Fagor 3FIS-882 User manual

FAGOR
3FIS-882
INSTRUCTIONS FOR USE
GUIDE D'INSTALLATION ET D'UTILISATION
GEBRUIKSAANWIJZING
BEDIENUNGSANLEITUNG

EN -1-
Index
BEFOREUSINGTHEAPPLIANCE ........................................................................2
SafetyInstructions ........................................................................................................ 2
Recommendations....................................................................................................... 3
SwitchingOnthe Appliance.......................................................................................... 4
HOWTOOPERATETHEAPPLIANCE ..................................................................5
Thermostat Setting ....................................................................................................... 5
FOODSTORAGEIN THEAPPLIANCE..................................................................6
CLEANINGANDMAINTENANCE ...........................................................................6
Defrosting ..................................................................................................................... 7
ReplacingtheLight Bulb .............................................................................................. 7
BEFORECALLINGYOURAFTERSALESSERVICE ............................................8
PARTSOFTHEAPPLIANCEAND THECOMPARTMENTS................................10
-Theoperatinginstructionsapply toseveralmodels.Differencesmaythereforeoccur.

EN -2-
PART1. BEFOREUSINGTHE APPLIANCE
SafetyInstructions
•IfthemodelcontainsR600a-seenameplateunderrefrigerant(thecoolantisobutane),
naturalsgasthat, is veryenvironmentallyfriendlybut alsocombustible.When
transporting andinstallingtheunitcaremustbetaken toensurethatnoneofthe
refrigerationcircuitcomponentsbecomedamaged. In theevent of damageavoid
nakedflamesorignitionsourcesand ventilatetheroomin whichthe unitisplaced
forafewminutes.
Warning: Keepventilationopeningsinapplianceenclosureorinstructureforbuilding
in,clearofobstruction.
•Donotusemechanicaldevicesorotherartificial meanstoaccelerate thedefrosting
process.
•Donotuseelectricalappliancesinthe refrigeratororfreezercompartmentofthe
appliance.
•If thisapplianceistoreplacean oldrefrigeratorwithalock;breakor removethe lock
asasafetymeasurebeforestoringit,toprotectchildren whileplayingmight lock
themselvesinside.
•Oldrefrigeratorsand freezerscontaininsulationgasesandrefrigerant,whichmust
be disposed ofproperly.Entrustthe disposal of ascrapunitcategoricallyto
competence ofyourlocalwastedisposalserviceandcontactyourlocalauthorityor
yourdealerifyouhaveanyquestions.Pleaseensurethatthepipeofworkof your
refrigerating unitdoesnotgetdamaged priortobeingpicked-upbythe relevantwaste
disposal service.
Importantnote:
Please read this booklet beforeinstalling and switching onthis appliance. The
manufacturerassumesno responsibilityforincorrectinstallationandusageasdescribed
inthisbooklet.
PleaseaskyourmunicipalauthorityaboutthedisposaloftheWEEEfor
thereuse,recycleandrecoverypurposes.

EN -3-
Recommendations
Warning: Donotusemechanicaldevicesorothermeanstoaccelerate thedefrosting
process,otherthan thoserecommended bythe manufacturer.Donot useelectrical
appliancesinsidethefoodstoragecompartmentsof theappliance,unlesstheyareof
the type recommended bythe manufacturer.Keepventilationopenings,inthe appliance
enclosureorinthebuilt-instructure,clearofobstruction. Donotdamagetherefrigerant
circuit.
•Donotdamagetherefrigerantcircuit.
•Donot allowchildren to playwith theappliance. Children must
neversitinthedrawersorhangfromthedoor.
•Donotuseadaptersorshunts,whichcould causeoverheating
orburning.
•Donotplugold,warpedpowersupply cables.
•Donottwist andbendthecables,andkeepthemawayfromhot
surfaces.
•Donotplugthepowersupply withwethands.
•Youroldappliancescontaininsulationgasesand refrigerant
thatmustbedisposedof properly.Pleaseensurethatthe
refrigerant circuitis notdamagedbefore theapplianceistaken
awayfordisposal.
•Afterinstallationmakesurethatthepowercable isnottrapped
underneath appliance.
•Thisapplianceis not intended for usebypersons(including
children)withreducedphysical,sensoryormentalcapabilities,
orlackofexperienceandknowledge,unless theyhavebeen
givensupervisionorinstructionconcerninguseofthe appliance
byapersonresponsible fortheirsafety.Childrenshouldbe
supervised toensurethattheydon’tplaywith theappliance.
•If thesupplycordisdamageditmustbereplacedbythe
manufacturer orserviceagentorappointedqualifiedperson.
•Donotdefrosttheappliancewithotherelectricaldevices(i.e.hairdryer)orother
artificialmeans,and donotusesharpmetalobjectstoremovethe iceonthefreezer,
asthiscouldcausedamagetothe refrigerantsystem.
•Donotoperate anyelectrical appliancesinsidethe refrigeratororfreezer.
•Donotplacebottles (glass ortin)containingliquids(especiallysparkling liquids)
intothe freezer astheycouldcausethe bottleto burstduring freezing.
•Donottouchthecoolingsurfaceswhiletheapplianceoperates,especiallywithwet
hands,becausetheskinmaystickto cold surfaces.

