INSTRUCTION MANUAL
MODEL: IDH2-50IN
INDUSTRIAL DIESEL FAN HEATER (INDIRECT-FIRED)
TO PREVENT SERIOUS INJURY, READ & UNDERSTAND ALL WARNINGS &
INSTRUCTIONS BEFORE USE. PLEASE KEEP THIS DOCUMENT FOR YOUR RECORDS
FOR INDUSTRIAL USE ONLY
ADEQUATE VENTILATION REQUIRED

FOR YOUR INFORMATION
Thank you for purchasing a Fanmaster diesel heater. Please read this instruction
manual carefully before using this heater.
Disclaimer:
Fanmaster reserves the right to make alterations to specications, quantities,
dimensions, for production or other reasons, subsequent to publication.
While we believe the information is accurate and complete, we make no warranty
or representation for any particular purposes. The information is offered in good faith
and with the understanding that any use of the units or accessories in breach of the
directions and warnings in this document is at the sole discretion and risk of the user
Disposal Guidelines:
Do not dispose of this product with general household waste. This product must be
disposed according to the laws governing Waste Electrical and Electronic Equipment.
If required, contact your local authorities for information regarding the available
disposal facilities.

1. GENERAL SAFETY RULES & WARNINGS
• PLEASE READ INSTRUCTIONS CAREFULLY.
• PLACE INSTRUCTION MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE. DO NOT ALLOW
ANYONE WHO HAS NOT READ THESE INSTRUCTIONS TO ASSEMBLE, ADJUST OR OPERATE THIS
HEATER.
• IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION
MAY RESULT IN CAUSING PROPERTY DAMAGE, SERIOUS INJURY OR LOSS OF LIFE.
• FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTIONS PROVIDED WITH THIS
HEATER, CAN RESULT IN DEATH, SERIOUS INJURY AND PROPERTY LOSS OR DAMAGE FROM
HAZARDS OF FIRE, EXPLOSION, BURN, ASPHYXIATION, CARBON MONOXIDE POISONING,
AND/OR ELECTRICAL SHOCK.
• ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE INSTRUCTIONS SHOULD USE OR
SERVICE THIS HEATER. IF YOU NEED ASSISTANCE OR REQUIRE HEATER INFORMATION SUCH AS
AN INSTRUCTION MANUAL, LABELS, ETC. CONTACT FANMASTER.
• ADEQUATE VENTILATION IS REQUIRED. DO NOT USE IN ENCLOSED ENVIRONMENTS.
• UNVENTED PORTABLE HEATERS USE AIR (OXYGEN) FROM THE EXISTING AREA. ADEQUATE
COMBUSTION & VENTILATION AIR MUST BE PROVIDED.
• DO NOT STORE OR USE GASOLINE, PETROL OR ANY OTHER FLAMMABLE OR COMBUSTIABLE
VAPORS AND LIQUIDS IN THE VICINITY OF THIS HEATER.
• FIRE, BURN, INHALATION, AND EXPLOSION HAZARD. KEEP SOLID COMBUSTIBLES, SUCH AS
BUILDING MATERIALS, PAPER OR CARDBOARD, A SAFE DISTANCE AWAY FROM THE HEATER
AS RECOMMENDED BY THE INSTRUCTIONS. NEVER USE THE HEATER IN SPACES WHICH DO OR
MAY CONTAIN VOLATILE OR AIRBORNE COMBUSTIBLES, OR PRODUCTS SUCH AS GASOLINE,
SOLVENTS, PAINT THINNER, DUST PARTICLES OR UNKNOWN CHEMICALS
• DIRECT-FIRED HEATERS MAY CAUSE CARBON MONOXIDE (CO) POISONING WHEN
INCORRECTLY USED, E.G INDOORS WITHOUT ADEQUATE AIR CIRCULATION, OR IF NOT
PROPERLY WORKING. CO POISONING MAY LEAD TO DEATH.
• NOT FOR DOMESTIC OR RECREATIONAL VEHICLE USE
• THE ELECTRICAL SYSTEM TO WHICH THE APPLIANCE IS CONNECTED MUST COMPLY WITH
LOCAL REGULATIONS. A RESIDUAL-CURRENT DEVICE (RCD) MUST BE INSTALLED.
• UNPLUG THE APPLIANCE BEFORE PERFORMING ANY MAINTENANCE OPERATIONS.
• ALWAYS CHECK THE POWER CABLE BEFORE USING THE APPLIANCE. IT MUST NOT BE BENT,
TAUT, STRETCHED, CRUSHED OR ANY WAY DAMAGED.
• IF THE POWER CORD AND/OR PLUG IS DAMAGED, IT MUST BE REPLACED BY FANMASTER, A
SERVICE AGENT OR A QUALIFIED PERSONS.
• THE FRONT OUTLET IS VERY HOT DURING OPERATION. DO NOT TOUCH! BURN DANGER.
• DO NOT LEAVE THE HEATER UNATTENDED WHEN IN USE.
• NEVER USE THE HEATER WITH WET HANDS OR WHEN EITHER THE HEATER OR THE POWER CABLE
IS WET.
• CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT THEY DO NOT PLAY WITH THE HEATER.
• THE HEATER IS NOT INTENDED FOR USE BY PERSONS (INCLUDING CHILDREN) WITH REDUCED
PHYSICAL, SENSORY OR MENTAL CAPABILITIES, OR LOCK OF EXPERIENCE & KNOWLEDGE.
FOR YOUR INFORMATION

