Festool TDK 12 User manual

Bedienungsanleitung Akku-Bohrschrauber 4 - 7
Operating Instructions Cordless Drill/Screwdriver 8 - 11
Mode demploi Perceuse visseuse á accumulateur 12 - 15
Instrucciones de servicio Taladradora-atornilladora con acumuladores 16 - 19
Istruzioni duso Trapano-avvitatrice a batteria 20 - 23
Gebruiksaanwijzing Accu-schroefboormachine 24 - 27
Bruksanvisning Ackumulatordriven-borrskruvdragare 28 - 31
Käyttöohje Akkukäyttoinen ruuviporakone 32 - 35
Driftsvejledning Akku-boreskruemaskine 36 - 39
Bruksanvisning Akkumulator-boreskrujern 40 - 43
Instruções de uso Furadeiras parafusadeiras com acumulador 44 - 47
Ðóêîâîäñòâî ïî ýêñïëóàòàöèè Àêêóìóëÿòîðíûå äðåëü-îòâ¸ðòêè 48 - 51
Návod k obsluze Akumulátorové vrtaèky+roubováky 52 - 55
Instrukcja obs³ugi Akumulatorowe wiertarko-wkrêtarki 56 - 59
Kezelési utasítás Akku-fúró-csavarozó 60 - 63
Ïäçãßá ëåéôïõñãßáò Âéäïôñýðáíá óõóóùñåõôþí 64 - 68
Festool GmbH Wertstr. 20 D-73240 Wendlingen ( 07024/804-0
463 971_004
TDK 12
TDK 15.6
Seen at Ideal Tools.

Seen at Ideal Tools.

Seen at Ideal Tools.

4
Technische Daten
Akku-Bohrschrauber TDK 12 TDK 15.6
Motorspannung 12 V 15,6 V
Leerlaufdrehzahl
1. Gang 0 - 430 m n-1 0 - 450 min-1
2. Gang 0 - 1400 min-1 0 - 1500 min-1
Drehmoment max.
weicher Schraubfall (Holz) 20 Nm 25 Nm
harter Schraubfall (Metall) 28 Nm 3 Nm
Drehmoment einstellbar
1. Gang 2 - 7 Nm 2 - 7 Nm
2. Gang 0,5 - 2,5 Nm 0,5 - 2,5 Nm
Bohrfutter-Spannbereich 1,5 - 13 mm 1,5 - 13 mm
max. Bohrdurchmesser in Holz 25 mm 35 mm
max. Bohrdurchmesser in Metall 14 mm 1 mm
Werkzeugaufnahme in Bohrspindel 1/4  1/4 
Gewicht mit Akku 2,0 kg 2,3 kg
Ladegerät LC 45
Netzspannung (Eingang) 230 -240 V~
Netzfrequenz 50/60 Hz
Ladespannung ( usgang) 7,2 - 18 V=
Ladestrom 3
Schnellladung max. 3
Erhaltungsladung pulsierend ca. 0,06
Ladezeit für
NiCd 2,0 h ca. 45 min
NiCd 2,4 h ca. 50 min
NiMH 3,0 h ca. 70 min
Akkupack BPS 12 NiCd 2.4 BPS 12 NiMH 3.0
Bestellnummer 492 268 491 821
Spannung 12 V 12 V
Kapazität 2,4 Ah 3,0 Ah
La etemperaturbereich 5 - 45° C 5 - 45° C
Temperaturüberwachung m i t t e l s N T C - W i e r s t a n
Gewicht 0,73 kg 0,75 kg
Akkupack BPS 15.6 NiCd 2.4 BPS 15.6 NiMH 3.0
Bestellnummer 492 269 491 823
Spannung 15,6 V 15,6 V
Kapazität 2,4 Ah 3,0 Ah
adetemperaturbereich 5 - 45° C 5 - 45° C
Temperaturüberwachung m i t t e l s N T C - W i d e r s t a n d
Gewicht 0,9 kg 0,92 kg
Die angegebenen Abbildungen befinden sich am Anfang dieser Bedienungsanleitung.
Seen at Ideal Tools.

