OWNER’S MANUAL
10048272-C
RXV EFI

Read and comply with all of the instructions and safety precautions in this manual and on all product
labels.
Failure to follow the safety precautions could result in serious injury or death.
Never modify the vehicle in any way that will alter the weight distribution of the vehicle, decrease its sta-
bility or increase the speed beyond the factory specifications. Such modifications can cause serious per-
sonal injury or death. The manufacturer prohibits and disclaims responsibility for any such modifications,
or any other alteration which would adversely affect the safety of the vehicle.
The Engine Exhaust from this product contains chemicals known to the
State of California to cause cancer, birth defects or other reproductive harm.
WARNING
California Proposition 65

1
OWNER’S MANUAL
RXV EX1 EFI
FLEET
FREEDOM
2+2
VALOR 2
VALOR 4
CONTACT INFORMATION
Textron Specialized Vehicles, Inc.
1451 Marvin Griffin Road.
Augusta, Georgia, USA 30906-3852
1-800-774-3946 Technical Assistance & Warranty
1-888-438-3946 Service Parts
001-706-798-4311 International
www.ezgo.com

2
WELCOME
Thank you for purchasing this vehicle. Before driving your new vehicle, read this owner’s manual to familiarize your-
self with safe driving practices, operation, features, and controls.
This manual contains instructions for minor maintenance only. Information about major repairs can be found in the
repair manual. Your dealer has thorough knowledge of your vehicle and wants your total satisfaction with your pur-
chase. We recommend you return to your dealership for all of your service needs during and after the warranty period.
Repair or replacement parts can be purchased from your dealer or through the manufacturer’s parts and accessories
department.
These are original instructions as defined by 2006/42/EC.
Textron Specialized Vehicles, Inc. maintains the right to change the design of the vehicle without responsibility to
make the changes on units purchased before changes were made. The information in this manual can change without
notice.
All information in this owner’s manual is based on the latest product information at the time of publication. Due to con-
stant improvements in the design and quality of production components, some discrepancies may be found between
your vehicle and the information presented in this publication. The content in this publication is intended for reference
use only. The manufacturer is not liable for omissions or inaccuracies. Any reprinting or reuse of the content in this
publication, whether whole or in part, is expressly prohibited.
Printed in USA

TABLE OF CONTENTS
3
INTRODUCTION
MANUFACTURER’S INTENDED USE ......................................................................................................................7
WARRANTY AND REGISTRATION ..........................................................................................................................7
EXHAUST EMISSIONS .............................................................................................................................................7
BATTERY PROLONGED STORAGE ........................................................................................................................ 8
BATTERY DISPOSAL................................................................................................................................................8
VEHICLE IDENTIFICATION NUMBERS ..................................................................................................................8
SERVICE AND PARTS MANUALS............................................................................................................................ 8
SAFETY LABELS
SAFETY LABLES....................................................................................................................................................... 9
Operation (P/N 664789) (2+2 Vehicles Only)..................................................................................................... 9
Warning (P/N 608522) ....................................................................................................................................... 9
Governor Warning (P/N 697730) .....................................................................................................................10
Tow Bar Warning (P/N 611716) (Fleet and Freedom Vehicles Only) ..............................................................10
Flip Seat / Load Deck Warning (P/N 697425) (2+2 and Valor 4 Vehicles Only) .............................................. 10
Pinch Warning (P/N 651671) ...........................................................................................................................10
SAFETY
MAXIMUM CARGO LOAD / MAXIMUM WEIGHT CAPACITY ................................................................................ 11
TIRE PRESSURE .................................................................................................................................................... 11
OPERATOR SAFETY ..............................................................................................................................................11
Unauthorized Operation ...................................................................................................................................12
Operating without Instruction ...........................................................................................................................12
Alcohol or Drugs...............................................................................................................................................13
Passenger ........................................................................................................................................................ 13
Before Operating..............................................................................................................................................13
Load Operation ................................................................................................................................................ 13
Fuel Handling Guidelines .................................................................................................................................13
Carbon Monoxide Exposure.............................................................................................................................13
Driving in Reverse............................................................................................................................................14
Driving a Damaged Vehicle.............................................................................................................................. 14
Driving at Maximum Speeds ............................................................................................................................14
Driving on Public Roads...................................................................................................................................14
Turning .............................................................................................................................................................14
Driving Uphill ....................................................................................................................................................14
Driving Downhill ...............................................................................................................................................14
Stalling on a Hill ...............................................................................................................................................14
Tires .................................................................................................................................................................14
Slippery Terrain................................................................................................................................................14
HOT EXHAUST SYSTEMS......................................................................................................................................15
VEHICLE LIFTING ...................................................................................................................................................15
VEHICLE MODIFICATION.......................................................................................................................................15
MAINTENANCE SAFETY ........................................................................................................................................ 15

