Fagor BMF-300X User manual

1
BMF-300X
24” REFRIGERATOR
Refrigerador de 24”
Write the serial number here: _______________
User’s Manual
Manual del Usuario
BMF-300X User's Manual.FINAL.indd 1BMF-300X User's Manual.FINAL.indd 1 9/3/16 7:58 PM9/3/16 7:58 PM

BMF-300X User's Manual.FINAL.indd 2BMF-300X User's Manual.FINAL.indd 2 9/3/16 7:58 PM9/3/16 7:58 PM

3
Contents
Brief Introduction
Important Safety Instructions
Brief Introduction....................................... 3
Important Safety Instructions.................... 3
Description of the Appliance..................... 5
Display Controls ........................................ 6
Using your Appliance ................................ 8
Thank you for selecting Fagor. We are sure
you will find your new appliance a pleasure
to use.
Before you use your new appliance, we
recommend that you read through these in-
structions carefully. This manual will provide
details about the appliance usage and func-
tions.
• Please make sure that all people using this
appliance are familiar with its operation
and safety features. It is important that
you install the appliance correctly and pay
attention to the safety instructions.
• We recommend that you keep this user’s
manual for future reference and pass it
along to any future users.
General Safety and Daily Use
It is important that you use your
appliance safely and that you follow
the safety guidelines below.
• Store any food in accordance with
the storage instructions from the
manufacturer.
• Don’t use mechanical devices or means
other than those recommended by the
food manufacturer to speed up the
thawing process.
• Don’t try to repair the appliance yourself.
It is dangerous to alter or modify this
product in any way.
• Be careful not to damage refrigeration
circuits or the unit’s power cord. Any
damage to the cord may cause a short
circuit and could potentially lead to
electric shock or fire.
Helpful Hints and Tips............................... 9
Cleaning and Care................................... 10
Troubleshooting....................................... 12
Disposal of the Appliance........................ 13
• This appliance is intended to be used in
households only, it is not intended for
commercial use.
• Refrigerator must be installed with correct
ventilation requirements and in areas
which are 60-70 degrees Fahrenheit.
• Ifyoufeelthattheapplianceisnotoperating
correctly, please checkthetroubleshooting
section (pg. 12) for assistance. If you
should need further assistance, contact
our customer service help line at
1-877-743-2467 to arrange a service call
by an authorized technician.
• Do not place food directly against the
air outlet on the rear wall of either the
refrigerator or freezer compartment, as
this could affect proper air circulation.
• Do not place hot items near the plastic
components of this appliance.
• Frozen food must not be refrozen once it
has been thawed out.
• Don’t store carbonated drinks or glass
bottles containing liquid in the freezer as
they can burst.
• Do not eat extremely cold ices or food as
they can produce burns in the mouth.
• To avoid items falling and causing injury or
damage to the appliance, do not overload
the door racks or put too much food in the
crisper drawers.
BMF-300X User's Manual.FINAL.indd 3BMF-300X User's Manual.FINAL.indd 3 9/3/16 7:58 PM9/3/16 7:58 PM

4
• Fagor will not be responsible for any
damage or defects caused by, or resulting
from, repairs, service, conversion or
alterations to the product or any of its
parts and accessories which have been
performed by service centers or repairmen
not authorized by Fagor.
• Fagor will not be responsible for any
direct, indirect or consequential damages,
losses or other costs and expenses
resulting from any spoilage of any items
stored this refrigeration system, whether
they be food, medicine, or otherwise.
Safety for Children and Others
This appliance is not intended for use
by people (including children) who lack
experience or knowledge, except under
supervision or after receiving instruction
regarding use of the appliance from a person
responsible for their safety. Use by children
should be supervised to prevent them from
playing with or otherwise misusing the
appliance.
• Keep packing materials out of reach of
children, these materials are potentially
hazardous. During unit disposal, observe
local standards for this type of waste material.
• Do not touch the hot compressor at the rear
bottom of the appliance as this may cause
physical injury. Keep children away from the
rear of the appliance.
• Do not place items on top of the appliance as
they could cause injury should they fall off.
• Never allow children to hang or stand on the
doors, racks, shelves and drawers etc.
Electrical Safety
To avoid the risks that are always
present when using an electric
appliance, we recommend that you
follow the instructions below.
• Unpack the appliance and carefully
check the interior and exterior. Should
any damage be evident, do not plug the
appliance in, but rather contact the store
immediately from which you purchased it.
Keep all packing materials if this should
occur.
• We recommend that you wait for 24 hours
before connecting the appliance to a
power source to allow the refrigerant to
flow back into the compressor.
• The appliance must be installed with
single phase alternating current of 110-
120/60Hz. If the voltage fluctuates, it
could exceed maximum voltage limit. An
automatic voltage regulator of more than
350W should be installed for safety.
• The main outlet must be accessible when
the appliance is installed. This appliance
must be grounded.
- This appliance is fitted with a fused
plug in accordance with local
standards. The fused plug should be
suitable for use in all houses fitted
with sockets in accordance with
current specifications.
- If the fitted plug is not suitable for
your outlets, contact a qualified
electrician.
• Do not use extension cords when
connecting your appliance. Always plug
your appliance into its own individual
electrical outlet which has a voltage
rating matching the rating plate on the
unit. Using an outlet with other electrics
plugged in could cause overloading of
wiring circuits and a potential fire.
• Make sure that the plug is not squashed
or damaged. Otherwise, it may cause a
short circuit, electric shock or fire.
• Do not plug the power cord in if the outlet
is loose as this could lead to a risk of
electric shock or fire.
• Switch off the appliance and disconnect it
from the main power before you clean or
move it.
• Never unplug the appliance by pulling
on the power cord. Always grip the plug
firmly and pull straight out from the outlet
to prevent damaging the cord.
• Do not operate the appliance without
the light cover for the interior light as the
light is very bright and might cause vision
damage if not properly protected by the
cover.
• Any electrical component of the appliance
must be replaced or repaired by a
qualified electrician or authorized service
personnel. Only authentic Fagor parts
should be used.
• Don’t place electrical devices such as
crock pots, blenders, ice cream makers,
etc. in the interior of the refrigerator, unless
recommended by the manufacturer of the
device.
BMF-300X User's Manual.FINAL.indd 4BMF-300X User's Manual.FINAL.indd 4 9/3/16 7:58 PM9/3/16 7:58 PM

