FALCOM DISCO-B5-MAGNET User manual

THIS DOCUMENT IS AVAILABLE AT HTTP://WWW.FALCOM.DE/
.
DISCO-B5-MAGNET
Hardware manual
Version: 1.0.1; Mo ifie : Thurs ay 4 October 2012

DISCO-B5-MAGNET HARDWARE MANUAL VERSION 1.0.1
Table of contents
1 INTRODUCTION.................................................................................5
1.1 General......................................................................................................................5
1.2 Circuit concept.........................................................................................................6
1.3 Related documents..................................................................................................7
2 SECURITY.......................................................................................8
2.1 General information.................................................................................................8
2.2 Exposure to RF energ ............................................................................................8
2.3 Driving.......................................................................................................................8
2.4 Electronic devices....................................................................................................9
2.5 Vehicle electronic equipment.................................................................................9
2.6 Medical electronic equipment.................................................................................9
2.7 Aircraft.......................................................................................................................9
2.8 Children.....................................................................................................................9
2.9 Blasting areas...........................................................................................................9
2.10 Potentiall explosive atmospheres......................................................................9
3 SAFETY STANDARDS.......................................................................11
4 TECHNICAL DATA...........................................................................12
4.1 Product features.....................................................................................................12
4.1.1 Power consumption............................................................................................13
4.1.2 Operating temperatures......................................................................................13
4.1.3 GSM/GPRS engine features..............................................................................14
4.1.4 GPS engine features..........................................................................................15
4.2 NMEA data message..............................................................................................16
5 DISCO-B5-MAGNET APPLICATION INTERFACE................................17
5.1 Power suppl ..........................................................................................................17
5.1.1 Power supply pins 1 and 2) on the 8-pin connector..........................................17
5.1.2 Automatic shutdown...........................................................................................17
5.1.3 Power saving......................................................................................................18
5.2 Determining the External Equipment T pe.........................................................18
6 HARDWARE INTERFACES..................................................................1
6.1 6/8pin female socket, pin assignments...............................................................19
6.1.1 Pinout of the 6/8pin female socket.....................................................................20
6.1.2 Special pin description Pins 5, 6)......................................................................20
6.1.2.1 How to use them as analog inputs.........................................................................................21
6.1.2.2 How to use these pins as digital Inputs (I/O2 and I/O3).........................................................22
6.1.2.3 How to use these pins as digital outputs (I/O2 and I/O3).......................................................23
6.1.3 Serial communication signals RxA and TxA)....................................................24
6.2 How to configure Track and Anti-tamper detection...........................................24
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Page 2 of 35

DISCO-B5-MAGNET HARDWARE MANUAL VERSION 1.0.1
7 OPENING THE UNIT AND INSERTING THE SIM CARD IN THE SIM CARD HOLDER
..................................................................................................26
7.1.1 Procedure for greasing the O-ring......................................................................29
7.2 Enter the PIN of the SIM card................................................................................30
7.3 Magnetic Mount Installation..................................................................................32
8 HOUSING.....................................................................................33
APPENDIX....................................................................................34
9.1 Schematics.............................................................................................................34
9.1.1 Installation guidance when using the I/Os on the 8-pin socket..........................34
9.2 What should be considered when using the DISCO-B5-MAGNET device.......35
Version history:
This table provides a summary of the document revisions.
Version Author Chan es Modified
.0. F. Beqiri - Added configuration settings for the light/dark sensor - see chapter 6.2.
- Added "Hint:" - An annual replacement of the O'ring rubber recommended.
- Added chapter 7. . - Procedure for greasing the O-ring.
04/ 0/20 2
.0.0 F. Beqiri - Initial version. 9/ 0/20
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Page 3 of 35

DISCO-B5-MAGNET HARDWARE MANUAL VERSION 1.0.1
Cautions
Information furnished herein by FALCOM is believed to be accurate and reliable. However, no responsibility
is assumed for its use. Please, read carefully the safety precautions.
If you have any technical questions regarding this document or the product described in it, please contact
your vendor.
General information about FALCOM and its range of products are available at the following Internet
address: http://www.falcom.de/
Trademarks
Some mentioned products are registered trademarks of their respective companies.
Copyright
This document is copyrighted by FALCOM WIRELESS COMMUNICATIONS GmbH with all rights reserved. No part
of this documentation may be produced in any form without the prior written permission of FALCOM
WIRELESS COMMUNICATIONS GmbH.
FALCOM WIRELESS COMMUNICATIONS GmbH.
No patent liability is assumed with respect to the use of the information contained herein.
Note
Specifications and information given in this document are subject to change by FALCOM without notice.
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Page 4 of 35

