-T7C-E-Micro40-PLC
EZ7DT-T8C-E-Micro40-PLC
EZ7DT-T10C-E-Micro40-PLC
EZ7DT-T12C-E-Micro40-PLC
EZ7DT-T7C-E-Micro44-PLC
EZ7DT-T8C-E-Micro44-PLC
EZ7DT-T10C-E-Micro44-PLC
EZ7DT-T12C-E-Micro44-PLC
EZ7DT-T7C-E-Micro48-PLC
EZ7DT-T8C-E-Micro48-PLC
EZ7DT-T10C-E-Micro48-PLC
EZ7DT-T12C-E-Micro48-PLC
EZ7DT-T8C-EH-Micro40-PLC
EZ7DT-T10C-EH-Micro40-PLC
EZ7DT-T12C-EH-Micro40-PLC
EZ7DT-T8C-EH-Micro44-PLC
EZ7DT-T10C-EH-Micro44-PLC
EZ7DT-T12C-EH-Micro44-PLC
EZ7DT-T8C-EH-Micro48-PLC
EZ7DT-T10C-EH-Micro48-PLC
EZ7DT-T12C-EH-Micro48-PLC
Enclosure
Metal front bezel connects to back-end through HDMI cable, NEMA 4, 4X Class I Div II
Digital Inputs
24 Electrically Isolated 24 VDC Inputs
Digital Outputs
8 Short Circuit Proof 24 VDC Outputs
Relay Outputs
8 Relay Outputs (1 Form C Relays rated at 10 Amps each with RC Snubber Protection) up to 1 million cycles
Analog Inputs
4 12-bit resolution 0-10V inputs or 2, 12-bit resolution 4-20mA Inputs
Analog Outputs
4 12-bit resolution 0-10V inputs or 2, 12-bit resolution 4-20mA Outputs
High Speed Counter
2 Inputs can be configured as 2 x 32 bit UP counter, or 1 x 32 bit Up-DOWN counter, or 1 x 32 bit Quadrature Encoder 40 KHz
Display Type
7” TFT (65K Colors)
8” TFT (65K Colors)
10.4” TFT (65K Colors)
12.0” TFT w/Built-in Anti-glare
Brightness/Life
400 nits / 75,000 hours@55 ° C
500 nits / 75,000 hours@55 ° C
Screen Resolution
800 x 480
800 x 600
1024 x 768
Touch Screen
5-wire Analog Resistive Touch Screen
Num of Display
Screens
Up to 999 Limited by display memory
Display Screen Saver
Yes, Backlight Off
HMI User Memory
2MB Built-in Flash Memory (Note Due to how HMI memory is consumed in the EZTouch Hardware this is sufficient for 99% of
16 GB SSD
Maximum
applications)
Power Consumption
15 Watts @ 24 VDC
25 Watts @ 24VDC
Processors
Two 32 Bit, 40 MHz RISC Processors (One for PLC and One for HMI)
Intel Atom E640 1 GHz
Total PLC Memory
64 KB (Ladder)
# of PLC Registers
8192 16Bit, 8192 Variables
PLC Typical Scan
Time
3ms (1K Boolean)
Real Time Clock/Cal.
No PLC Real-time Clock, HMI has RTC
Battery Backup
Yes (Required only for Real Time Clock as everything else is stored in Flash)
PLC LED Indicators
Input Power, CPU Status
I/O Supported
Fixed I/O with Status LEDs
Electrical Noise
Nema ICS 2-230 Showering arc; ANSI C37.90a SWC; Level C Chattering Relay Test
Withstand Voltage
1000VDC (1 minute between power supply input terminal and protective ground)
Insulation Resistance
Over 20M Ohm between power supply input and terminal and protective ground
Enclosure
Nema 4, 4x (indoor)
Operating
Temperature
0 to 55°C (32 to 131°F)
Storage Temperature
-25 to 65°C (-13 to 149°F)
Vibration
5 to 55Hz 2G’s for 2 hours in X,Y,and Z axis
Shock
10G for under 12ms in the X,Y, and Z axis
Humidity
10-95% Non-Condensing
USB & microSD ports
1 USB port for programming, 1 USB port for Datalogging and 1 microSD slot for additional data storage
Communication Ports
Built-in USB, RS232 and Ethernet Ports
Agency Approval
UL, CUL, CE
External Dimensions
8.048” x 6.146” x 4.325”
10.894” x 8.748” x 4.363”
13.584”x10.594”x 4.299”
13.00”x16.75”x6.25”
(204.41 x 156.11 x 109.87mm)
(276.71 x 222.20 x 110.82mm)
(34 5x 269.1 x 109.20mm)
(330.2 x 425.25 x 158.7mm)
Weight
2 lbs
3.5 lbs
4.5 lbs
7 lbs