8
Technical data
Cordless drill/screwdriver TDK 12 TDK 15.6
Motor voltage 12 V 15.6 V
Idle-running speed
1. Speed 0 - 430 rpm 0 - 450 rpm
2. Speed 0 - 1400 rpm 0 - 1500 rpm
Max torque
So t boring (wood) 20 Nm 25 Nm
Hard boring (metal) 28 Nm 36 Nm
Adjustable torque
1. Speed 2 - 7 Nm 2 - 7 Nm
2. Speed 0.5 - 2.5 Nm 0.5 - 2.5 Nm
Chuck capacity 1.5 - 13 mm 1.5 - 13 mm
Max. drill diameter or wood 25 mm 35 mm
Max. drill diameter or metal 14 mm 16 mm
Tool itting in chuck 1/4  1/4 
Weight with battery pack 2.0 kg 2.3 kg
Charger LC 45
Supply voltage (input) 230 - 240 V~
Line frequency 50/60 z
Charging voltage (output) 7.2 - 18 V=
Charging current 3 A
Quick charge max. 3 A
Compensation charge pulsating app. 0.06 A
Charging time for
NiCd 2.0 Ah app. 45 min
NiCd 2.4 Ah app. 50 min
NiM 3.0 Ah app. 70 min
Battery pack BPS 12 NiCd 2.4 BPS 12 NiMH 3.0
Order number 492 268 491 821
Voltage 12 V 12 V
Capacity 2.4 Ah 3.0 Ah
emp. range for charging 5 - 45° C 5 - 45° C
emperature monitoring u s i n g N C r e s i s t o r
Weight 0.73 kg 0.75 kg
Battery pack BPS 15.6 NiCd 2.4 BPS 15.6 NiMH 3.0
Order number 492 269 491 823
Voltage 15.6 V 15.6 V
Capacity 2.4 Ah 3. Ah
Temp. range for charging 5 - 45° C 5 - 45° C
Temperature monitoring u s i n g N T C r e s i s t o r
Weight .9 kg .92 kg
The specified illustrations can be found at the beginning of the operating instructions.
Seen at Ideal Tools.