DISCO-B5-MAGNET HARDWARE MANUAL VERSION 1.0.1
1 INTRODUCTION
This product manual is only addressed to qualified personnel which are well skilled in
electronical/electrical installation and not addressed to private consumers/end users. The
installation, implementing or setting into operation of the product can only be performed by
qualified personnel.
The status of the product described in the data sheet may have changed since publication of
the data sheet and therefore information in this data sheet on product status may be
outdated. The latest information of the product is available on the download area of the
FALCOM website.
1.1 General
DISCO-B5-MAGNET is a free configurable smart tracking device which can be fully adapted to
different user needs. Using a Quad-Band GSM/GPRS technology for two way worldwide
communication, the latest GPS technology for positioning, a high-capacity Lithium-Ion rechargeable
battery, and housed in a weatherproof plastic case, the device is suitable for a wide range of mixed
outdoor applications in the AVL, fleet management, asset tracking, vehicle security and recovery
and transit sectors. The device has a protection class IP69K, which allows mounting of the device
permanently on the roof of the vehicles, including buses, trucks, trains, vessels and other assets. The
unit is magnetically mounted to your vehicle's roof, and its rubberised feet keep it from scratching your
paint. The DISCO-B5-MAGNET contains a truck detection and an anti-tamper detection system. The
truck detection automatically informs the user when the device has been mounted or removed from
the asset. The anti-tamper detection automatically informs the user when the device case has been
opened or closed.
DISCO-B5-MAGNET can be adapted to existing tracking solutions and can be easily configured to
gather or exchange relevant information with servers or users directly. An often used example is
sending the status reports or alarm messages directly to the users via SMS and/or to the tracking
servers via TCP/UDP/HTTP/SMTP. Drivers logbook and data logging functionalities are combined in
the history feature. Geofencing can be used to report violations of predefined routes or areas (for
example if a car enters or leaves a specific area or deviate a specific route). All of these features are
perfectly integrated in a device concept which significantly reduces time-to-market and provides low
cost tracking and security solutions.
DISCO-B5-M GNET is a device that can be configured and integrated onto any asset platform, including:
-Trailers,
-Trucks,
-Delivery vans,
-Rail cars,
-as well as other industrial monitoring installations.
and it can be used in a variety of applications, including:
•Online tracking,
•Fleet management / Monitoring / Territory management,
•Security / emergency services,
•Personalized drivers logbook,
•Route verification / Trip management / Distance calculations,
•Theft protection,
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Page 5 of 35

DISCO-B5-MAGNET HARDWARE MANUAL VERSION 1.0.1
•Truck detection / Anti-tamper detection system,
•Toll collection / Pay as you drive.
1.2 Circuit concept
DISCO-B5-M GNET architecture consists of the following major components (a block diagram
is available below):
HARDWARE ARCHITECTURE:
High-performance Quad-Band GSM/GPRS core
high sensitive GPS core
ARM7TDMI Processor controlling all functions of the system
Anti-tempering detection
Magnetic mounting
Internal Lithium-Ion battery pack (5 x 2250 mAh)
Internal GSM and GPS antennas
ADDITIONAL OPTIONS TO DISCO-B5-MAGNET
3D motion sensor
PHYSICAL INTERFACES:
Inside SIM card holder for ,8/3 V SIM cards
8pin connector
Fi ure 1: DISCO-B5-MAGNET block diagram
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Page 6 of 35

