Farberware FAC500G Quick reference guide

USE & CARE INSTRUCTIONS
COFFEE GRINDER
FAC500G
ACCENTS
ONE-YEAR LIMITED WARRANTY
Warranty: This Farberware® product is warranted by Salton, Inc. to be free from defects in materials or
workmanship for a period of (1) year from the original purchase date. This product warranty covers only the
original consumer purchaser of the product.
Warranty Coverage: This warranty is void if the product has been damaged by accident in shipment,
unreasonable use, misuse, neglect, improper service, commercial use, repairs by unauthorized personnel,
normal wear and tear, improper assembly, installation or maintenance abuse or other causes not arising out of
defects in materials or workmanship. This warranty is effective only if the product is purchased and operated
in the USA, and does not extend to any units which have been used in violation of written instructions
furnished with the product or to units which have been altered or modified or to damage to products or parts
thereof which have had the serial number removed, altered, defaced or rendered illegible.
Implied Warranties: ANY IMPLIED WARRANTIES WHICH THE PURCHASER MAY HAVE ARE LIMITED IN
DURATION TO ONE (1) YEAR FROM THE DATE OF PURCHASE. Some states do not allow limitations on how long
an implied warranty lasts, so the above limitation may not apply to you.
Warranty Performance: During the above one-year warranty period, a product with a defect will be either
repaired or replaced with a reconditioned comparable model (at our option) when the product is returned to
the Repair Center, or the purchase price refunded. The repaired or replacement product will be in warranty for
the balance of the one-year warranty period and an additional one-month period. No charge will be made for
such repair or replacement.
Service and Repair: Should the appliance malfunction, you should first call toll-free 1 [phone] between
the hours of 9:00 am and 5:00 pm Central Standard Time and ask for CONSUMER SERVICE stating that you are
a consumer with a problem. Please refer to model number FAC500G when you call.
In-Warranty Service (USA): For an appliance covered under the warranty period, no charge is made for
service or postage. Call for return authorization 1 [phone].
Out-of Warranty Service: A flat rate charge by model is made for out-of-warranty service. Include $8.00
(U.S.) for return shipping and handling. We will notify you by mail of the amount of the charge for service and
require you to pay in advance for the repair or replacement.
For Products Purchased in the USA, but Used in Canada: You may return the product insured, packaged
with sufficient protection, and postage and insurance prepaid to the USA address listed below. Please note
that all customs duty / brokerage fees, if any, must be paid by you and we will require you to pay the cost of
customs duty / brokerage fees to us in advance of our performing any service.
Risk During Shipment: We cannot assume responsibility for loss or damage during incoming shipment. For
your protection, carefully package the product for shipment and insure it with the carrier. Be sure to enclose
the following items with your appliance: any accessories related to your problem, your full return address and
daytime phone number, a note describing the problem you experienced, a copy of your sales receipt or other
proof of purchase to determine warranty status. C.O.D. shipments cannot be accepted.
To return the appliance, ship to: To contact us, please write to, call, or email:
ATTN: Repair Center Salton, Inc.
Salton, Inc. P.O. Box 7366
708 South Missouri Street Columbia, MO 65205-7366
Macon, MO 63552 1-888-881-8101
E-mail: [email protected]
Limitation of Remedies: No representative or person is authorized to assume for Salton, Inc. any other
liability in connection with the sale of our products. There shall be no claims for defects or failure of
performance or product failure under any theory of tort, contract or commercial law including, but not limited
to negligence, gross negligence, strict liability, breach of warranty and breach of contract. Repair,
replacement or refund shall be the sole remedy of the purchaser under this warranty, and in no event shall
Salton be liable for any incidental or consequential damages, losses or expenses. Some states do not
allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion
may not apply to you.
Legal Rights: This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.
For more information on Salton products, visit our website: www.eSalton.com
©2004 Salton, Inc. All rights reserved.
FARBERWARE® is a registered trademark of Farberware Inc.®
Manufactured and sold pursuant to a license from Farberware Inc.®
1/04 PRINTED IN CHINA P/N 61451

6
USER MAINTENANCE INSTRUCTIONS
This appliance requires little maintenance. It contains no user
serviceable parts. Do not try to repair it yourself. Any servicing
requiring disassembly other than cleaning must be performed by a
qualified appliance repair technician.
CAUTION: NEVER PLACE BASE OF APPLIANCE IN WATER OR
OTHER LIQUIDS.
1. Make sure the Grinder is unplugged before cleaning.
2. Remove all excess grounds from the Grinder Recovery Cup to
prevent stale coffee grounds from affecting the flavor of freshly
ground beans.
