FALMEC MILANO+ User manual

INSTALLATION MANUAL
falmecau.com
Milano
Genova 120

2
CONGRATULATIONS
Congratulations and thank you for choosing
a Falmec rangehood.
To avoid the risks that are always present
when you use an electrical appliance it is
important that the rangehood is installed
correctly and that you read the safety in-
structions carefully to avoid misuse and ha-
zards.
We recommend that you keep this instruction
booklet for future reference and pass it on to
any future owners.
IMPORTANT INFORMATION
AFTER UNPACKING THE RANGEHOOD PLEASE REVIEW YOUR NEW ITEM TO ENSURE
THAT IT HASN’T BEEN DAMAGED IN TRANSIT OR IS MISSING ANY COMPONENTS.
FAILURE TO REPORT ANY ISSUE WITHIN 72 HOURS OF RECEIPT OF YOUR ITEM MAY
RESULT IN ADDITIONAL CHARGES.
ENVIRONMENTAL TIP
Information on disposal for users Most of the packing materials are recyclable.
Please dispose of those materials through your local recycling depot or by placing
them in a appropriate collection bin.
If you wish to discard this product, please contact your local authorities and ask for
the correct method of disposal.
TO AVOID THE RISK OF INJURY OR DAMAGE TO THE PRODUCT IT IS ESSENTIAL TO
READ THESE INSTRUCTIONS PRIOR TO INSTALLATION AND USE.

3
CARTON 1 - HOOD UNIT
INTEGRATED HOOD - REMOTE MOTOR
Models include:
MILANO FP3ML60S2, FP3ML90S2,
MILANO FP3MLD90S2, FP3MLD12S2
GENOVA FP3GV12S2
Included in the carton:
1. Main hood housing including control module and lighting
2. Baffle lters
3. Grease trap
4. Fixing screws
5. Operating & installation guide
PRODUCT DESCRIPTION & CARTON CONTENTS
CARTON 2 - FAN MOTOR UNIT
You will be supplied with one of the three fan motor
options detailed.
OPTION 1 - IN ROOF SOLUTION (Fig. A)
Models include: IR-765 and IR-1140
Unit designed to be located in a roof space and then
ducted to an external vent.
Included in the carton:
1. In Roof Motor Unit
2. Mounting Bracket
3. Fixing Screws
4. Duct Clamps x4
5. 200 mm Flexi Duct (5 Meters Length)
6. White Stainless Steel Wall/Eave Vent
OPTION 2 - EXTERNAL HOOD SOLUTION (Fig. B)
Models include: ER-765, ER-1140 and ER-2010
Unit designed to be mounted externally penetrating
through the roof.
Included in the carton:
1. External Roof Motor Unit.
2. Duct Clamps (x2).
3. 200mm Flexi Duct (5 Meters Length).
OPTIONAL ACCESSORIES WHEN ROOF MOUNTING
1. 200 mm Tile Roof Install Kit (HBX200TILE).
Includes roof ashing for tile roof and mounting brackets x2.
2. 200 mm Metal Roof Install Kit (HBX200MET).
Includes roof ashing for metal roof and mounting brackets x2.
OPTION 3 - EXTERNAL WALL SOLUTION (Fig. C)
Models include: EW-765, EW-1140 and EW-2010
Unit designed to be mounted directly on an external wall.
Included in the carton:
1. External Wall Motor Unit.
2. Duct Clamps x 2.
3. 200 mm Flexi Duct (5 Meters Length).
Fig. A
Fig. B
Fig. C

4
512 / 822
250
505 / 815
541 / 851
12
379 / 665
358
184
541 / 851
280
118
200
280
247
332
204
MILANO + 56 / 87
FP3ML60S2
FP3ML90S2
EN - HOLE MEASUREMENTS FOR INSTALLATION
IT - MISURE FORO PER INCASSO

5
851 / 1137
12
815 / 1101
98
351
584 / 870
360
118
002
851 / 1137
824 / 1110
330
360
326
326
248
204
MILANO + 87 / 116 DEEP
FP3MLD90S2
FP3MLD12S2
EN - HOLE MEASUREMENTS FOR INSTALLATION
IT - MISURE FORO PER INCASSO

6
1137
12
1101
98
351
870
450
118
002
1137
1110
420
450
326
416
281
204
GENOVA + 116
FP3GV12S2
EN - HOLE MEASUREMENTS FOR INSTALLATION
IT - MISURE FORO PER INCASSO

7
600 - 650 mm
2
STEP 1:
Minimum distance by cooktop.
STEP 2:
Wall unit hole.
STEP 3:
You push the hood in wall unit hole.
x4
CAUTION
3
1

8
FOR BACK DUCTED
POSITION
TOP
DUCTED
POSITION
2
3
1
ATTENTION!
ONLY ON
MILANO + DEEP
3
FOR BACK DUCTED
POSITION
TOP
DUCTED
POSITION
2
3
1
ATTENTION!
ONLY ON
MILANO + DEEP
3
x4
CAUTION
CAUTION
10 ÷ 28 mm
5 5a
4
STEP 4:
You screw the blocking devices.
STEP 5:
Connect the hood outlet (in the top or back ducted position)
to 150mm ducting leading to an external output.

9
FOR BACK DUCTED
POSITION
5
4
ATTENTION!
ONLY
ON MILANO + 87 DEEP
FOR BACK DUCTED
POSITION
5
4
ATTENTION!
ONLY
ON MILANO + 87 DEEP
23
1
5b 5c
6 7
STEP 6:
Attach the male plug of the rangehood unit to the main
power supply.
STEP 7:
Assembling the metal lters.

10
2
1
98
10
STEP 8:
Remove the metal lters.
STEP 9:
Remove the cover caps.
STEP 10:
With your nger enter the hole and pull the lever to unlock
the stop.
SEQUENCE FOR REMOVING THE HOOD
