Operating manual
Infrared control
Series FCU2000/3000/4000-IR
Doc-ID: B_FCUxxxx-IR
Version: V 1.07
certificated

2 Operating manual Series FCU2000/3000/4000-IR B_FCUxxxx-IR / Version V 1.07
FASEL GmbH
Germany

Table of Contents
B_FCUxxxx-IR / Version V 1.07 Operating manual Series FCU2000/3000/4000-IR 3
Table of Contents
1 Safety................................................................................................................................5
1.1 Explanations of symbols ....................................................................................5
1.2 Demands on the operator and technicians........................................................5
1.3 Intended use ......................................................................................................6
1.4 Changes and modifications ...............................................................................6
1.5 Operational safety and special dangers ............................................................7
Information on the operating and installation manual ..................................................8
2 Identification ....................................................................................................................9
2.1 Nameplate..........................................................................................................9
3 Technical Data:................................................................................................................9
4 Design and function......................................................................................................10
4.1 Function ...........................................................................................................10
4.1.1 Infrared ..................................................................................................10
4.2 Operating and display elements ......................................................................11
4.2.1 FCU2000/3000/4000-IR-Design............................................................11
4.2.2 Control keys infrared control .................................................................12
4.3 Display symbols ...............................................................................................14
5 Operation .......................................................................................................................15
5.1 Safety and instructions ....................................................................................15
5.2 Turn Infrared control on and off .......................................................................16
5.2.1 Turn on Infrared control .........................................................................16
5.2.2 Turn off Infrared control.........................................................................16
6 “General settings” menu..............................................................................................17
6.1.1 Select or start the mode ........................................................................17
6.2 Adjust "Infrared" mode.....................................................................................17
6.3 Adjust the set point temperature, heating time, remaining heating time, timer
.........................................................................................................................18
6.3.1 Set temperature.....................................................................................18
6.3.2 Adjust heating time................................................................................19
6.3.3 Adjust timer............................................................................................19
6.3.4 Maximum allowed heating time .............................................................19
6.4 Menu for Options .............................................................................................20
6.4.1 RGB-LED brightness (only for FCU4xxx and menu "Pro") ...................20
6.4.2 Colour light mode (including parameter description).............................20
6.4.3 Colour light start (only for menu "Pro")..................................................23
7 „Basic settings“ menu..................................................................................................25
7.1 General basic settings .....................................................................................25
7.1.1 Time and Weekday................................................................................25
7.1.2 Select program (only for FCU4xxx) .......................................................26
7.1.3 Adjust display lighting (not for FCU2xxx) ..............................................26

4 Operating manual Series FCU2000/3000/4000-IR B_FCUxxxx-IR / Version V 1.07
7.1.4 Adjust display contrast (only for FCU4xxx)........................................... 27
7.1.5 Light settings (only for menu "Pro") ...................................................... 27
7.2 „Basic settings“ for Options............................................................................. 29
7.2.1 Colour light automatic ........................................................................... 29
7.2.2 RGB-LED settings (only for FCU4xxx and menu "Pro")....................... 29
7.2.3 Colour light automatic (only for menu "Pro") ........................................ 31
7.3 Versions and data (only in menu mode "Professional").................................. 32
8 Options menu ............................................................................................................... 34
8.1 Small/professional........................................................................................... 34
8.2 Parental/Keypad lock ...................................................................................... 34
8.3 Select language .............................................................................................. 34
9 Maintenance.................................................................................................................. 35
9.1 Cleaning .......................................................................................................... 35
10 Malfunctions ................................................................................................................. 35
10.1 Safety35
10.2 Malfunction messages .................................................................................... 36
10.3 Acknowledge malfunction message................................................................ 37
11 Decommissioning and disposal ................................................................................. 37
12 General Information ..................................................................................................... 38
12.1 Liability limitation............................................................................................. 38
12.2 Copyright......................................................................................................... 38
12.3 Scope of delivery............................................................................................. 38
12.4 Spare parts...................................................................................................... 39
12.5 Customer service ............................................................................................ 39
13 Setting values ............................................................................................................... 40
13.1 Range of Adjustment Infrared ........................................................................ 40
14 Declaration of Conformity ........................................................................................... 40
Index ...................................................................................................................................... 41

