Feider Machines ONYX User manual

ORIGINAL INSTRUCTIONS >EN
ASH VACUUM
ONYX
INSTRUCTION MANUAL
CAUTION: Read the instructions before using this product!

2
CONTENTS
1. SAFETY INSTRUCTIONS 3
2. PRODUCT DESCRIPTION 7
3. INTENDED USE 7
4. TECHNICAL DATA 8
5. BEFORE STARTING THE APPLIANCE 8
6. OPERATION 10
7. CLEANING AND MAINTENANCE 10
8. DISPOSAL AND RECYCLING 10
9. WARRANTY 11
10. PRODUCT FAILURE 12
11. WARRANTY EXCLUSIONS 13

3
1. SAFETY INSTRUCTIONS
IMPORTANT!
When using the appliance, a few safety precautions
must be observed to avoid injuries and damage. Please
read the complete operating instructions with due care.
Keep this manual in a safe place, so that the information
is available at all times. If you give the appliance to any
other person, hand over these operating instructions as
well.
We cannot accept any liability for damage or accidents
which arise due to a failure to follow these instructions
and the safety instructions.
CAUTION
Read all safety regulations and instructions. Any
failures made in following the safety regulations and
instructions may result in an electric shock, fire and/or
serious injury.
Keep all safety regulations and instructions in a safe
place for future use.
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance

4
shall not be made by children without supervision.
⚫IMPORTANT:Read the operating instructions before
assembling and using the appliance for the first time.
⚫Check that the mains voltage is the same as the
mains voltage specified on the rating plate.
⚫Pull out the power plug in the following circumstances:
Whenever the appliance is not in use, before opening
the appliance and before all cleaning and
maintenance work.
⚫Never clean the appliance with solvents.
⚫Never pull the plug out of the socket by pulling the
cable.
⚫Never leave the appliance unattended when
operational.
⚫Keep away from children.
⚫Take care to ensure that the power cable does not get
damaged by being run over, crushed, pulled or
suchlike.
⚫Do not use the machine if the power cable is in a less
than perfect condition.
⚫If the power cable has to be replaced, the replacement
must comply with the design specifications of the
manufacturer. Power cable: H05 VV - F 2 x 0,75 mm2
⚫Never vacuum the following: Burning matches,
smoldering ash and cigarette butts, combustible,
caustic, inflammable or explosive substances, vapour
or liquids.

5
⚫This appliance is not suitable for vacuuming dust
which can be harmful to health.
⚫Store the appliance in a dry indoor location.
⚫Never use the appliance if it is damaged.
⚫Only allow the appliance to be serviced by an
authorized customer service center.
⚫Only use the appliance to carry out work for which has
been designed.
⚫Use only genuine accessories and spare parts.
⚫The guidelines in the operating instructions must be
observed. The safety and accident-prevention
regulations from the lawgiver are also to be observed.
⚫IMPORTANT!Hazardous material must not be extracted
with the ash filter.
⚫Do not extract ashes from prohibited fuels.
⚫Do not use the ash filter to extract hot, glowing or
inflammable objects (e.g. charcoal, cigarettes ...).
⚫IMPORTANT.The ash vacuum cleaner is not suitable
for vacuuming soot or fine dust.
⚫IMPORTANT!The extracted material must not exceed a
temperature of 40°C.
⚫IMPORTANT!If this temperature of the extracted
material exceeds 40°C, there is a risk of fire.
⚫IMPORTANT!If the permissible temperature is
exceeded, the extractor, the ash filter and the hoses
could be damaged.
⚫IMPORTANT!Extracted material which looks as though

6
it has cooled off on the outside may still be hot on the
inside. Hot extracted material could be set alight again
in the air current.
⚫Before beginning extraction, please wait until the
material is completely cooled off. Hot ashes should
not be purged with water, as the sudden temperature
difference can cause ruptures to the chimney.
⚫Wait at least 24 hours before vacuuming an oven or a
fireplace in order to be sure that the fire has gone out
and the ash has cooled down.
⚫Check the hoses, the ash filter and the extractor
regularly when extracting, to assess levels of heating.
⚫If the appliance heats up, switch it off, pull the mains
plug out and remove the filter bag immediately.
Separate the ash filter from the extractor and remove
the extracted material. Next, let the extractor and the
ash filter cool off outside, under supervision.
⚫If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
⚫Cold ash is ash which has cooled for a sufficiently long
time and no longer contains any glowing embers. This
can be checked by combing through the ash with a
metal object before you use the ash vacuum cleaner.
Cold ash no longer radiates any perceivable heat.
⚫After and before vacuum cleaning, empty and clean
the tank in order to prevent the