4
TABLE OF CONTENTS
FEATURES AND CONTROLS
KEY SWITCH ...........................................................................................................................................................18
HEADLIGHT SWITCH (IF EQUIPPED) ...................................................................................................................18
TURN SIGNAL SWITCH (IF EQUIPPED)................................................................................................................18
FUEL GAUGE (IF EQUIPPED) ................................................................................................................................18
MALFUNCTION INDICATOR LIGHT (MIL)..............................................................................................................18
USB PORT (IF EQUIPPED).....................................................................................................................................18
DIRECTION SLECTOR............................................................................................................................................18
HOUR METER (IF EQUIPPED) ...............................................................................................................................19
ACCELERATOR PEDAL..........................................................................................................................................19
BRAKE AND PARKING BRAKE PEDAL .................................................................................................................19
FRONT SEAT...........................................................................................................................................................20
HIP RESTRAINT ......................................................................................................................................................20
CUP HOLDER..........................................................................................................................................................20
STEERING WHEEL .................................................................................................................................................20
REAR SEAT AND LOAD DECK (2+2 AND VALOR 4 VEHICLES ONLY)...............................................................20
REAR HAND RAIL AND GRAB HANDLE................................................................................................................20
OPERATION
SAFETY ...................................................................................................................................................................21
BEFORE INITIAL USE .............................................................................................................................................21
PRE-RIDE INSPECTION .........................................................................................................................................21
ENGINE RUN-IN ......................................................................................................................................................21
ENGINE WARMUP ..................................................................................................................................................22
FUEL ........................................................................................................................................................................22
STARTING AND STOPPING THE ENGINE ............................................................................................................22
Starting on a Hill...............................................................................................................................................23
ACCELERATING .....................................................................................................................................................23
BRAKING .................................................................................................................................................................23
DRIVING PROCEDURE ..........................................................................................................................................23
Coasting ...........................................................................................................................................................23
DRIVING WITH PASSENGERS ..............................................................................................................................24
SLIPPERY SURFACES ...........................................................................................................................................24
DRIVING UPHILL.....................................................................................................................................................24
TRAVERSING HILLSIDES.......................................................................................................................................24
DRIVING DOWNHILL ..............................................................................................................................................25
STALLING ON A HILL..............................................................................................................................................25
DRIVING IN REVERSE............................................................................................................................................25
PARKING THE VEHICLE.........................................................................................................................................25
BATTERY.................................................................................................................................................................26
HAULING CARGO ON THE LOAD DECK...............................................................................................................26
FLIP SEAT / LOAD DECK OPERATION (2+2 AND VALOR 4 VEHICLES) ............................................................27
LOAD DECK.............................................................................................................................................................27
Load Deck (P/N 697425)..................................................................................................................................27

TABLE OF CONTENTS
5
VEHICLE MAINTENANCE
MAINTENANCE SAFETY ........................................................................................................................................ 29
SCHEDULED MAINTENANCE................................................................................................................................29
Initial Service Requirements ............................................................................................................................29
SCHEDULED MAINTENANCE CHART...................................................................................................................30
RECOMMENDED LUBRICANTS AND FLUIDS ......................................................................................................32
REPLACEMENT OF MAINTENANCE ITEMS .........................................................................................................32
LIFTING THE VEHICLE...........................................................................................................................................33
Lifting the Entire Vehicle .................................................................................................................................. 33
Lifting the Rear of the Vehicle Only.................................................................................................................. 34
Lifting the Front of the Vehicle Only .................................................................................................................34
Lowering the Vehicle........................................................................................................................................34
VEHICLE CLEANING AND CARE...........................................................................................................................34
Washing the Vehicle ........................................................................................................................................ 34
Polishing the Vehicle........................................................................................................................................34
TIRES....................................................................................................................................................................... 35
Tire Pressure....................................................................................................................................................35
Tire Repair .......................................................................................................................................................35
Tire Replacement.............................................................................................................................................36
WHEELS ..................................................................................................................................................................36
Wheel Removal................................................................................................................................................36
Wheel Installation ............................................................................................................................................36
LIGHTS (IF EQUIPPED) ..........................................................................................................................................36
FUSE REPLACEMENT............................................................................................................................................36
FOUR CYCLE ENGINE ...........................................................................................................................................37
Engine Specifications.......................................................................................................................................37
CHECK THE OIL LEVEL..........................................................................................................................................37
CHANGE THE ENGINE OIL .................................................................................................................................... 38
Remove the Engine Oil ....................................................................................................................................38
Refill Oil............................................................................................................................................................39
AIR INTAKE AND COOLING FINS..........................................................................................................................39
CVT FILTER.............................................................................................................................................................39
REAR AXLE .............................................................................................................................................................40
Checking the Transaxle Oil Level ....................................................................................................................40
Checking the Differential Oil Level ...................................................................................................................40
AIR FILTER..............................................................................................................................................................41
MALFUNCTION INDICATOR LIGHT (MIL).............................................................................................................. 41
SPARK PLUG ..........................................................................................................................................................42
BRAKES................................................................................................................................................................... 43
Periodic Brake Test..........................................................................................................................................43
BATTERY.................................................................................................................................................................44
Battery Cleaning...............................................................................................................................................44
Battery Charging ..............................................................................................................................................44
Discharged Battery...........................................................................................................................................45
Battery Disposal ...............................................................................................................................................45
Battery Storage ................................................................................................................................................45