2. PRODUCT DESCRIPTION & SPECIFICATIONS
PRODUCT DESCRIPTION
Industrial diesel or kerosene indirect red portable space/fan heater with closed
combustion chamber.
SPECIFICATIONS
MODEL IDH2-50IN
Heat Output* 50KW
170,600 BTU
Air Flow (L/s) 555
Fuel Type Diesel or Kerosene
Fuel Consumption
(L/h) 4.7
Fuel Nozzle Size (gph) 1.00
Voltage (V/Hz) AC220-240V/50
Air Pressure Setting
(bar) 10.5
Current Rating (A) 3.2
Electrical Power (W) 750
Fuse Rating T3.15A
Net Weight (kg) 59
Dimensions (mm) 1370(L)*560(W)*995(H)
Tank Capacity (L) 69
Operating Range (H) ~14
Flue outlet Dia (mm) 157
Standard Accessories
Fuel Gauge Yes
Handle 1
Ambient Thermostat built-in
Malfunction detec-
tion light built-in

3. ASSEMBLING INSTRUCTIONS2. PRODUCT DESCRIPTION & SPECIFICATIONS
Remove the heater from the carton. If the heater is damaged, please contact
Fanmaster or where you purchased the heater from.
Fig 1.
Pos. Description Qty
A Handle 1
BFeet Pipe Assembly 1
C Nut M5 10 or 12
D Plain Washer 10 or 12
E Spring washer 6 or 8
F Screws 10 or 12
G Nut M12 2
H Plasher Washer 12 2
I Wheels 2
J Cotter Pin 2
K Wheel Shaft 1

3. ASSEMBLING INSTRUCTIONS - CONTINUED
1. Insert the wheel shaft “K” to the corresponding holes of the feet pipe
assembly “B”.
2. Insert the cotter pin “J” to the corresponding holes; slide the wheel “I”
over the wheel shaft “K”, put plain washer “H” to the two sides of shaft,
screw the nut “G” to x the wheel on the shaft.
3. Put the heater body on the feet pipe assembly “B”, make sure the 4 holes
of handle “A” point towards the corresponding 4 holes on the feet pipe
assembley “B” respectively.
4. Using the screw “F”, spring washer “E”, plain washer “D” and nut “C” to x
the feet pipe assembly and handle to the tank.

4. OPERATING INSTRUCTIONS3. ASSEMBLING INSTRUCTIONS - CONTINUED
• Position the heater on a at, level, non-ammable & solid surface.
• Indirect-red heaters while used in indoors, must be connected to an exhaust
pipe to vent the fumes of combustion outside. To maintain an adequate Oxygen
rate, a minimum of 80 m3/h airow from outside must occur.
• For indirect-red heaters: connect the heater to an exhaust duct. To get a proper
exhaust ow out, the fumes must rise throigh the ue. Avoid any elbows and
bends in the rst part of the exhaust ducts for at least 3m.
• Only position the heater in the normal upright position (on the wheels)
• Do not place the heater near walls, corners or low ceilings.
• Do not place the heater below a power socket outlet.
• Do not place the heater on moving vehicles or where it can tip over.
• Keep the heater away from ammable, combustible, explosive or corrosive
materials.
• Keep the heater away from curtains or similar materials that could block the air
inlet and outlet.
• Never block or restrict the air inlet and outlet for any reason.
• Keep the power cable away from heat sources, sharp edges, cutting and
moving parts.
• Do not expose directly to the weather or to excessive humidity.
• Do not place the heater in the immediate surroundings of a bath, shower or
swimming pool.
• Ensure the following minimum safety clearances from materials or objects in the
surroundings of the heater:
Side: 0.6m
Air inlet side: 1m
Top: 1.5m
Hot air outlet side: 3m