5
Description of the Appliance
Note: This diagram may not correspond exactly to your refrigerator. To get more space in the
freezer, you can remove the drawers (except the lower freezer drawer) and the twistable ice
tray.
1. Fridge door
2. LED light
3. Bottle rack
4. Glass shelves
5. Multi Fresh compartment
(fruits and vegetables)
6. Upper freezer drawer
7. Middle freezer drawer
8. Lower freezer drawer
9. Adjustable bottom feet
10. Covered dairy rack
11. Middle rack
12. Bottom rack
13. Handles
14. Freezer door
1
2
3
4
5
6
7
8
10
11
12
14
13
9
BMF-300X User's Manual.FINAL.indd 5BMF-300X User's Manual.FINAL.indd 5 9/3/16 7:58 PM9/3/16 7:58 PM

6
Display Controls
Use your appliance according to the following instructions, your appliance has the same
functions and modes as the control panels shown in the pictures below. When the appliance is
powered on for the first time, the backlighting of the icons on the display panel will illuminate.
If no buttons have been pressed and the doors are closed, the backlighting will turn off.
Temperature Recommendation
The recommended temperature for the
refrigerator compartment is 39ºF (4ºC) and
the freezer compartment -1ºF (-18ºC) for
already frozen food.
Caution! When you set a temperature, you
set an average temperature for the whole
refrigerator cabinet. The interior temperature
can be affected by the temperature of the
environment, the arrangement of food inside
and the frequency of the door opening.
1. °F/°C Exchange
The temperature display can be alternated
between °F and °C by pressing the “Holiday”
and “Alarm” button at the same time for 3
seconds.
2. Fridge
Press “ ” to set desired fridge tempe-
rature between 35ºF (2ºC) and 46ºF (8ºC).
The preset temperature for the fridge is 41ºF
(5ºC), each time you push the fridge button
the temperature will decrease by one degree.
Once you reach the lowest temperature of
35ºF (2ºC) pressing the button again will
cause the temperature to cycle back to the
highest temperature of 46ºF (8ºC).
BMF-300X User's Manual.FINAL.indd 6BMF-300X User's Manual.FINAL.indd 6 9/3/16 7:58 PM9/3/16 7:58 PM

