Fayat BOMAG BPR 50/55 D User manual

BPR 50/55 D
Reversible vibratory plate
Operating Instruction
Maintenance Instruction
Original Operating Instructions
S/N 101 695 29 1001>
© 07/2019008 204 51 EN
www.discount-equipment.com
Go to Discount-Equipment.com to order your parts

Discount-Equipment.com is your online resource for quality parts & equipment.
Florida: 561-964-4949 Outside Florida TOLL FREE: 877-690-3101
Need parts?
Click on this link: http://www.discount-equipment.com/category/5443-parts/ and
choose one of the options to help get the right parts and equipment you are looking
for. Please have the machine model and serial number available in order to help us
get you the correct parts. If you don’t find the part on the website or on one of the
online manuals, please fill out the request form and one of our experienced staff
members will get back to you with a quote for the right part that your machine needs.
We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman,
Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto,
Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack,
Lull, Skytrak, Tsurumi, Husquvarna Target, Stow, Wacker, Sakai, Mi-T-M, Sullair, Basic,
Dynapac, MBW, Weber, Bartell, Bennar Newman, Haulotte, Ditch Runner, Menegotti,
Morrison, Contec, Buddy, Crown, Edco, Wyco, Bomag, Laymor, EZ Trench, Bil-Jax, F.S.
Curtis, Gehl Pavers, Heli, Honda, ICS/PowerGrit, IHI, Partner, Imer, Clipper, MMD, Koshin,
Rice, CH&E, General Equipment ,Amida, Coleman, NAC, Gradall, Square Shooter, Kent,
Stanley, Tamco, Toku, Hatz, Kohler, Robin, Wisconsin, Northrock, Oztec, Toker TK, Rol-Air,
APT, Wylie, Ingersoll Rand / Doosan, Innovatech, Con X, Ammann, Mecalac, Makinex, Smith
Surface Prep,Small Line, Wanco, Yanmar

terminals, tank trucks and other facilities and equipment.
plants, transport and storage operations such as pipelines, marine
For more information go to www.P65Warnings.ca.gov/petroleum.
These exposures can occur in and around oil fields, refineries, chemical
WARNING: Crude oil, gasoline, diesel fuel and other petroleum
products can expose you to chemicals including toluene and benzene,
which are known to the State of California to cause cancer and birth
defects or other reproductive harm.
WARNING: Breathing diesel engine exhaust exposes you to chemicals
known to the State of California to cause cancer and birth defects or other
reproductive harm.
Always start and operate the engine in a well-ventilated area.
If in an enclosed area, vent the exhaust to the outside.
Do not modify or tamper with the exhaust system.
Do not idle the engine except as necessary.
For more information go to www.P65warnings.ca.gov/diesel.
2
Go to Discount-Equipment.com to order your parts

Table of contents
1Introduction........................................................................................................................................... 7
1.1 Foreword........................................................................................................................................ 8
1.2 Machine type plate and engine type plate................................................................................ 10
2 Technical data...................................................................................................................................... 11
2.1 Noise and vibration data............................................................................................................ 14
2.1.1 Noise data.................................................................................................................................. 14
2.1.2 Vibration data............................................................................................................................. 14
3 Concerning your safety...................................................................................................................... 15
3.1 Basic prerequisites..................................................................................................................... 16
3.1.1 General...................................................................................................................................... 16
3.1.2 Explanation of signal words used:.............................................................................................. 16
3.1.3 Personal protective equipment................................................................................................... 17
3.1.4 Intended use.............................................................................................................................. 18
3.1.5 Improper use.............................................................................................................................. 18
3.1.6 Estimated service life of the machine......................................................................................... 19
3.2 Definition of responsible persons............................................................................................. 20
3.2.1 Operating company.................................................................................................................... 20
3.2.2 Expert / qualified person............................................................................................................ 20
3.2.3 Driver / operator......................................................................................................................... 20
3.3 Basic safety regulations for safe operation............................................................................. 22
3.3.1 Remaining dangers, remaining risks.......................................................................................... 22
3.3.2 Regular safety inspections......................................................................................................... 22
3.3.3 Modifications and alterations to the machine............................................................................. 22
3.3.4 Damage, defects, misuse of safety devices............................................................................... 22
3.4 Handling fuels and lubricants.................................................................................................... 23
3.4.1 Preliminary remarks................................................................................................................... 23
3.4.2 Safety regulations and environmental protection regulations for handling diesel fuel............... 24
3.4.3 Safety regulations and environmental protection regulations for handling oil............................ 25
3.4.4 Safety regulations and environmental protection regulations for handling hydraulic oil............. 26
3.4.5 Safety regulations and environmental protection regulations for handling battery acid............. 27
3.4.6 Safety regulations and environmental protection regulations when handling lubrication
grease........................................................................................................................................ 28
3.5 Loading/transporting the machine............................................................................................ 29
3.6 Start-up procedure...................................................................................................................... 30
3.6.1 Prior to starting up...................................................................................................................... 30
3.6.2 Starting the engine..................................................................................................................... 30
3.7 Operation..................................................................................................................................... 31
3.7.1 Persons in the danger area........................................................................................................ 31
3.7.2 Operation................................................................................................................................... 31
3.7.3 Parking the machine.................................................................................................................. 31
3.8 Refuelling..................................................................................................................................... 32
3.9 Maintenance work....................................................................................................................... 33
3.9.1 Preliminary remarks................................................................................................................... 33
3.9.2 Working on the engine............................................................................................................... 33
Table of contents
BPR 50/55 D
3
Go to Discount-Equipment.com to order your parts

