Technotherm VPS 1000 User manual

D
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE
REFERENCE. BE SURE TO OBSERVE ALL LABELS AND WARNINGS ON THE APPLIANCE
Edition: 12/17
Id_Nr. 911 360 870
Installation and technical manual
VP / VPS / VPS H / VPS DSM / VPS RF with feet´s
GB
Eco-Design Directive 2015/1188:
Feet using:
This product is only suitable for well-
insulated rooms or for occasional use

2 Edition: 12/17
Manual
VP / VPS / VPS H / VPS DSM / VPS RF
GB
1. For your safety
•This appliance is intended for normal household
use and not for use for vehicles or on board
ships or aircrafts.
•This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
•Children of less than 3 years should be kept
away unless continuously supervised.
•Children aged from 3 years and less than 8
years shall only switch on/off the appliance
provided that it has been placed or installed in
its intended normal operating position and they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
aged from 3 years and less than 8 years shall
not plug in, regulate and clean the appliance or
perform user maintenance.

3 Edition: 12/17
Manual
VP / VPS / VPS H / VPS DSM / VPS RF
GB
•CAUTION — Some parts of this product can
become very hot and cause burns. Particular
attention has to be given where children and
vulnerable people are present.
•Make sure that your supply rating corresponds
to what specified on the rating plate: 230V~,
50Hz.
•During function, place the heater in a safe
position:
- at least 1m far from inflammable objects or
furnitures;
- leaving not less than 1m of free space in
front of the heater;
- not located immediately below a socket-
outlet.
•Do not leave animals or children touch or play
with the appliance.
•Do not use the heater in rooms with explosive
gas or while using inflammable solvents or
varnish or glues.
•If the cordset is damaged and you have to
change it, do not do the job yourselves! Take the
product to an after sales authorised repair centre
or to a person with similar skill and knowledge,
in order to avoid any risk of danger.
•The appliance must be positioned so that the
plug is always accessible.
•Do not mount the product on walls made of
synthetic material.

4 Edition: 12/17
Manual
VP / VPS / VPS H / VPS DSM / VPS RF
Warning! this device has to be grounded
This device may only be operated using alternating current and the operating voltage indicated
on the power rating plate
•Nominal Voltage 230V AC, 50 Hz
•Protection Class I
•Degree of Protection IP 24
•Room Thermostat 7°C till 30°C
2.1 User Manual for the VPS / VPS H / VP
The console is segmented into the following parts
:
(+ ) key
( )key
Mode selector key
On\ Off switch
2.1 Selectror key:
The Selector Key has 4 basic Functions: “Comfort,” “Setback”, “Frost Protection”, and “Off”
Comfort Mode: The heater is in continuous operation. To change the set temperature press the + or
- key
Setback Mode: Here you can make adjustments for night -time operating
Frost Protection: The heater is working in Frost Protection Array (7°C)
OFF: The two parallel lines in the display indicate that the heater is still running.
2.2 Normal Operation:
To turn the heating device on, press the On\Off key and select between the Comfort and Setback mode.
You can switch between the different modes by pressing the selector key until the desired token appears
on the display. In addition the digital visual display will show the amount of electricity used and the room
temperature. By pressing the + or – key, you can adjust the different settings. The display will flash
approximately 4 times in two intervals. If the current room temperature is different to the desired room
temperature you can make adjustments by pressing the + or – key. Almost instantly you will feel the warm
air coming out of the heater .The + or- keys allow you to set the heater to your desired defaults at any time.
GB

5 Edition: 12/17
Manual
VP / VPS / VPS H / VPS DSM / VPS RF
Note: On your display you will also see a clock. . However this function is unavailable and can
therefore be ignored.
2.3 User Manuel for the VPS DSM
Please see additional manual at http://www.lucht-lhz.de/lhz-app-gb.html and download the manual
3.1 User Manuel VPS RF Model
3.1.1 Setting the Room Thermostat
Press the receiver button for more than 3 seconds, until the indicator light begins to flash. Subsequently
press the transmitter key in the configuration mode. (see User Manual Receiver) As soon as the indicator
light stops flashing the two products are assigned.
3.1.2 Setting the sender
Press the receiver button for at least 3 seconds until the indicator light starts flashing.
Two modes of operation are possible.
Slow flashing: On\Off switch
Fast flashing:instigator
To switch the mode again, press the key briefly. Take the transmitter into the Configuration mode (see
user manual transmitter). Check that the indicator light is no longer flashing.
Application Example
The use of a room thermostat in combination with a opening detector is ideal, because the opening detector
will detect if a window is open and will automatically switch to frost protection. By pressing the receiver
button for approximately 10 seconds, you can change the relay´s setting. You know the setting is changed
as soon as the signal light stops flashing.
3.1.3 Deleting Allocations
To delete the setting simply press the receiver key for approximately 30 seconds until you see the
receiver light flash briefly. All transmitters are now deleted.
3.1.4 Receiver RF- Technical Specifications
•Power Supply 230 V, 50 Hz +/-10%
•Protection Class II
•Expenditure : 0,5 VA
•Switching capacity max.: 16 A 230 Veff Cos j =1 or max. 300 W with lighting control
•Radio Frequency 868 MHz (NormEN 300 220),
•Radio Range up to 300 m in an open field, indoors up to ca. 30m, depending on the
construction of the building and the electromagnetic interference
•Maximal Number of receivers: 8
GB
GB
GB