Page 7of 44
EZ7-TouchPLC Micro
4Quick-Start
System diagram shown in introduction is repeated here. As shown, EZTouch Editor is required to program EZ7-
TouchPLC. This is a common editor software for all EZTouch Families of panels.
Pre-requisite- Make sure you have everything you need:
This is what you will need to get started:
EZ7-TouchPLC Unit
A PC Running Windows 7 or Windows 10 with EZTouch Editor Programming Software* installed
Proper cable to connect the PC to EZ7 Panel for project transfer and monitoring:
oRS-232C Programming cable (P/N EZ-PGMCBL) (or make your own) *, and/or
oUSB Type A to Type B cable, and/or
oEthernet cable (Ethernet IP must be setup before using Ethernet connection)
24VDC Power Supply*
Optionally, your plc and connecting cable
*These accessories have to be purchased separately
Follow these steps to get started:
1. Please connect power to the unit, and (optionally) connect your PLC.
2. If not already done, please Install EZTouch Editor on the PC. See below.
3. Run EZTouch Edit and start creating project
4. Transfer the project to the panel and start working with screens.
Serial or Ethernet or USB Connection
PC running
EZTouch Editor
EZ7-TouchPLC

Page 8of 44
EZ7-TouchPLC Micro
5Installation
Guidelines
Safety Considerations
Please follow all applicable local and national codes to ensure maximum safety of the equipment and personnel. The
installation and operational environment must be maintained per the latest revision of these codes.
You are responsible to determine the codes to be followed and to verify the compliance of equipment, installation,
and operation with the latest revision of these codes.
It is an absolute must to follow all applicable sections of:
The National Fire Code
The National Electrical Code (NEC)
The National Electrical Manufacturer's Association (NEMA) codes
Safety Guidelines
Safety is the most important element of a proper system installation. Adhering to these safety considerations ensures
the safety of yourself and others, as well as the condition of your equipment. We recommend reviewing the following
safety guidelines:
1) Disconnecting Main Power
The main power switch should be easily accessible to the operators and maintenance personnel. It is important
to make sure that all other sources of power including pneumatic and hydraulic are de-energized before
starting the work on a machine or process controlled by an EZ7 Series TouchPLC.
2) Safety Circuits
Most of the machines are installed with safety circuits such as limit switches, emergency stop push buttons,
and interlocks. These circuits should always be hardwired directly to the EZ7 Series TOUCHPLC. These devices
must be wired in series so that when any one device opens, the PLC is automatically de-energized. This
removes power to the machine. These circuits should not be altered in any case, since this could result in
serious injury or damage to the machine.
3) Fail-Safe Operation
Our products are not fault-tolerant. They are not designed or intended for use as online control equipment in
hazardous environments requiring fail-safe performance, such as in operation of nuclear facilities, aircraft
navigation or communication systems, air traffic control, direct life-support machines, weapons systems,
clutch control systems on presses, in which the failure of the product could lead directly to death, personal
injury or severe physical or environmental damage. External fail-safe and/or redundant components are
required to make your control system fail-safe.
Installation Considerations
Our products have been designed and tested for operation in the most demanding industrial environments. Modern
solid-state industrial controls are complex electronic equipment that operate at low levels of voltage and current, co-
existing with components that operate at much higher levels of power. The difference in operating power
characteristics between the high and low power control devices creates the possibility of unwanted signals being
generated, thus causing interference. The interference, which is a by-product of electrical noise, is not present at all
times. However, if it appears at random and for brief periods of time, it can cause disruptions and errors in the
operation of a control system.
Enhancement of a system’s noise level immunity and its tolerance to other environmental hazards can be
accomplished by following proper system installation guidelines. The recommendations are of a general nature and
constitute good industrial installation practice.