3.9.3 Maintenance work on electric components and battery............................................................. 33
3.9.4 Cleaning work............................................................................................................................ 33
3.9.5 Measures for longer shut-down periods..................................................................................... 34
3.9.6 After maintenance work............................................................................................................. 34
3.10 Repair......................................................................................................................................... 35
3.11 Signage...................................................................................................................................... 36
3.12 Safety Components.................................................................................................................. 40
4 Indicators and control elements........................................................................................................ 41
5 Checks prior to start up...................................................................................................................... 43
5.1 Notes on safety........................................................................................................................... 44
5.2 Visual inspections and function tests....................................................................................... 45
5.3 Checking the engine oil level..................................................................................................... 46
5.4 Checking the fuel level; topping up fuel................................................................................... 47
5.5 Checking the rubber buffers...................................................................................................... 48
6 Operation............................................................................................................................................. 49
6.1 Folding down the steering rod and adjusting it....................................................................... 50
6.2 Starting the engine...................................................................................................................... 51
6.3 Operation..................................................................................................................................... 53
6.4 Parking the machine in secured condition............................................................................... 55
6.5 ECONOMIZER.............................................................................................................................. 56
7 Loading/transporting the machine.................................................................................................... 57
7.1 Loading the machine.................................................................................................................. 58
7.2 Lashing the machine to the transport vehicle.......................................................................... 60
8 Maintenance........................................................................................................................................ 61
8.1 Preliminary remarks and safety notes...................................................................................... 62
8.2 Preparations / concluding work................................................................................................. 63
8.2.1 Opening / closing the protection hood........................................................................................ 63
8.3 Fuels and lubricants................................................................................................................... 65
8.3.1 Engine oil................................................................................................................................... 65
8.3.2 Fuel............................................................................................................................................ 65
8.3.3 Oil for exciter shaft housing........................................................................................................ 66
8.3.4 Mineral oil based hydraulic oil.................................................................................................... 66
8.4 List of fuels and lubricants........................................................................................................ 68
8.5 Running-in instructions.............................................................................................................. 69
8.5.1 General...................................................................................................................................... 69
8.5.2 After 25 operating hours............................................................................................................. 69
8.6 Maintenance Table...................................................................................................................... 70
8.7 Weekly.......................................................................................................................................... 71
8.7.1 Checking, cleaning the air filter.................................................................................................. 71
8.7.2 Checking and cleaning the water separator............................................................................... 73
8.8 Semi-annually.............................................................................................................................. 74
8.8.1 Battery service........................................................................................................................... 74
8.9 Annually / every 250 operating hours....................................................................................... 75
8.9.1 Replacing the V-belt................................................................................................................... 75
8.9.2 Checking, adjusting the valve clearance.................................................................................... 77
Table of contents
BPR 50/55 D
4
Go to Discount-Equipment.com to order your parts