4. OPERATING INSTRUCTIONS - CONTINUED
FLUE/EXHAUST INSTALLATION
For indirect-red heaters: connect the heater to an exhaust duct. To get a proper
exhaust ow out, the fumes must rise throigh the ue. Avoid any elbows and bends in
the rst part of the exhaust ducts for at least 3m.

4. OPERATING INSTRUCTIONS - CONTINUED4. OPERATING INSTRUCTIONS - CONTINUED
START-UP
• Fill the tank with clean fuel. Only use Diesel or Kerosene
• The fuel gauge on top of the tank allows you to check the fuel level
• Connect the plug to the relevant power source
• The left display will show “- -”, the right display will show the ambient temperature.
• Push the power switch to “ON”.
• The default temperature setting is 20’C (left display)
• If the ambient temperature is lower than the default temperature, the electrodes
will start sparking & after 7 seconds the heater will start.
• If the ambient temperature is higher than the default temperature, turn the
thermostat control knows to desired temperature. the electrodes will start
sparking & after 7 seconds the heater will start.
COLD START-UP
In low temperature, in Alpine/Highland/Inland regions, unseasonably cold weather.
Block the air vent hole on the air pump (see Fig. 4) by using your nger during ignition
to make start-up easier.
ABNORMAL OPERATION:
In case of malfunction (ame failure, reduced air ow, bad combustion) the heater
stops and the indicator light starts FLASHING (THE LOCK-OUT MODE code will be
showed on the display window).
MANUAL RESET/RESTART
If the heater is in lock-out mode, check and remove the cause of lock-out before
restarting the heater. To reset, turn the ON/OFF switch to 0 and then again to I. If
problem continues please contact Fanmater. Turning the thermostat control knob will
NOT reset the heater.
SHUTDOWN
Move switch to “OFF” (O) position.
• Never disconnect the heater from mains to stop it while in operation.
• Always allow the cooling sequence to be completed, otherwise the residual heat
could damage internal components.
• Do not cover the heater. Do not block the air inlet and outlet.
• The heater outlet is very hot during operation and after use. Do not touch! Use
personal protecting equipment if needed.
• Unplug the heater before moving it. Never pull the cable to unplug or move the
unit.

5. CLEANING, MAINTENANCE & STORAGE
• Before starting any maintenance task, shut down, unplug and let the heater cool
down for at least 15 minutes.
• Do not attempt any electrical repair yourself. If the heater needs service or repair,
contact a qualied persons.
• When cleaning, make sure that water does not enter the unit.
• Do not open the enclosure to clean the inner parts. Do not spray water into the
heater.
• Never use solvents, gasoline, toluene and similar aggressive chemicals to clean
the heater.
Regularly wipe the enclosure using a soft sponge or cloth. For very dirty parts, use a
sponge wetted with lukewarm water and a mild detergent, then dry using a clean
cloth. Keep air inlet and fan free from dust and dirt. To clean inner parts, gently blow
compressed air through air inlet. Regularly inspect the power cable: if worn, cracked
or damaged have it replaced by a qualied persons only.
Before storing the heater, make sure it is perfectly cool and dry. Cover the unit with a
blanket or tarp and store it in a dry, ventilated plac
The following checks are recommended before every seasonal use:
Nozzle
Carefully unscrew nozzle from nozzle tting. Blow compressed air through nozzle
orice to free it from dirt. Replace nozzle if necessary.
Fuel Filters
Clean fuel lters by unscrewing the lter tray (clockwise) Remove the lter cartridge
and wash it with petrol or replace it if necessary. Check seal O-ring and replace it
if necessary. Reassemble the tray (Fig.2). The fuel lter installed on the gear pump
should be cleaned or replaced if necessary by unscrewing cap H (see Fig. 4)
Fig 2.
Whirl disc (extract the burner head)
Clean the whirl disc (Fig.3) using a brush and then
blow compressed air on it. To get good combustion
the air ow openings in the whirl disc should be
perfectly clean and free.
Fig 3.
Ignition Electrodes (qualied peron only)
Clean, adjust, & if necessary replace
ignition electrode. For electrode gaps see
Fig.5-6 (dimensions in mm)
Fig 5. Fig 6.

