F&F PK-1Z-LED 230 V User manual

- 1 -
PK-1Z-LED 230 V
Electromagnetic
relay
Electromagnetic relay in a single-module housing for direct mo-
unting on the TH-35 rail.
The "LED" version of the relay is equipped with a contact
designed to cooperate with receivers with high starting
current, such as: LED fluorescent lamps, ESL fluorescent
lamps, electronic transformers, discharge lamps, etc.
Applying the supply voltage to the relay coil will switch the con-
tacts to the position 11-12. This state is indicated by a green LED.
After a power failure, the contacts return to position 11-10.
Purpose
Functioning
F&F Filipowski sp. j.
Konstantynowska 79/81, 95-200 Pabianice, POLAND
phone/fax [phone]
www.fif.com.pl; e-mail: [e-mail]
Do not dispose of this device in the trash along with other waste!
According to the Law on Waste, electro coming from households free of charge and can
give any amount to up to that end point of collecon, as well as to store the occasion of
the purchase of new equipment (in accordance with the principle of old-for-new, regard-
less of brand). Electro thrown in the trash or abandoned in nature, pose a threat to the
environment and human health.

- 2 -
1.Disconnect the power supply.
2.Fix the relay on the rail in the distribution box.
3.Connect the power supply to terminals 1-3 (any order).
4.Power supply circuit of controlled receiver's connect by con-
tacts 11-12 (NO contact).
1-3 power supply 230 V AC
11-12 NO contact (active)
Mounting
Wiring diagram

- 3 -
power supply 230 V AC
maximum load current (AC-1) 16 A*
switching voltage 250 V AC
contact separated 1×NO (120 A/20 ms)
usage category AC-7a
insulation voltage 400 V
surge voltage
contacts-coil 2.5 kV
contact separation 1.2 kV
surge resistance 3 kV
current consumption 25 mA
activation time <40 ms
deactivation time <20 ms
mechanical durability min. 5×10⁶ cycles
electrical durability min. 1×10⁵ cycles
power indication LED
power consumption 25 mA
working temperature -25÷50°C
terminal 2.5 mm² screw terminals
tightening torque 0.4 Nm
dimensions 1 module (18 mm)
mounting on TH-35 rail
ingress protection IP20
* modular contactors are recommended
Technical data

- 4 -
Table for loads supplied with 230 V AC:
tungsten halogen fluorescent energy-saving LED
3000 W 2500 W 1500 W 750 W 750 W
The above data are indicative and will heavily depend on the
design of a specific receiver (that is especially important for
LED bulbs, energy-saving lamps, electronic transformers and
pulse power supply units), switching frequency and operating
conditions.
For more information visit: www.fif.com.pl.
The F&F products are covered by a warranty of the 24 months
from the date of purchase. Effective only with proof of purchase.
Contact your dealer or directly with us.
F&F Filipowski sp. j. declares that the device is in conformity
with the essential requirements of The Low Voltage Directive
(LVD) 2014/35/EU and the Electromagnetic Compatibility (EMC)
Directive 2014/30/UE.
The CE Declaration of Conformity, along with the references to
the standards in relation to which conformity is declared, can be
found at www.fif.com.pl on the product page.
Power table
Warranty
CE declaration
E220329