Safety
B_FCUxxxx-IR / Version V 1.07 Operating manual Series FCU2000/3000/4000-IR 5
1 Safety
1.1 Explanations of symbols
Warnings Warnings in this operating manual are indicated through symbols. The instructions are
introduced through signal words, which express the degree of danger.
Follow these instructions strictly and take care to avoid accidents, personal injuries and
property damage.
DANGER!
…indicates an imminent dangerous situation, which could lead to loss
of life or cause serious injuries if not avoided.
WARNING!
…indicates a possible dangerous situation, which can be fatal or cause
serious injuries if not avoided.
CAUTION!
…indicates a possible dangerous situation, which could lead to small or
slight injuries if not avoided.
ATTENTION!
…indicates a possible dangerous situation, which could lead to property
damage if not avoided.
Tips and
recommen-
dations
NOTE!
…highlights useful tips and recommendations as well as information for
an efficient and smooth operation.
1.2 Demands on the operator and technicians
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved. Children shall not play with the appli-

Safety
6 Operating manual Series FCU2000/3000/4000-IR B_FCUxxxx-IR / Version V 1.07
ance. Cleaning and user maintenance shall not be made by children without supervi-
sion.
The operating instructions are to be read carefully before switching on the unit! To en-
sure safe operation and safe working practices you must comply with all the given
safety and handling instructions.
If you have any doubts, please contact your customer service.
Inadequate qua-
lifications
WARNING!
Danger caused by inadequate qualifications!
Improper handling could lead to considerable personal injuries and
damages to property.
Therefore:
The assembly, installation, commissioning, troubleshooting, mainte-
nance and repair work should be carried out only by qualified persons
unless otherwise mentioned.
1.3 Intended use
The FASEL Infrared controls of the series FCU2000/3000/4000-IR are solely intended
for operating and controlling infrared cabins. The control units are approved for private
and commercial use.
Intended
use
CAUTION!
Danger caused by improper use!
Using the Infrared control for purposes other than the intended use
could lead to dangerous situations.
Therefore:
– Use the Infrared control only for the intended purpose.
– Operate the Infrared control only within the permissible ambient
temperature and humidity range. →See page 9.
– All the information in the operating and installation manual are to be
strictly followed.
– When the Infrared control is not in use, then switch off the main
switch (230V) or the fuses.
– Before switching on the Infrared control, make sure that nothing is on
the infrared heater.
Any damage claims which arise due to improper use are excluded. Only the user is
responsible for damages caused by improper use.
1.4 Changes and modifications
Changes and modifications to the control unit or to the installation could lead to
unpredictable dangers.
The written approval of the manufacturer must be obtained before making any technical
changes and enhancements to the Infrared control.

Safety
B_FCUxxxx-IR / Version V 1.07 Operating manual Series FCU2000/3000/4000-IR 7
1.5 Operational safety and special dangers
Pay attention to the safety and warning notes in the following chapters of this manual to
minimize health hazards and to avoid dangerous situations.
The following instructions are to be adhered to for your own safety and the safety
of the unit:
Electric poten-
tial
DANGER!
Danger to life due to electric potential!
Contact with live components can be fatal.
Damage of the insulation of the individual components can be dange-
rous to life.
Therefore:
– For switching off the mains, the power supply cable must be
equipped with a fuse with a contact opening width corresponding to
the requirements of the excess voltage category III for total discon-
nection.
– Disconnect the unit from the mains before carrying out any work on
it (switch off the fuse in the distribution box) and secure against re-
starting. Check for zero potential. The control device should be dis-
connected from the mains before opening the casing.
– In case of damage to the insulation, switch off the power supply im-
mediately and carry out the repair.
– Work on electrical unit should be carried out by certified electricians
only.
– Never bypass fuses or switch them off.
– While replacing fuses, pay attention to correct current specifications.
– Keep moisture away from live components, since it can lead to short
circuit.
WARNING!
If a short circuit occurs in a 230V/400V load, the relay contact can
be welded by the high short-circuit current. Is turned on before
removing the short circuit, the safety relay can be also welded.
This can lead to the continuous operation of the load. Turn off the
circuit breaker in the junction box. Send the unit back to the fac-
tory for check/repair.
Improper
operation
WARNING!
Improper operation can result in serious injuries!
Therefore:
– read and note the operating manual.

Safety
8 Operating manual Series FCU2000/3000/4000-IR B_FCUxxxx-IR / Version V 1.07
Information on the operating and installation manual
An operating manual as well as an installation manual are available for the FASEL con-
trol unit.
The operating manual is meant for the user and gives important instructions for handling
the FASEL control unit.
The installation manual describes the assembly, installation, commissioning, rectifica-
tion of defects and repair and is provided exclusively for the technical personnel.
To ensure safe operation and working practices, all the prescribed safety instructions
and guidelines have to be followed.
Furthermore, the local accident prevention regulations and general safety regulations
applicable for the fields of use of the control unit are to be adhered to.
The operating manual must be read carefully before switching on the device. The oper-
ating manual as well as the installation manual are an integral part of the product and
must be kept in the immediate vicinity of the control unit so that they are always acces-
sible.
The number of available connections and functions depends on the version of the de-
vice. The keys and the display text can be customized depending on the particular
model and can differ from the figures shown.
If you pass on the control unit to a third party, make sure you hand over also the operat-
ing and installation manual.
Components from other suppliers have their own operating manuals, safety regulations
and guidelines, which must be followed as well.

