AromaFlo®
Installation & Operation Manual

RISK OF ELECTRIC SHOCK - This pump is
supplied with a grounding conductor and grounding-type
attachment plug. To reduce the risk of electric shock, e
certain that it is connected only to a properly grounded,
grounding-type receptacle.
RISQUE DE CHOC ÉLECTRIQUE - Cette
pompe est fournie avec un conducteur de mise à la terre et
une fiche de ranchement de type mise à la terre. Pour
réduire le risque de choc électrique, assurez vous qu'il est
connecté uniquement à une mise à la terre, à la terre prise.
mr
.
steam
®
AROMAFLO Operation & Installation
__________________________________________________________________
2
• Do not use with water solu le fragrance or fragrance
containing emulsifiers or aldehydes. AromaFlo sys-
tem damage may result. Mr.Steam oils are approved
for operation with this system.
• The use of any oils other than Mr.Steam oils may
introduce excessive concentration of oil into the
steam room, resulting in a health hazard.
• Vapors may cause drowsiness and dizziness. Keep
out of the reach of children. In case of contact with
eyes, rinse immediately with plenty of water and
seek medical advice. If swallowed, rinse mouth with
water (only if the person is conscious), seek medical
advice immediately and show this container or la el.
• Highly Flamma le. Keep away from sources of igni-
tion–No smoking. Keep container tightly closed & in
a well-ventilated place. This material & its container
must e disposed of as hazardous waste.
• Not for use in acrylic or fi erglass rooms. Material
Safety Data Sheet (MSDS) availa le upon request
IMPORTANT NOTE: As you follow these instruc-
tions, you will notice warning and caution sym ols. This
locked information is important for the safe and efficient
installation and operation of this generator. These are
types of potential hazards that may occur during installa-
tion and operation:
states a hazard may cause serious
injury or death if precautions are not followed.
signals a situation where minor injury
or product damage may occur if you do not follow
instructions.
IMPORTANT NOTE: This highlights information that
is especially relevant to a pro lem-free installation.
TABLE OF CONTENTS
Box Contents ....................2
Assembly and Installation
General.........................3
PumpAssem ly...................4
Installation of Hoses . . . . . . . . . . . . . . . 4
System Schematic . . . . . . . . . . . . . . . . 5
Electrical Wiring . . . . . . . . . . . . . . . . . . 6
Assem ly Diagram . . . . . . . . . . . . . . . . 7
Start-up
Initial Priming of Metering Pump . . . . . 8
Filling the Pressure Hose. . . . . . . . . . . . 8
Programming Ta le . . . . . . . . . . . . . . . . 9
Maintenance
Maintenance of Metering Pump,
Suction Valve, and Pressure Valve. . . . 10
Troubleshooting ...................11
Technical In ormation..............11
Spare Parts ......................11
Warranty ........................12
PUR 100193 10.14
Fragrance Metering Pump
or Commercial Steam Rooms
CU-AromaFloA 120V
Listed Oil Delivery
Pump 24VW
mr.steam®
Sussman-Automatic Corp®
[email protected]
www.mrsteam.com
43-20 34th Street
Long Island City, NY 11101
TEL : 1 800 76 STEAM
FAX : [phone]
9410 S. La Cienega Blvd.
Inglewood CA 90301
TEL : 1 800 72 STEAM
FAX : [phone]
WARNING
!
WARNING
!
NOTE: It is strongly recommended that this warning sign (supplied)
e posted in a conspicuous location near the steam room.
WARNING
!
CAUTION
!
AVERTISSEMENT
!
This room is equipped with an aromatic
oil dispensing system. Leave room
immediately if you have any adverse or
allergic reactions, including difficulty
breathing or eye, nasal, throat
.
Sussma -Automatic Corp.
3-20 34th Street, Lo g Isla d City NY 11101
1-800-76 STEAM
WARNING!
PUR 100381 3/02