7
3. Super Cool
This function sets the refrigera-
tor to the coldest temperature for
6 hours. It should be used if you
introduce a large quantity of food
into the refrigerator at once.
• Press the “Super Cool” button to activate
this function. The light will turn on.
• “Super Cool” automatically switches
off after 6 hours and the temperature
displays 35°F/2°C.
• To disable this function press “Super
Cool” or “ ” button and the refrigerator
temperature setting will revert back to
the previous setting.
4. Freezer
Press “ ” to set desired freezer tempe-
rature between 6ºF (-14ºC) and 12°F (-24ºC).
The preset temperature for the freezer is
-1ºF (-18ºC), each time you push the freezer
button the temperature will decrease by
one degree. Once you reach the lowest
temperature of -12ºF (-24ºC) pressing the
button again will cause the temperature to
cycle back to the highest temperature of 6ºF
(-14ºC).
5. Super Freeze
Super Freeze will quickly lower
the temperature within the freezer
so food will freeze faster and will
be kept fresh longer.
• Press the “Super Freeze” button to
activate the super freeze function.
The light will come on and the freezer
temperature setting will display -12ºF
(-24ºC).
• The function should be activated 24
hours before putting a large quantity
of food in the freezer. Super freeze
automatically switches off after 26 hours.
• When the “Super Freeze” function is on
you can deactivate it by pressing “Super
Freeze” or “ ” button and the freezer
temperature will revert back to the
previous setting.
6. Holiday
This function is very useful when
the refrigerator will not be used
for a long period of time, but you
want to keep food in the freezer.
Using this function, your refrigerator will
use less power and odors won’t develop in
the interior. To activate, press the “Holiday”
button for 3 seconds until the light comes
on.
Warning: Before enabling this function
empty the refrigerator, clean it, and close
the door.
• When the Holiday function is activated,
the temperature of the refrigerator is
automatically switched to 59°F (15°C)
to minimize the energy consumption.
Important! Do not store any food in the
fridge during this time.
• When the Holiday function is on, you
can switch it off by pressing either the
“Holiday”, “ ” or “Super Cool” button.
The fridge temperature setting will revert
back to the previous setting.
7. Alarm
In the event that the alarm should sound, the
“Alarm” icon will come on and there will be a
buzzing sound. Press the “Alarm” button to
silence the alarm and then the “Alarm” icon
will turn off and the buzzer will stop.
Door Alarm
• If the door of the fridge or freezer stays
open for more than 2 minutes, an alarm
will sound. This alarm will sound 3 times
every minute and will stop automatically
after 10 minutes.
• To save energy, please avoid keeping
the door open for a long time. The door
alarm can also be interrupted by closing
the fridge door.
Temperature Alarm
• If the temperature of the freezer
is unusually high, there will be a
temperature alarm and the freezer
temperature setting will display “--”.
In the event of a temperature alarm, the
alarm will sound 10 times consecutively
and then stop automatically.
BMF-300X User's Manual.FINAL.indd 7BMF-300X User's Manual.FINAL.indd 7 9/3/16 7:58 PM9/3/16 7:58 PM

8
Using your Appliance
• If the temperature alarm goes off, press
the “Alarm” button for 3 seconds to
check the highest freezer temperature.
The temperature reading and “Alarm”
icon will simultaneously flash for 5
seconds.
Door Rack
• The door rack is used for the storage
of eggs, canned goods, bottled drinks,
packed food, etc. Do not place too many
heavy things in the door racks.
• The middle door shelf can be placed
at different heights according to your
requirements. Please take food out
of the shelf before lifting vertically to
reposition.
Note: There are egg trays in the upper shelf
and a bottle holder in the lower shelf.
Shelves in Refrigerator Cavity
• There are shelves in the refrigerator
cavity which can be taken out to facilitate
cleaning.
Caution! In the event of loss of electrical
power, open the refrigerator doors as little
as possible. When the power returns it is
normal for the temperature alarm to sound, it
can be deactivated by pressing the “Alarm”
button. Check if the frozen food has thawed
and discard if necessary.
Your appliance has the accessories shown in the “Description of the appliance” section on
page 10. This portion of the user manual shows you how to correctly use them.
Multi Fresh Compartment
• Thanks to the design of this compartment
and its location in the coldest part of the
fridge, the Multi Fresh drawer meets
the ideal temperature requirements for
conserving fruits and vegetables for
longer.
Freezer Drawers
• The freezer drawers are used to store
food which needs to be frozen, including
meat, fish, ice cream, etc.
BMF-300X User's Manual.FINAL.indd 8BMF-300X User's Manual.FINAL.indd 8 9/3/16 7:58 PM9/3/16 7:58 PM

9
Helpful Hints and Tips
Twistable Ice Tray
Note: If the ice tray is being used for the first
time or has not been used for a long time,
please clean it before using.
• The twistable ice tray is used to make
and deposit ice cubes. You should use it
as follows.
1. Pull out the twistable ice tray from
the installation bracket.
2. Pour water into the ice tray, please
make sure the water level does not
exceed the maximum line.
Energy Saving Tips
We recommend that you follow the tips
below to save energy.
• Avoid leaving the doors open more time
than necessary. It causes unnecessary
excess power consumption.
• Make sure the appliance is away from
any sources of heat (direct sunlight,
other large kitchen appliances, etc).
• Don’t set the temperature colder than
necessary.
• Avoid placing hot foods in the refrigera-
tor or freezer. The internal temperature
will increase resulting in the compressor
having to work harder and will consume
more energy to maintain the set temper-
ature.
• Place the appliance in a well ventilated,
humidity free, room. Please refer to the
“Installing your New Appliance” section
(page 5).
3. Place the filled ice tray back to the
bracket and let freeze for a few
hours.
4. When the ice cubes fully solidify,
twist the knobs clockwise and the
ice will drop into the ice box below.
5. Ice cubes can be stored in the ice
box. You can pull out the ice box and
take your ice cubes out as needed.
Hints for Fresh Food Refrigeration
• Store food in airtight containers to pre-
vent drying.
• Try to leave space between food items
so that air circulates around them.
Hints for Refrigeration
• Meat (All Types): Wrap and place on the
glass shelf above the vegetable drawer.
Always follow food storage times and
use by dates suggested by manufactur-
ers.
• Cooked Food, Cold Dishes, Etc.:
Should be covered and may be placed
on any shelf.
• Fruit and Vegetables: Should be stored
in the special drawer provided.
• Butter and Cheese: Should be wrapped
in airtight foil or plastic film wrap.
• Milk Bottles: Should have a lid and be
stored in the door racks.
BMF-300X User's Manual.FINAL.indd 9BMF-300X User's Manual.FINAL.indd 9 9/3/16 7:58 PM9/3/16 7:58 PM