Identification
B_FCUxxxx-IR / Version V 1.07 Operating manual Series FCU2000/3000/4000-IR 9
2 Identification
2.1 Nameplate
The nameplate is located on the control unit on the left side:
2
1
8
5
3
4
7
6
Art Nr
Spg.:
Geräte Nr.: RoHS
conform
9
10 11
12
Fig.1 Control unit nameplate
1 Type designation
2 Company logo
3 Article number
4 Voltage and max. power
5 Device number
6 Barcode
7 article number
8 Barcode article number
9 VDE mark (for devices that are approved by VDE)
10 RoHS marking
11 CE mark
12 Protection category
3 Technical Data:
Label Type
Series FCU2000 Series FCU3000 Series FCU4000
Ambient temperature 0 to +40 °C
Rel. humidity max. 80 % r.H., non condensing
Table 1: Technical Data

Design and function
10 Operating manual Series FCU2000/3000/4000-IR B_FCUxxxx-IR / Version V 1.07
4 Design and function
4.1 Function
Die the control unit is suitable for the following mode:
Infrared
4.1.1 Infrared
In the "Infrared" mode, an infrared heater (infrared lamp or heating surfaces) produces
an IR-radiation. This heats the air in the cabin.
As long as the infrared heater heats up, the status LED shows "IR" and the display
shows heat-up phase. Once 2/3 of the desired temperature is reached, this message
disappears. The cabin is ready for use.

Design and function
B_FCUxxxx-IR / Version V 1.07 Operating manual Series FCU2000/3000/4000-IR 11
4.2 Operating and display elements
4.2.1 FCU2000/3000/4000-IR-Design
2 "IR-heater" symbol
6 "IR" key
8 Control unit ON (only design)
9 Control unit OFF (only design)
11 "Set temperature" symbol
12 "Set heating time / remaining heating time "
13 "Timer" symbol
14 Display
15 key "light"
16 key " fan"
17 key "basic settings""
18 Navigation keys
19 Cleaning light OFF
20 Cleaning light ON

Design and function
12 Operating manual Series FCU2000/3000/4000-IR B_FCUxxxx-IR / Version V 1.07
4.2.2 Control keys infrared control
The Infrared control is equipped with the following control keys:
Key Description
"Infrared mode" key
Depending on the status of the green lamp, the "Infrared mode" key has different func-
tions.
Status lamp next to the key Meaning
Does not light up Mode is not selected.
The lamp flashes after pressing the "Infrared mode"
key.
Flashes Mode can be adjusted.
Control unit can be turned off using the "Control unit
OFF" switch.
The lamp lights up after pressing the " Infrared
mode" key.
Lights up "Infrared" mode is turned on.
The lamp flashes after pressing the "Infrared mode"
key.
“Cabin light”-key
Switch ON and OFF the cabin light. By pressing the key, the light can be switched on
or off. Automatically the menu for setting brightness is shown.
If the special function Light “LIS” is active, the light output is active only as long as the
key “light” is pushed. With this function, external dimmers can be controlled. The
internal dimmer is out of action.
„Fan“-key
Switch ON and OFF the fan. By pressing the key, the fan can be switched on or off.
Automatically the menu for setting the speed is shown.
"Basics menu settings" key
Call "Basic settings menu".
Navigate upwards within the menu.
Scroll one line upwards on the display
Increase the value by one.
Select option
Navigate downwards within the menu.
Scroll one line downwards on the display
Reduce the value by one.
Select option.