3
Receptacle and Face Plate
Warning Sign
1/2 inch NPT
Atomizing Nozzle
Injector with
Injection Hose
Scent Container
Cover
Metering Pump 6 ft. 2 ft.
Pressure Hose Suction Hose
with Filter
mr
.
steam
®
AROMAFLO Operation & Installation
__________________________________________________________________
Box Contents
Shipping Hose
CAUTION
ForAromaFlo120V
pumpconnection only.
Otherconnectionsmayresult
incircuitoverload.
PUR103876
This room is equipped with an aromatic oil dispensing
system.
Leave the room immediately i you have any adverse
or
allergic reactions, including di iculty breathing or eye,
nasal, throat, or skin irritation and seek medical atten-
tion.
mr
.steam
®Commercial Steam Generators
Sussman-Automatic Corp. 43-20 34th Street , Long Island City NY 11101
1 800 76 STEAM • www.mrsteam.com
WARNING
!
Installation &
Operation Manual
GENERAL INSTALLATION
Do Not alter or modify any Mr. Steam
product. Doing so may result in an inopera le or hazardous
installation and will void the warranty.
The AromaFlo pump is quali ied or use
with Mr.Steam commercial steam generators. The use
with other brand equipment must be quali ied by instal-
lation owner/ installer. For use with commercial steam
rooms only. Not or use in residential installations.
1. Mr.Steam AromaFlo Pumps are designed and intended
for indoor use only and are to e located indoors in a dry
clean location and not su ject to moisture, condensation
or similar high humidity environments.
2. Do not install AromaFlo Pumps outdoors.
3. Do not install AromaFlo Pumps in a location where water
could freeze.
4. Do not install AromaFlo Pumps near flamma le or corro-
sive materials and chemicals. Installation in areas having
high concentrations of chlorine (such as pool equipment
room) should e avoided.
5. Install AromaFlo Pump on a solid and level surface.
6. Provide access to AromaFlo Pump for servicing.
7. The unit should not e installed in areas accessi le to the
general pu lic (ie: utility room). A LOCKED UTILITY
ROOM IS STRONGLY RECOMMENDED.
8. Height difference etween metering pump and 90
degree T is to e held to a maximum 6 ft.(see page 5).
9. Place scent container elow metering pump. Height dif-
ference etween metering pump and scent container is
to e no greater than a maximum of 3 feet(see page 5).
Clearance to heat sources
•Do not install the metering pump directly elow or a ove
the steam generator where it is su ject to heat.
•Distance etween metering pump and heat source (e.g.
Steam Line
90˚ T
Figure 2
steam generator, heating system) minimum 3 ft. If this
distance of minimum 3 ft cannot e maintained, install a
radiation plate or heat insulation etween the heat
source and metering pump.
•Am ient temperature at pump should not exceed 90˚ F.
Installing the 90 degree T & Atomizing Nozzle
1. For optimal results locate the 90 degree T (not provid-
ed) and atomizing nozzle in the steam supply line no
more than 10 feet from the steam head (see page 5).
2. T must face downward as shown on (see page 5).
3. Screw the atomizing nozzle into 90° T fitting.(see pg. 5).
IMPORTANT NOTE: Follow the installation instructions
or the steam pipeline in the Mr.Steam Commercial
Steam Bath Installation and Operating Manual (PUR
101376).
CAUTION
!
WARNING
!

mr
.
steam
®
AROMAFLO Operation & Installation
__________________________________________________________________
4
Installing the Pressure Hose to Atomizing Nozzle
1. Unscrew the nut from the atomizing nozzle and insert the pressure
hose through the nut.
2. Firmly push the pressure hose onto the atomizing nozzle (see pg 5).
3. Screw on the nut
IMPORTANT NOTE:
HAND-TIGHTEN ONLY
Installation o Pressure Hose to AromaFlo Pump.
1. Unscrew the pressure end nut from the pump head and remove the
shipping hose and the pressure end nut.
2. Insert the pressure hose through the hole of the pressure end nut
and firmly push the pressure hose onto the pressure valve.
3. Screw the pressure end nut onto the pressure valve and tighten the
nut y HAND only.
Installation o Suction Hose in Scent Container
1. Locate the “container cover” in the AromaFlo ox.
2. Unscrew the cover from the Mr.Steam scent container and discard.
3. Insert the suction hose with the open end from elow through
the hole in the container cover (see Fig. 3).
4. Insert the filter into the scent container so that the filter rests
on the ottom.
5. Screw the cover onto the scent container.
NOTE: Limit height difference etween metering pump
and scent container to 3 feet.
Installation o Suction Hose to AromaFlo Pump
1. Unscrew the suction end nut from the pump head and remove
short end of shipping hose (see Fig. 3)(discard shipping hose,
keep pressure end nut).
2. Remove suction end nut from the shipping hose.
3. Insert the open end of the suction hose through the hole of
the suction end nut.
4. Firmly push the hose onto the cone of the suction valve at
the pump head.
5. Screw the suction end nut to the suction valve.
IMPORTANT NOTE: HAND-TIGHTEN ONLY.
Figure 4
Open End
Container Cover
Suction Hose
Filter
Container Height
Pressure End Nut
Pressure Valve
Pump Head
Suction Valve
Suction End Nut
Figure 3

