The Celano™
FP5420PW
SPECIFICATION SHEET
Product Specifications Subject To Change

Copyright 2007 Fanimation, Inc. 2007/12
The Celano™Fan Assembly – FP5420PW
Dimensions shown in inches
10983 Bennett Parkway
Zionsville, IN 46077
Toll Free [phone]
FAX [phone]
Outside U.S. call [phone]
Visit Our Website www.fanimation.com
INSTALLATION REQUIREMENTS:
Ceiling fan attaches to electrical junction box securely anchored and capable of withstanding a load of at least 50 lbs.
ELECTRICAL REQUIREMENTS:
Ceiling fan requires a grounded electrical supply line of 120 volts AC, 60 Hz, 15 amp circuit.
MOTOR SPECS:
188 x 20 motor is designed for optimal performance with this fan.
FAN SPEEDS:
3 fan speeds with reversing switch (on top of the motor). High – 160 rpm; Med – 108 rpm; Low – 59 rpm
CONTROL OPTIONS:
The hand-held remote control (C24) with canopy receiver (RECFP5420) is included. Push button remote control will
consist of 3 separate fan speeds, infinite light levels, and off position. Reversing switch located on fan housing. Optional
wall control (C25) is available (to be used in conjunction with fan receiver).
LIGHTING OPTIONS:
The 3-bulb (40 watt max candelabra bulbs - not included) downlight fixture is included with this fan assembly. Maximum
downlight wattage not to exceed 120 watts.
DOWNROD OPTIONS:
The Celano™fan comes with a 1˝Dia. x 6˝(DR1-6) downrod. Optional downrods are available in 12”, 18”, 24”, 36”,
48”, 60”, and 72”. For installations requiring a longer downrod, a downrod coupler is available. Optional Decorative DR
Sleeve (DRS54PW) is available, requires a 18˝DR or longer. The Celano™fan can be mounted on a sloped ceiling up
to 30°. Most sloped ceiling installations require a downrod longer than the standard 6˝downrod. Optional sloped ceiling
ball kits (SCB1-52) are available for up to 52°. Call tech support for more information.
BLADE SETS:
A set of 5 walnut wood blades are included. Optional set of 5 cherry wood blades (B5400CY) is available and sold
separately. Not recommended for Damp Location.
DAMP LOCATION:
Fan not rated for Damp Location usage.
Optional DR Sleeve
DRS54PW
Optional Cherry
Blade Set
B5400CY
Fan Assembly - FP5420PW
Distance from Ceiling to Blade Edge
(with 6˝DR) 11.6˝
Blade Sweep / Pitch 54˝/ 14°
Canopy Diameter 6½˝
Net Hanging Weight: (with Light Kit) 29 lbs
Distance from Ceiling to
Bottom of Fan
Fan w/6˝downrod 18˝
Fan w/12˝downrod 24˝
Fan w/18˝downrod 30˝
Fan w/24˝downrod 36˝
Fan w/36˝downrod 48˝
Fan w/48˝downrod 60˝
Fan w/60˝downrod 72˝
Fan w/72˝downrod 84˝
Available Finish
PW Pewter with Opal/Frosted
Glass