8.9.3 Changing the engine oil and cleaning the oil filter...................................................................... 79
8.9.4 Replacing the fuel filter............................................................................................................... 81
8.9.5 Replacing the air filter................................................................................................................ 82
8.9.6 Changing the oil in the exciter housing...................................................................................... 83
8.9.7 Checking the hydraulic oil level.................................................................................................. 85
8.9.8 Replacing the starter rope.......................................................................................................... 87
8.9.9 Lubricating the machine............................................................................................................. 89
8.10 Every 2 years / every 500 operating hours............................................................................. 90
8.10.1 Changing the hydraulic oil........................................................................................................ 90
8.11 As required................................................................................................................................ 92
8.11.1 Cleaning the machine............................................................................................................... 92
8.11.2 Cleaning the cooling fins and the cooling air intake openings.................................................. 92
8.11.3 Servicing the V-belt.................................................................................................................. 93
8.11.4 Checking the oil level in the exciter housing............................................................................ 94
8.11.5 Measures prior to extended shut-down period......................................................................... 94
9 Troubleshooting.................................................................................................................................. 97
9.1 Preliminary remarks.................................................................................................................... 98
9.2 Starting the engine with the recoil starter................................................................................ 99
9.3 Starting the engine with jump leads........................................................................................ 101
9.4 Fuse assignment....................................................................................................................... 102
9.5 Engine malfunctions................................................................................................................. 103
9.6 Malfunctions during operation................................................................................................ 105
9.7 Trouble shooting ECONOMIZER.............................................................................................. 106
10 Disposal............................................................................................................................................. 107
10.1 Final shut-down of machine................................................................................................... 108
11 List of special tools........................................................................................................................... 109
Table of contents
BPR 50/55 D
5
Go to Discount-Equipment.com to order your parts

Table of contents
BPR 50/55 D
6
Go to Discount-Equipment.com to order your parts

1 Introduction
Introduction
BPR 50/55 D
7
Go to Discount-Equipment.com to order your parts

1.1 Foreword
BOMAG manufactures machines for earth, asphalt and refuse
compaction, stabilizers/recyclers as well as planers and
pavers.
BOMAG’s vast experience in connection with state-of-the-art
production and testing methods, such as lifetime tests of all
important components and highest quality demands guar-
antee maximum reliability of your machine.
These operating and maintenance instructions are part of your
machine.
They provide necessary information to operate your machine
safely and properly.
They also contain information on required operating, maintenance
and repair measures.
Carefully read the operating and maintenance instructions before
taking your machine into operation.
Please observe the safety regulations strictly and follow all instruc-
tions to ensure safe operation.
If you are not yet acquainted with the controls and indicating ele-
ments on this machine, you should thoroughly read the corre-
sponding chapter
Ä Chapter 4 ‘Indicators and control elements’
on page 41.
The description of the individual operating steps including the
notes on safety to be followed can be found in chapter “Operation”
Ä Chapter 6 ‘Operation’ on page 49.
Before every start up, carry out all required visual inspections and
function tests
Ä Chapter 5 ‘Checks prior to start up’ on page 43.
Ensure the compliance with the specified operating, maintenance
and repair measures to maintain the functional safety of your
machine.
A description of all necessary maintenance work, maintenance
intervals as well as information on fuels and lubricants can be
found in the chapter “Maintenance”
Ä Chapter 8 ‘Maintenance’
on page 61.
Do not service or repair your machine by yourself to avoid harming
persons or damaging material or environment.
The machine must only be serviced and repaired by qualified and
authorized personnel.
Contact our Customer Service to carry out the required mainte-
nance work or necessary repairs.
In case of operating errors, inadequate maintenance or the use of
unapproved fuels and lubricants all warranty claims will become
null and void.
For your own personal safety you should only use original parts
from BOMAG.
For your machine we offer service kits to make maintenance
easier.
Introduction – Foreword
BPR 50/55 D
8
Go to Discount-Equipment.com to order your parts

In the course of technical development we reserve the right for
technical modifications without prior notification.
These operating and maintenance instructions are also available in
other languages.
Apart from that, you can also order the spare parts catalogue
against the serial number of your machine.
The above notes do not constitute an extension of the warranty
and liability conditions specified in the general sales and delivery
conditions of BOMAG GmbH.
We wish you successful work with your BOMAG machine.
Introduction – Foreword
BPR 50/55 D
9
Go to Discount-Equipment.com to order your parts