6
TABLE OF CONTENTS
TRANSPORTING THE VEHICLE ............................................................................................................................45
Hauling the Vehicle ..........................................................................................................................................45
Neutral Lock Procedure....................................................................................................................................46
Towing the Vehicle (Fleet and Freedom Vehicles Only) ..................................................................................46
VEHICLE STORAGE ...............................................................................................................................................47
Returning the Vehicle to Service......................................................................................................................47
SPECIFICATIONS
RXV FLEET..............................................................................................................................................................49
RXV FREEDOM .......................................................................................................................................................51
RXV 2+2...................................................................................................................................................................53
VALOR .....................................................................................................................................................................55
VALOR 4 ..................................................................................................................................................................57

SAFETY
7
INTRODUCTION
The following symbols appear throughout this manual and on vehicle labels. Your safety is involved when these sym-
bols are used. Become familiar with their meanings before reading the manual.
DANGER indicates a hazardous situation that, if not avoided, will result in death or seri-
ous injury.
WARNING indicates a hazardous situation that, if not avoided, could result in death or
serious injury.
CAUTION indicates a hazardous situation that, if not avoided, could result in minor or
moderate injury.
The PROHIBITION SAFETY SIGN indicates an action NOT to take in order to avoid a hazard.
The MANDATORY ACTION SIGN indicates an action that NEEDS to be taken to avoid a hazard.
Failure to comply with the warnings in this manual can result in severe injury or death.
Read this entire manual carefully before operating this vehicle. Do not attempt to operate
this vehicle until you have thorough knowledge of the controls and features.
Regular inspections and maintenance, along with good operating techniques, will help
ensure your safe enjoyment of the capabilities and reliability of this vehicle.
This vehicle was designed and manufactured in the United States of America (USA). The standards and specifica-
tions in the following information originate in the USA unless otherwise indicated.
When servicing engines, all adjustments and replacement components must be per the original vehicle specifications
to maintain the USA Federal and State emission certification applicable at the time of manufacture.
MANUFACTURER’S INTENDED USE
This vehicle is designed and manufactured for off road use only. Use on public streets, roads, or highways is illegal in
most areas and increases the risk of an accident involving other vehicles and people. This vehicle does not meet
FMVSS (Federal Motor Vehicle Safety Standards) for public street, road, or highway use.
Check all laws and regulations before choosing an area to operate your vehicle.
WARRANTY AND REGISTRATION
Register the vehicle at www.ezgo.com.
A vehicle warranty statement is included with the purchase of a new vehicle.
Use Original Equipment Manufacturer (OEM) approved parts to keep the vehicle warranty effective.
Tampering with or adjusting the governor to allow the vehicle to operate above factory specifications will void the vehi-
cle warranty.
All information, including coverage, limitations, exclusions and how to obtain warranty service is included in the litera-
ture package with the purchase of the vehicle. It can also be obtained from an authorized dealer.
EXHAUST EMISSIONS
The exhaust emissions of this vehicle’s engine complies with regulations set forth by the Environmental Protection
Agency (EPA) of the United States of America (USA) at time of manufacture. Significant fines could result from modifi-
cations or tampering with the engine, fuel, ignition, or air intake systems. Refer to the warranty statements provided
with the vehicle for all information.