6 Edition: 12/17
Manual
VP / VPS / VPS H / VPS DSM / VPS RF
•Mode of operation: type 1.C (Micro-disconnection)
•Operating Temperature: -5°C to +50°C
•Storage Temperature: -10 °C +70°C
•Dimensions: 120 x 54 x 25 mm
•Degree of Protection : IP 44 - IK 04
•To be installed in average polluted Areas
WARNING
Do not install this device in areas that present an explosion hazard like a garage. Remove
all protective coverage before turning on the device. When using the device for the first time
you might detect a strong odor. This is no reason for concern; it is caused by residues of
production and will disappear shortly.
The rising heat may cause stains on the ceiling, however this phenomena can be caused by
any other heating device as well. Only a qualified electrician may open or remove the device from the power
supply.
4. Maintenance
Before cleaning the device be sure to turn it off. To clean use a damp towel and a mild detergent.
5. Assembly instruction
This Manual is very important and has to be kept at a safe place at all times. Be sure to hand this manual
to any other succeeding owner of the device. The device comes with a power plug that has to be plugged
into an outlet.
The device is designed to be connected to 230V (nominal) alternating current (AC).
5.2 Assembling the Feed
Do not put the device near any inflammable items.
1. Put the convector on a table or any other work surface.
2. Align the holes you find on the bottom of the convector to the
holes implemented on the feet.
3. Attach the feet to the device using the screws in your accessories kid.
Attention: The model VPS H 1200 is only used by wall mounting!
5.3 Installation of Electricity
The device was developed for an electrical voltage of 230 V(nominal) and an alternating current of (AC)
50 Hz. The electrical installation may only be performed according to the user manual and only by
a qualified Electrician.The device was designed to be used with termination and the connection cable
has to be plugged into an appropriate socket at all times. (Notice Permanent cables may not be used)The
distance between the receptacle and the device hast to be at least 10cm. The connection line may not
touch the device at any time

7 Edition: 12/17
Manual
VP / VPS / VPS H / VPS DSM / VPS RF
Technical data´s
Model
Power
[Watt]
With
A
High
B
Deep
C
[mm]
D
[mm]
E
[mm]
F
[mm]
G
[mm}
H
[mm]
I
Weight
[kg]
VPS 1000
1000
750
450
85
442
140
375
250
115
375
11.5
VPS 1200
1200
750
450
85
442
140
375
250
115
375
11.5
VPS 1500
1500
1050
450
85
740
140
375
250
115
525
15.0
VPS 2000
2000
1050
450
85
740
140
375
250
115
525
15.0
VPS DSM
1000 1000 750 450 85 442 140 375 250 115 375 11.5
VPS DSM
1200 1200 750 450 85 442 140 375 250 115 375 11.5
VPS DSM
1500 1500 1050 450 85 740 140 375 250 115 525 15.0
VPS DSM
2000 2000 1050 450 85 740 140 375 250 115 525 15.0
VPS RF
1000 1000 750 450 85 442 140 375 250 115 375 11.5
VPS RF
1200 1200 750 450 85 442 140 375 250 115 375 11.5
VPS
RF1500 1500 1050 450 85 740 140 375 250 115 525 15.0
VPS RF
2000 2000 1050 450 85 740 140 375 250 115 525 15.0
VP 1000
1000
750
450
85
442
140
375
250
115
375
8.2
VP 1200
1200
750
450
85
442
140
375
250
115
375
8.2
VP 1500
1500
1050
450
85
740
140
375
250
115
525
10.3
VP 2000
2000
1050
450
85
740
140
375
250
115
525
10.3
VPS H 1200
1200
450
1054
85
210
87
984
250
100
223
15,0

8 Edition: 12/17
Manual
VP / VPS / VPS H / VPS DSM / VPS RF
6. Regulation
From 01.01.2018, the EU conformity of these devices is additionally linked to the fulfillment of
the Ecodesign requirements 2015/1188.
The installation and commissioning of the devices is only permitted in conjunction with external
room temperature controllers that fulfill the following functions:
•electronic room temperature control
and has at least one of the following properties:
•room temperature control, with presence detection
•room temperature control, with open window detection
•with distance control option
•with adaptive start control
•with working time limitation
•with black bulb sensor
The following room temperature controller systems
•RF Receiver together with the TPF-Eco Thermostat (Art.Nr.: 750 000 641) and the Eco-
Interface (Art.Nr.750 000 640) or
•DSM-Thermostat with the DSM-Interface (Art.No.:911 950 101)
from Technotherm meet the following requirements and therefore the ErP Directive:
•electronic room temperature control plus week timer (RF/DSM)
•room temperature control, with open window detection (DSM)
•with distance control option (DSM)
•with adaptive start control (DSM)
Use of the VPS / VP Standard range (without external thermostat control) is only permitted on feet.
Installation of the receiver and the interfaces see separate instructions. For customer service - see last
page.
Failure to comply with these requirements will result in the loss of the CE mark.