DISCO-B5-MAGNET HARDWARE MANUAL VERSION 1.0.1
1.3 Related documents
Some other PDF documents such as FCC approval, application notes, Certificate of Conformity
R&TTE etc. are also available on the Web at: http://www.falcom.de/ in the published
download area.
In addition to this document, the following files comprise the full set of FALCOM DISCO-B5-
M GNET product manuals:
NR PDF file name Description
[ ] SteppIII_fox_bolero_lt_PFAL_Configuration_Command_Se
t.pdf
Contains the description of the internal firmware and the supported
Configuration Command Set for the FALCOM STEPPIII, FOX/-LT/-IP and
BOLERO-LT.
[2] AppNotes_Transform_history_data.pdf Contains information of how to transform history data that is being
transmitted from a FALCOM AVL device via TCP connection.
[3] AppNote_Remote_update.pdf Contains information of how to upgrade FALCOM AVL devices to a new
firmware revision remotely via TCP (server based application).
[4] STEPPIII_FOX_BOLERO_LT_Software_Update.pdf Contains information how to upgrade a FALCOM AVL device to a new
firmware version locally via serial port.
[5] AppNotesRemoteUpdateWithWorkbench.pdf Contains information how to upgrade a FALCOM AVL devices to a new
firmware version remotely via TCP.
These PDF files are viewable and printable from dobe Reader. If you do not have the dobe Reader installed, you can
download it from http://www.adobe.com.
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Page 7 of 35

DISCO-B5-MAGNET HARDWARE MANUAL VERSION 1.0.1
2 SECURITY
IMPORTANT FOR THE EFFICIENT AND SAFE OPERATION OF YOUR GSM-MODEM, READ THIS
INFORMATION BEFORE USE!
Your cellular engine DISCO-B5-M GNET is one of the most exciting and innovative electronic
products ever developed. With it you can stay in contact with your office, your home,
emergency services and others, wherever service is provided.
This chapter contains important information for the safe and reliable use of the DISCO-B5-
M GNET device. Please read this chapter carefully before starting to use the cellular engine
DISCO-B5-M GNET.
2.1 General information
Your DISCO-B5-M GNET device utilizes the GSM/GPS standard for cellular technology. GSM is
a newer radio frequency („RF“) technology than the current FM technology that has been used
for radio communications for decades. The GSM standard has been established for use in the
European community and elsewhere. Your DISCO-B5-M GNET is actually a low power radio
transmitter and receiver. It sends out and receives radio frequency energy. When you use your
modem, the cellular system handling your calls controls both the radio frequency and the
power level of your cellular modem.
SIM cards are needed for the use of the acquired devices, which are not included in the scope
of delivery of the device. The SIM cards can be acquired e.g. by specific providers. Additional
costs can result from the use of the SIM cards which are to be borne by the purchaser (client)
of the devices. The seller does not cover the extra costs for the use of the devices. The seller
gives no recommendation for the use of specific SIM cards and is not liable for the fact that the
devices are usable with all available SIM cards. The seller is also not liable for any other costs
that are needed for the application of the customer in connection with this device.
2.2 Exposure to RF ener y
There has been some public concern about possible health effects when using GSM modems.
Although research on health effects from RF energy has focused for many years on the current
RF technology, scientists have begun research regarding newer radio technologies, such as
GSM. After existing research had been reviewed, and after compliance to all applicable safety
standards had been tested, it has been concluded that the product is fit for use.
If you are concerned about exposure to RF energy, there are things you can do to minimize
exposure. Obviously, limiting the duration of your calls will reduce your exposure to RF energy.
In addition, you can reduce RF exposure by operating your cellular modem efficiently by
following the guidelines below.
2.3 Drivin
Check the laws and regulations on the use of cellular devices in the area where you drive.
Always obey them. Also, when using your DISCO-B5-M GNET while driving, please pay full
attention to driving, pull off the road and park before making or answering a call if driving
conditions so require. When applications are prepared for mobile use, they should fulfil road-
safety instructions of the current law!
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Page 8 of 35