5. CLEANING, MAINTENANCE & STORAGE - CON5. CLEANING, MAINTENANCE & STORAGE
Fuel Pump Pressure Adjustment (Fig 4.)
The Fuel pump pressure is factory set and must be checked and adjusted by
qualied technicians only. Tampering with the unit may be dangerous.
Remove pressure gauge cap (P). Connect a pressure gauge on the pressure
measuring port on pump. Start heater and read fuel pressure value. If necessary
adjust pressure to the correct value turning the adjusting screw (P1) clockwise to
increase, anticlockwise to decrease the pressure:
HIGH ALTITUDE ISTALLATION
Due to lower oxygen rate with reference to high altitude installation on sea level, it
may be necessary to increase air rate by opening the air collar (Fig. 8), or to reduce
the setting pressure on fuel pump (Fig. 7). This setting adjustment can be necessary to
prevent excessive smoke emission due to lack of Oxygen.
Model Air Pressure (bar)
IDH2-50IN 10.5
Fig 4.
Fig 3.
Fig 7.
Fig 8.

6. WIRING DIAGRAM

6. WIRING DIAGRAM 7. PARTS BREAKDOWN

8. TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
Motor does not start
The power indicator is
ashing
No power or low voltage
Check power supply &
voltage
Check fuse & replace if
necessary
Faulty or damaged power
cord Check & replace
Faulty motor/capacitor Check & if necessary replace
Lock-out mode due to
previous overheating
Detect the cause of
overheating. Shut the heater
down. Check air inlet &
outlet. Wait 5 minutes &
restart the heater.
Motor runs but the
heater does not ignite
& locks out after a short
time.
Empty fuel tank, dirty or
wrong fuel
Check fuel level, ll the tank
with clean diesel or kerosene
if required. Remove wrong or
dirty fuel.
Fuel lters clogged Clean or replace tlers
The power indicator
light is ashing
Air leaks in fuel line
Check fuel lines, connections
are tight, no cracks. Replace
if required
Fuel Nozzle clogged
Clean nozzle by blowing
compressed air or replace if
required
Fuel viscosity increased at
low temperature Blend diesel with kerosene
Flame comes out of
body
Insufcient air ow into
combustion chamber
Check air pump, air inlet, fan
& motor
Air pressure too high Check air pump pressure
Heater stops during
operation
The room temperature set
has been acheived
Adjust the thermostat control
knob clockwise for higher
setting
Flame failure Check & remove the
cause(s) of the malfunction
Reset, turn the ON/OFF
switch to 0 and then again
to I.
Bad combustion
Reduced air ow
Overheating

9. WARRANTY8. TROUBLESHOOTING
Any claim under this warranty must be made within 12 months of the date of
purchase of the product. To make a claim under the warranty, take the product
(with proof of purchase) to the store where you purchased the product or go to
https://www.fanmaster.com.au/warranty-claims-returns.
This warranty is given by Fanmaster Pty Ltd
ABN: 45 353 934 457
Unit 1/6-8 Yalgar Rd, KIRRAWEE NSW 2232
P: 1300 900 345
E: [email protected]
This warranty is provided in addition to other rights and remedies you have under law:
Our goods come with guarantees which cannot be excluded under the Australian
Consumer Law. You are entitled to replacement or refund for a major failure and
to compensation for other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
Exclusions: This warranty does not cover:
• Any defects caused by an accident, misuse, abuse, improper installation or
operation, lack of reasonable care, unauthorized modication, loss of parts,
tampering or attempted repair by a person not authorized by the distributor.
• Any product that has not been installed, operated or maintained to a
satisfactory level.
• Any damage caused by improper power input or improper cable connection.

N11664
MADE IN CHINA
Fanmaster Pty Ltd | 1/6-8 Yalgar Road, KIRRAWEE NSW 2232
1300 900 345 | [email protected] | www.fanmaster.com.au
FA NM A ST E R
cooling heating ventilation extraction