mr
.
steam
®
AROMAFLO Operation & Installation
__________________________________________________________________
5
Max.distance10'
Max.
height 6 ft.
Max.
height 3 ft.
Steam
head
Utility
Room
Steam
Room
Steam line
Pump line cord 120V
90°T
Atomizer nozzle
Pressure hose
AromaFlo pump
Suction hose
Scent Container
Steam solenoid with
electrical box
Typical MrSteam Commercial steam generator
Electrical connection to Digital 1
Temperature Control (see wiring diagram page 6)
• • • • • • • • ••• • • • • •••••• • • • •••• • • • •••• • • • • • •• • •• • • • •• • •••• • • •• • • • • • • • • • • • • • •• • • • • • • • • • • •• • •• • • •
Typical AromaFlo Installation
__________________________________
FOR ILLUSTRATIVE PURPOSES ONLY
(see full disclaimer)
__________________________________

mr
.
steam
®
AROMAFLO Operation & Installation
__________________________________________________________________
6
CU Steam Generator Digital 1 Control CU AROMAFLO
PROBE
Electrical Connection o Metering Pump
This metering pump is factory wired and operates on 120VAC 50/60hZ
power supply. Refer to nameplate on AromaFlo pump. If the power cord of the meter-
ing pump is damaged it must e replaced y the Sussman-Automatic service depart-
ment or similarly qualified personnel in order to avoid risks. All electrical connections to
e made y a licensed, qualified electrician. Disconnect all power to the steam genera-
tor efore making power connections.
Digital 1 Control and CU-AromaFlo Wiring Schematic
CAUTION
!

mr
.
steam
®
AROMAFLO Operation & Installation
__________________________________________________________________
7
Electrical Box Assembly
To avoid possi le electric
shock, the AromaFlo pump must e suita ly
grounded according to National Electric and
local Codes. Disconnect all power supplies
efore proceeding. Such wiring should e
done y a licensed electrician.
NOTE: Refer to the wiring diagram
on pg.6 for all wiring connections
Fully Assembled
The electrical
outlet shown is for AromaFlo
Pump connection only. Make
no other connections to this
outlet. Other connections may
result in circuit overload.
CAUTION
For AromaFlo120V
pumpconnectiononly.
Other connectionsmayresult
incircuitoverload.
PUR103876
Receptacle Faceplate
(supplied with AromaFlo)
Single Receptacle
(supplied with AromaFlo)
(2x4) NEMA Electrical Box
(supplied y others)
Steam Solenoid
with Electric Box
Mr.Steam Commercial
Steam Solenoid.
3 Conductor, Grounding-
Type Line Cord
AromaFlo Metering Pump
Mr.Steam Commercial
Steam Solenoid.
CAUTION
!
CAUTION
!

