Ezup INSTANT SHELTER Pyramid II User manual

Care and MaintenanCe
IMPORTANT! Read this information before proceeding.
It is the user’s responsibility to take the following
precautions at all times.
• Always stake or weigh down your shelter. Do not use in any
potentially windy or rainy weather.
Wind and rain can damage the E-Z UP®Instant Shelter® product
and may also result in injury to you or others. Therefore, do not
rely on shelter for protection in heavy or prolonged rain storms.
• The E-Z UP®Instant Shelter®product is designed as a temporary
shelter. Do not leave up for extended periods.
• Use caution when handling the E-Z UP®folding frame.
Avoid pinching hands or fingers as frame opens or closes.
• Do not use shelter in a lightning storm.
• Do not leave your E-Z UP®Instant Shelter®product unattended.
• Do not build fires within shelter enclosure.
For long lasting durability and the best possible protection
for your E-Z UP®Instant Shelter® products, follow these
E-Z care and maintenance instructions:
• Use a mild soap (not detergent) and plenty of water for top
cleaning.
• Let the E-Z UP®top and frame dry completely before closing
or storing to avoid mildew.
• Frame will operate and look better if occasionally wiped with
silicone spray, especially before and after use in damp conditions.
Remove excess silicone residue before applying top.
• Use a seam sealer if top leaks or drips water. Available at most
sporting goods and hardware stores.
• Slightly tighten bolts if frame becomes loose.
iMportant inforMation
PRODUCT WARRANTY
INTERNATIONAL E-Z UP, INC., manufacturer of E-Z
UP®Instant Shelter®
products, warrants to the original
purchaser who provides a dated sales receipt, from
an Authorized Dealer, each part of the E-Z UP®Instant
Shelter®product to be free from defects in material or
workmanship for a period of THREE YEARS after the
date of original purchase. This warranty applies only
for normal and expected uses, as determined by the
manufacturer. INTERNATIONAL E-Z UP, INC.’s obliga-
tion and liability under this warranty is limited to the
repair or replacement (at its option) of the product
or its parts, after its own review and examination.
RETURN ADVISORY - Before returning any part or
product to INTERNATIONAL E-Z UP, INC. or its desig-
nated representative, please phone or write to obtain
specific return shipping instructions. All shipping costs
must be prepaid, and INTERNATIONAL E-Z UP, INC.
is not responsible for products damaged in transit.
CONDITIONS - This warranty shall be void as to any
product which has been altered or modified in any man-
ner. This warranty does not apply to damages caused by
wind, rain, or other forces of nature, not to accidental or
deliberate damage of the product, nor to use of the prod-
uct that does not conform with the product instructions.
This warranty is provided in lieu of all
other warranties, expressed or implied.
E-Z UP
®
INSTANT SHELTER
®
“Sets Up in Seconds!”™
10’ x 10’
(3.0 m x 3.0 m)
With proper care, this shelter will deliver years
of trouble free service. Please take a few minutes
to read the following use and care instructions.
If you have any questions or require assistance,
please call.
WARNING: Keep all flame and heat sources away from all
shelter fabrics. These fabrics meet the flammability requirements
of CPAI-84. The fabric may burn if left in continuous contact with
any flame source. The application of any foreign substance to
the fabric may render the flame-resistant properties ineffective.
© Copyright 2014 International E-Z UP, Inc. USA. All rights reserved.
We Make Life E-Z!™
INTERNATIONAL E-Z UP, INC.
1900 Second Street, Norco, California 92860 USA
[phone] • Fax [phone]
ezup.com
Customer Service Hot Line
800-SHADE ME
800-742-3363
Customer Service Hot Line
800-SHADE ME
800-742-3363
ezup.com
ezup.com
OWNER’S MANUAL

How toSet UpHow totake down
Repeat Step 1 in First Time Top Attachment.
1. Place your E-Z UP®
frame in the center of
area to be shaded. With
partner on opposite side,
grasp two outer legs,
slightly lift off ground and
step backwards, stopping
at full arms’ length.
1. With partner on opposite side
of shelter, stand diagonally facing one another. Grasp the top and
bottom of the diamond shaped area of trusses on opposite sides.
Lift up and step backward until shelter is 3/4 opened, being careful
not to pinch fingers.
3. Lift two adjacent outer legs and slide out inner legs until
the pull pin engages the inner leg. Repeat on the opposite legs.
Use spike or weight bags to secure in windy conditions.
2. To engage the Pull - Pin
Auto Slider®at each corner,
first lift the fabric off of the
slider, then with one hand hold
the top of the leg while pushing
up on the slider with the other
hand. The pull pin will engage
the hole. Pull down the fabric
valance over the slider. Repeat
on all four corners.
1. With partner, slightly lift
up two adjacent outer legs,
release the pull pin lock and
telescope inner legs into outer
legs. Repeat on the opposite
legs.
2. Release pull pin slider
at each corner by first lifting
valance fabric away from slid-
er. With one hand, push up
on truss near slider to remove
the weight of the shelter from
the pull pin. Release slider
by disengaging pull pin and
pushing slider down.
Note: It is much easier to release
pull pin when the shelter weight
has been removed from the
pull pin.
Pull Pin
3. With partner on opposite
sides grasp the top and bot-
tom diamond shaped area over
trusses by “close“ sticker. Lift the
shelter up slightly and shake it
while stepping towards your
partner until the shelter is 3/4
closed. Grasp adjacent outer
legs and push shelter together
until it fully closes.
Be careful not to pinch
fingers.
4. Store shelter in roller bag.
2. Gently unfold the
fabric top and place it
over the open frame.
3. Attach the top to the frame by
matching the quick attachment strips
on the top with the strips on the frame.
Push firmly together at each corner.
*Note: First Time Attachment Is Required.
Top and frame are shipped unattached to avoid damage.
A first time setup requires that top be attached to the frame. Once
top is attached, set up and take down are easily accomplished within
seconds.
• 1 10’ x 10’ (3.0 m x 3.0 m) Pyramid™ II Frame
• 1 Recreational Grade Top *
• 4 Piece Standard Spike Kit
• 1 Roller Bag *
*
Available in the Shelter Package only
Please read each step before you attempt to set up.
Save these instructions for future reference.