DISCO-B5-MAGNET HARDWARE MANUAL VERSION 1.0.1
2.4 Electronic devices
Most electronic equipment, for example in hospitals and motor vehicles is shielded from RF
energy. However, RF energy may affect some malfunctioning or improperly shielded electronic
equipment.
2.5 Vehicle electronic equipment
Check your vehicle manufacturer’s representative to determine if any on board electronic
equipment is adequately shielded from RF energy.
2.6 Medical electronic equipment
Consult the manufacturer of any personal medical devices (such as pacemakers, hearing aids,
etc.) to determine if they are adequately shielded from external RF energy. Turn your DISCO-
B5-M GNET device OFF in health care facilities when any regulations posted in the area
instruct you to do so. Hospitals or health care facilities may be using RF monitoring equipment.
2.7 Aircraft
Turn your DISCO-B5-M GNET OFF before boarding any aircraft. Use it on the ground only with
crew permission. Do not use it in the air.
To prevent possible interference with aircraft systems, Federal Aviation Administration (FAA)
regulations require you to have permission from a crew-member to use your modem while the
plane is on the ground. To prevent interference with cellular systems, local RF regulations
prohibit using your modem whilst airborne.
2.8 Children
Do not allow children to play with your DISCO-B5-M GNET device. It is not a toy. Children
could hurt themselves or others (by poking themselves or others in the eye with the antenna,
for example). Children could damage the modem or make calls that increase your modem bills.
2.9 Blastin areas
To avoid interfering with blasting operations, turn your device OFF when in a “blasting area”
or in areas posted: „turn off two-way radio“. Construction crew often uses remote control RF
devices to set off explosives.
2.10 Potentially explosive atmospheres
Turn your DISCO-B5-M GNET device OFF when in any area with a potentially explosive
atmosphere. It is rare, but your modems or their accessories could generate sparks. Sparks in
such areas could cause an explosion or fire resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They
include fuelling areas such as petrol stations; below decks on boats; fuel or chemical transfer
or storage facilities; and areas where the air contains chemicals or particles, such as grain, dust
or metal powders. Do not transport or store flammable gas, liquid or explosives, in the
compartment of your vehicle, which contains your modem or accessories.
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Page 9 of 35

DISCO-B5-MAGNET HARDWARE MANUAL VERSION 1.0.1
Before using your modem in a vehicle powered by liquefied petroleum gas (such as propane or
butane) ensure that the vehicle complies with the relevant fire and safety regulations of the
country in which the vehicle is to be used.
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Page 10 of 35

DISCO-B5-MAGNET HARDWARE MANUAL VERSION 1.0.1
3 SAFETY STANDARDS
Your GSM/GPRS/GPS device complies with all applicable RF safety standards.
DISCO-B5-M GNET meets the safety standards for RF receivers and the standards and
recommendations for the protection of public exposure to RF electromagnetic energy
established by government bodies and professional organizations, such as directives of the
European Community, Directorate General V in matters of radio frequency electromagnetic
energy.
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Page 11 of 35

DISCO-B5-MAGNET HARDWARE MANUAL VERSION 1.0.1
4 TECHNICAL DATA
4.1 Product features
Supply volta e ran e:
➢Operating power supply voltage range of + 0.8 V to +32.0 VDC.
➢Internal Lithium-Ion rechargeable battery pack (5 x 2250 mAh)
Power savin :
➢6 different energy-saving modes - programmable with PFAL
commands. Refer to the chapter 5. .3, "Power saving" for a brief
overview.
Operatin temperature ran e:
➢-20°C to + 60°C (see chapter 4. .2 for more details).
Physical characteristics:
➢Dimensions max. (L x W x H): 235mm x 58mm x 2 0mm.
➢Weight: ca. 325 gr.
Ma netic Holdin Force:
➢Ca. 5 kg (Ca. 50 Newton).
Physical Interfaces:
➢Internal SIM Card holder (supports .8/3 V SIM cards) - SIM card should be
inserted by skilled personnel.
➢2 x buttons for Truck detection (User configuration dependant - see
chapter 6.2)
➢Inside Light/Dark sensor for Anti-tamper detection (User configuration
dependant - see chapter 6.2).
➢6/8 pin female-socket.
Housin :
➢PA6 Plastic; Protection class: IP67.
➢Metal plate with 6 magnetic mounts.
Mountin :
➢Magnetically mounted by 6 magnetic mounts.
Directive:
➢RoHS compliant.
Firmware:
➢Embedded TCP/IP stack, including TCP, IP and SMTP protocols.
➢Accessible via PFAL commands.
➢Upgradable locally via serial port and remotely over the air (GPRS/TCP).
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Page 12 of 35

