2. Possibilities of the ITM-A
The possibilities of the ITM-A depend on the hardware configuration. The following hardware configurations are
available:
•ITM-A without additional analog output.
•ITM-A with additional analog output.
Set the type of control required using dipswitch 6, 7 and 8.
2.1 ITM-A without analog output - ITM-A
CentralFlow
The ITM-A can be used as an intelligent control module in a CentralFlow system. The ITM-A receives the required
ventilation position from the climate computer. The ITM-A controls the ventilation in a section by measuring the air
flow (DSR feedback signal) and by controlling the valve of the ATM unit.
2.2 ITM-A with analog output - ITM-A
ProFlow/NatuFlow
The ITM-A controls the ventilation in a section by measuring the air flow (DSR feedback signal) and by controlling
the I-fan and the valve of the ATM unit.
The ITM-A can be used as:
1. Energy saving mechanical ventilation system (no possibility to switch to natural ventilation)
2. Energy saving mechanical. & natural ventilation system (possible to switch to natural ventilation)
3. Traditional mechanical ventilation system (no possibility to switch to natural ventilation, fan runs at higher
speed)
4. Mechanical several units in same room (no possibility to switch to natural ventilation)
Remote I/O-module
The climate controller controls the ventilation in the section by directly controlling the outputs of the ITM-A.
When used as a CentralFlow module, the first analog output is not available for direct control.

Gndf
4
g
3. Installing the ITM-A
Install the ITM-A and associated components as follows:
1. Mount the ITM-A (see page 4)
2. Connect the ITM-A (see page 4)
3. Test the ITM-A (see page 7)
3.1 Mounting the ITM-A
When mounting/installing the ITM-A, the following should be observed:
Never mount the ITM-A in a room where animals are present because of the (manual) control.
Place the ITM-A at such a height that the manual control can be used.
Mount the ITM-A on a flat surface.
Make sure that the gland nuts are at the bottom of the ITM-A.
Seal all gland nuts after connection of the ITM-A to prevent entry of dust, aggressive gases and/or
humidity
3.2 Connecting the ITM-A
Connecting as an I/O network module
1. Set an I/O-address using dipswitches 1 thru 5. All the I/O-network modules in an I/O-network should have a
unique address.
2. Choose the type of control using dipswitches 6, 7 and 8.
3. When all settings and calibration values are set in the climate controller no adjustment is necessary. Otherwise
adjust the ITM-A according to the procedures described
Do not forget to terminate the beginning and end of the I/O-net with a 120 Ω resistance. This can be
activated on the ITM-A by placing a jumper.
Connecting as a traditional end station
1. Set the I/O-address to 0 using dipswitches 1 thru 5.
2. Remove jumpers TEMP so the ITM-A can be used with 10-0Vdc analog control.
3. Choose the type of control using dipswitches 6, 7 and 8
4. Adjust the ITM-A according to the procedures described.
Do not forget to terminate the beginning and end of the I/O-net with a 120 Ω resistance. This can be
activated on the ITM-A by placing a jumper.

Gndf
5
g
Settings
I/O address Control type
I/O
adrr.
DIP 1
DIP 2
DIP 3
DIP 4
DIP 5
DIP 6
DIP 7
DIP 8
Control type
AN
On
On
On
On
On
On
On
On
CentralFlow (ATM with DSR)
1
Off
On
On
On
On
On
On
Off
AT(M) without DSR
2
On
Off
On
On
On
On
Off
On
NatuFlow / ProFlow direct
(analog output direct with
DSR-feedback)
3
Off
Off
On
On
On
4
On
On
Off
On
On
On
Off
Off
NatuFlow / ProFlow direct with
inverted manual operation
(analog output 10-0V direct
with DSR-feedback)
5
Off
On
Off
On
On
6
On
Off
Off
On
On
7
Off
Off
Off
On
On
8
On
On
On
Off
On
Off
On
On
Energy saving mechanical
9
Off
On
On
Off
On
Off
On
Off
Energy saving mech. & natural
10
On
Off
On
Off
On
Off
Off
On
Traditional mechanical
11
Off
Off
On
Off
On
Off
Off
Off
Mechanical several units
12
On
On
Off
Off
On
13
Off
On
Off
Off
On
Adjustment
14
On
Off
Off
Off
On
DIP 9*
DIP
10*
15
Off
Off
Off
Off
On
On
On
No adjustment (working position)
16
On
On
On
On
Off
Off
On
Adjust control input
17
Off
On
On
On
Off
On
Off
Adjust 1% fan control output
18
On
Off
On
On
Off
Off
Off
Adjust max. revolutions
19
Off
Off
On
On
Off
* Change dipswitch settings 9 and 10 one at the time and
not simultaneously!
20
On
On
Off
On
Off
21
Off
On
Off
On
Off
22
On
Off
Off
On
Off
23
Off
Off
Off
On
Off
24
On
On
On
Off
Off
25
Off
On
On
Off
Off
26
On
Off
On
Off
Off
27
Off
Off
On
Off
Off
28
On
On
Off
Off
Off
29
Off
On
Off
Off
Off
30
On
Off
Off
Off
Off
31
Off
Off
Off
Off
Off

