Ecowell Homeguard User manual
Perfect Sterilizing & Cleaning Water Maker
ECOWELL CO., LTD.
- 03 -
- 04 - - 05 -
Sterilization Removes 99.9% of bacteria, viruses, fungi and harmful microbes
Deodorization Reduces bad odors by spraying on bad-smelling spot or wiping the
spot with cloth or toilet tissue
Cleaning Spray the water to wash out any stains or stubborn dirt on the surface of item
Removing pesticides Wash fruit and vegetables with the electrolyzed water
How long does electrolyzed water keep its effect?
The electrolyzed water generated with salt in 'Operation Mode' maintains its
sterilizing and deodorizing effects for 3 to 7 days on average. This effect gradually
decreases over time, then it returns to its original state, normal water. If the
electrolyzed water is kept in an airtight container and completely sealed when
refrigerated, its effects will last over 3 months.
Check out more applications in the Recipe Book.
High
Low Operation Mode
NO
YES
Parts
Pitcher lid
Pitcher（1000ml）
Electrode
Base station
Operation button
Spray Head
Spray bottle(300ml)
Stirring stick
Adapter
Adapter plug
Salt (70g)
Spoon
(scoop - to add salt)
Composition
- 07 -- 06 -
[Fig. 2][Fig. 1]
Place the device on a dry, flat place.
Place the device at least 10cm away from the wall.
As shown in [Fig. 1], connect the plug to the adapter.
After connecting the adapter with the hole beneath Base Station, store the
cord to fit along the hollow as [Fig. 2]
Use normal tap water with a temperature between 5-35℃.
Do not use underground water, contaminated water or purified water.
A slight smell of chlorine during operation is completely normal.
We do not recommend adding salt when applying on the human body,
animals or plants.
- 08 - - 09 -
- As shown in [Fig. 3], Along with the initial power-up beeps,
all LEDs will flash and set to sleep mode.
- When connecting the power while the pitcher is fitted on
the base station.
1. when there is an water in the pitcher, set to sleep mode.
(To use, press the button for 1 second, or place the pitcher on
the base station again.)
2. It does work when there is no water in the pitcher.
(Put water in the pitcher and let it operate)
- As shown in [Fig. 4], the white LED operation button is turned on.
Press the operation button in standby mode, the device will work.
- How to set up standby mode.
1. When the water bottle is fitted on the base station, which is
recognized automatically, then goes into standby mode with a
beep sound to ready for generating operation. # when the Pitcher
is removed from base station, it goes into sleep mode with a beep
sound.
2. In sleep mode, press and hold button for 1 second to enter
standby mode with beep sound.
- How to switch to sleep mode to minimize power consumption in
standby mode.
1. In standby mode, press and hold the operation button for 5
seconds to enter the sleep mode.
2. In standby mode, the device switches to sleep mode
automatically if no buttons are operated for 3 minutes
[Fig. 3]
[Fig. 4]
[Fig. 5]
[Fig. 6]
[Fig. 8]
[Fig. 7]
- 10 - - 11 -
Vinegar
citric
acid
200ml 100ml
100ml
CheckProblem Solution
Maintenance
Do not keep water in the Pitcher for a long time (less than 3-5 days).
Store the device in completely dry conditions away from humidity or direct sunlight
when not used form any length of time. If the device is stored in too low a temperature,
it may not work as effectively and be damaged by frozen water inside the device.
Cleaning Outside
Use a dry cloth when you clean the outside of device. Do not use any chemicals or
detergents. The contacting part between Pitcher and Base station must be away from
water. If so, wipe the water and dry well.
Cleaning Inside
Do not remove the electrodes on the bottom of Pitcher, or wipe it with excessive force.
If you find any scale in Pitcher, clean inside of the Pitcher with care to avoid any damage
to electrodes. Then, operate the device for 3 minutes by adding salt. Keep the Pitcher for
one hour and rinse with clean tap water for next use.
Removing Scale
After using this device for a long time, if you find white scale in electrodes, clean its
surface. Pour 1) 200ml of warm water and 20g of citric acid (sold separately) or 2) 100ml
of water and 100ml of vinegar into the Pitcher and leave it for one hour more, the
electrode will be cleaned. Then, empty the pitcher and rinse it. Wash this way every
2 or 3 months.