EN -4-
•Donoteatice,which hasjustbeenremovedfromthefreezer.
•Theapplianceisnotintended forusebypeople(includingchildren)withreduced
physical,sensoryormentalcapabilities,orlackofexperienceandknowledge,unless
theyhavebeengivensupervisionorinstructionconcerninguseoftheapplianceby
apersonresponsiblefortheirsafety.Childrenshouldbesupervised toensurethat
theydon’t playwith theappliance.
•Ifthesupply cordisdamageditmustbereplacedbythemanufacturerorservice
agentorsimilaryqualifiedpeople inordertoavoid ahazard.
Switching OntheAppliance
•Beforeswitching on, placetheapplianceon upright position
andwaitat leastthreehourswithoutmoving theappliance. This
will givethe refrigerantcircuittimeto settle andoperate
efficiently.
•Cleanthe appliancethoroughly,especiallyintheinterior, before
use(SeeCleaningandMaintenance).
•Installationofthe appliance andelectrical connectionsmust be
carriedout byaqualified technician, in accordancewith the
Installation Manualandlocalregulations.
•Installationprocedureintothekitchenunitisgiven in the
Installation Manual. Thisproductis intended tobe used in
properkitchenunitsonly.
•Theappliancemustbe connected with aproperly installedfused
socket.Powersupply (AC)andvoltageattheoperatingpoint
mustwiththe detailson the name plate ofthe appliance (name
plateislocated ontheinsideleft oftheappliance).
•Inserttheplugintoasocket withanefficient groundconnection.
If the sockethasnogroundcontactortheplugdoesnot match,
wesuggestyoutocallanauthorized electricianforassistance.
•Manufacturerisnot responsibleforfailuretocompletethe
groundconnection as describedinthisbooklet.
•Therecan beanodorwhenyou firstswitchonthe appliance.Itwilldisappearafter
theappliancestartstocool.

EN -5-
PART2. HOWTOOPERATETHE APPLIANCE
ThermostatSetting
•Thermostat automaticallyregulatesthe insidetemperatureoftherefrigerator
compartment andfreezercompartment.Byrotatingtheknobfromposition1to5,
coldertemperaturescanbe obtained.
•The“0“ positionshowsthermostatisclosedand nocoolingisavailable.
•Forshort-termstorageoffoodinthefreezercompartment,youcansetthe knob
between minimumandmediumposition(1-3).
•Forlong-termstorage of food inthe freezercompartment,you cansetknobmedium
position.(3-4)
• Notethat; theambienttemperature,temperature of thefreshlystoredfoodand
howoftenthedooris opened, affectsthetemperatureintherefrigeratorand
freezercompartments. If required, change thetemperaturesetting.
•When youfirstswitchon theappliance, youshouldideallytrytorun itwithoutanyfood
infor24hoursandnotopen thedoor.Ifyouneedto useitstraightaway,trynottoput
muchfood inside.
•Iftheunitis switchedofforunplugged,youmustallowatleast5minutesbefore
restartinginordernotto damagethecompressor.
• LARDERS (withoutstarrating):Larders(coolers)havenotanyfreezercompartment
butcancooldownto4-6°C.