Design and function
B_FCUxxxx-IR / Version V 1.07 Operating manual Series FCU2000/3000/4000-IR 13
Key Description
Change mode ON: (the green lamp next to navigation keys lights up): Move cursor
to the left.
Change mode OFF: (the green lamp next to navigation keys does not light up): Go
back to the parent menu.
Change mode ON: (the green lamp next to navigation keys lights up): Move cursor
to the right.
Change mode OFF: (the green lamp next to navigation keys does not light up):
Call sub-menu.
Call sub-menu.
Turn on change mode. Point flashes.
Accept value.
Keys "Cleaning light OFF" and "Cleaning light ON"
(not for FCU-4x00-Design-Glas)
Use these keys to turn the cleaning light on and off. The control unit need not be
turned on.
Keys "Control unit mains OFF" and "Control unit mains ON"
Turn the control unit mains on and off.
Key “Standby Control Unit”
(only for FCU-4x00-Design-Glas)
Turn On / Off the standby of control unit
For avoiding an uncontrolled switching ON and OFF while cleaning the keyboard,
the control unit switches off automatically after 2 minutes. In this mode, only the
LED of the standby-key lights. For restarting or for starting a mode please press the
corresponding key of 0,5 – 1 second. (from software-version 3 upwards)
Table: 2 Control keys Sauna control

Design and function
14 Operating manual Series FCU2000/3000/4000-IR B_FCUxxxx-IR / Version V 1.07
4.3 Display symbols
The following symbols can appear in the display:
Display elements Description

Selection checkmark

0 / 1

Enter
Table: 3 Display symbols FCU2/3000-IR
Display elements Description

Temperature

Heating time

Remaining heating time

Time

Colour light

Light

Weekly timer

Display lighting

Display contrast

Start time
Table: 4 Display symbols FCU4000-IR

Operation
B_FCUxxxx-IR / Version V 1.07 Operating manual Series FCU2000/3000/4000-IR 15
5 Operation
5.1 Safety and instructions
Electric
potential
DANGER!
Danger to life due to electric potential!
Touching live parts can cause immediate danger to life.
Therefore:
– Control unit should be opened only by authorised electricians.
– Electrical work on the machine should be carried out only by qualified
electricians.
Improper
operation
WARNING!
Improper operation can result in serious injuries!
Therefore:
– Carry out all the operating steps according to this operating manual.
Danger of fire
WARNING!
Danger of injury caused by fire!
Objects on the heater or in the vicinity of the heater can cause a fire
and thus result in injuries.
Therefore:
– Always keep the heater and the area around the heater free of ob-
jects.
Health
hazard
WARNING!
Danger of injury caused by covering the temperature sensor and /
or the humidistat!
Covering the temperature sensor and / or the humidistat could lead to
increased temperatures and humidity. These increased levels could
lead to health hazards or serious injuries.
Therefore:
– Do not cover the temperature sensor and humidistat.
– Ensure free circulation of air.

Operation
16 Operating manual Series FCU2000/3000/4000-IR B_FCUxxxx-IR / Version V 1.07
NOTE!
The temperature values displayed on the control unit may vary from that
displayed on the thermometers mounted additionally in the cabin. This
may be because of the following reasons:
Depending on the cabin, temperatures differences of up to 40K can oc-
cur from the floor to ceiling.
Analogue instruments are slower to react than the electronic measure-
ment and display system used in the control unit.
5.2 Turn Infrared control on and off
5.2.1 Turn on Infrared control
Ensure that the heater, the surroundings and the sensors are free of objects.
1. Turn on the Infrared control using the "Control unit ON" key. →See page 11.
2. The set point temperature and the heating time are displayed. The green lamp
flashes.
5.2.2 Turn off Infrared control
PLEASE NOTE!
The electronic components can be damaged by repeated improper
turning off!
Therefore:
– Turn off the Infrared control as described.
A mode is selected. The corresponding green lamp lights up.
1. Press the key of the selected mode. The green lamp next to the key flashes.
2. The green lamp of the selected mode flashes. Turn off the Infrared control using
the "Control unit OFF" key. →See page 11

“General settings” menu
B_FCUxxxx-IR / Version V 1.07 Operating manual Series FCU2000/3000/4000-IR 17
6 “General settings” menu
6.1.1 Select or start the mode
Mode
select or start
1. Turn on Infrared control according to chapter 5.2.1.
2. The green lamp flashes.
3. Press the key for Infrared mode. The desired mode has been started only when the
green lamp stops flashing.
Key Description
Infrared mode
Table 5: Mode control keys
6.2 Adjust "Infrared" mode
NOTE!
There are two menu navigations available for the control unit. All the
menus are displayed only in the "Professional" menu. These menus are
indicated accordingly in this chapter. If these menus are not displayed,
your control has been set to the "Small" menu
Furthermore, the control unit can be equipped with extension boards
like for e.g. for aroma feeding. This requires additional menus, which
are indicated accordingly in this chapter. For information about the fit-
tings of your control unit, please contact the installer or the dealer of
your infrared system.
The control unit is turned on.
1. Press the key (infrared mode). The lamp next to the key must flash or light up.
2. The symbol (adjust the temperature) lights up. →See Page 17, chapter 6.3
3. Press the botton.
4. The symbol (adjust heating /  remaining heating time) lights up.
5. Depending on the status of the lamp next to the mode key, adjust the heating time
or the remaining heating time. →See page 17, chapter 6.3
6. Press the key.
7. Optional: "Adjust colour light mode" view is displayed.
8. Press the key.
9. Press the key. The "Infrared" view is displayed again.
NOTE!
If the key is not operated for a few seconds, the program automatically
switches back to the "main" view. (If the controller has a timer and it is
active, he switches into the timer menu.)