Gndf
6
g
Item DIP Switch Control
A
Central Flow (PROLOW ENDSTATION)
•Central flow to control ATM unit (Vortex damper and
measuring fan DSR). Only with Lumina 20/21 and
Lumina 17 controller.
B
AT without DSR (PROFLOW DIRECT)
•Direct control. [%] in = [%] out, using with control AT
unit, (vortex damper without measuring fan DSR).
C
NatuFlow/ProFlow direct
•Analog output 0-10Volt direct with DSR-
feedback Only
possible with Lumina 20/21 and Lumina 17 controller
(PROFLOW DIRECT)
D
NatuFlow/ProFlow direct (with inverted manual
operation)
•Analog output 10-0Volt
direct with DSR feedback. Only
possible with Lumina 20/21 and Lumina 17 controller
(PROFLOW DIRECT)

Gndf
7
g
I/O-network
Possibility of communication via the I/O-network. One control computer and a maximum of 31 network modules may
be connected to the I/Onetwork. Each connected network module hasa unique address. After an address has been
changed, the network module should always be restarted (power off-on).
In-/output type ITM-A address . sequence number
Ventilation (analog)
“ITM-A address” . 1
Relay output 1
“ITM-A address” . 1
Relay output 2
“ITM-A address” . 2
Analog measurement (temp.)
“ITM-A address” . 1
RPM feedback-measurement
“ITM-A address” . 1
Direct analog output 1
“ITM-A address” . 1
Direct analog output 2
“ITM-A address” . 2
The ITM-A can
be connected to a PFB+battery. If the 24Vac power supply fails, it automatically switches
over to 24Vdc. In that case the analog outputs of the ITM-A are controlled on 5V. Relays are not
controlled.
3.3 Testing the ITM-A
1. Check whether the ITM-A has been connected correctly.
2. Check whether the ITM-A works optimally.

Gndf
8
g
4. Using the ITM-A
4.1 Setting the knob
The knob on the front of the ITM-A is used to set the ATM-unit to:
•Automatic (A) or
•Manual (M)
4.2 Display (option)
A key on the front panel is available as an option.
If this key is pressed, the following will be displayed alternately:
•Temperature
Own temperature measurement of the ITM-A, without offsets of
the control computer, without averaging of other values (only
when controlled via the IO-network).
•Control and measured value ventilation
The control value is the control of the ITM-
A (ventilation position or
position of analogue output) measured value based on the
calibration value in the ITM-A.
If the key is not used, then the temperature readout will be displayed again, 30 seconds after the key was used for
the last time.
If the rotary knob is set to manual (M), the display will flash.
When type of control is CentralFlow, only the vortex damper can be controlled manually.
When type of control is ProFlow/NatuFlow, both I-fan and vortex damper can be controlled manually.