DISCO-B5-MAGNET HARDWARE MANUAL VERSION 1.0.1
Internal memory:
➢8 Mbyte FLASH for configuration, data-logging and firmware storage.
➢2 MByte RAM.
Supported protocols:
➢NMEA Msg.: GLL, GGA, RMC, VTG, GSV, GSA
FALCOM Msg.: IOP, GSM, AREA, 3DP, BIN - see related
documents [ ] and Table 4.
4.1.1 Power consumption
Measurement conditions: DISCO-B5-MAGNET, GSM 800 MHz, Power Level 0, Tamb=23°C, V BAT=4.2
VDC.
Operatin modes Avera e power consumption
Value Unit
Comments
Max.
CPU on / GSM Off / GPS Off
CPU on / GSM Off / GPS On
CPU on / GSM On / GPS Off
CPU on / GSM On / GPS On
1 A In atransmit burst the current consumption can rise to typical peaks of A
80 mA Microcontroller is ON.
138 mA GPS-fix valid
106 mA GSM idle (registered) and GPRS detached
164 mA GPRS is attached and TCP-connected.
Device sends a TCP packet every 30 sec.
Note: These values may vary over time and environments condition can not be guaranteed.
Table 1: Current consumption @ 2 VDC
Avera e current consumption in sleep mode
Sleep Modes approx. [mA]
IGN 0,2
IGN-Rin 22
IGN-Timer=1:20:00 0,3
Note: These values may vary over time and environments condition can not be guaranteed.
Table 1.1: Current consumption for different sleep modes
4.1.2 Operatin temperatures
Parameter Min. Typ. Max. Unit
Storage temperature -40 +25 +90 °C
Operating temperature -20 +25 +60 °C
Charging temperature 0 +25 +45 °C
Discharging temperature -20 +25 +60 °C
Table 2: Operating temperature
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Page 13 of 35

DISCO-B5-MAGNET HARDWARE MANUAL VERSION 1.0.1
4.1.3 GSM/GPRS en ine features
GSM/GPRS core:
➢Telit GE865-Quad-Band module
➢Quad-Band: GSM 850, 900, DCS 800, PCS 900.
➢Compliant to GSM Phase 2/2+
Output power:
➢Class 4 (2 W) at EGSM900/850
➢Class ( W) at GSM 800 and GSM 900
GPRS connectivity:
➢GPRS multi-slot class 0
➢GPRS mobile station class B
DATA:
GPRS
➢GPRS data downlink transfer: max. 85.6 kbps (see table 3).
➢GPRS data uplink transfer: max. 42.8 kbps (see table 3).
➢Coding scheme: CS- , CS-2, CS-3 and CS-4.
CSD
➢CSD transmission rates: 2.4, 4.8, 9.6, 4.4 kbps, non-transparent, V. 0.
SMS:
➢Text mode.
Rin tones:
➢Offers a choice of 30 different ringing tones, easily selectable with
PFAL commands.
GPRS Codin scheme:
Codin scheme 1 Timeslot 2 Timeslots 4 Timeslots
CS- : 9.05 kbps 8. kbps 36.2 kbps
CS-2: 3.4 kbps 26.8 kbps 53.6 kbps
CS-3: 5.6 kbps 3 .2 kbps 62.4 kbps
CS-4: 2 .4 kbps 42.8 kbps 85.6 kbps
Table 3: Coding schemes and maximum net data rates over air interface
Please note that, the values listed above are the maximum ratings which, in practice, are influenced by a great
variety of factors, primarily, for example, traffic variations and network coverage.
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Page 14 of 35

DISCO-B5-MAGNET HARDWARE MANUAL VERSION 1.0.1
4.1.4 GPS en ine features
GPS engine:
➢Single chip from u-blox
➢50-channel u-blox 6 engine
➢GPS L C/A code
Accuracy:
➢Position: < 0 m CEP
Time to First Fix (TTFF :
➢Hot starts < sec., average
➢Cold starts 29 sec, average
Sensitivity:
➢Tracking - 60 dBm
Dynamic Conditions:
➢Velocity < 5 5 m/s ( 000 knots)
➢Max. update rate Hz
A-GPS support:
➢AssistNow Online,
➢AssistNow Offline,
Crystal oscillator (TCXO :
➢Load sensitivity ± 0 % load change, 0.2 ± ppm
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Page 15 of 35