Page 9of 44
EZ7-TouchPLC Micro
General Environmental Considerations
Avoid installing EZ7 Series TouchPLC in areas where the following conditions may exist:
Environmental temperatures above or below those specified by the EZ7 Series TouchPLC
Prolonged exposure to humidity and liquids which may be sprayed or splashed on the equipment
Dusty environments where airborne particles may accumulate on equipment causing reduction of heat
dissipation and reduction in effective electrical spacing between components
Areas with excessive vibration
Areas with high-radiated electrical noise, such as near fields of transmitting antennas and areas in close
proximity of arc welding stations
Physical Layout in a Control Cabinet
When possible, cabinets housing electronic equipment should be designed with provisions for natural or forced
ventilation to facilitate heat dissipation. Observe the following rules for cabinet installation:
Heat generating equipment (power supplies and other heat inducing components) should be installed toward
the top of the cabinet. The lower space in the cabinet is cooler than the top area.
Install heat-sensitive components in the lower section.
Provide enough space between components to allow a free flow of air for better heat dissipation.
Provide the maximum possible physical separation between solid state and electromechanical controls. If
possible, the electromechanical controls (motors, starters, solenoids, etc.) should be housed separately or at
the farthest point when enclosed within the cabinet.
We recommend that the EZ7 Series TOUCHPLC have a minimum clear space of 2" on all sides for adequate
ventilation as shown in the image on the left.
Electrical Considerations
This section is designed to provide you with a very basic understanding of electrical noise and how to keep it away
from CPUs. Industrial plants have a number of generators of electrical noise that are sometimes also referred to as
Radio Frequency Interference (RFI). Anytime an inductive load like a motor, motor starter, or solenoid is turned off, it
generates a burst of excess energy that has to flow back to ground, just like electrical energy from a lightning storm
has to flow back to Earth. RFI is short bursts of electrical energy at very high frequencies. Other sources include RF
Welders or Radio Transmitters.
Effect of RFI on Electronic Automation Equipment
Electronic controls use faster and faster CPUs today. These CPUs are also operating at 2.5V to 5VDC logic level power
supply. RFI, if allowed to enter the CPU inside, is a killer of logic. A CPU under this environment loses its brain and
behaves erratically. A smart industrial-grade CPU like the EZ7 Series
TOUCHPLC Card Engine, when faced with RFI, halts its operation instead of
giving false outputs.
Types of RFI
RFI enters electronic controls in two ways: radiated RFI or conducted RFI.
For most practical purposes, electronic devices, unless sitting right next to a
powerful RFI transmitter, will not be affected by noise because air space
severely attenuates such interference. On the other hand, conducted RFI
travels over conductive surfaces such as power supply wires, electrical
wiring of field devices, and worst of all; improper ground planes.
Equipment cabinets usually incorporate one or two doors and/or hinged cabinet panels. Relying on door hinges and
swinging panels for a good metallic bond between hinged parts and the main body of the cabinet does not insure
adequate grounding. Instead, the use of ground straps is recommended. It is vital for the reliable operation of any
electronic device to have any of its metallic surfaces well ground to Earth. This not only provides for safe operation, it
will also drain out any conducted RFI to Earth, away from the CPU's signal ground.

Page 10 of 44
EZ7-TouchPLC Micro
Shielding from RFI
Shielded Cables
Power cables, I/O cables or wiring, and communication cables should all be separate so that they do not couple the
conducted RFI on any of these wires/cables. Another path for RFI into the PLC is through its RS232 port. Hence, the
cables to this port must be shielded properly.
Equipment Cabinets
As mentioned, equipment cabinets typically incorporate one or two doors and/or hinged cabinet panels. In addition,
sub-panels may be utilized on those electronic controls and electromechanical items that are mounted. The goal is to
create a medium for mounting the equipment and ensure grounding of the control’s chassis to it. However, the door
hinges and swinging panels by themselves are not enough to ensure adequate grounding.
Similarly, the equipment enclosures are generally either painted or
anodized. Mounting of painted or anodized enclosures to like
surfaces also does not ensure good metallic contact between the
equipment chassis and cabinet. It is imperative that the equipment
chassis are grounded such as through the use of grounding straps as
illustrated below.
Cabinet Wiring
The wiring of the EZ7 Series TOUCHPLC to the “field” outside the
cabinet must be by design. The wiring cannot be random in order to
get the various points of the cabinet and the “field” electrically
connected. Below are some general rules that apply in most
situations:
Provide a separate power source to electronic controls and keep this power bus away from any I/O power.
The cabinet should be wired with a safety ground (the main safety ground wire gauge is determined by the cabinet’s
total current consumption) and in accordance with all electrical code requirements.
Once the cabinet doors, stationary sub-panels and swing-out sub-panels have been “strapped” to the main cabinet, it
is not necessary to run safety ground wires from the equipment chassis terminals to the main safety ground
connection.
The safety ground terminal of each component can, and should be, connected with the shortest wire possible, to the
cabinet or sub-panel frame.
Plan the wiring routing. Keep all switched power in separate ducts and if there is AC and DC power being switched,
keep the wiring of each branch separate from all wires and cables carrying low level signals.
Keep all three phase power outside of the cabinet, but if it becomes necessary, keep the runs as short as possible and
maintain the maximum possible distance between the three phase bus and all other wiring.
Primary power leads to the control equipment (Base power terminals) should be made with a two wire twisted cable
with approximately 12 turns per foot. The length of these cables should be kept to a minimum, and to the greatest
extent possible, such cable runs should be kept separate from other wiring.

