F&F PK-4PZ User manual

- 1 -
PK-4PZ 110 V
Electromagnetic
relay
Electromagnetic relay in a single-module housing for direct mo-
unting on the TH-35 rail.
When the supply voltage is applied to the relay coil, the contacts
are switched into positions 5-6, 8-9, 2-10 and 11-12.
This state is indicated by a green LED.
After a power failure, the contacts return to the positions: 5-4, 8-7,
and contacts 2-10 and 11-12 are opened up.
Purpose
Functioning
Do not dispose of this device in the trash along with other waste!
According to the Law on Waste, electro coming from households free of charge and can
give any amount to up to that end point of collec� on, as well as to store the occasion of
the purchase of new equipment (in accordance with the principle of old-for-new, regard-
less of brand). Electro thrown in the trash or abandoned in nature, pose a threat to the
environment and human health.
F&F Filipowski sp. j.
Konstantynowska 79/81, 95-200 Pabianice, POLAND
phone/fax [phone]
www.fif.com.pl; e-mail: [e-mail]

- 2 -
1.Disconnect the power supply.
2.Mount the relay on the rail in the distribution box.
3.Connect to the system according to the diagram.
Mounting
Wiring diagram

- 3 -
norm IEC 61095
power supply 110 V AC/DC
contact 2×NO/NC, 2×NO
maximum load current (AC-1) 4×8 A, 250 V AC
switching current Ie= 4×8 A
thermal current Ith= 4×8 A
switching voltage Ue= 250 V
insulation voltage 400 V
maximum surge voltage contacts - coil 2.5 kV
separate circuits 3.6 kV
contact separation 1.2 kV
pollution degree 3
short-circuit protection installation switch B8 (8 A)
surge resistance 3 kV
coil voltage Uc= 110 V AC/DC
control circuit voltage Us= 110 V AC/DC
safety class B
usage category AC-7a
activation time max 40 ms
deactivation time max 20 ms
mechanical durability min. 5×10⁶
power indication green LED
current consumption 25 mA
terminal 2.5 mm² screw terminals
tightening torque 0.4 Nm
working temperature -25÷50°C
dimensions 1 module (18 mm)
mounting on TH-35 rail
ingress protection IP20
Technical data

- 4 -
E211223
Table for loads supplied with 230 V AC:
tungsten halogen fluorescent energy-saving LED
1000 W 600 W 500 W 250 W 120 W
The above data are indicative and will heavily depend on the
design of a specific receiver (that is especially important for
LED bulbs, energy-saving lamps, electronic transformers and
pulse power supply units), switching frequency and operating
conditions.
For more information visit: www.fif.com.pl.
The F&F products are covered by a warranty of the 24 months
from the date of purchase. Effective only with proof of purchase.
Contact your dealer or directly with us.
F&F Filipowski sp. j. declares that the device is in conformity
with the essential requirements of The Low Voltage Directive
(LVD) 2014/35/EU and the Electromagnetic Compatibility (EMC)
Directive 2014/30/UE.
The CE Declaration of Conformity, along with the references to
the standards in relation to which conformity is declared, can be
found at www.fif.com.pl on the product page.
Power table
Warranty
CE declaration