10
Cleaning and Care
Hints for Freezing
• When first starting-up or after a period
without use, let the appliance run at least
2 hours on the coldest setting before
putting food in.
• For faster freezing and thawing, we
recommend storing food in small
portions.
• Wrap food in aluminum foil or airtight
food containers.
• Do not allow fresh, unfrozen food to
touch the food which is already frozen to
avoid temperature rise of frozen product.
• Frozen products, if consumed imme-
diately after removal from the freezer
compartment, will probably cause frost
burns to the skin and mouth.
• We recommend labeling and dating each
frozen package in order to keep track of
the storage time.
For hygienic reasons, the appliance
(including exterior and interior accessories)
should be cleaned regularly at least every
two months.
Caution! The appliance must not be
connected to the power source during
cleaning to avoid the risk of electric shock.
Before cleaning switch the appliance off and
remove the plug from the socket.
Exterior Cleaning
Wipe the digital display and control panel
with a clean, soft cloth.
• Spray water onto the cleaning cloth
instead of spraying directly on the
surface of the appliance. This helps
ensure an even distribution of moisture
to the surface.
• Clean the doors, handles and cabinet
surfaces with a mild detergent and then
wipe dry with a soft cloth.
Hints for the Storage of Frozen Food
• Ensure that frozen food has been stored
in accordance with the manufacturer’s
instruction.
• Once defrosted, food quality rapidly
decreases and should not be re-frozen.
Do not exceed the storage period of
time indicated by the food manufacturer.
Switching off your Appliance
• If the appliance needs to be switched
off for an extended period of time,
the following steps should be taken
to prevent mold from growing in the
appliance.
1. Remove all food.
2. Unplug the power plug from the main
socket.
3. Clean and dry the interior thoroughly.
4. Ensure that all the doors are wedged
open slightly to allow air to circulate.
Caution!
• Don’t use rough cleaning pads such as
steel wool or brushes as they are likely
to scratch the surface.
• Don’t use chemical thinner, car
detergent, Clorox, ethereal oil, abrasive
cleaners or organic solvent such as
Benzene for cleaning. They may damage
the surface of the appliance.
Interior Cleaning
You should clean the appliance interior
regularly. It will be easier to clean when
there are no shelves or food in the unit. Use
a sponge or a dish cloth soaked in water
with baking soda to clean the inside of
the refrigerator and to prevent odors from
developing. Wipe the interior completely
dry before replacing the shelves and other
accessories.
BMF-300X User's Manual.FINAL.indd 10BMF-300X User's Manual.FINAL.indd 10 9/3/16 7:58 PM9/3/16 7:58 PM

11
Thoroughly dry all surfaces and removable
parts. Although this appliance automatically
defrosts, a layer of frost may occur on the
freezer compartment’s interior walls if the
freezer door is opened frequently or kept
open too long. If the frost is too thick,
choose a time when there is less food in the
unit and proceed as follows:
1. Remove existing food and all
accessories, unplug the appliance
from the outlet and leave the doors
open. Ventilate the room thoroughly to
accelerate the thawing process.
2. When defrosting is completed, clean
your freezer as described in the
“Cleaning and Care” section (page 15).
Caution! Don’t use sharp objects
to remove frost from the freezer
compartment. Only after the interior is
completely dry should the appliance be
plugged back in and switched back on.
Door Seal Cleaning
Remember to keep door seals clean. Sticky
food and drinks can cause seals to stick
to the cabinet and tear when you open the
door. Wash seal with a mild detergent and
warm water. Rinse and dry it thoroughly
after cleaning.
Caution! Only after the door seals are
completely dry should the appliance be
powered on.
Replacing the LED Light
Warning: If the LED light is damaged,
contact the customer service help line for
assistance at 1-877-743-2467. To replace
the LED light:
1. Unplug your appliance.
2. Remove the light cover by pushing up
and out.
3. Hold the LED cover with one hand and
pull it toward you with the other hand
while pressing the connector latch.
4. Replace LED light and snap correctly in
place.
BMF-300X User's Manual.FINAL.indd 11BMF-300X User's Manual.FINAL.indd 11 9/3/16 7:58 PM9/3/16 7:58 PM

