F&F BIS-410i User manual

- 3 - - 4 -
- 1 - - 2 -
D141223/150116
SpecificationsWiring diagram
BISTABLE RELAY
with switch off timer
BIS-410i
power supply V AC
contact / load current
current control pulse L < mA
response delay 0.1÷0.2s
off time - adjustable 1÷15min.
supply signalling green LED
power consumption
standby 0. W
on 0.6W
working temperature - ÷50°C
terminal screw terminals
tightening torque 0.4Nm
mounting in the Ø60 flush-mounted box
ingress protection I 20
100÷265
AC-1 1NO / <16A (160A/20ms)
5
15
25
dimensions Ø54 (□48×43mm), h= 20mm
P
2.5mm ²
2000W 1000W
1250W
incandescent fluorescent energy-saving
halogen LED
500W 250W
Power table
The above data are indicative and will depend to a large extent on
the design of a specific receiver (especially for LED bulbs, energy
saving lamps, electronic transformers and pulse power supplies),
switching frequency and working conditions.
For more information visit: www.fif.com.pl.
Purpose
Electronic bistable impulse relay allows switching of lighting or
other equipment from several different points of using the control
buttons are connected in parallel.
L N
N
L
BIS
Functioning
L
N
2 3 5
L
1
N L
64
N
PWR
L
N
The receiver is followed by current pulse triggered by pressing any
(bell) connected to the relay. Turning off the receiver will be the
next pulse or automatically turn off after a preset time. Longer
duration (minimum 2 seconds) pressing the relay instantaneous
permanently. It will cut out after a momentary button is pressed
again (or after a power failure).
t >t
>2s
t
U
t t
F&F Filipowski sp. j.
Konstantynowska 79/81 95-200 Pabianice
phone/fax: [phone] POLAND
http://www.fif.com.pl e-mail: [e-mail]
Do not dispose of this device to a garbage bin with other unsorted waste!
In accordance with the Waste Electrical and Electronic Equipment Act
any household electro-waste can be turned in free of charge and in any
quantity to a collection point established for this purpose, as well as to the
store in the event of purchasing new equipment (as per the old for new rule,
regardless of brand). Electro-waste thrown in the garbage bin or abandoned
in the bosom of nature pose a threat to the environment and human health.
WARRANTY. The F&F products are
covered by a warranty of the 24 months
from the date of purchase. Effective only
with proof of purchase. Contact your
dealeror directly with us. More
information how to make a compliant can
be found on the website:
www.fif.com.pl/reklamacje
Assembly
1. Disconnect the power supply.
2. The relay mounted in flush-mounted box.
3. Connect the power supply to a group of PWR: L phase wire
to terminal 5 or 6. The N neutral to terminal 3 or 4.
4. Parallel momentary switches connected to terminal 1 and
the L phase conductor.
5. Powered receiver connected in series to terminal 2 and
the N neutral conductor.
6. Potentiometer to set the switch-off time.
Note!
BIS-410 can be used with illuminated buttons.
5 908312 598312
Relay version "i" is to pin adapted to cooperate with the receivers
with high starting current, such as LED fluorescent lamps,
ESL fluorescent lamps, electronic transformers, discharge lamps,
etc.