9
1 Before starting up, please observe
the following
1.1 Intended use
Cordless drills are suitable for drilling metal,
wood, plastics and similar materials, as well as
tightening and screwing in screws (into wood,
up to a diameter of 6 mm).
The LC 45 battery charger is designed for
recharging the battery pac listed.
The user is liable for damage and injury
resulting from incorrect usage!
1.2 Safety instructions
Before using the machine, please read
the enclosed safety instructions.
1.3 Noise and vibration information
Cordless drill/screwdriver
The typical values determined in accordance
with EN 50144 are:
Sound pressure level 72 dB A)
Measured acceleration <2.5 m/s²
The noise level can exceed 85 dB A)
during operation.
Wear ear protection!
1.4 Wall mounting LC 45
The charger LC 45 has two longitudinal slots
on its rear by which it can be suspended on
walls using two screws (e.g. button-headed
or flat head screw with a shaft diameter of
5 mm). Screw both screws into the wall 6 mm
apart until the screwhead is protruding from
the wall by approx. 4 mm.
2 Machine settings
Remove the battery pack before any
adjustments, maintenance or repair is carried
out!
2.1 Exchanging the battery pack
Removing battery pack
Press the two buttons (1.1) and slide the
battery pack forwards to remove.
Inserting battery pack
Slide the battery pack into the holder on the
underside of the handle until it latches into place
(see Fig. 1).
2.2 To change the direction of rotation
The selector button (1.4) determines the
direction of rotation.
Turn button from right to left = clockwise
rotation.
Turn button from left to right = anticlockwise
rotation.
Selector button in central position = circuit
interlock.
2.3 Shifting speeds
Change only when completely
stopped!
Using the shift lever (1.5), the speed can be
changed.
1. Speed: Lever forward - Figure 1 is visible.
2. Speed: Lever backwards - Figure 2 is visible.
2.4 Torque adjustment
By turning the adjustment ring (1.6) the
required torque can be adjusted. The arrow
(1.7) aligns with the adjusted state.
Drilling
Drilling symbol on adjustment ring aligns with
the arrow = maximum torque.
Screws
Torque corresponding to setting:
Position 1 = low torque
Position 20 = high torque
3 Tool holding fixture, attachments
3.1 Chuck BF-FX
The chuck is used to clamp drills and bits.
a) Fitting/removing the chuck
Fitting
- Place the chuck on the drill spindle (2.5) and
twist until the hexagon key (2.4) of the chuck
latches into the hexagon socket of the drill
spindle.
- Pull the unlocking ring (2.3) forwards, press
the chuck onto the drill spindle up to the stop
and release the unlocking ring.
Removal
- Pull the unlocking ring forwards and remove
the chuck.
b) Changing tools
- Turn the clamping sleeve (2.2) anti-clockwise
to open the clamping jaws (2.1) (Note: the
spindle is automatically locked when the
machine is switched off).
- Insert the tool into the chuck.
- Clamp the tool by turning the clamping sleeve
clockwise. Always make sure that the tool is
clamped centrally in the chuck.
3.2 Angle attachment DD-AS
The angle attachment permits work (drilling,
screwing) vertical to the machines longitudi-
nal axis.
a) Fitting/removing the angle
attachment
Fitting
- Place the angle attachment on the drill spindle
and turn until it catches in the desired position
(Note: The angle attachment can be fitted in
16 different angle settings).
- Lock the angle attachment by turning the
fastening ring (2.7) tightly clockwise.
Removal
- Turn the fastening ring anti-clockwise up to
the stop and remove the angel attachment.
Seen at Ideal Tools.

10
b) Fitting/removal of chuck on angle
attachment
The chuck is fitted on the shaft (2.6) of the
angle attachment in the same way as on the
drill spindle of the machine.
3.3 Eccentric attachment DD-ES
The eccentric attachment is used to hold bits.
It allows screwing close to edges.
a) Fitting/removing the eccentric
attachment
The eccentric attachment is fitted/removed in
the same was as the angle attachment (see
Chapter 3.2).
b) Changing tools
- Pull the unlocking ring (2.8) back and remove
the tool and/or insert the new tool.
3.4 CENTROTEC WH-CE toolholder
The CENTROTEC toolholder enables rapid
changes of tools with CENTROTEC shafts.
Do not fit CENTROTEC tools at the
round shaft section in a conventional
chuck to prevent damage to the shaft.
Danger of injury! When changing
tools, handle the tool and its sharp
cutters with special care and wear
protective gloves, if necessary.
a) Fitting/removing CENTROTEC
Fitting
- Pull the release ring (2.11) forwards, place
the toolholder as far as it will go on the drill
spindle (2.5) and let go of the release ring.
Removal
- Pull the release ring forwards and take off
the toolholder.
b) Changing tools
- To insert or remove a tool with CENTROTEC
shaft, pull the green release ring (2.10 back.
On inserting the tool, turn it until its hex shank
arbour (2.9 locks in place in the hexagonal
shank of the drill spindle, and push the tool
into the toolholder as far as it will go.
3.5 Tool holding fixture in the drill
spindle
Bits can be fitted directly in the hexagon socket
holder of the drill spindle (2.5) to make the
machine lighter and shorter.
4 Charge battery pack
To load the battery pack, push it into the hol-
der (3.1) on the charger up to the stop. Per-
form this in reverse to remove the battery pack
from the charger.
The battery type used ( iCd or iMH) is
detected automatically.
Charging is controlled by a microprocessor.
If a warm iMH battery pack (>37° C) is
inserted, charging will only be carried out at a
lower charge current. In this case, the charging
time is extended.
The LED (3.2) indicates the respective
charging state of the charger.
LED yellow  steady:
Charger is ready for use.
LED green  flashing:
Battery pack being charged.
LED green  steady:
Battery pack fully charged, conservation
charge on.
LED red  flashing:
General malfunction, e. g. full contact not
being made, short-circuit, battery pack faulty.
LED red  steady:
Temperature of battery pack is outside
permissible limit.
It is essential that you read the
instructions in the Chapter
Working instructions -
Maintenance - Care.
5 Working with the machine
5.1 Initial operation
Turn on by pressing button (1.3). Depending
on the pressure exerted on the button, the
adjustment of running speed can be varied
infinitely.
Turn off by releasing the button (1.3).
fter releasing the button, the chuck is stopped
and therefore, after-running of the equipment
is prevented.
5.2 Bit storage well
You can insert several bits or bit extensions
into the bit magazine (1.2) from the side.
The magnetic attachment allows you to pic
up screws and similar objects.
6 lnstructions on application -
maintenance - care
Please pay attention to the
following instructions. Otherwise
there is a risk of damage to the tool,
charger or battery pack.
- Repairs may only be performed by authorised
technicians. LC 45 charging device: Even after
disconnection from the mains, there is still a
high capacitor voltage on the po er output
component on the inside of the device.
- Keep the air vents of the electronic equipment
and the charger clean to guarantee the air
circulation for cooling.
- No metal objects (metal chips) should enter
the charger at the contact points as ell as
through the cooling slits into the equipment
(danger of short circuit).
- Only use original Festool battery packs.
Seen at Ideal Tools.

