Fast Mover FMT121027 Installation and operation manual

FMT121027
Bumper Trestle with Extension Arms
roduct Information Guide
T: 01582 661993 F: 01582 667100 E: [email protected]
www.fastmovertoolsuk.com
FMT121027_in t 26/03/2014 10:51 Page 1

Ref. Code Description Q’ty
1 FMT121027/1 Base Oblique 2
2 FMT121027/2 Screw 1
3 FMT121027/3 Washer 15
4 FMT121027/4 Lock Nut 3
5 FMT121027/5 Nut 4
6 FMT121027/6 Eye Bolt & Chain 1
7 FMT121027/7 Hook Bolt 1
8 FMT121027/8 T-tube 2
9 FMT121027/9 Swivel late 2
10 FMT121027/10 Knob 4
11 FMT121027/11 Screw 2
12 FMT121027/12 Extension Arm 2
FMT121027
Bumper Tres le wi h Ex ension Arms
Bumper stand that comes with very useful extension arms that allow bumpers to be held in shape whilst in the oven.
Par s Lis and Assembly Diagram
General Safe y Informa ion
1 This tool is not to be use for any other purpose than that described above.
2 Not for use by unauthorised persons and minors.
3 Not to be used as a climbing frame or anchor point.
4 Tie back long hair and avoid wearing loose clothing when using this tool.
5 Wear appropriate E at all times when using this tool.
6 Use on a stable, level and dry surface.
7 Keep your work area clean and tidy at all times.
8 Do not put more that one bumper on this stand at any time.
9 Do not carry out any work in such a way that will compromise the integrity of the stand or the safety
of yourself, colleagues or visitors, or that will cause damage to property.
www.fa tmovertool uk.com
