Ferono FSS User manual

Axial fan installation direction
FSS
English
FST
www.ferono.pl

Installation and importance
1. When installing and carring,be carefull not deform to the impeller. If the blades are deformed,it will be unbalanced and cause noise and
vibration.
2. Fans can be mounted to a window, ceiling or wall,The fan is intended for mounting in outside windows or walls.Install the fan on a solid
surface,like a wall column or other solid wood.
3. Precautions must be taken to avoid the back-ow of gases into the room from the open ue of gas or other fuel-burning appliances.
4. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children
without supervision.
5. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible
for their safety.Children should be supervised to ensure that they do not play with the appliance.
Caution on installation
Do not install in the following ares:
1. A place of frequent vibration or where vibration easily occurs.(Installation has to be a sound place where there is no vibration.)
2. A place where the temperature is too low and high.
3. A place where there is corrosive gas or use of chemical products.
4. A place where there is explosive duct or gas or where it may occur.
5. A place where there is signicant humidity over 90% of humidity.
Installation
1. When installing and carring,be carefull not deform to the impeller.If the blades are deformed,it will be unbalanced and cause noise and
vibration.
2. Fan can be mounted to a oor,ceiling or wall.Install the fan on a solid surface,like a wall column or other solid wood. Do not install it on a
unstable surface like sheetrock.
Drawing and dimensions
English

Model A
(mm)
B
(mm)
C
(mm)
D
(mm)
E
(mm)
F
(mm)
G
(mm)
FSS250 92 250 270 70 95 4320
FST250 92 250 270 70 95 4320
FSS300 92 300 320 80 116 4 360
FST300 92 300 320 80 116 4 360
FSS350 102 350 370 80 130 6 422
FST350 102 350 370 80 130 6460
FSS400 102 400 420 90 135 6 470
FST400 102 400 420 90 135 6 500
FSS450 102 450 470 90 147 6 522
FST450 102 450 470 90 147 6 540
FSS500 138 500 520 90 158 6 570
FST500 138 500 520 90 158 6 570
FSS550 136 550 570 100 160 6 675
FST550 138 550 570 100 173 6 622
FSS630 136 630 650 100 185 7,8 775
FST630 138 630 650 100 193 7,8 750
Maintenance
• Before cleaning the fan,disconnect the power cord.
• Make periodic cleaning on ring & fan impeller.
Wiring diagram
English
Wiring diagram FST350,
FST400, FST450
MOTOR
Red
Blue
Yellow
N
L
Yellow-Green
Wiring diagram FSS550
MOTOR
Brown
Blue
Black
L2
N
Yellow-Green
Wiring diagram FSS630
MOTOR
Black
Black
Black
L3
L1
Yellow-Green
L2
L1