mr
.
steam
®
AROMAFLO Operation & Installation
__________________________________________________________________
8
START-UP
Initial Priming o the Pump
1. Insure Mr.Steam scent container is full.
2. Insert the short injector hose onto the tip of the injec-
tor (see Fig. 5).
3. Unscrew the pressure end nut from the pump head and
remove the pressure hose from the pressure valve (see
Fig.3).
4. Insert the open end of the injection hose onto the
pressure valve (see Fig. 5).
5. Draw liquid from the injector slowly and evenly.
Continue until the injector is full of liquid.
6. If you have drawn up the injector completely and no
liquid is in the injector, remove the injector hose from
the pressure valve.
7. Drain injector. Repeat steps until the injector is filled.
Figure 5
Pressure Valve
Injector Hose
Filling the Pressure Hose
1. Insure the AromaFlo Pump is primed and
the scent container is full.
2. Locate the Push- utton at the rear of the
metering pump (see Fig. 6). Depress this
push- utton to start metering pump.
3. Continue to depress push- utton until the
pressure hose is filled with liquid.
IMPORTANT NOTE: Push utton to e used
only for initial filling of the pressure hose.
Figure 6
Push Button
AromaFlo
Metering Pump
Injector
Tip

mr
.
steam
®
AROMAFLO Operation & Installation
__________________________________________________________________
9
"X" indicates switch position.
In this illustration the switch is "On".
Adjusting the Amount o Oil Delivery
Programming
Programming Switch is located
inside the metering pump.
1. After switching off power
supply, open cover of the
metering pump
2. Program the switches to
desired settings
3. Close cover of the metering
pump
4. Reconnect the power
The AromaFlo is factory set to
deliver 0.07 ounces (VOLUME) of
Mr.Steam essential oil every 1
minute 15 seconds (INTERVAL).
Increase and/or decrease the
VOLUME and INTERVAL settings
in any com ination to adjust the
flow of essential oil. Use the
settings guide provided.
Contact the Mr.Steam Technical
Service Department at (800) 76
STEAM (East coast) or (800) 72
STEAM (West coast)
for assistance
or additional information.
VOLUME STAND-BY
Switch S1 (Top) Switch S2 (Bottom)
________________________________________________
0.018 Oz
________________________________________________________
0.035 Oz 2 min 30 sec
________________________________________________________
0.053 Oz 3 min 45 sec
________________________________________________________
*0.070 Oz 5 min
________________________________________________________
0.088 Oz 6 min 15 sec
________________________________________________________
0.106 Oz 7 min 30 sec
________________________________________________________
0.123 Oz 8 min 45 sec
________________________________________________________
*Factory Setting
Switch o power be ore opening
cover to prevent electric shock!
1 2 3 4
DECREASE
INCREASE
AMOUNT
OF OIL
DECREASE
INCREASE
AMOUNT
OF OIL
Programming
Switch
ON
OFF
ON
OFF
X
XXXX
The metering pump
has een factory set to deliver a suita le
amount of aromatic oil into a typical
sized steam room. PLEASE CONTACT
THE MR.STEAM TECHNICAL SERVICE
DEPARTMENT BEFORE CHANGING
THIS SETTING. Increasing the settings
may introduce excessive concentration
of oil into the steam room, resulting in a
health hazard.
*1 min 15 sec
*0.070 Oz
Factory “Interval” Setting
Factory “Volume” Setting
Location o
Programming Switch
Circuit oard inside metering pump
Note: Switch 3 should not e adjusted
1 2 3 4
XXXX
1 2 3 4
ON
OFF
ON
OFF
X
XXX
1 2 3 4
X
XXX
1 2 3 4
ON
OFF
ON
OFF
X
X
XX
1 2 3 4
X
X
XX
1 2 3 4
ON
OFF
ON
OFF
XX
XX
1 2 3 4
XX
XX
1 2 3 4
ON
OFF
ON
OFF
XX
X
X
1 2 3 4
XX
X
X
1 2 3 4
ON
OFF
ON
OFF
X
X
X
X
1 2 3 4
X
X
X
X
1 2 3 4
ON
OFF
ON
OFF
X
XX
X
1 2 3 4
X
XX
X
CAUTION
!
WARNING
!
Warning Sign (not actual size)
This room is equipped with an aromatic
oil dispensing system. Leave room
immediately if you have any adverse or
allergic reactions, including difficulty
breathing or eye, nasal, throat
.
Sussma -Automatic Corp.
3-20 34th Street, Lo g Isla d City NY 11101
1-800-76 STEAM
WARNING!
PUR 100381 3/02