7
accumulation of materials which could present a fire
hazard in the vacuum cleaner.
⚫The plug must be removed from the socket-outlet
before cleaning or maintaining the appliance.
2. PRODUCT DESCRIPTION
1. Handle
2. On/Off switch
3. Appliance head
4. Locking hook
5. Tank
6. Flexible hose
7. Hose connector
8. Ø40mm x23CM aluminum tube
9. Cartridge filter
10. Blowing hole
11. Wheel
3. INTENDED USE
The ash vacuum cleaner is suitable for vacuuming cold ash or cold material residues from
fireplaces, charcoal ovens, ash-trays or barbecues.
The machine is to be used only for its prescribed purpose. Any other use is deemed to be a case of
misuse. The user/operator - not the manufacturer - will be liable for any damage or injuries caused
as a result thereof.
Please note that our appliance has not been designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the appliance is used in commercial, trade or industrial
businesses or for equivalent purposes.
2
1
3
4
5
6
8
7
7
10
9
3
11

8
4. TECHNICAL DATA
Mains voltage: 220-240V~ 50/60Hz
Model
Power input:
Tank volume:
Weight:
ONYX
1000W
18 L
3,2/4 KG
Suction:
Hose:
Hose diameter:
Power cable:
16 Kpa
1 m
30 mm
2 m
5. BEFORE STARTING THE APPLIANCE
IMPORTANT!
⚫Before you connect the appliance to the mains supply make sure that the data on the rating
plate are identical to the mains data.
⚫The appliance may only be connected to a shockproof socket.
5.1 UNPACKING
1) Unpack all parts and lay them on a flat stable surface
2) Make sure the delivery contents are complete and free of damage. If you find that parts are
missing or show damage, do not use the product but contact your dealer/service centre. Do
not use the product unless missing parts have been delivered in addition or defective parts
have been replaced. Using an incomplete or damaged product represents a hazard to people
and property.
3) Ensure that you have all the accessories and tools needed for assembly and operation.
5.2 SCOPE OF THE DELIVERY
Carefully unpack the cordless drill and check that it is complete:
1) 1pc ash cleaner (18L tank, 1pc HEPA filter and appliance head included)
2) 1pc 1M flexible hose
3) 1pcs Ø40mm x23CM aluminum tube
4) 1pc 2m cable
5) 3 wheels
6) 2pc manuals
7) 1pc SWAP leaflet
5.3 ASSEMBLING THE APPLIANCE
⚫The appliance head (3) is fastened to the tank (5) by the locking hook (5). To remove the
appliance head (3), open the locking hook (4) and remove the appliance head (3). When fitting
the appliance head (3), make sure that the locking hook (4) locks into place correctly.

9
⚫Fit the Hose connector (7) into the suction hole on the tank and turn until securely attached.
⚫Assemble the wheels at 3 equational position of the tank bottom.
⚫Disassembly/ Assembly of the filter
IMPORTANT!
Never use the ash vacuum without the filter!
Always ensure that the filters are perfectly secure.
The filter was assembled before shipment, to change /disassemble the filter, hold on appliance
head then take off the filter.
To assemble a filter, push the cartridge filter (9) onto the appliance head (3)

10
6. OPERATION
6.1 ON/OFF switch
Press the ON/OFF switch (2) to switch the equipment ON and OFF.
6.2 Vacuuming
Fit the Hose connector (7) into the suction hole on the tank and turn until securely attached.
Important!
The ash vacuum cleaner is not suitable for the vacuuming of combustible materials!
6.3 Blowing
⚫Fit the Hose connector (7) into the blowing hole(10) on the tank and turn until securely
attached.
7. CLEANING AND MAINTENANCE
IMPORTANT!
Always pull out the mains power plug before starting any cleaning work.
7.1 Cleaning
Keep all safety devices, air vents and the motor housing free of dirt and dust as far as
possible.
We recommend that you clean the appliance immediately after you use it.
7.2 Cleaning the appliance head (3)
Clean the appliance regularly with a damp cloth and some soft soap. Do not use cleaning agents or
solvents; these may be aggressive to the plastic parts in the appliance.
7.3 Cleaning the tank (5)
The tank can be cleaned with a damp cloth and some soft soap or under running water, depending
on the amount of dirt.
7.4 Cleaning the filter (9)
Clean the cartridge filter (9) e.g. by tapping and brushing or by blowing out with compressed air at
low pressure.
7.5 Servicing
At regular intervals and before each use, check that the filters in the ash vacuum are securely fitted.
7.6. Ordering spare parts
Please provide the following information on all orders for spare parts:
⚫Model/type of the appliance
⚫Part number of the required spare part.
8. DISPOSAL AND RECYCLING
The appliance is supplied in packaging to prevent its being damaged in transit. This
packaging is raw material and can therefore be reused or can be returned to the raw
material system. The appliance and its accessories are made of various types of material,
such as metal and plastic. Defective components must be disposed of as special waste.
Ask your dealer or your local council.