8
INTRODUCTION
BATTERY PROLONGED STORAGE
Batteries discharge over time. The rate of discharge changes according to the ambient temperature, the age of the
battery, and the condition of the battery.
Completely charged batteries will not freeze in winter temperatures unless the temperature is less than -75°F (- 60°C).
BATTERY DISPOSAL
Lead-acid batteries are recyclable. Return discarded batteries to distributor, manufacturer, or lead smelter for recy-
cling. For neutralized spills, put any residue in acid-resistant containers with absorbent material such as sand. Dis-
pose of the container in accordance with local, state, and federal regulations for acid and lead compounds. Contact
local or state environmental authorized people for the disposal information.
VEHICLE IDENTIFICATION NUMBERS
Record the vehicle identification numbers in the spaces provided below. These identification numbers are required
when ordering parts from the manufacturer.
Vehicle Serial Number: _________________________________________________________________
SERVICE AND PARTS MANUALS
The following manuals can be purchased through an authorized dealer:
• service manual
• parts manual
Serial Number
Serial Number Location on Front Frame
Serial Number
Serial Number Location on Rear Frame
Serial Number
Serial Number Location on Steering Column

SAFETY
9
SAFETY LABELS
SAFETY LABLES
Safety and warning labels are on the vehicle for your protection. Read carefully and comply with the instructions on
the labels. If any label shown in this manual is different from the label on your vehicle, always follow the instructions on
the vehicle label.
If a label comes off or becomes illegible, contact your dealer for a replacement. The part number is provided in this
manual, printed on the label, or can be obtained from your dealer.
Operation (P/N 664789) (2+2 Vehicles Only)
Located on the steering wheel.
Warning (P/N 608522)
Located on the dash.
664789
READ AND OBEY THE FOLLOWING WARNINGS TO
DECREASE RISK OF SEVERE INJURY OR DEATH.
BEFORE OPERATING
•
READ the owner’s manual and all warning labels. Contact an authorized dealer or go to the manufacturer’s website for
replacement manual or labels.
•
This vehicle is equipped for personal use in most communities; however, state law or
local rules may require additional equipment in your community.
SAFE OPERATION & PARKING
•
Turn key to ON, select Forward or Reverse, release the parking brake (if required), and slowly press
accelerator pedal.
•
Always bring vehicle to a complete stop before shifting the direction selector.
•
Always
remain seated in a moving vehicle.
•
Operate from the driver’s seat only.
•
Never drink alcohol or use
drugs or medications before or during operation of the vehicle.
•
ALWAYS engage the parking brake
and remove the key before leaving the vehicle. In an electric vehicle, put the direction selector in
OFF or Neutral; in a gasoline vehicle, put the selector in Forward.
MAINTENANCE & TOWING
•
This vehicle requires regularly scheduled maintenance (see the
periodic service schedule in owner’s manual).
•
ONLY qualified
personnel should service this vehicle.
•
Vehicle is not
to be towed; consult owner’s manual for
transport instructions.
Pressing the accelerator pedal releases the parking brake even when the key is in the OFF position; the vehicle may
move when the accelerator pedal is pressed. Unintentional movement of the vehicle can cause injury or death. Do not
allow anyone to stand directly in front or behind the vehicle.
•
Driver must have a valid driver’s license.
•
Do not
operate vehicle until all occupants are properly seated with their backs against the seat and feet flat on the floor.
•
Do not leave children unattended or allow them to play on a parked vehicle.
SAFETY INSTRUCTIONS
608522
Except where PERMITTED BY LAW:
To be operated by persons with valid drivers license, in accordance with state requirements. Operate from Driver’s side only.
Reduce the RISK OF ACCIDENTS:
For non-road use, and in designated areas only. Do not operate under the influence of drugs or alcohol.
AVOID FALLS from the vehicle:
All occupants must be fully seated, keep entire body inside vehicle and hold on while vehicle is in motion.
STARTING the vehicle:
Apply service brake , move direction selector to desired position and accelerate smoothly. On Gas Vehicle, direction selector is
the F-N-R. On Electric vehicle, direction selector is the key switch.
DO NOT OVERLOAD this vehicle:
Maximum vehicle payload is 800 lbs. (363 kg) including a maximum of 2 persons, options, and accessories.
Drive with CAUTION:
Drive slowly straight up and down slopes and in turns. Use care in reverse, congested areas, and wet or loose terrain.
STOPPING the vehicle:
To stop, release accelerator pedal and apply service brake.
PARKING the vehicle:
Before leaving vehicle , turn key ‘OFF’. On Gas vehicle, move the direction selector to “FORWARD” and engage park brake.
Failure to follow these instructions can result in SERIOUS INJURY or DEATH