mr
.
steam
®
AROMAFLO Operation & Installation
__________________________________________________________________
10
MAINTENANCE
Maintenance o Metering Pump
IMPORTANT NOTE: Clean the suction and pressure valves
of deposits every 6 months, more frequently if necessary.
Maintenance o Suction Valve
1. Disconnect power supply.
2. Unscrew the suction end nut and remove the suction
hose.
3. Unscrew suction valve. Carefully remove the valve spring
with the pressure olt and the valve plate.
4. Rinse suction valve, valve spring, pressure olt and valve
plate with clear water. Remove deposits using a moist
cloth.
5. Clean the spring guide in the pump head and the valve
seat in the suction valve y means of a moist cloth.
Remove deposits and de ris.
6. Position the valve plate in the valve seat and place the
valve spring with the pressure olt in the center of the
valve plate.
7. Carefully screw the suction valve with the valve spring
into the pump head and tighten y HAND only.
8. Install the suction hose, see page 4, “Installation of
Pressure Hose.”
IMPORTANT NOTE:
The valve plate must e level in the pump head!
Maintenance o Pressure Valve
1. Disconnect power supply.
2. Unscrew pressure end nut and remove pressure hose.
3. Unscrew pressure valve. Cautiously remove the valve spring
with the pressure olt and the valve plate.
4. Rinse pressure valve, valve spring, pressure olt and valve
plate with clearwater. Remove deposits using a moist cloth.
5. Clean the valve seat in the pump head and the spring guide
in the pressure valve with a moist cloth and remove
deposits.
6. Position the valve plate in the valve seat of the pump head
and place the valve spring with the pressure olt in the cen-
ter of the valve plate.
7. Cautiously insert the pressure valve with the valve spring
into the pump head and tighten it y HAND only.
8. Install the pressure hose, see page 4, “Installation of
Pressure Hose.”
IMPORTANT NOTE: The valve plate must e level within the
pump head. Insert the valve spring without off-setting the
pressure valve spring guide.
Pressure End Nut
Pressure Valve
Valve Spring with
Pressure Bolt
Valve Plate
Pump Head
Valve Spring with
Pressure Bolt
Valve Plate
Suction Valve
Suction End Nut
Figure 9

11
mr
.
steam
®
AROMAFLO Operation & Installation
__________________________________________________________________
TROUBLESHOOTING
Metering pump does not prime
1. Check if voltage is availa le.
2. Check liquid level in scent container. Replenish liquid, if necessary.
3. Check for air u les in the suction hose or the pump head.
To eliminate air u les see: Priming Pump.
4. Check valves for contamination. Clean valves, if necessary.
5. Check filter in container for contamination. Rinse filter under clean water.
Metering pump does not inject oil into steam room
1. Check if voltage is availa le.
2. Check liquid level in scent container. Replenish liquid, if necessary.
3. Check for air u les in the suction hose or the pump head.
To eliminate air u les see: Priming Pump.
4. Check valves for contamination. Clean valves, if necessary.
5. Check filter in container for contamination. Rinse filter under clean water.
6. Check the pressure hose for kinking or jamming. Straighten or replace.
7. Check if liquid is freely flowing through the atomizing nozzle when the metering
pump is energized. Apply compressed air through the atomizing nozzle.
Attach the compressed air at the point of connection of the pressure hose.
Metering pump oil delivery too much or too little
See page 8 or call Sussman-Automatic Corp. 1-800-76 STEAM
TECHNICAL SPECIFICATIONS
Dimensions: 7” L x 6.5” W x 4.5” H
_______________________________________________________
Weight: 5 pounds
_______________________________________________________
EN 60335, UL-CSA
_______________________________________________________
Motor voltage 120 VAC, 50/60 Hz
Power consumption, total [W] 12 Watt
_______________________________________________________
List o Spare Parts
Description Part No.
Pump Head 103861
Pressure/Suction Hose EO1-1032
(ordered y the foot)
Re uild Kit 104159