Page 11 of 44
EZ7-TouchPLC Micro
Mounting Information
5.2.1 Overall Dimensions
Unit Size
A
B
C
D
E
F
G
H
7”
8.66[220]
6.09[154.8]
5.91[150]
3.43[87.1]
7.42[188.3]
4.81[122.2]
0.78[19.9]
5.52[140.2]
8”
10.61[269.6]
6.41[162.8]
8.52[216.4]
4.81[122.3]
9.89[251.3]
4.81[[122.3]
0.78[19.9]
5.52[140.2]
10”
12.00[304.8]
8.37[212.6]
9.50[241.3]
6.25[158.6]
9.89[251.2]
4.81[122.3]
0.78[19.9]
5.52[140.2]
12”
13.19[335]
9.80[249]
10.63[270]
7.38[187.5]
9.89[251.3]
4.81[122.3]
0.97[24.7]
5.52[140.2]

Page 12 of 44
EZ7-TouchPLC Micro
5.2.2 T7C (7” Display) Mounting dimensions
5.2.3 T8C (8” Display) Mounting dimensions

Page 13 of 44
EZ7-TouchPLC Micro
5.2.4 T10C (10” Display) Mounting dimensions
5.2.5 T12C (12” Display) Mounting dimensions

Page 14 of 44
EZ7-TouchPLC Micro
Mounting Instructions
EZ7-TouchPLC comes in two parts:
1. TouchPLC Processor Unit, mounted using 4 studs on backside of the control cabinet door
2. Display Unit, mounted on studs (number of studs depends on size).
A cable connects the two parts, which passes through a ¾” hole in the cabinet door.
To mount the unit, in summary:
Mark location of all holes
Drill holes for the back and front unit mounting studs. (Please note that the mounting holes for the back unit
require countersink holes.
Drill ¾” hole for the cable.
Connect display cable to the back side and mount the back side
Thread the display cable through ¾” cable hole to the other side.
Connect cable to front side and mount the front unit.
These steps are described below with pictures:
The EZ7-TouchPLC is stud mounted. All the necessary mounting hardware is provided with the unit. Both the processor
and the TOUCHPLC screen have studs with nuts provided. Below is a full installation guide with step by step
instructions.
1. Use the provided screen with screw holes indicators to drill holes in your control cabinet.

Page 15 of 44
EZ7-TouchPLC Micro
2. Once all the holes have been drilled in the cabinet. Take the Processor Box and plug in the provided HDMI
cable into its connector port.
3. Then use the provided screws (6-32 Philips Flat head ½” length. (X 4),Screw driver – Philips #2 ) to install the
Processor Box to the inside of the Control Cabinet. Also make sure that the HDMI cable is pulled through the
large middle hole.

Page 16 of 44
EZ7-TouchPLC Micro
4. Now connect the cable to the Front Display screen, make sure that the cable is pulled through the large middle
hole.
5. Now insert all studs through their respective holes, and use provided nuts (Hex-head nut, size 10-32 requiring
3/8” nut driver/wrench) to secure the front to the cabinet.
6. When looking from bottom or top the screen should look like the image below.

Page 17 of 44
EZ7-TouchPLC Micro
6Wiring
Ports and Communications
Power: 24 VDC
1
Positive
2
Negative
3
Earth GND
Indicator Light at the backside of the unit
Flashes Red, then continuously Green
Power connected, Normal Operation
Blinking Red / Continuously Red
Some Panel Issue has occurred. Please try a power cycle, if that does not
fix the issue please contact Tech Support.
No Light
Power source not connected or inadequate
15 Pin D-Sub Serial
RS232/422/485 PLC
Port
Reserved Port, Do
not use!
9 Pin D-Sub Serial
Programming Port
RJ45-Ethernet
connector
Micro SD card
Connector
Display Cable
Connector for
connecting FRONT unit
3-Terminal Power
Connector
USB Type B for
Programming
USB Type A for flash
drives

Page 18 of 44
EZ7-TouchPLC Micro
Micro PLC - I/O
6.2.1 Connection for I/O
The EZ7-TouchPLC comes with Easy to Wire Phoenix Terminals.
As shown in the picture, simply insert the wire and screw to tighten. You can wire up to ONE 14 AWG wire, TWO 18
AWG wires, or FOUR 22 AWG wires in every terminal. You will need a 2.5mm blade screwdriver (P/N EZIO-SCDRV) to
work with the I/O terminals and wiring.
Wires Supported
UL rated at 300 volts, 10 amps 14 AWG

Page 19 of 44
EZ7-TouchPLC Micro
6.2.2 Terminal Layout
Please note: On 44 I/O unit, Only 2 analog In (Pin 6, 8 of terminal block TBA) and 2 analog out (Pin 1, 3 of TBA)
available.

Page 20 of 44
EZ7-TouchPLC Micro
6.2.3 Terminal Pinouts
