FEDERAL PACIFIC PSE Installation instructions

1075 Old Airport Road • Bristol, VA 24201 Phone [phone] • FAX [phone] • www.federalpacic.com • ISO9001:2015
SECTION IB-2B-800
INSPECTION & MAINTENANCE RECOMMENDATIONS
DEAD-FRONT PAD-MOUNTED SWITCHGEAR TYPE PSE
JUNE 2021, REV. 1.1
Page 1
TYPE PSE
DEAD-FRONT PAD-MOUNTED SWITCHGEAR
15kV • 25kV
INSPECTION & MAINTENANCE RECOMMENDATIONS
Qualied Persons
The equipment covered by this publication must be selected for a specic
application and it must be operated and maintained by Qualied Persons
who are thoroughly trained and knowledgeable in the installation, operation,
and maintenance of underground power distribution equipment along with the
associated hazards that may be involved.This publication is written only for such
qualied persons and is not intended to be a substitute for adequate training
and experience in safety procedures for this type of equipment. Proper instal-
lation is the responsibility of the operating and construction personnel and the
utility performing and authorizing the work. Completion of these instructions
implies no further warranty by the manufacturer.
A Qualied Person is dened in the National Electrical Code (NEC/NFPA-70)
as:
One who has skills and knowledge related to the construction and operation of
the electrical equipment and installations and has received safety training to
recognize and avoid the hazards involved.
The specic electrical safety training requirements to be considered a qualied
person are detailed in NFPA-70E, Article 110.1(D), Employee Training.
Some of the requirements from the 2012 edition are shown below. For the
specic detailed training requirements for a Qualied Person make certain to
refer to the most recent applicable edition.
These training requirements would include, but are not limited, to the following
key points:
• The skills and techniques necessary to distinguish exposed energized parts
from other parts of electrical equipment.
• The skills and techniques necessary to determine the proper approach
distances corresponding to the voltages to which the qualied person will be
exposed.
• The proper use of the special precautionary techniques, personal protective
equipment, insulating and shielding materials, and insulated tools for working
on or near exposed energized parts of electrical equipment.
• Tasks performed less often than once per year have additional training require-
ments.
These instructions are intended only for such qualied persons. They are not
intended to be a substitute for adequate training and experience in safety
procedures for this type of equipment. Additionally, the recommendations in
this instruction bulletin are not intended to supersede or to take the place of
established utility safety guidelines and established practices. If there is any
question, consult with your foreman or supervisor, as appropriate.
Please refer to OSHA 29 CFR 1910.399 and NFPA 70E Articles 100 and 110.
WARNING
© 2021 Electro-Mechanical Corporation