12
Troubleshooting
If you experience a problem with your appliance or are concerned that the appliance is not
functioning correctly, you can carry out some easy checks before calling for technical service.
Warning! Don’t try to repair the appliance yourself. If the problem persists after you have made
the checks, contact a Fagor authorized service technician.
Problem Possible Cause and Solution
Appliance is not working
correctly
Check whether the power cord is plugged into the outlet.
Check the fuse box or circuit breaker. Replace fuse if necessary.
The room temperature is too low or too high. Try setting the fridge and
freezer to a colder level.
It is normal for the freezer not to operate during the automatic defrost cycle or
for a short time after the appliance is switched on to protect the compressor.
Odors from the
compartments
The interior may need to be cleaned.
Some food is producing odors in the refrigerator. Wrap the food or cover it
correctly.
Noise from the
appliance
The sounds below are normal:
• Compressor running noises.
• Noise from the small fan motor in the freezer compartment or other
compartments.
• Gurgling sound similar to water boiling.
• Popping noise during automatic defrosting.
• Clicking noise before the compressor starts.
Other unusual noises are due to the reasons below and may need your
attention:
• The cabinet is not leveled.
• The appliance is touching the wall.
• The internal motor might need maintenance.
The compressor runs
constantly
It is normal to frequently hear the sound of the compressor, it will need to
run more if:
• Temperature setting is set colder than necessary.
• Large quantity of food has recently been stored within the appliance.
• The temperature outside the appliance is too high.
• Doors have been open for too long or too often.
• You have recently installed the appliance or it has been switched back on
after being off for a long time.
A layer of frost occurs in
the compartment
Check that the air outlets are not blocked by food and ensure food is placed
within the appliance to allow sufficient ventilation. Ensure that door is fully
closed. To remove the frost, please refer to Cleaning and Care section (page
15).
Temperature inside the
appliance is too warm
You may have left the doors open too long or too frequently. The doors are
kept open by some obstruction. The appliance is located with insufficient
clearance at the sides, back and top.
BMF-300X User's Manual.FINAL.indd 12BMF-300X User's Manual.FINAL.indd 12 9/3/16 7:58 PM9/3/16 7:58 PM

13
Temperature inside the
appliance is too cold
Increase the temperature by following the “Display Controls” section
(page 11).
Doors won’t close Check whether the top of the refrigerator is tilted back to allow the doors to
self close, or if something inside is preventing the doors from closing.
Water drips from the
appliance
The water pan (located at the rear bottom of the cabinet) may not be properly
leveled. The draining spout located underneath the top of the compressor
depot may not be properly positioned to direct water into this pan, or the
water spout is blocked. You may need to pull the refrigerator away from the
wall to check the pan and spout.
The light is not working
• The LED light may be damaged. Refer to the “Replacing the LED Light” in
the “Cleaning and Care” section (page 16).
• The control system has disabled the lights due to the door being kept
open too long, close and reopen the door to reactivate the lights. This will
happen when the doors are opened for more than 10 minutes, the alarm
will sound for 1 minute and the light will automatically switch off.
Disposal of the Appliance
It is prohibited to dispose of this appliance as household waste.
Packaging materials
Packaging materials with the recycle symbol are recyclable. Dispose of the packaging into a
suitable waste collection container to recycle it.
Before Disposal of the Appliance
1. Unplug the unit.
2. When disposing of the appliance, the doors should be removed and the power cord should
also be cut off or removed.
Warning! Refrigerators contain refrigerant and gases in the insulation. Refrigerant and gases
must be disposed of professionally as they may cause eye injuries or ignition. Ensure that
tubing of the refrigerant system is not damaged prior to proper disposal.
Correct Disposal of this Product
This symbol indicates that the appliance must not be disposed of in
traditional bins for domestic waste. Deliver your refrigerator to a special
collection center. Recycling domestic appliances prevents negative
impacts on health and the environment and helps save energy and
resources. For more information, contact your local authorities or the
establishment where you purchased your refrigerator.
BMF-300X User's Manual.FINAL.indd 13BMF-300X User's Manual.FINAL.indd 13 9/3/16 7:58 PM9/3/16 7:58 PM

BMF-300X User's Manual.FINAL.indd 14BMF-300X User's Manual.FINAL.indd 14 9/3/16 7:58 PM9/3/16 7:58 PM