LED is not turned on. Is Adapter (and its plug) properly
connected to power socket?
Make sure to connect adapter to
power.
LED is turned on,
but bubbles do not come up. Is Pitcher placed properly on
Base Station?
Put Pitcher on Base Station
properly and check if the
device works in order. power.
Bubbles are faintly coming up. Is purified water or mineral water
used instead of tap water?
use tap water only. Also, you will
see more bubbles when salt is
added than when tap water is
used alone.
LED of operation button keeps
blinking with beeping sounds
in the middle of operation.
Did you put 1000ml of water and
1g of salt exactly?
If the water is not enough with too
much salt, the device will not
operate for safety reasons.
Retry the device after adding
suggested quantity of salt.
After finishing generation of
sterilizing water, the device
doesn't work by pressing
Operation Button.
Did you wait 3 minute after
previous operation?
It's normal that the device can't
be operated for 3 minute after
making electrolyzed water
LED is still on even after
completion.
After the water has been made, it's
normal for the LED in bottom of
Pitcher and the LED on Operation
Button to stay on to let you know
the operation is over
Remove Pitcher from Base Station
to turn off LED in the bottle.
However, this does not turn off
the LED on Base Station.
Spray doesn't work. Did you use hard water?
If you use hard water,the spray
nozzle
will be blocked because scale is
formed. Please avoid using hard
water if possible. If the spray
doesn't work well, soak the nozzle
in a diluted solution of vinegar
(1:1 mixture of vinegar and water).
If this still doesn't help, please
contact our customer center.
Spray doesn’t work
If the spray doesn’t work well, pull
the trigger and hold for about 5
seconds, and flick (release quickly)
it and repeat this 2 ~ 3 times.
Unlike others, this spray has a
small cylinder in it to suck up water
by moving together with the trigger.
But, if the straw has no water inside
(or without a specific reason),
there may be some problems to
spray well. Once the straw is filled
with water, you won't see this
problem anymore.
- 13 -- 12 -
Cautions for Safety
Notes before use / Please use it safely
- 14 -
Product name
Model name
Effectiveness
DC adaptor
Power consumption
Dimensions (WxDxH)
Net weight
Capacity of water
Material
This Warranty specifies that we offer free repair service according to this User Manual in case defects or
malfunctions occur within the period of warranty (as written below) from the date of purchasing.
1. We offer free repair service in case of defects or malfunctions during the period of
warranty in using the device in accordance with this User Manual or any labels on
this product.
(a) If you want free repair service, please submit your request it the dealer/store where you
purchased this product by referring to this User Manual and Warranty.
(b) The page of Warranty should be accompanied by your request for free repair service. When
you use parcel delivery service, send this Warranty together with the product.
2. Even within the period of warranty, we are not responsible for following breaches or
cases, of which repair costs should be borne by you;
(a) Damage or Trouble caused by misusage (shock by drop, etc) or mal repair or modification
(b) Any trouble and/or damage due to fire, natural disaster, pollution, salt water, contamintion
by gas, abnormal voltage, power supply other than suggested voltage and/or frequency
(c) Loss of this Warranty
(d) In case of any absence, omission or correction by discretion of Date of purchase, customer
information, dealer/store
(e) The consumables and accessories, such as Adapter etc., are not covered by this Warranty
(f) Damage or Trouble by user’s fault, even undescribed in this Warranty
3. This warranty is not reissued. Please keep this with care.
※ Your personal information provided by you is used for free repair service within the period of warranty and
safety check service after expiry of warranty period.
Customer Information
Name :
Contact :
Address :
Purchase date :
Dealer/Store
□ Online
Website :
Seller name or Seller id :
□ Offline
Store name :
Branch name :
Warranty period 12 months from the date of purchase Date of Purchase . .
Product name
Homeguard
EEH-E11111
Sterilize, Deodor
Input AC 100~240V 50/60Hz
Output DC 9V 3A
Rated 27W
Pitcher (1000ml), Spray (300ml)
104 x 104 x 70 (mm)
112 x 160 x 251 (mm)
52 x 80 x 247 (mm)
Base Station :
Pitcher :
Spray :
240g
360g
95g
Base Station :
Pitcher :
Spray :
PC + SAN
ABS
PP + PET
Base Station :
Pitcher :
Spray :
This manual suits for next models