1075 Old Airport Road • Bristol, VA 24201 Phone [phone] • FAX [phone] • www.federalpacic.com • ISO9001:2015
SECTION IB-2B-800
INSPECTION & MAINTENANCE RECOMMENDATIONS
DEAD-FRONT PAD-MOUNTED SWITCHGEAR TYPE PSE
JUNE 2021, REV. 1.1
Page 2
Barriers, viewing windows and insulators can be cleaned with a non-
alcohol and non-solvent based cleaner that does not leave any residue
when dry. Residue must be removed.
3. Exercising
Yearly mechanical exercising of the switch is recommended. Refer to
Instruction Bulletin Section IB-2A-210 for information on operating
the switch.
Current carrying parts must be completely de-energized from all
sources before any maintenance is performed on these parts. Follow
normal system operating practices to de-energize, test for voltage
and ground these parts before any work is performed.
4. Exercise Fuse Mountings
Open and close hinged fuse panels and insure proper latching
as described on the label on the inside of the compartment door
and in Instruction Bulletin Section IB-2A-210. Inspect fuse contact
interfaces for damage and overheating, which will be evidenced
by distortion or discoloration of the contacts. Note that contacts are
copper and may be silver plated. There will be normal oxidation of
these parts. Slight irregularities can be burnished with an emery
cloth or paper.
5. Replacement Parts
If parts or labels are required they may be ordered by contacting Federal
Pacic at 276-669-4084 or your local Federal Pacic Manufacturer's
Representative. A directory of the representatives can be found at www.
federalpacic.com. If parts are ordered, the unit serial number and date
of manufacture must be provided along with the part description.
6. Maintaining the Exterior
The exterior nish can be maintained by periodic washing, touch up
of any scratches and abrasions, and waxing.
For areas to be touched-up, clean the area removing all rust. Apply a
red-oxide primer, available in spray cans from a local paint supplier
or home improvement store. Spray cans of the topcoat nish are
available from Federal Pacic (specify the original color).
7. Verify Security Devices
Verify the operational integrity of security devices such as door
latches, penta-head bolts, hinges and key-interlock systems. Make
certain padlocks are properly installed on all doors and covers.
1. Switch Operation
Check switch for proper operation refer to Instruction Bulletin
IB-2A-210. If the switch is closed on a short circuit within the fault
closing rating and the short circuit is cleared by circuit breakers or
fuses, the switch will not sustain damage which would require major
repairs. However, the switch should be inspected before returning to
service to determine switch condition. See Lubrication.
2. Cleanliness
Check for cleanliness generally, but particularly for accumulation of
any foreign material on insulators, barriers and viewing windows.
The procedures required for operation of the Federal Pacic Auto-jet®II
Load-Interrupter Switches, the dead-break hinged fuse panels, the doors,
the barriers and other accessory components are covered in detail in the
Federal Pacic Instruction Bulletin Section IB-2A-210. The inspection and
maintenance recommendations covered in this bulletin are expected to
be performed in conjunction with a review of IB-2A-210. This bulletin
does not cover all the detailed and specic operational procedures and
checks. In addition, these instructions are not intended as a substitute for
the user’s standard operating practices and procedures. A copy of Instruc-
tion Bulletin Section IB-2A-210 can be printed from the internet at www.
federalpacic.com.
When cleaning components, NEVER use any industrial strength cleaners.
NEVER apply lubricants to the probe contact or the tulip contact which
are the interrupting contacts. NEVER use any solvent-based or ammable
products on any components in the pad-mounted switchgear. Solvents
and ammable products can attack non-metallic components of the
equipment and reduce electrical and mechanical properties.
Maintenance
Federal Pacic switchgear does not require routine mechanical or electri-
cal maintenance. However, the following are some recommendations for
enhancing continued service of the equipment.
NOTICE
WARNING WARNING
Before Opening the Switchgear
The following inspection and maintenance procedures must be
performed with the current-carrying parts completely de-energized
and isolated from voltage. Any attempt to perform the inspection and
maintenance with the current-carrying parts energized may result in
electrical arc ash that can cause equipment damage, personal injury
or death.
DANGER
CAUTION
Do not put any lubricant on switch probe or puffer contacts. Refer to sec-
tion "10. Lubrication".

1075 Old Airport Road • Bristol, VA 24201 Phone [phone] • FAX [phone] • www.federalpacic.com • ISO9001:2015
SECTION IB-2B-800
INSPECTION & MAINTENANCE RECOMMENDATIONS
DEAD-FRONT PAD-MOUNTED SWITCHGEAR TYPE PSE
JUNE 2021, REV. 1.1
Page 3
a. On the fuse panel main contact stab. See Figure 1.
b. On the contact interface at the fuse-mounting stationary main
contact. See Figure 1.
c. The contact rod and fuse ferrule on the fuse assembly and/or fuse
holder.
d. DO NOT LUBRICATE ANY OTHER CURRENT CARRYING AREAS.
e. If lubrication is required apply a coating of NYE Rheolube 363,
which is the only approved lubricant for electrical contact sur-
faces.
3) Fuse-Mounting
Upper Contact
(Receiver)
2) Fuse-Mounting
Lower Contact
(Hinge End)
1) Main Contact Stab
Figure 1. Lubrication points for electrical contacts on PSE fuse panel.
8. Replacing Labels
Replace any missing, damaged or obscure labels. Replacement
labels are available from Federal Pacic.
9. Lubrication of Non-Current Carrying Parts
a. Non-current carrying parts, such as operating mechanism, hinges
and latches, may be lubricated with any lubricants that the user
has determined to be suitable for such applications.
b. Door latches on units with a date of manufacture prior to March
2008 should be regularly lubricated to prevent corrosion that
may render the latches inoperable. If latches become non-func-
tional and the door does not release, refer to Instruction Bulletin
IB-9D-810 (previously IB-1H-810).
10. Lubrication of Current Carrying Parts
When maintenance is performed, check for lubrication at the follow-
ing locations:
Lubrication is NOT required on any other current carrying sur-
faces than the locations identied. Applying lubrication in other
areas may reduce mechanical and electrical performance. DO
NOT OVER LUBRICATE!
WARNING

1075 Old Airport Road • Bristol, VA 24201 Phone [phone] • FAX [phone] • www.federalpacic.com • ISO9001:2015
SECTION IB-2B-800
INSPECTION & MAINTENANCE RECOMMENDATIONS
DEAD-FRONT PAD-MOUNTED SWITCHGEAR TYPE PSE
JUNE 2021, REV. 1.1
Page 4
Notes:
Date: ___________________________
Every effort is made to ensure that customers receive an up-to-date instruction manual on the use of Federal Pacic products; however, from
time to time, modications to our products may without notice make the information contained herein subject to alteration.