Gndf
9
g
5. Adjusting the ITM-A
5.1 General
Before the ITM-A can be used, the Triac, the maximum number of revolutions and the control input should first be
adjusted, depending on the setting. The position of the dipswitches is important for this adjustment (see table
below).
Adjustment of: DIP 9 DIP 10
Adjust 1% fan control output
On
Off
Maximum revolutions
Off
Off
Control input
Off
On
5.2 Adjusting the 1% fan control output
Only adjust the 1% fan control output to increase the minimum fan speed. When an I-fan is used, this is
not necessary.
1. Open the lid of the ITM-A housing.
2. Position the dipswitches (9 =On, 10 =Off).
3. Turn the rotary knob on the front to its “minimum position”, so that the fan is running at the desired minimum
speed (this depends on installation).
4. The red led (L1) flashes: briefly on, long period off. The green led (L2) is off. This means that the 1% is be
adjusted.
5. When the required voltage has been set, confirm this by pressing the calibration knob. The green led (L2)
flashes.
6. The green led will go off after five seconds, 1% adjustment has been completed.
7. The ITM-A has completed the 1% adjustment after five seconds. The status of adjustment can now be shown:
- Green led on : Adjustment successful.
- Red led on : Adjustment unsuccessful. Adjust again.
Control vortex damper
The ITM-A also controls the analog output for the control or adjustment of the vortex damper. The output of the
analog output is 1% during 1% adjustment.
After adjustment set dipswitches 9 and 10 to ON and the knob to A.

Gndf
10
g
5.3 Adjusting the maximum revolutions
Only applicable when using DSR-feedback.
Method
1. Open the lid of the ITM-A housing.
2. Position the dipswitches (9 =Off, 10 =Off) and set the knob and the switch on the front to A.
3. Press the knob to start adjustment.
4. The vortex damper will open, the fan will run at high speed after 10 seconds. The red led (L1) is off. The green
led (L2) flashes, to indicate that adjustment has started. The fan will run at high speed for a maximum of 60
seconds.
5. Wait until the fan has come to a standstill.
6. Check whether adjustment has been successful:
- Green led on : Adjustment successful.
- Red led on : Adjustment unsuccessful. The most common cause is that the ITM-A has
measured none or too few pulses. Check the DSR-feedback sensor and
repeat the adjustment procedure.
After adjustment set dipswitches 9 and 10 to ON.
5.4 Adjusting the control input
Not applicable when using the I/O-network.
Method 1% adjustment
1. Open the lid of the ITM-A housing.
2. Position the dipswitches (9=Off, 10=On) and remove the jumpers TEMP.
3. Set the analog output of the controller to 1%. Check the voltage; this should be between 9 and 10V (with a
0-10V control this is between 0.1V and 1V).
4. Turn the knob on the front to its minimum position. The red led (L1) flashes: briefly on, longer period off. The
green led (L2) is off. This means that the 1% is to be adjusted.
5. Confirm the 1% adjustment by pressing the knob. The green led (L2) flashes.
6. The green led (L2) will go off after five seconds. The ITM-A has completed the 1% adjustment.

Gndf
11
g
Method 99% adjustment
1. Set the analog output of the controller to 99%. Check the voltage, this should be between 0.1 and 1V (with a
0-10V control this is between is 9V and 10V).
2. Turn the knob on the front to its maximum position. The red led (L1) flashes: longer period on, briefly off. The
green led (L2) is off. This means that the 99% will be adjusted.
3. Confirm the 99% adjustment by pressing the knob. The green led (L2) flashes.
4. The ITM-A has completed adjustment after five seconds. The status of the adjustment can now be shown.
- Green led on : Adjustment successful.
- Red led on : Adjustment unsuccessful. The most common cause is that the ITM-A has
measured none or too few pulses. Check the DSR-feedback sensor and
repeat the adjustment procedure.
After adjustment set dipswitches 9 and 10 to ON and the knob to A.

Gndf
12
g
6. Alarms
Alarm indication
Led 1 and Led 2 flash simultaneously.
Backup alarm
Led 1 and Led 2 flash alternately.
Memory alarm

Gndf
13
g
7. Technical specifications
Power supply
Mains voltage
230Vac (-10%, +10%)
Mains frequency
50/60Hz
Maximum power consumption
5VA
Fuse electronics
see connection diagram
Inputs
Analog In
Voltage
0-10Vdc
Temperature sensor type S7
-9.9°C to +99.9°C
DSR-feedback
4 pulses per revolution
max. frequency: 200Hz
Knob
Adjust ventilation between 0 – 100%
Outputs
Power outage relay
30Vac/60Vdc, max. 2A
Relay 2×
30Vac/60Vdc, max. 2A
Analog out
10-0Vdc
Housing
Plastic housing with screw-on lid
IP54
Dimensions (l×w×h)
300×240×140mm
Weight (unpacked)
2.2kg
Ambient climate
Operating temperature range
0
°
C to +40
°
C
Storage temperature range
–10
°
C to 50
°
C
Relative humidity
< 95%, uncondensed
Options
Display with key on front panel
Available as an option