DISCO-B5-MAGNET HARDWARE MANUAL VERSION 1.0.1
4.2 NMEA data messa e
DISCO-B5-MAGNET delivers data in the NMEA-0 83 format. Table below lists the NMEA and
FALCOM output messages supported by the DISCO-B5-MAGNET device and gives a brief
description for each protocol. For further description about these protocols, refer to the
related documents [ ].
The running firmware inside the device offers the possibility to switch on and off each protocol
that is listed in the table below. As mentioned above the firmware inside the device supports a
lot of PFAL commands enabling full control of the device. There are also PFAL commands
which allow sending of these protocols via SMS, TCP, Data call and e-mail. For example, the
PFAL commands "PFAL,GSM.SMS.Send..." and "PFAL,GSM.Send.TCP..." allow you to send an
SMS message to a user or a TCP packet to a TCP server to let him know the current location,
GPS state, UTC time, Date, Speed and Course over ground of the device. The received SMS
contents or TCP packet can then be forwarded to a map software for graphical representation
of the device location. When you install such a device in a vehicle, you are then able to have
always full control of the vehicle. In this way you will know where your vehicle is, what is
happening with your vehicle, has your vehicle been moved without authorization from a park
area, real time vehicle movements and more. The TCP server developed by FALCOM called
"Trace4You" has a lot of such features allowing you to have full control of your vehicle, fleet
and other assets.
NMEA Description
GGA Time, position and fix type data
GLL Latitude, longitude, UTC time of position fix and status
GSA GPS receiver operating mode, satellites used in the position solution and DOP values
VTG The direction and the ground speed
GSV The number of GPS satellites in view, satellite ID numbers, elevation, azimuth and SNR values
RMC Time, date, position, course and speed data
FALCOM Description
IOP The status of the digital/analog inputs and output ports and battery voltage
GSM The GSM operator, reception, registration status, GSM field strength, area code and cell ID
AREA The state (entered / remaining) of 32 areas/geofences - such as territory management, route verification,
prohibited locations, parking area and more
3DP The state of the Motion Sensor (hardware option)
BIN User protocol including time, date, position, course and speed data in binary format (small sized - only 21
characters)
Table 4: NMEA Output Messages
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Page 16 of 35

DISCO-B5-MAGNET HARDWARE MANUAL VERSION 1.0.1
5 DISCO-B5-MAGNET APPLICATION INTERFACE
5.1 Power supply
The DISCO-B5-MAGNET is powered by a 5x2250 mAh Li-Ion rechargable battery pack. Before
using the DISCO-B5-MAGNET device you will need to recharge the internal battery of the
device even if it may be shipped pre-charged from the factory. Because it may has been some
time in transit and storage before reaching you, it is recommended to charge the battery while
turned off for approx. 24 hours before the first use. DISCO-B5-MAGNET uses a special cable
called KA33 "Service and Charging Cable" for charging the internal battery. This cable is not
included in the DISCO-B5-MAGNET package, so it should be ordered separately. The power
supply for recharging internal battery pack has to be a single voltage source of V +IN = +10.8 V...
+32.0 V DC.
The operating voltage (V+IN and GND) is protected against voltage spikes and reverse polarity,
but not against continuous-overvoltage.
NOTE: Operating voltage range must never be exceeded; care must be taken in order to fulfill
min/max voltage requirements.
5.1.1 Power supply pins (1 and 2) on the 8-pin connector
One +IN pin on the 6/8-pin double row connector is dedicated to connect the supply voltage,
and the GND pin for grounding. Both +IN and GND pins serve for charging the internal Li-Ion
battery pack.
Si nal name I/O Parameter Description
+IN I+10.8V...+32.0VDC. The operating
voltage must never be exceeded.
Positive operating voltage.
For security reason, it is recommended to integrate externally
a 2 fuse link between interconnection plug and d.c.-power
source.
GND - 0 V Ground
5.1.2 Automatic shutdown
Automatic shutdown takes effect if:
•Battery voltage level runs low and external power supply is disconnected.
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Page 17 of 35