3. After each use, remove the
Grinder Recovery Cup. Using
the Cleaning Spatula (bent end
of the Measuring Spoon), clear
any debris from the Grinding
Chute. See Figure 4.
4. Wipe the Grinder Cup clean
with a soft, dry cloth.
NOTE: Do not use water when
cleaning the Grinder Cup.
5.The Grinder Recovery Cup may be rinsed in warm water and
dried with a cloth.
CAUTION: THE GRINDER CUP, GRINDER CUP LID, GRINDER
RECOVERY CUP AND RECOVERY CUP LID ARE NOT
DISHWASHER SAFE.
CARE AND CLEANING
1. Clean exterior of Base and all parts with a soft, damp cloth.
STORAGE
1. Store Grinder with both the Grinder Cup and Recovery Cup in
position on the Grinder Base and both of the Lids in place.
2. Turn upside down and wrap cord around cord storage on inside
of Base.
3. Store Grinder in its original box or in a clean, dry area.
Figure 4
1
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed including the following:
1. Read all instructions.
2. To protect against risk of electrical shock do not put cord, plugs,
or appliance in water or other liquid.
3. Close supervision is necessary when any appliance is used by
or near children.
4. Unplug from outlet when not in use, before putting on or taking
off parts, and before cleaning.
5. Avoid contacting moving parts.
6. Do not operate any appliance with a damaged cord or plug or
after the appliance malfunctions, or is dropped or damaged in
any manner. Contact Consumer Service for examination, repair
or electrical or mechanical adjustment.
7. The use of attachments not recommended or sold by the
manufacturer may cause fire, electric shock or injury.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter.
10. Do not let cord contact hot surface, including the stove.
11. Check Grinder Cup for presence of foreign objects before using.
SAVE THESE INSTRUCTIONS
THIS PRODUCT IS FOR HOUSEHOLD USE ONLY

5
OPERATING INSTRUCTIONS
1. Place the Coffee Grinder onto a flat, level work surface.
2. Insert the Grinder Cup into the Main Body of the Grinder.
See Figure 2.
3. See Figure 3. Place the Grinder Recovery Cup onto the Base (1)
and push towards the Main Body until the window of the
Recovery Cup aligns with the Grinder Chute (2). You will hear
a click as the Cup locks into position.
4. Place the Recovery Cup Lid onto the Cup so that the Lid cutout
faces the Recovery Cup Window.
5. Place the required amount of whole coffee beans into the
Grinder Cup. The amount will vary depending on the type of
coffee and your own taste, but we suggest 1 measuring spoon
of coffee beans per cup of coffee. The Grinder Cup will hold up
to a maximum of 2.1 oz. (60g) of whole coffee beans.
6. Place the Grinder Cup Lid onto the Grinder Cup.
7. Turn the Fineness Control Ring to adjust from a fine grind,
medium grind, or coarse grind.
8. Turn the Cups Control Knob to grind beans for 1 to 6 cups
of coffee.
9. Plug the Grinder into a 120V AC electrical outlet.
10. Press the On/Off Button to begin grinding. When the Grinder
has finished grinding, it will turn OFF automatically or you may
also press the On/Off Button to turn unit OFF. Remove ground
coffee from Grinder Recovery Cup.
NOTE: The maximum capacity of this Grinder is 2.1 oz. (60g).
Please do not exceed MAX marking on the Grinder Cup.
11. Remove plug from electrical outlet when not in use.
Figure 2 Figure 3
Recovery
Cup
Window
Grinder
Chute
2
ADDITIONAL IMPORTANT SAFEGUARDS
1. All users of this appliance must read and understand this
Owner’s Manual before operating or cleaning this appliance.
2. The cord to this appliance should be plugged into a 120V AC
electrical outlet only.
3. Do not leave this appliance unattended during use.
4. If this appliance begins to malfunction during use, immediately
turn the unit OFF and unplug the cord. Do not use or attempt to
repair the malfunctioning appliance.
5. If this appliance falls or accidentally becomes immersed in water,
unplug it immediately. Do not reach into the water!
Do not use this appliance after it has fallen into or becomes
immersed in water.
6. To reduce the risk of injury to persons or property, never use this
appliance in an unstable position.
7. Do not use this appliance for other than its intended use.
8. Make sure that the Grinder Cup is properly inserted into the
Main Body of the machine and the Grinder Cup Lid is in position
on top of the Cup. The Grinder Recovery Cup should be securely
assembled into position on the Base and the Recovery Cup Lid
should be placed on top of the Recovery Cup before use.