11
Do not use spent and recycled battery packs.
The user shall be liable for damages if Festool
original battery packs are not used.
- Keep the connection contacts of electronic
equipment, charger and battery pack clean.
- By keeping the battery pack in a ready for
use charger, the battery pack ill be kept in
a state of readiness by float charging
conservation.
- Do not keep discharged battery pack
(maximum one month) attached to charger
henever charger is detached from the
po er supply (danger of deep discharging).
- A ne battery pack or a battery pack not
used for a longer period of time reaches it
full capacity after about 5 charging and
discharging cycles.
- Battery packs should, before charging, be
fully discharged if possible.
Continuous starting of the charging process
shortens the lifespan of the batteries.
- A considerably reduced time of operation per
charging sho s that the battery pack is used
up an should be replaced by a ne one.
- NiCd battery packs that are not used for
longer periods should be stored in a
discharged state.
Special instructions for NiMH battery
packs:
- The output of NiMH battery packs drops
noticeably at ambient temperatures below
0° C or above 4 ° C.
- Do not overload the tool (do not load the
tool excessively so that it comes to a
standstill).
- Even if NiMH battery packs are not used,
recharge them approx. every 4 months so
that they retain their full capacity.
- NiMH battery packs should be left for 60 min.
in the charger after every 10th fast charge
to compensate any differences in capacity
between the cells.
- Because NiMH battery packs discharge
automatically, store them preferably at
ambient temperatures of between 0° C and
2 ° C.
6.1 Changing carbon brushes
If the carbon brushes have worn to a length of
less than 6 mm, this may reduce the
performance of the machine or cause the
machine to stop. In this case, the brushes (4.2)
should be replaced.
- nscrew the cover (4.4) and remove the
worn brushes.
- Push in the retaining plate (4.3) on the new
carbon brushes until it latches into the notches
(4.1) and screw the covers back on.
- Operate the machine in idling state for a few
minutes so that the carbon brushes attain
optimal contact.
7 Recycling battery packs
Never throw spent battery packs
into domestic waste containers!
Return spent or defective battery packs to
dealers, the Festool after-sales service
department or approved waste disposal
facilities. This ensures that they are correctly
recycled.
8 Warranty
Our equipment is under warranty for at least
12 months with regard to material or
production faults in accordance with national
legislation.
In the EU countries, the warranty period is 24
months (an in oice or deli ery note is required
as proof of purchase).
Damage resulting from, in particular, normal
wear and tear, o- erloading, improper handling,
or caused by the user or other damage caused
by not following the operating instructions, or
any fault acknowledged at the time of
purchase, is not co ered by the warranty.
Complaints will only be acknowledged if the
equipment has not been dismantled before
being sent back to the suppliers or to an
authorised Festool customer support
workshop.
Store the operating instructions, safety notes,
spare parts list and proof of purchase in a safe
place.
In addition, the manufacturers current
warranty conditions apply.
Note
We reserve the right to make changes to the
technical data contained in this information as
a result of ongoing research and development
work.
Seen at Ideal Tools.