10
SAFETY
Governor Warning (P/N 697730)
Located on the throttle rod guard.
Tow Bar Warning (P/N 611716) (Fleet and Freedom Vehicles Only)
Located on top of the tow bar.
Flip Seat / Load Deck Warning (P/N 697425) (2+2 and Valor 4 Vehicles Only)
Located on the rear-facing grab handle.
Pinch Warning (P/N 651671)
Located on the base of the rear facing seat.
DO NOT TAMPER WITH OR ATTEMPT TO CHANGE THE ADJUSTMENT
OF THE GOVERNOR. GOVERNOR TAMPERING CAN RESULT IN SERIOUS
PERSONAL INJURY AND WILL VOID THE VEHICLE WARRANTY.
697730
This device is ONLY to be used for towing E-Z-GO vehicles. NEVER tow other vehicles or equipment.
READ Owner’s Manual before towing. NO RIDERS in towed cars.
NEVER tow more than 3 vehicles at one time. Max speed towing 2 or 3 vehicles is 5 mph. Max speed
towing 1 vehicle is 12 mph.
MONTHLY INSPECTION: tow bar pins, attaching hardware, and front frame attachment of towed cars.
Replace worn or damaged parts. CHECK alignment of wheels on towed cars.
FULLY ENGAGE coupling. Rubber latch-stop must be under latch release lever.
611716
DRIVE SLOWLY, it is not recommended to tow vehicle over rough or unsafe terrain or on grades
greater than 10%.
MAX
14o/ 25%
MAX 300 lb.
136 kg
MAX
4 in.
10 cm
697425
651671
PINCH WARNING
KEEP HANDS AND
FINGERS AWAY

SAFETY
11
SAFETY
For questions about the vehicle or the material in this manual, see the contact information on page 1 or the back of
this publication.
Certain replacement parts can be used independently and/or in combination with other accessories to modify a TSV
manufactured vehicle to permit the vehicle to operate at or in excess of 20 mph. When a TSV-manufactured vehicle is
modified in any way by the Distributor, Dealer or customer to operate at or in excess of 20 mph on public streets or
roads, UNDER FEDERAL LAW the modified product will be a Low Speed Vehicle (LSV) subject to the strictures and
requirements of Federal Motor Vehicle Safety Standard 571.500. In these instances, pursuant to Federal law the Dis-
tributor or Dealer MUST equip the product with headlights, rear lights, turn signals, seat belts, top, horn and all other
modifications for LSVs mandated in FMVSS 571.500, and affix a Vehicle Identification Number to the product in
accordance with the requirements of FMVSS 571.565. Pursuant to FMVSS 571.500, and in accordance with the State
laws applicable in the places of sale and use of the product, the Distributor, Dealer or customer modifying the vehicle
also will be the Final Vehicle Manufacturer for the LSV, and required to title or register the vehicle as mandated by
State law.
Information on FMVSS 571.500 is found at Title 49 of the Code of Federal Regulations, section 571.500. For informa-
tion on-line, go to www.ecfr.gov.
TSV will NOT approve Distributor, Dealer or customer changes that change a TSV product into a Low Speed Vehicle
(LSV).
This vehicle meets the current applicable standard for safety and performance requirements.
MAXIMUM CARGO LOAD / MAXIMUM WEIGHT CAPACITY
Exceeding the maximum weight capacities can cause the loss of vehicle control and
possible injury or death.
• Do not exceed the maximum vehicle weight capacity (includes weight of operator, passenger, cargo, and accesso-
ries).
• Always fill the forward facing seat to capacity prior to seating any passengers on the rear facing seat.
TIRE PRESSURE
Improper tire pressure or uneven tire pressure can cause the loss of vehicle control and
possible injury or death.
Maintaining the correct tire inflation pressure is essential for safe vehicle operation. The inflation pressure can vary
within the recommended range to suit the condition of the terrain.
OPERATOR SAFETY
Safe and responsible use of this vehicle is necessary to prevent dangerous conditions for the operator, passengers,
and other people in the area of operation. See OPERATION on page 21 for information on the safe operation of the
vehicle. Make sure to read, understand, and comply with all of this information to decrease the risk of personal injury
or death.
Fleet Freedom Valor 2+2 Valor 4
Maximum Vehicle Weight Capacity 500 lb (227 kg) 500 lb (227 kg) 500 lb (227 kg) 800 lb (363 kg) 800 lb (363 kg)
Maximum Load Deck Weight Capacity N/A N/A N/A 300 lb (136 kg) 300 lb (136 kg)
TIRE PRESSURE RANGE TERRAIN CONDITIONS RECOMMENDATION
18 - 22 psi (124 - 152 kPa)
Hard surfaces or pavement Inflate to higher pressure within the range; never exceed
maximum pressure indicated.
Soft terrain or turf Inflate to lower pressure within the range to reduce
potential damage to the terrain or turf.