9. Only coffee beans should be placed into the Grinder Cup.
10. WARNING! To avoid serious injury, never place fingers or
objects through the Grinder Chute or through the Recovery Cup
Window where ground coffee beans are emptied into the
Recovery Cup.
POLARIZED PLUG
This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit
into a polarized outlet only one way. If the plug does not fit fully in
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to modify the plug in any way.
SHORT CORD INSTRUCTIONS
A short power-supply cord is provided to reduce the risk resulting
from becoming entangled in or tripping over a longer cord.
Do not use an extension cord with this product.
ELECTRIC POWER
If the electrical circuit is overloaded with other appliances, your
appliance may not operate properly. It should be operated on a
separate electrical circuit from other appliances.

BEFORE USING FOR THE FIRST TIME
CAUTION: To protect against electric shock, do not submerge the
Grinder or allow power cord to come into contact with water
or other liquids.
1. Remove all packaging and packing materials from the Grinder.
Remove any labels from the outer stainless steel surfaces.
2. Use a clean, dry cloth to wipe the Grinder Cup before first use.
Rinse the Grinder Recovery Cup in water. Dry thoroughly
before use.
HINTS FOR GRINDING COFFEE BEANS
GRINDING CHART
Fine Grind espresso machines
Medium filter coffee makers
Coarse percolators, cafetieres, etc.
1. Approximately 3 ⁄4 cup of coffee beans will yield ground coffee
for 10 to12 cups of brewed coffee.
2. Store coffee beans in an airtight container inside the freezer for
up to 2 months. Coffee beans can be ground while frozen.
4
NOTE: THIS UNIT SHOULD NOT BE USED FOR MORE THAN
3 MINUTES AT A TIME.
GETTING TO KNOW YOUR FARBERWARE®
COFFEE GRINDER
1.
2.
9.
4.
8.
10.
7.
6.
12.
5.
3.
11.
3
1. Grinder Cup Lid (P/N 71067)
2. Grinder Cup (P/N 71068)
3. Fineness Control Ring
4. On/Off Button
5. Cups Control Knob
6. Base
7. Measuring Spoon (P/N 71069)
8. Cleaning Spatula
9. Grinder Recovery Cup
(P/N 71070)
10. Recovery Cup Lid
(P/N 71071)
11. Cutout
12. Main Body
Figure 1
PRODUCT MAY VARY SLIGHTLY FROM ILLUSTRATIONS

BEFORE USING FOR THE FIRST TIME
CAUTION: To protect against electric shock, do not submerge the
Grinder or allow power cord to come into contact with water
or other liquids.
1. Remove all packaging and packing materials from the Grinder.
Remove any labels from the outer stainless steel surfaces.
2. Use a clean, dry cloth to wipe the Grinder Cup before first use.
Rinse the Grinder Recovery Cup in water. Dry thoroughly
before use.
HINTS FOR GRINDING COFFEE BEANS
GRINDING CHART
Fine Grind espresso machines
Medium filter coffee makers
Coarse percolators, cafetieres, etc.
1. Approximately 3 ⁄4 cup of coffee beans will yield ground coffee
for 10 to12 cups of brewed coffee.
2. Store coffee beans in an airtight container inside the freezer for
up to 2 months. Coffee beans can be ground while frozen.
4
NOTE: THIS UNIT SHOULD NOT BE USED FOR MORE THAN
3 MINUTES AT A TIME.
GETTING TO KNOW YOUR FARBERWARE®
COFFEE GRINDER
1.
2.
9.
4.
8.
10.
7.
6.
12.
5.
3.
11.
3
1. Grinder Cup Lid (P/N 71067)
2. Grinder Cup (P/N 71068)
3. Fineness Control Ring
4. On/Off Button
5. Cups Control Knob
6. Base
7. Measuring Spoon (P/N 71069)
8. Cleaning Spatula
9. Grinder Recovery Cup
(P/N 71070)
10. Recovery Cup Lid
(P/N 71071)
11. Cutout
12. Main Body
Figure 1
PRODUCT MAY VARY SLIGHTLY FROM ILLUSTRATIONS

5
OPERATING INSTRUCTIONS
1. Place the Coffee Grinder onto a flat, level work surface.
2. Insert the Grinder Cup into the Main Body of the Grinder.
See Figure 2.
3. See Figure 3. Place the Grinder Recovery Cup onto the Base (1)
and push towards the Main Body until the window of the
Recovery Cup aligns with the Grinder Chute (2). You will hear
a click as the Cup locks into position.
4. Place the Recovery Cup Lid onto the Cup so that the Lid cutout
faces the Recovery Cup Window.
