Faber FBG Blendy 125 GRN User manual

INSTRUCTION MANUAL
220-240V~ 50Hz 400W
Blender
Model No: FBG Blendy 125 GRN
Read this booklet thoroughly before using and save it for future reference.

1
IMPORTANT SAFEGUARDS
When using electrical appliance. Basic safety precautions should always be
followed including the following:
1. Read all instructions.
2. Before using check that the voltage power corresponds to the one shown on the
appliance nameplate.
3. Do not let cord hang over edge of table or counter.
4. Do not operate any appliance with a damage cord or plug or after the appliance
malfunction or has been damaged in any manner. Return the appliance to the
nearest authorized service facility for examination, repair or adjustment.
5. If the supply cord is damaged， it must be replaced by the manufacture or its service
agent or a similarly quality person in order to avoid a hazard .
6. Close supervision is necessary when any appliance is used by or near children.
7. Avoid contacting moving parts.
8. Blades are sharp, so handle carefully.
9. Never use hot liquids or run the appliance empty.
10. The use of accessory not recommended or sold by the manufacturer may cause
fire，electric shock or injury。
11. The appliance can not be used for blendingorgrindinghardanddrysubstance,
otherwise the blade could be blunted. But it can be used for blending ice cube.
12. Unplug from outlet when not in use, before putting on or taking off parts, and
before cleaning.
13. To protect against risk of electrical shock do not put unit in water or other liquid.
14. Be sure blending cover is accurately put in place before operating appliance
15. Keep hands and utensils out of container while blending or grinding to reduce the
risk of severe injury to persons or damage to the blender. A scraper may be used
but must be used only when the blender is not running.
16. To reduce the risk of injury, never place cutter-assembly blades on base without
jar or bowl properly attached.
17. This appliance is not intended for used by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use
of the appliances by a person responsible for their safety.

2
18. Children should be supervised to ensure that they do not play with the appliance.
19. Do not immerse the Motor Unit into water or other liquids.
20. Do not use outdoors.
21. This appliance is intended to be used in household and similar applications such
as:
– Staff kitchen areas in shops, offices and other working environments;
– Farm houses;
– By clients in hotels, motels and other residential type environments;
–Bed and breakfast type environments.
22. Potential injury from misuse.
23. Care shall be taken when handling the sharp cutting blades, emptying the bowl
and during cleaning.
24. Be careful if hot liquid is poured into the food processor or blender as it can be
ejected out of the appliance due to a sudden steaming.
25. Switch off the appliance and disconnect from supply before changing accessories
or approaching parts that move in use.
26. Ensure that the blender is switched off before removing it from the stand.
27. Save these instructions.
Grinding cup
Jar base seal ring 2
Blade asm 2
Cup base
Body
Knob
Base
Control panel
Jar cover
Glass Jar
Jar base seal ring2
Glass Jar blade base
Jar base
Samll jar
Jar base seal ring1

3
BEFORE THE FIRST USE
Check that all parts are complete and not damaged. Choose the appropriate
attachment to perform your desired task. The blender attachment is suitable for
blending fruits or vegetables or crushing ice, while the grinder attachment for
grinding coffee beans. Clean the attachment according to the section “CLEANING
AND MAINTENANCE”.
WARNING: The blade is sharp, handle with great care and ensure that unplug the
appliance from outlet before assembling and removing parts.
BLENDER OPERATION
1. Lay the motor unit on the flat horizontal surface and make sure it is unplugged.
NOTE: There is a safety interlock device at the bottom of jar, if the jar is not
assembled in place, the blender will not operate.
2. Open the jar cover by turning anticlockwise and place it on the surface. Peel or
core the fruits or vegetables and then cut it into small pieces, then put them into the
jar. Usually certain amount of purified water has to be added to facilitate the
smooth running of appliance. The amount of mixture should not exceed the max
level as indicated on the jar, nor sit lower the min level. The best proportion of the
fruits or vegetables and water is 2:3.
NOTE: The blender is not applicable for beating egg white, mashing potatoes,
mixing dough, extracting juice from fruit and vegetable.
3. Replace jar cover on the jar and turn it clockwise.
NOTE: There is a safety interlock device at the side of jar cover, if the jar cover
is not assembled in place, the blender will not operate.
4. You may add ingredients into the jar through the center opening of jar cover during
operation, then replace measuring cup if necessary. Let the tabs of measuring cup
aligns with the grooves of jar cover, put down and turn the measuring cup by
clockwise until it in place.
5. Ensure the Speed Selector to “0”Position,then plug into power outlet and set
Speed Selector to your desired setting. You can press down the Pulse button
without releasing it if want to accelerate the process of blending. The detailed
informationisshowninbelowFig.1

