FASANO TOOLS FGA 334/AN Operator's manual

9
FGA 334/AN
SAFETY MANUAL AND
INSTRUCTION MANUAL
AIR GRINDER
Rev.112017
The reproduction of this document (even in partial form) is prohibited without the Fasangas S.r.l. authorization

10
1 GENERAL WARNINGS
2 TECHNICAL FEATURES OF THE TOOL
3 IMPORTANT SAFETY INSTRUCTION
4 FUNCTIONAL INSTRUCTIONS
5 MAINTENANCE
6 TROUBLESHOOT
7 DISPOSAL INFORMATIONS
8 EC DECLARATION OF CONFORMITY
9 WARRANTY
INDEX

11
Before to use the tool, please read carefully the instruction contained in this manual.
Improper or unsafe use of this tool can result in death or serious bodily injury.
This manual of instructions constitutes an integral part of product and it has to be edited
by the end user for every
possible future consultation. It contains important informations about the safety use of the product.
USE DESTINATION.
This tool and its accessories, must only be used for the purpose for which they have been conceived. A dif
ferent
wrong and unreasonable uses, as, for example, the un-
observance of the safety instruction, the use of no original
accessories and operation not authorized on the product.
MODEL: FGA 334/AN
TYPE: AIR DIE GRINDER
WEIGHT: 0.50 kg (1.1 lb)
LENGHT: 160 mm
COMPRESSED AIR:
Max working pressure: 6.2 BAR (90 PSI)
Raccommanded pressure: 6.2 BAR (90 PSI)
Air consumption at 90 PSI: 2.6 CFM (74 L/min)
Free speed: 20000 rpm
Min hose size:
NOISE VALUES (EN ISO 15744:2008):
A-weighted sound pressure level at workstation: 77 dB (A)
A-weighted sound power level: 80 dB (A)
Peak C-weighted instantaneous sound pressure level at workstation:
< 88 dB
Measurement uncertainty: 3 dB
VIBRATION VALUES
Vibration value according to EN ISO 28927-12:2009: 0.8 m/s2
Measurement uncertainty (Standard): 0.1 m/s2
1. GENERAL WARNINGS
2. TECHNICAL FEATURES

12
When using this air tool, the following basic safety precautions should always be followed to reduce the risk of personal
injury:
Always wear safety glasses with side shields (DP I- Dir. 89/686/EEC)
Air powered equipment
are capable of propelling materials such as metal chips, saw dust
and other debris at high speed, which could result in serious eye injury.
Tool attachments
can become loose or break and fly apart propelling particles at the operator.
Compressed
air can be hazardous. The air stream can cause injury to soft tissue arrears such as eyes,
Always wear hearing protection (DPI - Dir.89/686/EEC)
Long
term exposure to noise produced from the operation of air tools can lead to
permanent hearing loss.
ALWAYS WEAR PROTECTIVE GLOVES DURING USE (DPI - Dir.89/686/EEC)
Always protect the respiratory system when
using the tool by using protective
equipment (mask) in accordance with current standards (DPI - Dir.89/686/EEC)
Abrasive tools, such as grinders and sanders generate dust and abrasive materials, which
can be harmful to human lungs and respiratory systems.
Some materials such as adhesives and tar
, contain chemicals whose vapors could cause
serious injury with prolonged exposure.
Avoid prolonged and continuous use of the tool.
Prolonged exposure to tool vibrations can cause severe neurological and circula
tory
disorders.
Never exceed the maximum pressure rating of the tool. The maximum pressure rating
of the tool is reported in the technical specifications (Paragraph 2 of this user manual)
and on the same tool.
Exceeding the MAX. pressure
rating of tool could cause an explosion resulting in serious
injury.
- Never operate tools near flammable substance such as gasolin
e, naphtha, cleaning
solvents, etc.
- Work in a clean, well ventilated area free of combustible materials.
- Never use oxygen, carbon dioxide or other bottled gases as a power source for air tool
3.
IMPORTANT SAFETY INSTRUCTIONS