12
SAFETY
Serious injury or death can occur if you do not follow the instructions and procedures
shown in this owner’s manual.
• Read this entire manual and all product labels carefully. Follow the safety information and operating procedures
described.
• Operate your vehicle responsibly to prevent dangerous conditions for the operator, passengers, and other people in
the area of operation
• Operate the vehicle responsibly and keep the vehicle in safe condition of operation.
• A damaged vehicle or a vehicle that is not functioning properly is dangerous and must not be operated until repairs
are made.
• Do not carry a passenger until you have a minimum of two hours driving experience on this vehicle.
• Keep feet, legs, hands, and arms inside the vehicle at all times.
• The driver must keep both hands on the steering wheel and both feet on the floor or pedals.
• Inspect the vehicle before each use to make sure it is in safe operating condition. Perform the pre-ride inspection
described in this manual. See page 21.
• Always have the vehicle checked by an authorized dealer if it is involved in an accident.
• Always put the direction selector in forward (F) and engage the parking brake before exiting the vehicle.
• Remove the key from the key switch when the vehicle is not in use to prevent accidental starting, unauthorized use
by someone below the age of 16, or someone without a driver’s license and proper training.
• Drive the vehicle at appropriate speeds for the terrain and conditions. Be aware of environmental conditions that
change the terrain and your ability to control the vehicle.
• Do not drive on excessively steep hills. Evaluate the terrain before descending a hill. Drive slowly and deliberately.
Use the brake to limit speed and maintain control. Sudden braking or turning can cause the loss of vehicle control.
Drive straight down the hill. Do not drive across the hill.
• Operate only in approved areas. Follow all applicable safety rules for the area.
• Avoid driving on terrain that is too rough for the vehicle’s capabilities and your driving skills.
• Before driving in the reverse direction, make sure the area behind the vehicle is clear. Accelerate slowly and avoid
making sharp turns.
• Make sure the direction selector is in the correct position before pressing the accelerator pedal.
• Decrease speed before and during turns.
• Decrease speed when driving on wet or slippery surfaces.
• Bring the vehicle to a complete stop before moving the direction selector.
• Do not exceed the cargo or vehicle weight capacities. Do not exceed the occupant capacity. See SPECIFICA-
TIONS on page 49 for the vehicle load and seat capacity.
• If there is a risk of lightning, leave the vehicle and look for a safe location to wait until the lightning has stopped.
Additional information about safety is included throughout this manual or can be obtained from your dealer.
Failure to operate this vehicle as instructed can cause collision, loss of control, or roll-
over resulting in severe injury or death. Follow all safety warnings in this section of the
owner’s manual. See the OPERATION section of the owner’s manual for operating proce-
dures and additional safety information.
Unauthorized Operation
This vehicle is for adult use only. Any person below the age of 16 is not permitted to operate the vehi-
cle.
Any person who does not have a valid driver’s license is not permitted to operate the vehicle.
Any person who is below the height of 59 in. (150 cm) is not permitted to operate the vehicle.
Leaving the key in the key switch allows unauthorized operation of the vehicle by someone under 16
years of age, an unlicensed driver, or someone who does not meet the height requirement. Always
remove the key from the key switch when the vehicle is not in operation.
Operating without Instruction
Operation of this vehicle without proper instruction increases the risk of an accident. The operator
must understand how to operate the vehicle correctly in different situations and on different types of
terrain.
All operators must read, understand, and comply with the owner’s manual and all warning and instruc-
tion labels before operating the vehicle.

SAFETY
13
Alcohol or Drugs
Operation of the vehicle during or after consuming alcohol or drugs can adversely affect operator judg-
ment, reaction time, balance, and perception.
Never drink alcohol or use drugs or medications before or during operation of the vehicle.
Passenger
All passengers must be at least 59 in. (150 cm) tall. Passengers must be able to sit with their back against the seat
and both feet on the floor.
For additional safety and operational information, see DRIVING WITH PASSENGERS on page 24.
Before Operating
Perform the PRE-RIDE INSPECTION on page 21 before each use to make sure the vehicle is in safe operating con-
dition. Failure to inspect and confirm that the vehicle is safe to operate increases the risk of an accident.
Follow all inspection and maintenance procedures and schedules described in SCHEDULED MAINTENANCE on
page 29.
Load Operation
The weight of cargo and occupants affects vehicle operation. Carefully calculate how the vehicle is loaded and how to
safely operate it. Follow the instructions in this manual for loading guidelines and tire pressure.
Do not exceed weight capacities specified for the vehicle. Capacities are listed in MAXIMUM CARGO LOAD / MAXI-
MUM WEIGHT CAPACITY on page 11 of this manual and also on the label affixed to the load deck (if equipped). As
passenger weight increases, cargo weight should be adjusted to ensure the maximum vehicle weight capacity is not
exceeded.
Tire pressure must be adjusted to accommodate the load being carried. See TIRE PRESSURE on page 11 for pres-
sure specifications.
Verify tire pressure, and drive slowly and carefully to maintain control of the vehicle if driving under any of the following
conditions:
• passenger and/or cargo exceeds half the maximum weight capacity
• driving over obstacles
• towing
• climbing a hill
Fuel Handling Guidelines
Gasoline is flammable and can be explosive in some conditions. Use the following guidelines when handling fuel:
• Always use caution when handling gasoline.
• Refuel in a well-ventilated area.
• Turn off the engine before refueling.
• Use an approved gasoline container to store fuel.
• Remove portable gasoline containers from the vehicle and place on the ground before filling to prevent ignition
caused by electrical static discharge.
• Do not smoke or allow open flames or sparks in or near the area where refueling is done or where gasoline is
stored.
• Do not overfill the tank. Do not fill the tank neck.
• If any gasoline contacts skin, immediately wash with soap and water. If any gasoline gets on clothing, change
immediately.
For refueling procedure, refer to FUEL on page 22.
Carbon Monoxide Exposure
Carbon monoxide is an odorless gas that is formed as a natural part of the combustion of hydrocarbon fuels.
Carbon monoxide is poisonous and can cause loss of consciousness or death in a short period of time. Never start the
engine or allow it to run in an enclosed area.
If you experience any of the following symptoms, stop the engine and get fresh air immediately:
Operate this vehicle outdoors or in well-ventilated areas only.
• dizziness • vomiting
• intense headache • muscular twitching
• weakness and sleepiness • throbbing in temples