12
mr
.
steam
®
AROMAFLO Operation & Installation
__________________________________________________________________
Terms, Conditions and Exclusions
To ensure expedient processing of any warranty claim, a
Merchandise Return Authorization (MRA) must e o tained y
the original consumer purchaser and prominently shown on any
correspondence or packages. Returns made without a MRA will
not e processed. To o tain a MRA, call 1-800-76 STEAM (East
Coast), 1-800-72 STEAM (West Coast).
The purchaser is responsi le for all shipping charges. All
AromaFlo-A products returned pursuant to an MRA must e
shipped freight prepaid. Proof of purchase (original sales
receipt) identifying the model num er and serial num er must
accompany all warranty claims.
This warranty does not apply to repairs or replacements neces-
sitated y any cause eyond the control of Sussman-Automatic
Corporation including, ut not limited to, any malfunction,
defect or failure caused y or resulting from unauthorized serv-
ice or parts, improper maintenance and/or pro lems arising
due to local water conditions, operation contrary to furnished
instructions, shipping or transit accidents, modification, or
repair y the user, a use, misuse, neglect, accident, incorrect
power line voltage, fire, flood or other Acts of God.
The foregoing is in lieu of all other expressed warranties and
Sussman Automatic Corporation does not assume or authorize
any party to assume for it any other o ligation or lia ility.
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE
DESCRIPTION CONTAINED HEREIN AND SPECIFICALLY LIA-
BILITY FOR ANY BREACH OF ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PURPOSE IS EXCLUD-
ED. THE DURATION Of ANY WARRANTIES WHICH MAY BE
IMPLIED BY LAW NOTWITHSTANDING THE PREVIOUS SEN-
TENCE (INCLUDING THE WARRANTIES OF MERCHANTABILI-
TY AND FITNESS) IS LIMITED TO THE TERM OF THIS WAR-
RANTY. IN NO EVENT SHALL SUSSMAN-Automatic
Corporation BE LIABLE FOR SPECIAL, INCIDENTAL OR CON-
SEQUENTIAL DAMAGES ARISING FROM OWNERSHIP OR
USE OF ANY MR.STEAM PRODUCT, OR FOR ANY DELAY IN
THE PERFORMANCE OF ITS OBLIGATIONS UNDER THIS
WARRANTY DUE TO CAUSES BEYOND ITS CONTROL. SOME
STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS AND/OR DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF CONSEQUENTIAL DAM-
AGES, SO THE ABOVE LIMITATIONS AND EXCLUSIONS MAY
NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS. YOU MAY HAVE OTHER RIGHTS, WHICH
VARY FROM STATE TO STATE.
AROMAFLO-A
One-Year Limited Warranty
Sussman-Automatic Corporation here y extends to the
original purchaser of its AromaFlo-A a warranty against
defects in it's material and workmanship for the term
indicated elow.
This warranty is only valid on AromaFlo-A products
purchased and used in the United States of America
and Canada. This warranty applies only to the original
purchaser. This warranty is also su ject to the terms set
forth elow.
Sussman-Automatic Corporation will repair or replace
(at its option) an AromaFlo-A product if it fails to con-
form to this warranty. This warranty period commences
on the date the AromaFlo-A product was first pur-
chased y the original purchaser. All warranty work will
e performed without charge when the AromaFlo-A
product is returned within one year of the date of pur-
chase to the location designated y Sussman-
Automatic Corporation in accordance with the terms
and conditions noted elow.
SUSSMAN-AUTOMATIC CORPORATION warrants the
AromaFlo-A product from manufacturing defects for
one year from the date of the product was first pur-
chased y the original purchaser.
IMPORTANT NOTE: Several items are not within the
control of our manufacturing processes and are not
considered manufacturing defects.
SUSSMAN-AUTOMATIC CORPORATION WILL NOT
BE RESPONSIBLE FOR DAMAGE DUE TO:
• The use of oils, fragrances or other materials not
supplied y Mr.Steam.
• Handling after removal from the original packaging.
• Use of a rasive cleaners, chlorine- ased cleaners,
a rasive cleaning pads, or similar materials and/or
cleansers are used or if there is any misuse and/or
a use. Use of these materials and/or cleaners can
cause damage.
• Damage as a result of its location and/or environ-
ment including exposure to excessive temperatures.
• Improper installation such as over-tightening
connections.