9 Edition: 12/17
Manual
VP / VPS / VPS H / VPS DSM / VPS RF
Model: VPS DSM (additional DSM interface necessary)
Item
Symbol
Value
Value
Item
Value
Heat output
Type of heat input, for electric storage local space heaters only (select one)
Nominal heat
output
Pnom 1000 1200 1500 2000 Watt manual heat charge control, with integrated thermostat No
Minimum heat
output
(indicative)
Pmin 1000 1200 1500 2000 Watt manual heat charge control with room and/or outdoor temperature
feedback No
Maximum
continuous heat
output
Pmax,c 1000 1200 1500 2000 Watt electronic heat charge control with room and/or outdoor
temperature feedback No
Auxiliary
electricity
consumption
fan assisted heat output No
At nominal heat
output el
max
1000 1200 1500 2000 Watt
Type of heat output/room temperature control (select
one)
At minimum heat
output
el
min
0,87 0,87 0,87 0,87 Watt single stage heat output and no room temperature control No
In standby mode el
SB
0,87 0,87 0,87 0,87 Watt Two or more manual stages, no room temperature control No
with mechanic thermostat room temperature control
No
with electronic room temperature control
No
electronic room temperature control plus day timer
No
electronic room temperature control plus week timer
Yes
Other control options (multiple selections possible)
room temperature control, with presence detection
No
room temperature control, with open window detection
Yes
with distance control option
Yes
with adaptive start control
Yes
with working time limitation
No
with black bulb sensor
No
Model: VPS RF (additional TPF Thermostat and Eco-Interface necessary)
Item
Symbol
Value
Value
Item
Value
Heat output
Type of heat input, for electric storage local space heaters only (select one)
Nominal heat
output
Pnom 1000 1200 1500 2000 Watt manual heat charge control, with integrated thermostat No
Minimum heat
output
(indicative)
Pmin
1000 1200 1500 2000 Watt manual heat charge control with room and/or outdoor temperature
feedback No
Maximum
continuous heat
output
Pmax,c 1000 1200 1500 2000 Watt electronic heat charge control with room and/or outdoor
temperature feedback No
Auxiliary
electricity
consumption
fan assisted heat output No
At nominal heat
output
el
max
1000 1200 1500 2000 Watt
Type of heat output/room temperature control (select
one)
At minimum heat
output
elmin
<0,5 <0,5 <0,5 <0,5 Watt single stage heat output and no room temperature control No
In standby mode
elSB
<0,5 <0,5 <0,5 <0,5 Watt Two or more manual stages, no room temperature control No
with mechanic thermostat room temperature control
No
with electronic room temperature control
No
electronic room temperature control plus day timer
No
electronic room temperature control plus week timer
Yes
Other control options (multiple selections possible)
room temperature control, with presence detection
Nein
room temperature control, with open window detection
No
with distance control option
Yes
with adaptive start control
No
with working time limitation
nein
with black bulb sensor
nein
Contact details:
Lucht LHZ Elektroheizung GmbG & Co. KG | Reinhard-Schmidt.Str.1 D-09217 Burgstädt

10 Edition: 12/17
Manual
VP / VPS / VPS H / VPS DSM / VPS RF
Model: VPS (only use with feet´s – no wall mounting allowed)
Item
Symbol
Value
Value
Item
Value
Heat output
Type of heat input, for electric storage local space heaters only (select one)
Nominal heat
output
Pnom 1000 1200 1500 2000 Watt manual heat charge control, with integrated thermostat No
Minimum heat
output
(indicative)
Pmin 1000 1200 1500 2000 Watt manual heat charge control with room and/or outdoor temperature
feedback No
Maximum
continuous heat
output
Pmax,c 1000 1200 1500 2000 Watt electronic heat charge control with room and/or outdoor
temperature feedback No
Auxiliary
electricity
consumption
fan assisted heat output No
At nominal heat
output el
max
1000 1200 1500 2000 Watt
Type of heat output/room temperature control (select
one)
At minimum heat
output
el
min
Watt single stage heat output and no room temperature control No
In standby mode el
SB
Watt Two or more manual stages, no room temperature control No
with mechanic thermostat room temperature control
No
with electronic room temperature control
yes
electronic room temperature control plus day timer
No
electronic room temperature control plus week timer
No
Other control options (multiple selections possible)
room temperature control, with presence detection
No
room temperature control, with open window detection
No
with distance control option
No
with adaptive start control
No
with working time limitation
No
with black bulb sensor
No
Contact details
Lucht LHZ Elektroheizung GmbH & Co. KG Reinhard-Schmidt-Str. 1 D 09217 Burgstädt
Lucht LHZ Elektroheizung GmbH & Co. KG
Reinhard-Schmidt-Str. 1
D 09217 Burgstädt
Fon: [phone]
Fax: [phone]
E-mail: [email protected] web: www.technotherm.de
GB