15
Índice
Breve Introducción
Instrucciones de Seguridad Importantes
Breve Introducción .................................. 15
Instrucciones de Seguridad Importantes 15
Descripción del Electrodoméstico .......... 17
Controles de la Pantalla .......................... 18
Uso del Electrodoméstico....................... 20
Gracias por elegir Fagor. Estamos seguros
de que será un placer para usted usar su
nuevo electrodoméstico.
Antes de usar el electrodoméstico, le
recomendamos que lea atentamente las
instrucciones, donde encontrará datos
concretos sobre su uso y funciones.
• Por favor asegúrese de que todas las
personas que usarán el electrodoméstico
están familiarizadas con sus funciones
y características de seguridad. Es
importante que instale correctamente el
electrodoméstico y preste atención a las
instrucciones de seguridad.
• Le recomendamos que guarde este
manual del usuario para futuras consultas
Seguridad General y Uso Diario
Es importante que usted use su
electrodoméstico de forma segura y
que siga las pautas de seguridad a
continuación.
• Guarde cualquier alimento de acuerdo
con las instrucciones del fabricante.
• No utilice aparatos mecánicos u otros
medios distintos de los recomendados
por el fabricante de alimentos para
acelerar el proceso de descongelación.
• No trate de reparar el electrodoméstico
usted mismo. Es peligroso alterar o
modificar este producto de cualquier
manera.
• Tenga cuidado de no dañar los circuitos
de refrigeración o cable eléctrico de la
unidad. Cualquier daño en el cable puede
causar un cortocircuito y potencialmente
podría provocar una descarga eléctrica o
un incendio.
Consejos Útiles ....................................... 21
Limpieza y Mantenimiento ...................... 22
Localización de Averías........................... 24
Eliminación del Electrodoméstico ........... 25
y que lo conserve para futuros usuarios.
• Este electrodoméstico está diseñado para
ser utilizado en los hogares únicamente,
no está destinado para el uso comercial.
• Refrigerador debe ser instalado con los
requisitos de ventilación correctos y en las
áreas que son 60-70 grados Fahrenheit.
• Si usted siente que el electrodoméstico
no funciona correctamente, consulte la
sección <<Localización de Averías>> (pg.
24) para obtener ayuda. Si necesita más
ayuda, llame nuestra línea de ayuda de
servicio al 1-877-743-2467 para hacer una
cita de servicio por un técnico autorizado.
• No coloque alimentos en frente de la
salida de aire en la pared posterior de los
compartimientos del refrigerador y del
congelador, ya que esto podría afectar la
circulación de aire.
• No coloque objetos calientes cerca
de los componentes plásticos de este
electrodoméstico.
• Los alimentos congelados no deben
volver a congelarse una vez que han sido
descongelados.
• No guarde bebidas carbonatadas o
botellas de vidrio que contienen líquido
en el congelador ya que podrían explotar.
• No coma alimentos muy fríos o hielo, ya
que pueden producir quemaduras en la
boca.
• Para evitar la caída de objetos y lesiones,
o daños en el electrodoméstico, no
sobrecargue los estantes de la puerta o
ponga demasiada comida en los cajones.
BMF-300X User's Manual.FINAL.indd 15BMF-300X User's Manual.FINAL.indd 15 9/3/16 7:58 PM9/3/16 7:58 PM

16
• Fagor no se hace responsable de ningún
daño o desperfecto ocasionados por
reparaciones, servicio , manipulación
o alteración del producto o alguna de
sus partes y accesorios realizados por
servicios técnicos no autorizados por
Fagor.
• Fagor no se hace responsable por
cualquier daño, pérdida o coste directo
o indirecto resultante de cualquier
deterioro de los elementos almacenados
en este sistema de refrigeración, ya sean
alimentos, medicinas o similares.
Seguridad Para los Niños y Otras Personas
Este electrodoméstico no está diseñado
para ser utilizado por personas (incluyendo
niños) sin experiencia o conocimiento,
excepto bajo supervisión o después de
recibir instrucción con respecto al uso
del electrodoméstico por una persona
responsable de su seguridad. Uso por
niños debe ser supervisado para evitar que
jueguen con el aparato.
• Mantenga los materiales de embalaje fuera
del alcance de los niños, estos materiales
son potencialmente peligrosos. Durante
la eliminación del electrodoméstico,
observe las normas locales para este tipo
de residuos.
• No toque el compresor caliente en la parte
inferior trasera del electrodoméstico,
ya que puede provocar lesiones físicas.
Mantenga a los niños lejos de la parte
trasera del electrodoméstico.
• No coloque objetos en la parte superior
del electrodoméstico, ya que podrían
causar lesiones si se caen.
• Nunca permita que los niños se cuelguen
o se paren en las puertas, bastidores,
estantes, cajones, etc.
Seguridad Eléctrica
Para evitar los riesgos que siempre
están presentes cuando se utiliza un
aparato eléctrico, le recomendamos
que siga las instrucciones a
continuación.
• Desembale el electrodoméstico y revise
cuidadosamente el interior y exterior.
En caso de cualquier daño evidente, no
conecte el electrodoméstico, póngase
en contacto inmediatamente con la
tienda donde lo compró. Mantenga los
materiales de embalaje.
• Le recomendamos que espere 24 horas
antes de conectar el electrodoméstico a
una fuente de potencia para permitir que
el refrigerante fluya hacia el compresor.
• El electrodoméstico debe ser instalado
con corriente alterna monofásica de 110-
120 / 60Hz. Si el voltaje fluctúa, se podría
exceder el límite de voltaje máximo. Un
regulador automático de voltaje de más
de 350W se debe instalar por seguridad.
• La toma de corriente debe estar accesible
una vez que el electrodoméstico ha sido
instalado. Este electrodoméstico debe
estar conectado a tierra.
- Este electrodoméstico está equipado
con un enchufe de acuerdo con las
normas locales. El enchufe debe ser
adecuado para uso en todas las casas
equipadas con tomas de acuerdo con
las especificaciones actuales.
- Si el enchufe no es adecuado para
su toma, consulte a un electricista
calificado.
• No utilice cables de extensión para
conectar su electrodoméstico. Siempre
conecte el electrodoméstico en una
toma de corriente individual que tenga un
voltaje apropiado que corresponda con la
unidad. El uso de una toma de corriente
con otros aparatos conectados podría
causar sobrecarga en los circuitos de
cableado y un posible incendio.
• Asegúrese de que el enchufe no esté
roto o dañado, ya que puede provocar un
cortocircuito, una descarga eléctrica o un
incendio.
• No enchufe el cable eléctrico en la toma
de corriente si está suelta, ya que esto
podría provocar una descarga eléctrica o
un incendio.
• Apague el electrodoméstico y desen-
chúfelo antes de limpiarlo o moverlo.
• Nunca desenchufe el electrodoméstico
tirando del cable eléctrico. Siempre agarre
firmemente el enchufe y tire derecho hacia
afuera del tomacorriente para evitar dañar
el cable.
• No haga funcionar el electrodoméstico
sin la tapa de la luz ya que la luz es muy
brillante y puede causar daño a la visión si
no está cubierta.
• Cualquier componente eléctrico de este
electrodoméstico debe ser reemplazado
o reparado por un electricista cualificado
o personal de servicio autorizado. Utilice
sólo piezas auténticas Fagor.
• No coloque aparatos eléctricos en el
interior de la nevera, a menos que este
recomendado por el fabricante del
aparato.
BMF-300X User's Manual.FINAL.indd 16BMF-300X User's Manual.FINAL.indd 16 9/3/16 7:58 PM9/3/16 7:58 PM