“General settings” menu
18 Operating manual Series FCU2000/3000/4000-IR B_FCUxxxx-IR / Version V 1.07
6.3 Adjust the set point temperature, heating time, remaining heating time,
timer
The following example describes how to adjust the set point temperature.
The heating time, the remaining heating time and the timer are adjusted similarly.
Note the following points:
If you want to adjust the set point temperature, set point humidity, heating time, re-
maining heating time or the timer, the corresponding symbol must light up at the
right of the display. That is, the symbol "Temperature" should light up if you want to
adjust the temperature.
The heating time and the remaining heating time use the same symbol. The value
which you adjust depends on the status of the lamp next to the mode key.
Heating time Remaining heating time
The heating time is the operating time for
the selected mode..
The remaining heating time is the re-
maining time when the mode is turned
on. The remaining heating time is re-
duced automatically.
The heating time can be adjusted if the
lamp next to the mode key flashes.
The remaining heating time can be ad-
justed if the lamp next to the mode key
lights up.
The modified remaining heating time
does not change the programmed heat-
ing time.
Table 6: Heating time / remaining heating time
Timer can be released or blocked. The models FCU2x00 and FCU3x00 have no
timer.
6.3.1 Set temperature
6.3.1.1 Set temperature of IR-heater
1. Press -key until the symbol (IR-heater) lights.
2. The following view is shown:












fig. 2: View "Infrared" (example)

“General settings” menu
B_FCUxxxx-IR / Version V 1.07 Operating manual Series FCU2000/3000/4000-IR 19
3. Press -key. The last digit flashes.
4. Select desired value:
Press -key to reduce value.
Press -key to increase value.
Note!
After the digit „9“ or „0“ the higher digit of the temperature value is changed. That is:
“40” is displayed after “39”.
You can also select the higher digit using the -key or -key and change then.
5. Press -key to confirm value
6.3.2 Adjust heating time
1. Press the -key until the symbol (adjust heating time) lights up.
2. Press the -key
3. Adjust the desired value (see above)
4. Press the -key to accept value
5. Key “mode” flashes
6.3.3 Adjust timer
1. Press the -key until the symbol (adjust timer) lights up.
2. Adjust desired time (see above)
3. Press the -key to adjust the value.
4. Press the mode-key (flashes)
5. Symbol flashes.
6. For turning off the timer, please turn off the control unit or press mode-key once for
starting and once again for stopping.
6.3.4 Maximum allowed heating time
After starting a mode, the remaining heating time is displayed in place of the full heating
time. The heating time can be changed only in standby mode.
The EN 60335-2-53 "Specific requirements for sauna heating devices" allows the follo-
wing maximum heating times:
Max. heating time Description
more than 12 hours Public cabins which are supervised by trained
personnel.
max. 12 hours Hotels, apartment blocks, etc.
max. 6 hours All other cabins / private households
Table: 7 Maximum heating time

“General settings” menu
20 Operating manual Series FCU2000/3000/4000-IR B_FCUxxxx-IR / Version V 1.07
The control devices are delivered with a maximum adjustable heating time of 6 hours. If
you need heating times exceeding 6 hours, please contact the installer or the dealer of
your sauna system.
6.4 Menu for Options
6.4.1 RGB-LED brightness (only for FCU4xxx and menu "Pro")
NOTE!
The "RGB-LED brightness" menu is only available for control devices
which are connected to a RGB-LED control from the company
Licht2000.
In this menu you can set the brightness of the RGB-LEDs.
1. -Press the key until you see the following view:








Not available with FCU2000 and
FCU3000!
Fig. 3: View "RGB-LED brightness"
2. Press key.
3. Select RGB-LED brightness. Digit flashes.
Press the key: Increase value.
Press the key: Reduce value.
There are 4 brightness levels possible.
4. Press the key. The selection is saved.
6.4.2 Colour light mode (including parameter description)
NOTE!
The "Colour light mode" menu is only available for control devices with
the extension board type FCU-EXT-COLOR LIGHT or a RGB-LED con-
trol from the company Licht2000.
In this menu, you can adjust the coloured lights. The following table shows the parame-
ters and their explanations.