5. Place the required amount of whole coffee beans into the
Grinder Cup. The amount will vary depending on the type of
coffee and your own taste, but we suggest 1 measuring spoon
of coffee beans per cup of coffee. The Grinder Cup will hold up
to a maximum of 2.1 oz. (60g) of whole coffee beans.
6. Place the Grinder Cup Lid onto the Grinder Cup.
7. Turn the Fineness Control Ring to adjust from a fine grind,
medium grind, or coarse grind.
8. Turn the Cups Control Knob to grind beans for 1 to 6 cups
of coffee.
9. Plug the Grinder into a 120V AC electrical outlet.
10. Press the On/Off Button to begin grinding. When the Grinder
has finished grinding, it will turn OFF automatically or you may
also press the On/Off Button to turn unit OFF. Remove ground
coffee from Grinder Recovery Cup.
NOTE: The maximum capacity of this Grinder is 2.1 oz. (60g).
Please do not exceed MAX marking on the Grinder Cup.
11. Remove plug from electrical outlet when not in use.
Figure 2 Figure 3
Recovery
Cup
Window
Grinder
Chute
2
ADDITIONAL IMPORTANT SAFEGUARDS
1. All users of this appliance must read and understand this
Owner’s Manual before operating or cleaning this appliance.
2. The cord to this appliance should be plugged into a 120V AC
electrical outlet only.
3. Do not leave this appliance unattended during use.
4. If this appliance begins to malfunction during use, immediately
turn the unit OFF and unplug the cord. Do not use or attempt to
repair the malfunctioning appliance.
5. If this appliance falls or accidentally becomes immersed in water,
unplug it immediately. Do not reach into the water!
Do not use this appliance after it has fallen into or becomes
immersed in water.
6. To reduce the risk of injury to persons or property, never use this
appliance in an unstable position.
7. Do not use this appliance for other than its intended use.
8. Make sure that the Grinder Cup is properly inserted into the
Main Body of the machine and the Grinder Cup Lid is in position
on top of the Cup. The Grinder Recovery Cup should be securely
assembled into position on the Base and the Recovery Cup Lid
should be placed on top of the Recovery Cup before use.
9. Only coffee beans should be placed into the Grinder Cup.
10. WARNING! To avoid serious injury, never place fingers or
objects through the Grinder Chute or through the Recovery Cup
Window where ground coffee beans are emptied into the
Recovery Cup.
POLARIZED PLUG
This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit
into a polarized outlet only one way. If the plug does not fit fully in
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to modify the plug in any way.
SHORT CORD INSTRUCTIONS
A short power-supply cord is provided to reduce the risk resulting
from becoming entangled in or tripping over a longer cord.
Do not use an extension cord with this product.
ELECTRIC POWER
If the electrical circuit is overloaded with other appliances, your
appliance may not operate properly. It should be operated on a
separate electrical circuit from other appliances.

6
USER MAINTENANCE INSTRUCTIONS
This appliance requires little maintenance. It contains no user
serviceable parts. Do not try to repair it yourself. Any servicing
requiring disassembly other than cleaning must be performed by a
qualified appliance repair technician.
CAUTION: NEVER PLACE BASE OF APPLIANCE IN WATER OR
OTHER LIQUIDS.
1. Make sure the Grinder is unplugged before cleaning.
2. Remove all excess grounds from the Grinder Recovery Cup to
prevent stale coffee grounds from affecting the flavor of freshly
ground beans.
3. After each use, remove the
Grinder Recovery Cup. Using
the Cleaning Spatula (bent end
of the Measuring Spoon), clear
any debris from the Grinding
Chute. See Figure 4.
4. Wipe the Grinder Cup clean
with a soft, dry cloth.
NOTE: Do not use water when
cleaning the Grinder Cup.
5.The Grinder Recovery Cup may be rinsed in warm water and
dried with a cloth.
CAUTION: THE GRINDER CUP, GRINDER CUP LID, GRINDER
RECOVERY CUP AND RECOVERY CUP LID ARE NOT
DISHWASHER SAFE.
CARE AND CLEANING
1. Clean exterior of Base and all parts with a soft, damp cloth.
STORAGE
1. Store Grinder with both the Grinder Cup and Recovery Cup in
position on the Grinder Base and both of the Lids in place.
2. Turn upside down and wrap cord around cord storage on inside
of Base.
3. Store Grinder in its original box or in a clean, dry area.
Figure 4
1
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed including the following:
1. Read all instructions.
2. To protect against risk of electrical shock do not put cord, plugs,
or appliance in water or other liquid.
3. Close supervision is necessary when any appliance is used by
or near children.
4. Unplug from outlet when not in use, before putting on or taking
off parts, and before cleaning.