11
9. WARRANTY
The manufacturer guarantees the product against defects in material and workmanship for a period
of 2 years from the date of the original purchase. The warranty only applies if the product is for
household use. The warranty does not cover breakdowns due to normal wear and tear.
The manufacturer agrees to replace parts identified as defective by the designated distributor. The
manufacturer does not accept responsibility for the replacement of the machine, in whole or in part,
and/or ensuing damage.
The warranty does not cover breakdowns due to:
insufficient maintenance.
abnormal assembly, adjustment or operations of the product.
parts subject to normal wear and tear.
The warranty does not extend to:
shipping and packaging costs.
using the tool for a purpose other than that for which it was designed.
the use and maintenance of the machine done in a manner not described in the user manual.
Due to our policy of continuous product improvement, we reserve the right to alter or change
specifications without notice. Consequently, the product may be different from the information
contained therein, but a modification will be undertaken without notice if it is recognized as an
improvement of the preceding characteristic.
READ THE MANUAL CAREFULLY BEFORE USING THE MACHINE.
When ordering spare parts, please indicate the part number or code, you can find this in the spare
parts list in this manual. Keep the purchase receipt; without it, the warranty is invalid. To help you
with your product, we invite you to contact us by phone or via our website:
+33 (0)9.70.75.30.30
https://services.swap-europe.com/contact
You must create a "ticket" via the web platform.
Register or create your account.
Indicate the reference of the tool.
Choose the subject of your request.
Describe your problem.
Attach these files: invoice or sales
receipt, photo of the identification plate
(serial number), photo of the part you
need (for example: pins on the
transformer plug which are broken).

12
10. PRODUCT FAILURE
WHAT TO DO IF MY MACHINE BREAKS DOWN?
If you bought your product in a store:
•Make sure that your machine is complete with all accessories supplied, and clean! If this is not
the case, the repairer will refuse the machine.
•Go to the store with the complete machine and with the receipt or invoice.
If you bought your product on a website:
•Make sure that your machine is complete with all accessories supplied, and clean! If this is not
the case, the repairer will refuse the machine.
•Create a SWAP-Europe service ticket on the site: https://services.swap-europe.com When
making the request on SWAP-Europe, you must attach the invoice and the photo of the nameplate
(serial number).
Contact the repair station to make sure it is available before dropping off the machine.
Go to the repair station with the complete machine packed, accompanied by the purchase invoice
and the station support sheet downloadable after the service request is completed on the
SWAP-Europe site
Please keep your original packaging to allow for after-sales service returns or pack your
machine with a similar cardboard box of the same dimensions.
For any question concerning our after-sales service you can make a request on our website
https://services.swap-europe.com
Our hotline remains available at [phone].

13
11. WARRANTY EXCLUSIONS
THE WARRANTY DOES NOT COVER:
•Start-up and setting up of the product.
•Damage resulting from normal wear and tear of the product.
•Damage resulting from improper use of the product.
•Damage resulting from assembly or start-up not in accordance with the user manual.
•Breakdowns related to carburetion beyond 90 days and fouling of carburetors.
•Periodic and standard maintenance events.
•Actions of modification and dismantling that directly void the warranty.
•Products whose original authentication marking (brand, serial number) has been degraded,
altered or withdrawn.
•Replacement of consumables.
•The use of non-original parts.
•Breakage of parts following impacts or projections.
•Accessories breakdowns.
•Defects and their consequences linked to any external cause.
•Loss of components and loss due to insufficient screwing.
•Cutting components and any damage related to the loosening of parts.
•Overload or overheating.
•Poor power supply quality: faulty voltage, voltage error, etc.
•Damages resulting from the deprivation of enjoyment of the product during the time necessary
for repairs and more generally the costs related to the immobilization of the product.
•The costs of a second opinion established by a third party following an estimate by a
SWAP-Europe repair station
•The use of a product which would show a defect or a breakage which was not the subject of an
immediate report and/or repair with the services of SWAP-Europe.
•Deterioration linked to transport and storage*.
•Launchers beyond 90 days.
•Oil, petrol, grease.
•Damages related to the use of non-compliant fuels or lubricants.
* In accordance with transport legislation, damage related to transport must be declared to carriers
within 48 hours maximum after observation by registered letter with acknowledgement of receipt.
This document is a supplement to your notice, a non-exhaustive list.
Attention: all orders must be checked in the presence of the delivery person. In case of refusal by
the delivery person, it you must simply refuse the delivery and notify your refusal.
Reminder: the reserves do not exclude the notification by registered letter with acknowledgement
within 72 hours.
Information:
Thermal devices must be wintered each season (service available on the SWAP-Europe site).
Batteries must be charged before being stored.

BUILDER SAS
32, rue Aristide Bergès - ZI 31270 Cugnaux –France
Made in PRC 2022