Gndf
14
g
8. Connection diagram
VL POWER BOARD
AI Temperature (type S7) / Analog control
AO Control vortex damper
-S+ DSR sensor
RL1/RL2 Relays

Gndf
15
g
9. Appendix: EG declaration of conformity
Manufacturer: Fancom B.V.
Address: Industrieterrein 34
City: Panningen (the Netherlands)
Hereby declares that the: ITM-A / ADS
Complies with the provisions of the:
1. EMC directive 2004/108/EC
Emission according to NEN-EN-IEC 61326-1: 2013
Immunity according to NEN-EN-IEC 61326-1: 2013
Place: Panningen Date: 01-04-2014
Paul Smits
Managing Director

N.B.: De originele, authentieke versie van deze handleiding is de door Fancom B.V. of door een van haar
dochterondernemingen (verder aangeduid als Fancom) geproduceerde Engelstalige versie. Achteraf door derden
aangebrachte wijzigingen in deze handleiding zijn door Fancom noch gecontroleerd, noch goedgekeurd. Onder
wijzigingen verstaat Fancom o.a. het vertalen in een andere taal dan het Engels en het toevoegen en/of verwijderen
van tekst en/of illustraties aan/uit de originele inhoud. U kunt Fancom niet aansprakelijk stellen voor schade, letsel,
garantieclaims en andere claims die verband houden met dit soort wijzigingen, voor zover deze wijzigingen
resulteren in een inhoud die afwijkt van de authentieke door Fancom geproduceerde Engelstalige versie van deze
handleiding. Voor actuele informatie over productinstallatie en bediening, neem contact op met de klantenservice
en/of technische serviceafdeling van de betreffende Fancom-onderneming. Mocht u onverhoopt toch een fout
ontdekken, dan vragen wij u vriendelijk Fancom B.V. hiervan schriftelijk in kennis te stellen. Fancom B.V., Postbus
7131, 5980 AC Panningen (the Netherlands)
Copyright © 2014 Fancom B.V.
Panningen (the Netherlands)
Alle rechten zijn voorbehouden. Niets uit deze handleiding mag worden gekopieerd, gedistribueerd of vertaald in
andere talen, geheel of gedeeltelijk, zonder voorafgaande schriftelijke toestemming van Fancom. Fancom houdt
zich het recht voor om wijzigingen in de handleiding aan te brengen. Fancom kan echter geen garantie geven,
impliciet noch expliciet, voor deze handleiding. Het risico hiervan ligt volledig bij de gebruiker.
Deze handleiding is met de grootst mogelijke zorg samengesteld. Mocht u onverhoopt toch een fout ontdekken, dan
vragen wij u vriendelijk Fancom B.V. hiervan in kennis te stellen.
Art.nr. 35911849
NL140401
gNdf

gNdf
i
n
Inhoudsopgave
1. Algemene inleiding..................................................................................................................................... 1
1.1 Hoe gebruikt u deze handleiding....................................................................................................1
1.2 Fancom-helpdesk...........................................................................................................................1
1.3 Veiligheidsinstructies en waarschuwingen......................................................................................2
2. Mogelijkheden van de ITM-A...................................................................................................................... 3
2.1 ITM-A zonder analoge uitgang – ITM-A..........................................................................................3
2.2 ITM-A met analoge uitgang – ITM-A............................................................................................... 3
3. De ITM-A installeren................................................................................................................................... 4
3.1 De ITM-A monteren........................................................................................................................4
3.2 De ITM-A aansluiten.......................................................................................................................4
3.3 De ITM-A testen ............................................................................................................................. 7
4. De ITM-A gebruiken.................................................................................................................................... 8
4.1 De knop instellen............................................................................................................................8
4.2 Display (optie)................................................................................................................................. 8
5. De ITM-A afregelen..................................................................................................................................... 9
5.1 Algemeen .......................................................................................................................................9
5.2 De 1%-waarde voor de ventilatorregeling afregelen.......................................................................9
5.3 Het maximumaantal omwentelingen afstellen .............................................................................. 10
5.4 De regelingang afregelen ............................................................................................................. 10
6. Alarmen ..................................................................................................................................................... 12
7. Technische gegevens .............................................................................................................................. 13
8. Aansluitschema........................................................................................................................................ 14
9. Bijlage: EG-verklaring van overeenstemming........................................................................................ 15