13
ATTENTION:
- Never carry the tool by the hose.
Always hold the tool only from the the ergonomic
handle it is endowed.
- Never wear loose fitting clothes, or apparel, which contains loose straps or ties, etc.
which could become entangled in moving parts of the tool. Remove any jewelry,
watches, identifications, bracelets, necklaces, etc. which might become caught by the
tool.
- Remove air hose when tool is not in use and store tool in secure location away
in
particular from reach of children.
-
Before removing the compressed air supply hose from the tool, make sure to have
previously closed the tap supply compressed air coming from the supply.
- Remove air hose to lubricate or add attachments and accessories to the tool.
- Never operate tool while under the influence of drugs or alcohol.
-
- Keep handles dry, clean and free from oil and grease.
- Do not use accessories designed for use without a manual as locking systems.
- Make sure that any attachments are securely assembled before to use the tool.
- Do not remove the labels placed on the tool.
Before each use:
ATTENTION
Before proceeding with the operation of lubrication, detachment/attachment,
adjustment or installation of accessories, disconnect the air supply hose from the tool,
having first taken care to close the tap of compressed air supply.
a)
operation manual.
b)
c) Install the accessories verifying its integrity and that they are securely housed.
ATTENTION
Always use clean, dry air at 90 PSI (6.2 bars) maximum air pressure. Dust, corrosive
fumes and/or excessive moisture can ruin the internal components of a pneumatic tool.
4. FUNCTIONAL INSTRUCTIONS

14
a) Connect tool to air hose of recommended size (see the Technical specifications paragraph of this
user manual)
IMPORTANTE:
Use:
1. Turn air compressor on and allow air tank to fill.
2.
3. Connect tool to air hose of recommended size (see the Technical specifications
paragraph of this user manual)
4. Press the lever placed on the tool handle to operate tool.
5. Release the same lever to stop the tool.
When job is complete, turn the air compressor off and store as described in the air compressor
operator manual.
ATTENTION
- With this tool, use only accessories reccomanded from the producer.
- Do not use hand accessories because they are not endowed of appropriate locking
systems.
- Before assembly the accessories on the tool, always check the integrity of their
locking systems.
ATTENTION
- DO NOT start to work with the tool if it seems damaged..
- Before assembly the accessories on the tool, always check the integrity of their
locking systems .
ATTENTION
Do not use damaged, frayed or deteriorated air hoses and fitting.

15
LUBRIFICATION
Air tools require regular lubrication throughout the life of the tool. The air motor and bearing use
compressed air to power the tool. Because moisture in compressed air will rust the air motor, you
must lubricate the motor daily. An inline oiler is recommended.
To lubricate the air motor manually:
Disconnect the tool from the air supply holding it so the air inlet faces up.
Depress the trigger and place one to two drops of air tool oil in the air inlet.
Connect the tool to an air source, cover the exhaust end with a towel and run for a few seconds.
Every 3 or 4 hours of operation, oiling is necessary.
Do not lubricate tools with flammable or volatile liquids such as kerosene, diesel or jet fuel.
ATTENTION
ALWAYS DISCONNECT AIR SUPPLY BEFORE LUBRICATING,
INSTALLING, REMOVING OR ADJUSTING THE TOOL
ATTENTION
Any excess oil in the motor is
immediately expelled from the exhaust port. Always direct
exhaust port away from people or objects.
5. MAINTENANCE

16
If the tool does not start:
- Make sure that in the compressed air circuit there is really pressure;
- Check that all the valves are opened;
- Check all the connections of the air supply;
- Check if the safety valves are actived;
- If the problem persists, the tool need to be repaired from qualified personell.
When the tool is not usable and not repairable, dispose it according to regulations of the place in
order to safeguard the environment.
This product complies with the dispositions of the following European Directives and Harmonized
Standards:
2006/42/EC
Machinery Directive
EN ISO 12100 :2010
EN ISO 11148-9:2012
EN ISO 15744 :2008
EN ISO 28927-12 :2012
This instrument is warranted to be free from defects in materials and workmanship (for a normal
use of service) for a period of one year. Any instrument found detective within one year from the
delivery date and returned to the factory with transportation charges prepaid, will be repaired,
adjusted, or replaced at no c
items such as batteries or fuses. If the defect has been caused by a misuse or abnormal operating
conditions, the repair will be billed to the customer at a nominal cost.
ATTENTION
ALWAYS DISCONNECT AIR SUPPLY BEFORE PERFORMING ANY WORK ON
THE TOOL
6. TROUBLESHOOTING
7. DISPOSAL INFORMATIONS
8. EC DECLARATION OF CONFORMITY
9. WARRANTY