DISCO-B5-MAGNET HARDWARE MANUAL VERSION 1.0.1
5.1.3 Power savin
SLEEP mode reduces the functionality of the modules of the DISCO-B5-M GNET device to a
minimum and thus minimizes the current consumption to the lowest level. Settings can be
made using the $PFAL,Sys.Device.Sleep command. For details, see example in table below.
Following SLEEP modes are supported by the DISCO-B5-M GNET device:
Modes Description
IGN Device goes to sleep and wakes up when the device is removed from the asset (both buttons on
the back of the device changes their state from Low to High).
Rin Device goes to sleep and wakes up when the GSM module receives a voice call or an SMS.
Timer=1:20:00 Device goes to sleep and wakes up after the defined time has expired.
Motion=5,20,20 Device goes to sleep and wakes up when motion is detected.
ExtPwrDetect Device goes to sleep and wakes up when external power (higher than 9 V) is connected to the
device.
ExtPwrDrop Device goes to sleep and wakes up when external power is disconnected or it drops below 8 V.
Example $PFAL,Sys.Device.Sleep=IGN+Rin +Timer=1:20:00
IMPORTANT: The sleep and wake-up procedures are quite different depending on the selected
sleep mode. Please keep in mind that the power saving with "Ring" parameter
works properly only when PIN authentication has been done and the device is
already registered in the GSM network. If you attempt to activate power saving
while the device is not registered in the GSM network, the SIM card is not inserted
or the PIN not correctly entered, the device responds with an error "ring shutdown
aborted due to bad GSM coverage" and the power saving does not take place. For
more details, refer to the manual "steppIII_FOX-
LT_bolero_lt_PFAL_Configuration_Command_Set.pdf".
NOTE (This note is related to the battery-powered devices only): The internal battery pack of the
DISCO-B5-MAGNET must have enou h power to safely wake up the device from a sleep mode.
If the internal battery of the DISCO-B5-MAGNET device does not have enou h power, the
device cannot complete the wake up operation.
5.2 Determinin the External Equipment Type
DISCO-B5-MAGNET is designed for use as a DCE device. It communicates with the customer
application (DTE) using the following signals:
DISCO-B5-MAGNET Terminal (DCE) to Application (DTE)
RxA <---------- TXD
TxA ----------> RXD
Table 5: The signalling definitions between DTE and DCE.
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Page 18 of 35

DISCO-B5-MAGNET HARDWARE MANUAL VERSION 1.0.1
6 HARDWARE INTERFACES
This figure shows the main parts of the DISCO-B5-MAGNET.
6.1 6/8pin female socket, pin assi nments
Fi ure 3: Pin assignments of the 6/8pin female socket.
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Page 19 of 35

DISCO-B5-MAGNET HARDWARE MANUAL VERSION 1.0.1
6.1.1 Pinout of the 6/8pin female socket
PIN NAME DIRECTION DISCRIPTION LEVEL
1+IN Input
Power supply input. The power supply must be able to meet the
requirements of current consumption. Care must be taken so that the
operating voltage applied to the terminal stays within the voltage
range. Applying a voltage outside of the voltage range can damage the
module. For security reason, it is recommended to integrate
externally a 2A fuse link between power source and DISCO-B5-
MAGNET.
V+IN = + 0.8 ... + 32.0 V
Imax ≤ 2A
2GND - Ground. 0 V
3NC - - -
4NC - - -
5I/O2
6I/O3
Input/Outp
ut
Software configurable pins. Each pin has dual functions as analog or
digital. Each digital pin can be individually set to operate either as
input or output.
OUT: 00 mA max. @ +0 .. +32.0V
DC
IN: 0 V..+32.0V DC
(Hi h & Low levels are free-
programmable)
Analo : Up to 32.0 V DC/ 0 bits
resolution
7RxA Input Serial port (receive data) for direct connection to the host PC
(configuration, evaluation, firmware). If not used leave open. V24, ±2 V
8TxA Output
Serial port (transmit data) for direct connection to the host PC
(transmitting history data, output GPS protocols and others). If not
used leave open.
V24, ±2 V
NC = Not Connected
Table 6: Description of the 6/8pin female socket
6.1.2 Special pin description (Pins 5, 6)
Please note: In the figures below the 6/8pin female socket on the DISCO-B5-MAGNET is
represented as an 8pin row connector.
These pins have dual functions. They are controlled by the internal firmware of DISCO-B5-
MAGNET. Therefore, the user must specify whether they will be as analog or digital pins.
This function is controlled by the command PFAL,IO1[2].Confi . If, for example, you want to
use I/O2 as an analog pin, and I/O3 as digital, the command settings would look like this:
PFAL,IO1.Confi =AI,2,11 //1 = I/O2; AI = analog input; 2 and 11 = min. and max.
voltages for Low and High events.
PFAL,IO2.Confi =DI,5,10 //2 = I/O3; DI = digital input; 5 and 10 = min. and max.
voltages for Low and High events
If the pin I/O1, I/O2 or I/O3 is configured as a digital pin, then the pin must also be defined to
work as input or output. If you want I/O2 to be an input and I/O3 to be an output, the
command settings would look like the following:
PFAL,IO1.Confi =DI,5,10 //1 = I/O2; DI = digital input; 5 and 10 =
min. and max. voltages for Low and High
events.
PFAL,IO6.Set=high[low,hpulse,lpulse,cyclic] //6 = I/O3; high = sets output to high.
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Page 20 of 35