14
SAFETY
Driving in Reverse
Make sure the area behind the vehicle is clear before operating in reverse. After making sure it is clear and safe to
operate in reverse, accelerate slowly. Avoid making sharp turns in reverse. Refer to DRIVING IN REVERSE on
page 25 for operational information.
Driving a Damaged Vehicle
Driving a damaged vehicle is not safe.
If the vehicle has been involved in any type of accident, have it inspected by a qualified service dealer to verify that it
is safe for operation.
Driving at Maximum Speeds
Maximum speed operation increases the risk of loss of control. Always drive at a speed that is appropriate for the ter-
rain, visibility, operating conditions, and your skill and experience level. Use the brake to control speed and maintain
control of the vehicle.
Driving on Public Roads
Driving this vehicle on public streets, roads or highways could result in a collision with another vehicle. Never drive this
vehicle on any public street, road, or highway. This includes dirt and gravel roads unless they are designated for off
road use. Most areas prohibit the operation of this vehicle on public streets, roads, or highways and can result in traffic
violations and fines.
Turning
Improper or careless turning can cause loss of traction, loss of control, accident, or rollover. Do not turn quickly or at
sharp angles. Do not turn at high speeds. Practice turning at slow speeds before attempting to turn at faster speeds.
Driving Uphill
Do not climb hills that are too steep for the vehicle or your driving abilities. Loss of vehicle control or rollover can result
from climbing hills incorrectly. Refer to DRIVING UPHILL on page 24 for operational information.
Driving Downhill
Inspect the terrain before descending a hill. Avoid driving across hills. Use the brake to limit speed and maintain con-
trol. Loss of vehicle control or rollover can result from driving downhill incorrectly. Refer to DRIVING Downhill on
page 25 for operational information.
Stalling on a Hill
A rollover can result from stalling or rolling backward while climbing a hill. Drive uphill at a constant speed. See proce-
dure on page 25 for maintaining control of your vehicle if it stalls on a hill.
Tires
Operating the vehicle with the incorrect tires or with the incorrect or uneven tire pressure can cause loss of control or
an accident. Always use the size and type of tires specified for the vehicle. See Vehicle Specification for proper tire
type and size. Always maintain the correct tire pressures as specified in TIRE PRESSURE on page 11.
Slippery Terrain
Driving on rough, wet, or loose terrain increases the risk of loss of traction or control and accident or rollover. Drive
slowly and use the correct turning procedures when operating on slippery surfaces.
Tires that have lost traction and then regain traction suddenly can cause loss of vehicle control or rollover.
Refer to SLIPPERY SURFACES on page 24 for operational information.

