Fantom PROVAC P 5000 User manual

Cyclone Stick Vacuum Cleaner
PROVAC P 5000
USER MANUAL
1

1-Motor Body
2-On/Off Switch
3-Body Locking Latch
4-Hepa Filter
5-Dustbin Upper Cover
6-Cyclone Chamber
7-Dustbin
8-Cable Winding Latch
9-Pipe Locking Latch
10-Dustbin Bottom Cover
11-Dustbin Locking Latch
12-Extension Tubes
13-Floor Nozzle
COMPONENT PARTS
2
9
8
12
2
1
4
56
7
3
9
10
11
13

3
14-Hanger
15-Upholstery Nozzle
16-Crevice Nozzle
17-Stand Pipes
18-Stand Pipe Joint Adapter
19-Stand Pallet
COMPONENT PARTS
17
19
18
14
15
16

• The PROVAC P 5000 Stick Vacuum Cleaner is designed for
domestic use. Use your device for its intended purpose and only for
dry cleaning. Do not use for vacuuming water or other liquids.
• Always use original spare parts and accessories to protect the
safety of your device. Warranty will not be valid for
malfunctions caused by the use of unsuitable
parts. For repair of spare parts, apply to the nearest PROVAC
authorized service.
• Do not use the device with a damaged cable.
• Do not vacuum harmful dust.
• Never use your device without a motor protection filter.
• Do not leave the plug of your cleaner plugged into the socket. When
you are finished, turn off the device and remove the plug from the
socket. Do not handle the plug with wet hands.
• If your appliance does not work for any reason, if there is any
damage on the cable and plug, do not operate the vacuum cleaner
and apply to the nearest PROVAC authorized service.
• Do not carry your device by holding the cable.
• Only use the device as described in the user manual, do not use it
for any other purpose.
• Do not use your vacuum cleaner for cleaning materials such as hot
ash, razors and nails, as well as flammable liquids and oils.
• Keep your vacuum cleaner and its cord away from stoves, ovens
and similar heat sources.
• Never use your device in or near explosive atmospheres and
materials.
• In order to prevent the filters of your device from clogging and to
extend the engine life; flour, drill powder, gypsum powder etc. Do
not vacuum dust.
• Do not wash the engine compartment with water, do not immerse it
in water or similar liquids.
• It can be used by children aged 8 years and above, and people with
insufficient physical, emotional or mental capabilities or lack of
experience and knowledge, as long as they are supervised or
trained in the safe use of your device and its hazards. Children
should not play with the device. Cleaning and user maintenance
should not be performed by children unless they are supervised.
Children under the age of 3 who are not under constant supervision
should be kept away.
• Do not allow your device to be used as a toy by children and make
sure that it is not used.
SAFETY RULES
WARNING: READ BEFORE USING THE DEVICE,
IF THESE INSTRUCTIONS ARE NOT FOLLOWED.
WARRANTY IS VOID.
4

ASSEMBLY AND DRY VACUUMING
Before use vacuum cleaner, put the hepa filter in
the chamber, as shown in the picture.
To connect the extension tubes, lock them by
pushing the lock slots facing each other.
Lock the floor nozzle by pushing it so that the
lock slots on the extension tube are facing each
other. Your product will be ready to use.
Place the stand pallet on the floor. Connect the
long and short stand pipe by the joint adapter.
Place the stand pipes in a way that it assambled
before with the slot on the stand pallet and
press it into place. Insert the vacuum cleaner
hanger into the top of the stand pipe and push it
downwards until it is seated.
Your stand will be ready to use.
Place your vacuum cleaner on the stand as
shown in the picture. Place the crevice nozzle
and the upholstery nozzle on the right and left
edges of the vacuum cleaner hanger.
5

6
ASSEMBLY AND DRY VACUUMING
You can use your vacuum cleaner by plugging in
your vacuum cleaner and turning on the on/off
switch.
In order to use your vacuum cleaner in
hard-to-reach and narrow areas, you can attach
the crevice nozzle to the end of the extension
tube as shown in the picture.
For use your vacuum cleaner on sofa, etc. you
can use it by attaching the upholstery nozzle to
the end of the extension tube or directly to the
suction mouth for use in places as seen in the
picture.
When you finished vacuuming, turn the switch
to the off position and unplug your vacuum
cleaner when you are not using it. Keep your
device by placing it on its stand after use.

7
CLEANING AND STORAGE
Note: Before cleaning your device, be sure to
unplug it from the socket.
Before cleaning, remove the extension tubes by
pressing the lock latch on the extension tubes of
your vacuum cleaner and pulling it downwards.
For cleaning, first open the bottom cover of the
dustbin and ensure that the dust is emptied into
the trash.
By pressing the body opening latch, move the
body upwards and separate it from the chamber
as shown in the picture.

8
CLEANING AND STORAGE
Remove the dustbin cover by turning and
separate it from the dustbin. Remove the
cyclone chamber from the dustbin.
Clean the plastic parts by shaking them.
For hepa filter cleaning, pull out the hepa filter
from the dust chamber top cover, shake it and
replace it.
When placing the cyclone chamber into the
dustbin, make sure that the tab on the cyclone
chamber corresponds to the slot in the dust bin
as shown in the Picture.
Place the dust bin as shown in the picture so
that the tab part corresponds to the slot on the
motor body and push the hopper towards the
motor body so that it is seated.
Note: Do not wash the motor body of your
device, do not immerse it in water. Wipe clean
only. You can also clean other accessories of
your device by wiping them.

9
CLEANING AND STORAGE
After cleaning, fix the tubes by pressing the
extension tubes of your device so that they
coincide with the lock latches as seen in the
picture.
Put your vacuum cleaner on the stand hanger as
shown in the picture.
Make sure the vacuum cleaner is stable on the
stand.

10
CLEANING AND STORAGE
You can easily wind the power cable on the
extension tubes as shown in the picture. When
you are not using your device, you can store it
without taking up space by placing it on its
stand as shown in the picture.

TECHNICAL SPECIFICATIONS
TYPE P XY
Rated Voltage : 220-240 V AC
Rated Frequency : 50 / 60 Hz
Power : 850 W
Net Weight : 2.30 kg
11

12