17
Descripción del Electrodoméstico
Nota: Este esquema puede no coincidir exactamente con su refrigerador. Para obtener más
espacio en el congelador, puede quitar los cajones (excepto el cajón del congelador bajo) y la
bandeja de hielo manejable.
1. Puerta del refrigerador
2. Luz LED
3. Botellero
4. Estantes de Vidrio
5. Compartimento Multi Fresh
(frutas y verduras)
6. Cajón del congelador superior
7. Cajón del congelador medio
8. Cajón bajo del congelador
9. Pies ajustables
10. Estante de lácteos cubierto
11. Estante medio
12. Estante bajo
13. Mangos
14. Puerta del congelador
1
2
3
4
5
6
7
8
10
11
12
14
13
9
BMF-300X User's Manual.FINAL.indd 17BMF-300X User's Manual.FINAL.indd 17 9/3/16 7:58 PM9/3/16 7:58 PM

18
Controles de la Pantalla
Utilice el electrodoméstico de acuerdo con las siguientes instrucciones, su electrodoméstico
cuenta con las mismas funciones y modos que los paneles de control que se muestran en las
fotos de abajo. Cuando el electrodoméstico está encendido por primera vez, la luz de fondo
de los iconos en el panel de la pantalla se iluminará. Si ningún botón se han presionado y las
puertas están cerradas, la luz de fondo se apagará.
Recomendación de Temperatura
La temperatura recomendada para el
compartimento frigorífico es 39ºF (4° C) y en
el compartimento congelador es -1ºF (-18°
C) para los alimentos congelados.
¡Precaución! Cuando se establece una
temperatura, se establece una temperatura
media para todo el gabinete del refrigerador.
La temperatura interior puede ser afectada
por la temperatura del medio ambiente, la
disposición de los alimentos en el interior y
la frecuencia de la apertura de la puerta.
1. Cambio °F/°C
La temperatura indicada se puede alternar
entre °C y °F pulsando los botones de
“Alarma” y “Holiday” a la misma vez por 3
segundos.
2. Nevera
Presione “ ” para ajustar la temperatura
del refrigerador deseada entre 35ºF (2°C) y
46ºF (8°C). La temperatura preestablecida
para el refrigerador es 41°F (5°C). Cada
vez que se pulsa el botón del refrigerador,
la temperatura disminuirá en un grado. Una
vez que llegue a la temperatura más baja
de 35ºF (2°C) presionando el botón otra vez
hará que la temperatura vuelva de nuevo a
la temperatura más alta de 46ºF (8°C).
BMF-300X User's Manual.FINAL.indd 18BMF-300X User's Manual.FINAL.indd 18 9/3/16 7:58 PM9/3/16 7:58 PM