1.2 Machine type plate and engine type plate
Please enter here:
Machine type (1):
Serial number (2):
Please enter here:
Engine type (1):
Engine number (2):
Made by
Designation Type
Nominal Power Operating Mass Year of Construction
Serial-No.
Patent Protection
56154 Boppard;GERMANY Made in Germany
1
2
B-DEC-0270
Fig. 1: Machine type plate (example)
EMISSION CONTROL INFORMATION
MOTORENFABRIK HATZ KG ¬ D-94099 RUHSTORF
GMBH
+CO
Model:
S/N:
Power:
Displ:
Eng.Fam:
Emission Control System:
Power Category:
ULTRA LOW SULFUR DIESEL FUEL ONLY.
FOR MY2018 NONROAD DIESEL ENGINES.
EU-Type:
www.hatz-diesel.com
Build:
PV:
E1
1
2
B-HAT-0045
Fig. 2
Introduction – Machine type plate and engine type plate
BPR 50/55 D
10
Go to Discount-Equipment.com to order your parts

2 Technical data
Technical data
BPR 50/55 D
11
Go to Discount-Equipment.com to order your parts

B-692-0239
Fig. 3
H H1H2L L1W W1W2
Dimensions standard
790
(31.1)
980
(38.6)
1350
(53.1)
1700
(66.9)
900
(35.4)
450
(17.7)
550
(21.7)
750
(29.5)
Dimensions with "STONEGUARD" (special base plate for paving stones)
800
(31.5)
990
(39)
1360
(53.5)
1735
(68.3)
970
(38.1)
680
(26.8)
Dimensions in millimetres
(Dimensions in inch)
Weights
Operating weight (CECE) (W) 390
(860)
kg
(lbs)
Operating weight (CECE) (W1) 405
(893)
kg
(lbs)
Operating weight (CECE) (W2) 420
(926)
kg
(lbs)
Basic weight 400
(882)
kg
(lbs)
Dimensions
Technical data
BPR 50/55 D
12
Go to Discount-Equipment.com to order your parts

Weights
“STONEGUARD” (special base plate for paving stones) (optional
equipment)
+ 35
(+ 77)
kg
(lbs)
ECONOMIZER (optional equipment) + 5
(+ 11)
kg
(lbs)
Travel characteristics
Max. working speed 28
(92)
m/min
(ft/min)
Max. working speed with “STONEGUARD” 25
(82)
m/min
(ft/min)
Max. gradeability (depending on soil) 35 %
Drive
Engine manufacturer Hatz
Type 1B40
Cooling Air
Number of cylinders 1
Rated power ISO 3046 6.7
(9.0)
kW
(hp)
Rated speed 3000 min-1
Drive system mechanical
Exciter system
Frequency 66
(3960)
Hz
(vpm)
Centrifugal force 50
(11241)
kN
(lbf)
Amplitude 1.85
(0,073)
mm
(in)
Filling capacities
Fuel (diesel) 5.0
(1.3)
l
(gal us)
Technical data
BPR 50/55 D
13
Go to Discount-Equipment.com to order your parts

2.1 Noise and vibration data
The following noise and vibration data were determined in accord-
ance with the following guidelines under equipment specific condi-
tions and by using harmonized standards:
nEU Machine Directive edition 2006/42/EU
nNoise Emission Directive 2000/14/EU, Noise Protection Direc-
tive 2003/10/EU
nVibration Protection Directive 2002/44/EU
During operation these values may vary because of the prevailing
operating conditions.
2.1.1 Noise data
LpA = 95 dB(A), determined acc. to ISO 11201 and EN 500.
WARNING!
Loss of hearing caused by too high noise bur-
dens!
– Wear your personal protective equipment (ear
protection).
LWA = 108 dB(A), determined acc. to ISO 3744 and EN 500.
2.1.2 Vibration data
Vector total of the weighted effective acceleration in three orthog-
onal directions:
Total vibration value ahv £ 2.5 m/s2 on crushed rock determined
acc. to ISO 5349 and EN 500.
Associated uncertainty K = 0.6 m/s2, determined acc. to EN
12096.
Observe the daily vibration load (work safety acc. to 2002/44/EC).
Sound pressure level at the opera-
tor's stand
Guaranteed sound power level
Hand-arm vibration
Technical data – Noise and vibration data
BPR 50/55 D
14
Go to Discount-Equipment.com to order your parts