5. Avoid contacting moving parts.
6. Do not operate any appliance with a damaged cord or plug or
after the appliance malfunctions, or is dropped or damaged in
any manner. Contact Consumer Service for examination, repair
or electrical or mechanical adjustment.
7. The use of attachments not recommended or sold by the
manufacturer may cause fire, electric shock or injury.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter.
10. Do not let cord contact hot surface, including the stove.
11. Check Grinder Cup for presence of foreign objects before using.
SAVE THESE INSTRUCTIONS
THIS PRODUCT IS FOR HOUSEHOLD USE ONLY

USE & CARE INSTRUCTIONS
COFFEE GRINDER
FAC500G
ACCENTS
ONE-YEAR LIMITED WARRANTY
Warranty: This Farberware® product is warranted by Salton, Inc. to be free from defects in materials or
workmanship for a period of (1) year from the original purchase date. This product warranty covers only the
original consumer purchaser of the product.
Warranty Coverage: This warranty is void if the product has been damaged by accident in shipment,
unreasonable use, misuse, neglect, improper service, commercial use, repairs by unauthorized personnel,
normal wear and tear, improper assembly, installation or maintenance abuse or other causes not arising out of
defects in materials or workmanship. This warranty is effective only if the product is purchased and operated
in the USA, and does not extend to any units which have been used in violation of written instructions
furnished with the product or to units which have been altered or modified or to damage to products or parts
thereof which have had the serial number removed, altered, defaced or rendered illegible.
Implied Warranties: ANY IMPLIED WARRANTIES WHICH THE PURCHASER MAY HAVE ARE LIMITED IN
DURATION TO ONE (1) YEAR FROM THE DATE OF PURCHASE. Some states do not allow limitations on how long
an implied warranty lasts, so the above limitation may not apply to you.
Warranty Performance: During the above one-year warranty period, a product with a defect will be either
repaired or replaced with a reconditioned comparable model (at our option) when the product is returned to
the Repair Center, or the purchase price refunded. The repaired or replacement product will be in warranty for
the balance of the one-year warranty period and an additional one-month period. No charge will be made for
such repair or replacement.
Service and Repair: Should the appliance malfunction, you should first call toll-free 1 [phone] between
the hours of 9:00 am and 5:00 pm Central Standard Time and ask for CONSUMER SERVICE stating that you are
a consumer with a problem. Please refer to model number FAC500G when you call.
In-Warranty Service (USA): For an appliance covered under the warranty period, no charge is made for
service or postage. Call for return authorization 1 [phone].
Out-of Warranty Service: A flat rate charge by model is made for out-of-warranty service. Include $8.00
(U.S.) for return shipping and handling. We will notify you by mail of the amount of the charge for service and
require you to pay in advance for the repair or replacement.
For Products Purchased in the USA, but Used in Canada: You may return the product insured, packaged
with sufficient protection, and postage and insurance prepaid to the USA address listed below. Please note
that all customs duty / brokerage fees, if any, must be paid by you and we will require you to pay the cost of
customs duty / brokerage fees to us in advance of our performing any service.
Risk During Shipment: We cannot assume responsibility for loss or damage during incoming shipment. For
your protection, carefully package the product for shipment and insure it with the carrier. Be sure to enclose
the following items with your appliance: any accessories related to your problem, your full return address and
daytime phone number, a note describing the problem you experienced, a copy of your sales receipt or other
proof of purchase to determine warranty status. C.O.D. shipments cannot be accepted.
To return the appliance, ship to: To contact us, please write to, call, or email:
ATTN: Repair Center Salton, Inc.
Salton, Inc. P.O. Box 7366
708 South Missouri Street Columbia, MO 65205-7366
Macon, MO 63552 1-888-881-8101
E-mail: [email protected]
Limitation of Remedies: No representative or person is authorized to assume for Salton, Inc. any other
liability in connection with the sale of our products. There shall be no claims for defects or failure of
performance or product failure under any theory of tort, contract or commercial law including, but not limited
to negligence, gross negligence, strict liability, breach of warranty and breach of contract. Repair,
replacement or refund shall be the sole remedy of the purchaser under this warranty, and in no event shall
Salton be liable for any incidental or consequential damages, losses or expenses. Some states do not
allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion
may not apply to you.
Legal Rights: This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.
For more information on Salton products, visit our website: www.eSalton.com
©2004 Salton, Inc. All rights reserved.
FARBERWARE® is a registered trademark of Farberware Inc.®
Manufactured and sold pursuant to a license from Farberware Inc.®
1/04 PRINTED IN CHINA P/N 61451