19
3. Superfrío
Esta función ajusta el refrigerador
a la temperatura más fría por 6
horas. Debe ser utilizada si usted
pone una gran cantidad de ali-
mentos en el refrigerador de una
sola vez.
• Pulse el botón “Superfrío” para activar
esta función. La luz se encenderá.
• La función “Superfrío” se apaga
automáticamente después de 6 horas y
la temperatura mostrará 35°F/2°C.
• Para desactivar esta función, pulse
“Superfrío” o “ ” y la temperatura del
refrigerador volverá a la configuración
anterior.
4. Congelador
Presione “ ” para ajustar la temperatura
del congelador deseada entre 6ºF
(-14°C) y -12ºF (-24°C). La temperatura
preestablecida para el congelador es 1°F
(-18°C). Cada vez que se pulsa el botón del
congelador, la temperatura disminuirá en un
grado. Una vez que llegue a la temperatura
más baja de -12ºF (-24°C) presionando
el botón otra vez hará que la temperatura
vuelva de nuevo a la temperatura más alta
de 6ºF (-14°C).
5. Supercongelado
Supercongelado reducirá rápida-
mente la temperatura en el con-
gelador para que la comida se
congela más rápido y se manten-
drá fresca durante más tiempo.
• Pulse el botón “Supercongelado” para
activar la función. La luz se encenderá y
la temperatura del congelador mostrará
-12ºF (-24°C).
• La función debe ser activada
24 horas antes de poner una
gran cantidad de alimentos en el
congelador. Supercongelado se apaga
automáticamente después de 26 horas.
• Cuando la función “Supercongelado”
está activada, puede desactivar
pulsando el botón “Supercongelado” o
“” y la temperatura del congelador
volverá a la configuración anterior.
6. Vacaciones
Esta función es muy útil cuando el
refrigerador no será utilizado por
un largo período de tiempo, pero
desea mantener los alimentos
en el congelador. Con esta función, el
refrigerador usará menos energía y no habra
olores en el interior. Para activarlo, pulse
el botón de “Vacaciones” por 3 segundos
hasta que la luz se encienda.
Aviso: Antes de activar esta función, vacíe
el refrigerador, límpielo y cierre la puerta.
• Cuando se activa la función de
Vacaciones, la temperatura de la nevera
cambiará automáticamente a 59°F
(15°C) para reducir al mínimo el consumo
de energía. ¡Importante! No guarde
comida en el refrigerador durante este
tiempo.
• Cuando la función Vacaciones está
activada, se puede apagar pulsando
el botón de “Vacaciones”, “
” o “Superfrío”. La temperatura del
refrigerador volverá a la configuración
anterior.
7. Alarma
Si suena la alarma, el icono de “Alarma” se
encenderá y habrá un zumbido. Pulse el
botón “Alarma” para desactivar la alarma y
luego el icono de “Alarma” se apagará y el
zumbido se detendrá.
Alarma de la Puerta
• Si la puerta del refrigerador o del
congelador permanece abierta por más
de 2 minutos, una alarma sonará. Esta
alarma sonará 3 veces cada minuto y se
detendrá automáticamente después de
10 minutos.
• Para ahorrar energía, por favor evite
mantener la puerta abierta por mucho
tiempo. La alarma de la puerta también
puede ser interrumpida por el cierre de
la puerta de la nevera.
Alarma de Temperatura
• Si la temperatura del congelador está
inusualmente alta, habrá una alarma
de temperatura y la temperatura del
congelador mostrará “--”.
Si suena la alarma de temperatura,
sonará 10 veces seguidas y luego se
detendrá automáticamente.
BMF-300X User's Manual.FINAL.indd 19BMF-300X User's Manual.FINAL.indd 19 9/3/16 7:58 PM9/3/16 7:58 PM

20
Uso del Electrodoméstico
• Si suena la alarma de temperatura,
presione el botón “Alarm” por 3 segundos
para comprobar la temperatura del
congelador. La temperatura y el icono de
“Alarma” parpadearán al mismo tiempo
por 5 segundos.
Estante de Puerta
• El estante de la puerta se utiliza para
almacenar los huevos, productos
enlatados, bebidas embotelladas,
alimentos envasados, etc. No coloque
demasiados objetos pesados en los
bastidores de las puertas.
• El estante del medio puede ser
colocado a alturas diferentes según
sus requerimientos. Por favor, retire los
alimentos del estante antes de levantar
verticalmente para cambiar la posición.
Nota: Hay bandejas de huevos en el estante
superior y un soporte para botellas en el
estante inferior.
Estantes en el Refrigerador
• Hay estantes en el refrigerador que se
pueden quitar para facilitar la limpieza.
¡Precaución! Si se va la electricidad de su
casa, abra las puertas del refrigerador lo
menosposible. Cuando laenergíaregresa, es
normal que suene la alarma de temperatura,
se puede desactivar presionando el botón
“Alarma”. Vea si la comida congelada se ha
descongelado y descartar si es necesario.
Su electrodoméstico tiene los accesorios que se muestran en la “Descripción del
Electrodoméstico” en la página 27. Esta sección del manual de usuario muestra cómo utilizar-
los correctamente.
Compartimiento Multi Fresh
• Gracias al diseño de este compartimento
y su ubicación en la parte más fría del
refrigerador, el cajón Multi Fresh cumple
con los requisitos de temperatura ideal
para la conservación de frutas y verduras
por más tiempo.
Cajones del Congelador
• Los cajones del congelador sirven para
almacenar los alimentos que deben ser
congelados, incluyendo carne, pescado,
helados, etc.
BMF-300X User's Manual.FINAL.indd 20BMF-300X User's Manual.FINAL.indd 20 9/3/16 7:58 PM9/3/16 7:58 PM
