Fantech AC1209 Installation and operating instructions

Part No: INST-AIRCURTAIN Version 1.1
INSTALLATION &
MAINTENANCE
INSTRUCTIONS
SPECIFICATIONS
AIR CURTAIN
1. GENERAL
1.1 It is important these Installation and Maintenance Instructions are fully adhered to.
1.2 Full details of the unit supplied are shown on the product nameplate.
If in doubt about any detail, contact FANTECH or its agents for clarification.
1.3 Electrical installation must be carried out by suitably qualified and competent personnel in accordance
with all current statuary requirements.
1.4 Any declarations made by FANTECH about product installation and safety,
are dependent on the air curtain being used within installations which themselves meet the
requirements of the relevant Standards and Directives of your region.
1.5 The air curtain must be installed in a dry, sheltered position and is not suitable for operating in
temperatures above 40 °C. The air curtain is not suitable in corrosive or explosive atmospheres.
1.6 The installer should provide easy access to the air curtain to facilitate future maintenance.
1.7 The installer should ensure the air curtain is adequately supported.
1.8 This product is not intended for use by young children or infirm persons unless they have been
adequately supervised by a responsible person to ensure that they can use the product safely. Young
children should be supervised to ensure that they do not play with the appliance.
AC1209
AC1212
AC1215
Model Voltage
(V)
F
requency
(Hz)
Low Speed High Speed
Current
(A)
Power
(W)
Outlet
Velocity
(m/s)
Noise
(dB(A))
Current
(A)
Power
(W)
Outlet
Velocity
(m/s)
Noise
(dB(A))
AC1209 230 50 0.956 220 15 54 1.2 276 18 57
AC1212 230 50 1.217 280 15 55 1.391 320 18 58
AC1215 230 50 1.522 350 12.5 54 1.896 436 14 57
These instructions must be read fully
before commencing installation.
09/21
Page 1/4

2. INSTALLATION
The air curtain must not be installed in an area where there is any possibility of water/moisture ingress. The air curtain must
be isolated from the power supply during installation and maintenance, and must be earthed in accordance with the local
regulations.
2.1 Upon receipt, the air curtain should be visually inspected to check for any damage.
2.2 Check the details on the rating plate to ensure that the correct power supply (voltage, frequency and phase) is available.
An incorrect power supply will lead to permanent damage to the air curtain.
2.3 Supply connection is via terminal block behind centre inlet grille.
2.4 Means for electrical disconnections must be incorporated in the wiring installation in accordance with the relevant wiring
and electrical regulations.
2.5 Accessories: 6 sets of bolts (M8 x 60mm), washers, spring washers, nuts.
2.6 Installation position to follow the diagram below:
2.7 Coverage height: 3.5m (To install air curtain horizontally).
2.8 Installation on concrete wall:
• Remove installation support plate from rear of unit by removing the 3 fixing screws. See following diagram.
• Use Dyna bolts or equivalent to fit the Installation Support Plate to the wall
• Install the unit body onto the Installation Support Plate (see following diagram)
Important safety information
09/21Part No: INST-AIRCURTAIN Version 1.1
Page 2/4

3. START-UP
4. FAN MAINTENANCE
6. WIRING DIAGRAM5. DIMENSIONAL DRAWING
3.1 Before power is supplied to the unit, ensure that
the wiring is correct as per the connection diagram.
3.2 Check that the motor amperage draw does not
exceed the nameplate rating.
3.3 To set the required speed, select Lo
or Hi at the wall mounted switch.
3.4 Adjust AIR DEFLECTOR to preferred positions.
4.1 Inspection of the air curtain at least once every 12 months is recommended to ensure that the motor, fan blades, and inlet
filters are clean. Any build up of dust and deposit on the blades or guards should be removed using a non-abrasive cleaner.
4.2 All fastenings should be checked for tightness. In addition, all rotating items should be checked after 12 months
4.3 Bearings are of the ‘sealed for life’ type and will not need a detailed inspection.
Model
Dimensions, mm Weight
(kg)
A B C D E F G
AC1209 900 50 400 113 249 230 214 12.4
AC1212 1200 200 400 113 249 230 214 13.6
AC1215 1500 350 400 113 249 230 214 17.6
2.9 Other installation methods (see following diagram):
2.10 More than one air curtain unit can be used across the width of a doorway.
2.11 The recommended distance between 2 adjacent sets of air curtains to be 20-40mm.
G
F
D
A
BC
EEE
CB
8 mounting holes (8mm wood screws are used)
6 mounting holes
(8mm bolts are used)
Mounting
plate
Air Outlet
09/21Part No: INST-AIRCURTAIN Version 1.1
WARNING- Do not cover the air inlet and outlet. Only a suitably qualified and competent
person may carry out maintenance after the electrical supply has been isolated.
Page 3/4