3 Concerning your safety
Concerning your safety
BPR 50/55 D
15
Go to Discount-Equipment.com to order your parts

3.1 Basic prerequisites
3.1.1 General
This machine has been built in compliance with the latest technical
standard and complies with the applicable regulations and tech-
nical rules.
However, dangers for persons and property may arise from this
machine, if:
nit is used for purposes other than the ones it is intended for,
nit is operated by untrained personnel,
nit is changed or converted in an unprofessional way,
nthe safety instructions are not observed.
Each person involved in the operation, maintenance and repair of
the machine must therefore read and comply with these safety reg-
ulations. If necessary, the operating company must obtain the rele-
vant signatures as confirmation.
Furthermore, the following obviously also applies:
napplicable accident prevention instructions,
ngenerally accepted safety and road traffic regulations,
ncountry/state specific safety regulations.
It is the duty of the operator to be acquainted with the safety regu-
lations and to apply these accordingly. This also applies for local
regulations and regulations concerning different types of handling
activities. Should the recommendations in these instructions be dif-
ferent from the regulations valid in your country, you must comply
with the safety regulations valid in your country.
3.1.2 Explanation of signal words used:
DANGER!
Danger to life if failing to comply!
Sections marked accordingly indicate an extremely
dangerous situation that could lead to fatal or
severe injuries, if this warning is disregarded.
WARNING!
Danger to life or danger of severe injuries if
failing to comply!
Sections marked accordingly indicate a dangerous
situation that could lead to fatal or severe injuries,
if this warning is disregarded.
Concerning your safety – Basic prerequisites
BPR 50/55 D
16
Go to Discount-Equipment.com to order your parts

CAUTION!
Danger of injury if failing to comply!
Sections marked accordingly indicate a dangerous
situation that could lead to fatal or severe injuries,
if this warning is disregarded.
NOTICE!
Danger of material damage if failing to comply!
Sections marked accordingly indicate possible
dangers for machines or components.
Sections marked accordingly indicate technical
information or notes on using the machine or its
components.
ENVIRONMENT!
Environmental damage if failing to comply!
Paragraphs marked accordingly indicate practices
for safe and environment-friendly disposal of fuels
and lubricants as well as replacement parts.
3.1.3 Personal protective equipment
Depending on the work to be carried out, personal protective equipment is required (to be provided
by the operating company):
Working clothes Tight fitting working clothes with low tear resistance, tight
sleeves and without any projecting parts protect against
being caught by moving components.
Safety shoes To protect against heavy falling parts and slipping on
slippery ground.
Protective gloves To protect the hands against excoriation, punctures or
deep injuries, against irritating and caustic substances
as well as against burns.
Concerning your safety – Basic prerequisites
BPR 50/55 D
17
Go to Discount-Equipment.com to order your parts

Safety goggles To protect the eyes against airborne particles and
squirting fluids.
Face protection To protect the face against airborne particles and
squirting fluids.
Hard hat To protect the head against falling parts and to protect
against injuries.
Hearing protection To protect hearing against excessive noise.
Respiratory protection To protect respiratory tracts against substances or parti-
cles.
3.1.4 Intended use
This machine must only be used for:
nCompaction of all types of soils
nRepair work on all types of soil
nPaving of walkways
nWork in trenches
nUnderfilling and compaction of hard shoulders
Intended use also includes compliance with the specified oper-
ating, maintenance and repair measures.
3.1.5 Improper use
Dangers may arise from the machine when it is used for purposes
other than the one it is intended for.
Any danger caused by improper use is the sole responsibility of the
operating company or driver/operator, the manufacturer cannot be
made liable.
Concerning your safety – Basic prerequisites
BPR 50/55 D
18
Go to Discount-Equipment.com to order your parts

Examples for improper use are:
ndragging the machine along as a measure of transportation
nthrowing the machine off the transport vehicle
nattaching an additional weight to the machine
It is not permitted to stand on the machine while working.
Lifting tackle must be removed before starting work.
Starting and operating the machine in explosive environments and
in underground mining is prohibited.
The lifting and lashing points specified in these instructions must
be used. It is prohibited to use other lifting and lashing points (e.g.
guide handle, steering rod).
3.1.6 Estimated service life of the machine
If the following general conditions are met, the service life of the
machine is usually in the range of several thousand operating
hours:
nRegular safety inspections by an expert / qualified person
nPerformance of the prescribed maintenance work within the
specified time
nImmediate performance of necessary repair work
nExclusive use of original spare parts
Concerning your safety – Basic prerequisites
BPR 50/55 D
19
Go to Discount-Equipment.com to order your parts
