SPECIFICATION SHEET
Product Specifications subject to change
FP7300 / FP7400 / FP7500
UNI-PACK SERIES FANS
Copyright 2008 Fanimation, Inc. 2008/05
The Windpointe®
5 – Blade Traditional
Style Model
FP7500**
FP7500 Series – Traditional, 5 Blades
Available Uni-Packed Finishes
Fan Motor Assembly
(188 x 25)
Blades - Palm/Bamboo
(18° Pitch)
Blade
Sweep
Ceiling to Blade
Bottom Edge
Ceiling to
Switch Cup
RPM’s
(H / M / L)
FP7500AB – Antique Brass ISP4 – 22˝Narrow Oval Palm 52˝
14˝14½˝ 90 / 65 / 40
FP7500MW – Matte White ISP5 – 18˝Narrow Oval Palm 44˝ 14˝14½˝ 120 / 95 / 50
FP7500RS – Rust (Damp) ISD4A – 22˝Narrow Oval Bamboo 52˝ 14˝14½˝ 95 / 70 / 40
220V Models
FP7500AB-220 – Antique Brass ISP4 – 22˝Narrow Oval Palm 52˝ 14˝14½˝ 90 / 65 / 40
FP7500RS-220 – Rust (Damp) ISD4A – 22˝Narrow Oval Bamboo 52˝ 14˝14½˝ 90 / 70 / 40
INSTALLATION REQUIREMENTS:
Ceiling fan attaches to electrical junction box securely anchored and capable of withstanding a load of at least 50 lbs.
ELECTRICAL REQUIREMENTS:
Ceiling fan requires a grounded electrical supply line of 120 volts AC, 60 Hz, 15 amp circuit. 220 VAC, 50 Hz export
version available.
FAN SPEEDS:
Pull-chain, 3 fan speeds with reversing switch (on switch cup housing). Speeds will vary depending on blade size and
type.
CONTROL OPTIONS:
Optional remote and wall controls are available. See Catalog or visit our website, www.fanimation.com for more control
options.
LIGHTING OPTIONS:
Optional lighting fitters and light kits are available, including a single bowl fixture with a maximum of 180 watts and a
variety of four-light fixtures with a maximum of 240 watts. See Catalog or visit our web site, www.fanimation.com for more
lighting options.
DOWNROD OPTIONS:
The fan comes with a 1˝Dia. x 6˝(DR1-6) downrod. Optional downrods are available in 12˝, 18˝, 24˝, 36˝, 48˝, 60˝, and
72˝. The fan can be mounted on a sloped ceiling up to 30°. Most sloped ceiling installations require a downrod longer
than the standard 6˝downrod. Optional sloped ceiling ball kits (SCB1-52) are available for up to 52°. Call tech support
for more information.
BLADE SETS:
A set of 5 Palm or Bamboo blades are included.
DAMP LOCATION:
Rust finish model with bamboo blades is rated for Damp Location.

FP7300** FP7400**
4 – Blade Style Model3 – Blade Style Model
FP7300 Series – 3 Blades
Available Uni-Packed Finishes
Fan Motor Assembly
(188 x 25) Blades (14° Pitch) Blade Sweep
Ceiling to Blade
Bottom Edge
Ceiling to
Switch Cup
RPM’s
(H / M / L)
FP7300PW – Pewter B2000CP – Wood 60˝
13½˝14½˝ 125 / 95 / 60
FP7300RS – Rust (Damp) B3000BW – Wide Oval, Woven 56˝
15˝14½˝ 120 / 95 / 50
220V Model
FP7300RS-220 – Rust (Damp) B3000BW – Wide Oval, Woven 56˝ 15˝14½˝ 120 / 85 / 50
INSTALLATION REQUIREMENTS:
Ceiling fan attaches to electrical junction box securely anchored and capable of withstanding a load of at least 50 lbs.
ELECTRICAL REQUIREMENTS:
Ceiling fan requires a grounded electrical supply line of 120 volts AC, 60 Hz, 15 amp circuit. 220 VAC, 50 Hz export
version available.
FAN SPEEDS:
Pull-chain, 3 fan speeds with reversing switch (on switch cup housing). Speeds will vary depending on blade size and
type.
CONTROL OPTIONS:
Optional remote and wall controls are available. See Catalog or visit our website, www.fanimation.com for more control
options.
LIGHTING OPTIONS:
Optional lighting fitters and light kits are available, including a single bowl fixture with a maximum of 180 watts and a
variety of four-light fixtures with a maximum of 240 watts. See Catalog or visit our web site, www.fanimation.com for more
lighting options.
DOWNROD OPTIONS:
The fan comes with a 1˝Dia. x 6˝(DR1-6) downrod. Optional downrods are available in 12˝, 18˝, 24˝, 36˝, 48˝, 60˝, and
72˝. The fan can be mounted on a sloped ceiling up to 30°. Most sloped ceiling installations require a downrod longer
than the standard 6˝downrod. Optional sloped ceiling ball kits (SCB1-52) are available for up to 52°. Call tech support
for more information.
BLADE SETS:
A set of 4 wood blades are included. Not recommended for Damp Location.
DAMP LOCATION:
Fan not rated for Damp Location usage.
FP7400 Series – Wood, 4 Blades
Available Uni-Packed Finishes
Fan Motor Assembly
(188 x 25) Blades - Wood (14° Pitch) Blade Sweep
Ceiling to Blade
Bottom Edge
Ceiling to
Switch Cup
RPM’s
(H / M / L)
FP7400AB – Antique Brass B4010CP – Cairo Purple Wood 52˝
14˝14½˝ 175 / 120 / 70
FP7400RS – Rust B4020SS – Sambel Sand Wood 52˝
14˝14½˝ 160 / 110 / 65
220V Model
FP7400RS-220 – Rust B4020SS – Sambel Sand Wood 52˝ 14˝14½˝ 160 / 110 / 65
INSTALLATION REQUIREMENTS:
Ceiling fan attaches to electrical junction box securely anchored and capable of withstanding a load of at least 50 lbs.
ELECTRICAL REQUIREMENTS:
Ceiling fan requires a grounded electrical supply line of 120 volts AC, 60 Hz, 15 amp circuit. 220 VAC, 50 Hz export
version available.
FAN SPEEDS:
Pull-chain, 3 fan speeds with reversing switch (on switch cup housing). Speeds will vary depending on blade size and
type.
CONTROL OPTIONS:
Optional remote and wall controls are available. See Catalog or visit our website, www.fanimation.com for more control
options.
LIGHTING OPTIONS:
Optional lighting fitters and light kits are available, including a single bowl fixture with a maximum of 180 watts and a
variety of four-light fixtures with a maximum of 240 watts. See Catalog or visit our web site, www.fanimation.com for more
lighting options.
DOWNROD OPTIONS:
The fan comes with a 1˝Dia. x 6˝(DR1-6) downrod. Optional downrods are available in 12˝, 18˝, 24˝, 36˝, 48˝, 60˝, and
72˝. The fan can be mounted on a sloped ceiling up to 30°. Most sloped ceiling installations require a downrod longer
than the standard 6˝downrod. Optional sloped ceiling ball kits (SCB1-52) are available for up to 52°. Call tech support
for more information.
BLADE SETS:
A set of 3 blades are included.
DAMP LOCATION:
Rust finish model with woven blades is rated for Damp Location.