SAFETY
15
HOT EXHAUST SYSTEMS
Exhaust system components are very hot during and after use. To avoid burn injuries, do not touch hot exhaust sys-
tem components. Hot components can also cause a fire. Keep combustible materials away from the exhaust system.
Check for buildup around the exhaust system after driving through high and dry grass.
VEHICLE LIFTING
The vehicle must be on a firm and level surface for lifting. Remain constantly aware that the vehicle is not stable
during the lifting process. Do not get under a vehicle until you verify that it is stable on the jack stands. Never get
under a vehicle while it is on a jack only. Put wheel chocks in front of and behind the wheels that are not being lifted.
Do not allow anyone to remain or get on the vehicle at any time during the lifting process.
Read and comply with all warnings and follow the lifting procedures described on page 33.
VEHICLE MODIFICATION
Do not install any accessory not approved by the manufacturer. Do not modify the vehicle to increase the speed or
power. Any modifications or installation of accessories not approved by the manufacturer can create a safety hazard
and increase the risk of injury.
The warranty will be terminated if the vehicle is modified to increase vehicle speed or power.
The warranty may be terminated if the original (or equivalent) replacement parts are not installed on the vehicle.
The addition of some accessories can change the handling characteristics of the vehicle. Use only manufacturer
approved accessories and familiarize yourself with their function and effect on the vehicle.
MAINTENANCE SAFETY
Routine and scheduled maintenance of this vehicle is necessary to keep the vehicle in safe and reliable condition.
This section of the manual provides safety information for performing maintenance on the vehicle. Make sure to read,
understand, and comply with all of this information to decrease the risk of personal injury or death.
Serious injury or death can occur if the instructions and procedures shown in this
owner’s manual are not followed.
• Read this entire manual and all product labels carefully. Follow the procedures and comply with the safety informa-
tion in this manual and on the vehicle safety labels while performing vehicle service or maintenance.
• Use the tools shown in the tool list and wear the specified safety equipment when performing vehicle service or
maintenance.
• Remove all jewelry before servicing the vehicle.
• Do not allow loose clothing or hair to contact the moving parts.
• Do not touch hot objects.
• The drive wheels must be lifted and supported on jack stands before performing any service to the power-train
while the engine is in operation.
• Use wheel chocks and support the vehicle on jack stands. NEVER get under a vehicle that is supported by a jack
alone. Lift the vehicle following the instructions in LIFTING THE VEHICLE on page 33
•When servicing the vehicle, always wear eye protection. Be careful when working around batteries,
using solvents, or compressed air.
•Use insulated tools within the battery area to prevent sparks or battery explosion.
•To prevent the risk of battery explosion, keep all flammable materials, open flames or sparks away
from the battery.
• Hydrogen gas is produced as a battery is charged. Charge the battery only in well-ventilated areas.
• Maintain constant awareness that some components are heavy, spring loaded, corrosive, explosive, can cause
high amperage, or get extremely hot. Battery acid and hydrogen gas can cause bodily injury. Keep your hands,
face, feet, and body away from any area that can expose them to injury in the event that an unexpected situation
occurs.
• After making repairs or performing maintenance, test the vehicle in a safe area that is free from vehicle and person
traffic.

16
SAFETY

FEATURES AND CONTROLS
17
FEATURES AND CONTROLS
Vehicle controls and indicators consists of:
1. Key Switch
2. Fuel Gauge (if equipped)
3. Head Light Switch (if equipped)
4. Turn Signal Switch (if equipped)
5. Malfunction Indicator Light (MIL)
6. Center Compartment
7. USB Port (if equipped)
8. Accelerator Pedal
9. Brake Pedal
10. Parking Brake
11. Horn Button (if equipped)
12. Direction Selector
13. Hour Meter (if equipped)
3
11
10 98
2
14
5
Front of Vehicle
13
12
7
6

18
FEATURES AND CONTROLS
KEY SWITCH
To decrease the risk of component damage, bring the vehicle to a complete stop before
moving the key switch or the direction selector.
The key switch (1) is located on the dash panel. The switch controls the electrical system of the vehicle to be turned
on and off by turning the key. To prevent accidental operation of an unattended vehicle, turn the key switch to the OFF
position and remove it from the switch.
NOTICE: Some factory installed accessories continue to operate with the key switch in the off position.
HEADLIGHT SWITCH (IF EQUIPPED)
The headlight ON/OFF switch (3) is located on the
instrument panel to the left of the key switch (1).
TURN SIGNAL SWITCH (IF EQUIPPED)
The turn signal switch (4) is on the steering column
and controls the operation of the right and left turn sig-
nal lights.
FUEL GAUGE (IF EQUIPPED)
The fuel gauge (2) is located on the dash panel to the
left of the key switch (1). The fuel gauge indicates the
amount of fuel remaining in the fuel tank. The fuel
gauge operates only when the key switch is in the ON
position and the accelerator is pressed.
MALFUNCTION INDICATOR LIGHT (MIL)
The MIL (5) is located on the control panel. The MIL
can be used to diagnose a problem and to determine
whether a technician will be required to service the
vehicle. See MALFUNCTION INDICATOR LIGHT
(MIL) on page 41.
USB PORT (IF EQUIPPED)
A USB port (7) is located to the right of the center
compartment.
DIRECTION SLECTOR
To reduce the possibility of component damage, the vehicle must be completely stopped
before moving the direction selector.
3
4
1
2
5
7
8
