FAAC E024 U User manual

E024U Loop Detector
Interface
FAAC International Inc.
Headquarter & East Coast Operations
3160 Murrell Road
Rockledge, FL 32955
Tel. [phone]
www.faacusa.com
FAAC International Inc.
West Coast Operations
357 South Acacia Avenue
Fullerton, CA 92831

2
The 2670.1 loop detector interface allows to connect up to three plug-in detectors associ-
ated with standard functions. The board is designed to t in the FAAC standard 16” x 14”
enclosure on the existing DIN rail. To connect the interface board:
1) Connect the 2EASY BUS from the E024U to the interface board (no polarity)
2) Connect pin 8 on the E024U board (+24V) to the +24 input on the interface board
3) Connect pin 7 on the E024U board (GND) to the GND input on the interface board
4) Connect the loops to the interface board as in Fig. 1 below
A B STP CL OP
OPEN FSW
OPEN
REVERSE
SHADOW
E024U CONTROL BOARD
Turn the power on on the E024U board. The LED on the interface board will blink briey and
then will stay ON solid if the BUS connection is working correctly.
IMPORTANT: Briey press the SW1 button on the E024U board to make it aware of the pres-
ence of the additional interface board.
To make sure the board is working properly you can check the behaviour of BUS LED on the
E024U board. It will be normally on when none of the loop detectors is active. If any of the
detectors is activated the LED will turn o󰀨.
SHADOW
REVERSE
OPEN
LED
Loop Detector Interface
Fig. 1

3
Loop Detector Interface
To the original purchaser only:
FAAC International, Inc., warrants, for twenty-
four (24) months from the date of invoice, the
gate operator systems and other related sys-
tems and equipment manufactured by FAAC
S.p.A. and distributed by FAAC International,
Inc., to be free from defects in material and
workmanship under normal use and service for
which it was intended provided it has been prop-
erly installed and operated.
FAAC International, Inc.’s obligations under
this warranty shall be limited to the repair or
exchange of any part of parts manufactured by
FAAC S.p.A. and distributed by FAAC Interna-
tional, Inc. Defective products must be returned
to FAAC International, Inc., freight prepaid by
purchaser, within the warranty period. Items
returned will be repaired or replaced, at FAAC
International, Inc.’s option, upon an examination
of the product by FAAC International, Inc., which
discloses, to the satisfaction of FAAC Interna-
tional, Inc., that the item is defective. FAAC
International, Inc. will return the warranted item
freight prepaid. The products manufactured by
FAAC S.p.A. and distributed by FAAC Inter-
national, Inc., are not warranted to meet the
specic requirements, if any, of safety codes
of any particular state, municipality, or other
jurisdiction, and neither FAAC S.p.A. or FAAC
International, Inc., assume any risk or liabil-
ity whatsoever resulting from the use thereof,
whether used singly or in combination with other
machines or apparatus.
Any products and parts not manufactured by
FAAC S.p.A. and distributed by FAAC Interna-
tional, Inc., will carry only the warranty, if any, of
the manufacturer. This warranty shall not ap-
ply to any products or parts thereof which have
been repaired or altered, without FAAC Interna-
tional, Inc.’s written consent, outside of FAAC
International, Inc.’s workshop, or altered in any
way so as, in the judgment of FAAC Interna-
tional, Inc., to a󰀨ect adversely the stability or
reliability of the product(s) or has been subject
to misuse, negligence, or accident, or has not
been operated in accordance with FAAC Inter-
national, Inc.’s or FAAC S.p.A.’s instructions
or has been operated under conditions more
severe than, or otherwise exceeding, those set
forth in the specications for such product(s).
Neither FAAC S.p.A. nor FAAC International,
Inc., shall be liable for any loss or damage
whatsoever resulting, directly or indirectly, from
the use or loss of use of the product(s). Without
limiting the foregoing, this exclusion from liability
embraces a purchaser’s expenses for downtime
or for making up downtime, damages for which
the purchaser may be liable to other persons,
damages to property, and injury to or death of
any persons.
FAAC S.p.A. or FAAC International, Inc., neither
assumes nor authorizes any person to assume
for them any other liability in connection with
the sale or use of the products of FAAC S.p.A.
or FAAC International, Inc. The warranty herein
above set forth shall not be deemed to cover
maintenance parts, including, but not limited to,
hydraulic oil, lters, or the like. No agreement to
replace or repair shall constitute an admission
by FAAC S.p.A. or FAAC International, Inc., of
any legal responsibility to e󰀨ect such replace-
ment, to make such repair, or otherwise. This
limited warranty extends only to wholesale cus-
tomers who buy directly through FAAC Interna-
tional, Inc.’s normal distribution channels. FAAC
International, Inc., does not warrant its products
to end consumers.
Consumers must inquire from their selling dealer
as to the nature and extent of that dealer’s war-
ranty, if any. This warranty is expressly in lieu of
all other warranties expressed or implied includ-
ing the warranties of merchantability and tness
for use. This warranty shall not apply to prod-
ucts or any part thereof which have been sub-
ject to accident, negligence, alteration, abuse,
or misuse or if damage was due to improper
installation or use of improper power source, or
if damage was caused by re, ood, lightning,
electrical power surge, explosion, wind storm,
hail, aircraft or vehicles, vandalism, riot or civil
commotion, or acts of God.
LIMITED WARRANTY
© 2018, FAAC International, Inc. - All Rights Reserved
Published in May 2018