4
NOTE: Make sure the jar cover is placed in position completely before operating,
and never open the jar cover during operation. In addition, for the sake of
consistency, you can use the stir stick to stir mixture through the opening in the
center of the measuring cup.
6. Do not run the appliance for more than 2 minutes per time, and only wait until the
unit is cooled to room temperature before performing next operation cycle.
7. Turn the Speed Selector to “0”position once the mixture has been blended to
your desired consistency.
8. Turn the jar anti-clockwise and remove it from the motor unit, carefully take down
the jar cover, then pour and serve.
GRINDER OPERATION
1. Place the motor unit on the flat horizontal surface and make
sure it is unplugged.
2. Fill the grinding bowl with proper coffee bean, then assemble
the grinding blade assembly and grinding bowl together. Please
see Fig.3
NOTE: The quantity of coffee bean the grinding bowl allows
to grind is Max 50g.
3. Place the grinder attachment on the motor unit, Please see Fig.
4
NOTE: There is a safety interlock device at the bottom of
grinder, if the grinder is not assembled in place, the chopper
Fig. 2
Fig.3
Fig.4

5
will not operate.
4. Ensure the Speed Selector to “2” Position, then plug into power outlet.
5. Select the desired speed setting, the appliance will start grinding. During grinding,
you can press down the Pulse without releasing it if want to accelerate the process
of grinding.
6. Turn the Speed Selector to “2” Position once the coffee has been ground to your
desired result.
7. Disconnect from power supply once finished. Disassemble the grinder attachment
from the unit, keep the grinding bowl downward and turn it anticlockwise (see
fig.5), then empty the bowl and serve.
8. Do not run the appliance for more than 20 second per time, and only wait until the
unit is cooled to room temperature before performing next operation cycle.
WARNING:
1. Never operate the appliance continuously for more than 2 minutes per time.
2. Blades are very sharp. Handle with care.
3. Do not operate without the jar cover in place.
4. Do not disassemble the jar or bowl from the jar base or bowl base in general
condition.
5. This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not be made by children
without supervision.
NOTE: If the motor stops suddenly during operation, pull the plug out of the power
outlet immediately, let the unit cool to room temperature before plugging it in again.

6
position and press down the Pulse button without releasing it for a few seconds.
2. Dismantle all detachable parts.Dissemble the Jar from the motor unit and rinse it
under running water, then detach the blade assembly from the jar assembly, take
the blade assembly out, finally remove the jar base seal ring (see fig.6). In addition,
detach the measure cup from the jar cover. Rinse the jar, blade, jar base, jar cover
and measuring cup under running water.
3. Wipe the outer surface of motor unit and with a damp cloth.
NOTE: Do not use abrasive cleanser and never immerse motor unit in water for
cleaning
4. Dry all parts and then assemble them. The method of assembling blender
attachment just is in opposite of its detaching sequence.
NOTE: If any problem has been encountered during using, never disassemble
the Motor Unit by yourself. There are no user serviceable parts inside. Only
contact the authorized service facility for examination and repair.
CLEANING AND MAINTENANCE
Make sure to disconnect appliance from power supply before cleaning
For blender
The Auto Clean function can clean the blender easily and rapidly in complete safety.
1. Pour a little warm soapy water into the Jar and turn the Speed Selector to “1”

7
ENVIRONMENT FRIENDLY DISPOSAL
You can help protect the environment!
Please remember to respect the local
regulations: hand in the non-working
electrical equipments to an appropriate waste
disposal centre.
Dibuat untuk and diedarkan oleh:
FIMACO SDN BHD
8-2, Wisma Fiamma
No. 20, Jalan 7A, 62A,
Bandar Manjalara
52200 Kuala Lumpur,
Malaysia.