EN -6-
PART4. CLEANING AND MAINTENANCE
•Disconnecttheappliancefromthepowersupply beforecleaning.
•Donot pourwaterover theappliance.
•The refrigeratorcompartment should be cleaned periodically
usingasolution ofbicarbonate of soda andlukewarmwater.
•Cleanthe accessoriesseparatelywith soap andwater.Donot
puttheminthedishwasher.
•Donot useabrasiveproducts,detergentsorsoaps.After
washing, rinsewith cleanwateranddrycarefully.Whenthe
cleaningoperationshavebeencompleted,reconnectthe plug
with dry hands.
PART3. FOODSTORAGE INTHE APPLIANCE
Refrigeratorcompartmentisusedforstoring freshfoodforfewdays.
•Donotplacefoodindirectcontact withthe rearwallof therefrigeratorcompartment.
Leavesomespacearoundfoodtoallowcirculationof air.
•Donotplacehotfood orevaporating liquidin therefrigerator.
•Alwaysstorefood inclosed containersorwrapped.
•Toreducehumidityand avoid formation of frost, neverplaceliquidsin unsealed
containersintherefrigerator.
•Meat ofalltypes,wrappedinpackages,is recommendedto be placedon theglass
shelfjustabovethevegetablebin,wheretheairiscolder.
•Youcanputthefruitsandvegetablesinto crisperwithoutpacking.
•Toavoidthecoldairescaping,trynotto open thedoortoooften,andnot leavethe
dooropenforalongtime.

EN -7-
Defrosting
• Defrostingoccursautomatically in refrigerator compartment during operation;the
defrostwateris collectedbythe evaporatingtrayandevaporatesautomatically.
•The evaporatingtrayand the defrost waterdrain hole shouldbe cleanedperiodically
with defrostdrain plug to preventthe waterfromcollectingon the bottomof the
refrigerator insteadof flowing out.
•Youcanalsopour½glassofthewatertodrainholetocleaninside.
Replacing theLightBulb
Whenreplacingthebulbof therefrigeratorcompartment;
1. Unplugthe unitfromthepowersupply,
2. Press thehooks onthe sidesofthe lightcovertopandremovethelightcover
3. Changethe presentlightbulbwithanewoneof notmorethan15W.
4. Replacethelightcoverandafterwaiting5minutesplug theunit.

EN -8-
PART5. BEFORECALLING YOUR AFTERSALES SERVICE
Ifyourrefrigeratorisnotworkingproperly,itmaybeaminor problem,thereforecheckthe
following.
Theappliancedoesnotoperate,
Checkif;
•Thereisapowerfailure,
•Themainsplug isnotproperlypluggedin,orisloose
•Thethermostat setting isonposition “0”,
•Thesocketisdefective.Tocheckthis,plugin anotherappliancethat youknowwhich
isworkingintothe samesocket.
Theapplianceperformspoorly;
Checkif;
•Youhaveoverloaded theappliance,
•Thedoorsarenot closedperfectly,
•Therearenotenoughventilation ductsonthe kitchenunitasmentionedinthe
Installation Manual.
Ifthereisnoise;
The coolinggaswhichcirculatesin the refrigeratorcircuit maymakeaslightnoise
(bubblingsound)evenwhenthecompressorisnot running.Donotworry,thisisquite
normal.Ifthesesoundsaredifferent checkif;
•Theapplianceisinstalledfirmly asdescribedin theInstallationManual.
•Theobjectsontheappliancearevibrating.
Ifthereis waterinthelowerpartoftherefrigerator;
Checkif;
Thedrainholefordefrostwaterisnotclogged(usedefrostdrainplugtoclean thedrain
hole).

EN -9-
If yourfridge isnotcooling enough;
Yourfridge is designed tooperatein the ambient temperatureintervals statedin the
standards,accordingtotheclimateclassstatedintheinformationlabel.Wedonot
recommend operatingyourfridgeoutofstatedtemperaturesvaluelimitsintermsof cooling
effectiveness.
ClimateClass Ambient Temperature(°C)
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)
•TropicalClimateClassisdescribedasbetween16°Cand43°Cofambient
temperatures accordingtoEN ISO15502standards.
•Appliance complieswith EN15502, IEC60335-1/IEC60335-2-24, 2004/108/EC
standards.
Recommendations
•Inordertoincreasespaceand improvetheappearance, the “coolingsection”of
refrigeratorsis positionedinsidethebackwallof therefrigeratorcompartment. When
thecompressoris working, thiswallis covered with frostorwaterdrops.Donot
worry.This isquitenormal.The applianceshouldbe defrostedonly ifanexcessively
thickicelayerforms on thebackwall.
•Iftheapplianceisnotusedforalong time(forexample duringthesummer
holidays), setthethermostatknob toposition“0”.Defrostandcleantherefrigerator
leavingthe dooropento preventtheformationof mildewandsmell.