69
CE-Konformitetserklæring. Vi erklærer på eget
ansvar at dette produktet er i overensstemmelse med
følgende normer eller normative dokumenter: EN 50 44,
EN 55 0 4, EN 6 000 i henhold til bestemmelsene i direktivene
98/37/EF, 89/336/EØF.
EG-Konformitätserklärung. Wir erklären in alleiniger
Verantwortung, dass dieses Produkt mit den
folgenden Normen oder normativen Dokumenten
übereinstimmt:
EN 50 44, EN 55 0 4, EN 6 000 gemäß den Bestimmungen
der Richtlinien 98/37/EG, 89/336/EWG.
455 789/200803
EY-standardinmukaisuusvakuutus. Vakuutamme
yksinvastuullisina, että tuote on seuraavien
standardien ja normatiivisten ohjeiden mukainen: EN 50 44,
EN 55 0 4, EN 6 000 direktiivien 98/37/EY, 89/336/EY
määräysten mukaan.
EG-konformitetsförklaring. Vi förklarar i eget ansvar,
att denna produkt stämmer överens med följande
normer och normativa dokument: EN 50 44, EN 55 0 4,
EN 6 000 enligt bestämmelserna i direktiven 98/37/EG,
89/336/EEG.
EG-conformiteitsverklaring. Wij verklaren op eigen
verantwoordelijkheid dat dit produkt voldoet aan de
volgende normen of normatieve documenten. EN 50 44,
EN 55 0 4, EN 6 000 conform de richtlijnen 98/37/EG,
89/336/EEG.
CE-Dichiarazione di conformità. Dichiariamo sotto
la nostra esclusiva responsabilità che il presente
prodotto è conforme alle norme e ai documenti normativi
seguenti: EN 50 44, EN 55 0 4, EN 6 000 conformemente
alle normative delle direttive 98/37/CE, 89/336/CEE.
Owiadczenie o zgodnoci CE. Niniejszym
owiadczamy z ca³¹ odpowiedzialnoci¹, ¿e wyrób
ten odpowiada nast puj¹cym normom wzgl dnie dokumentom
normatywnym: EN 50 144, EN 55 014, EN 61 000 zgodnie z
postanowieniami wytycznych 98/37/EG, 89/336/EWG.
Äçëùóç óõììüñöùóçò ÅÊ. Ìå áíÜëçøç ôçò
óõíïëéêÞò åõèýíçò äçëþíïõìå, üôé ôï áñüí ñïéüí
óõìöùíåß ìå ôá áñáêÜôù ñüôõ á êáé ìå ôá
ñüôõ á ïõ áíáöÝñïíôáé óôá ó÷åôéêÜ Ýããñáöá ÅÍ 50 144,
ÅÍ 55 014, EN 61 000 óýìöùíá ìå ôïõò êáíïíéóìïýò
98/37ÅÊ, 89/336/ÅÏÊ
CE-konformitás-nyilatkozat.Kizárólagos
felelõsségvállalás mellett ezennel tanúsítjuk, ogy
a jelen termék megfelel az alábbi szabványoknak ill.
szabványdokumentációnak: EN 50 144, EN 55 014,
EN 61 000 a 98/37EG, 89/336/EWG irányvonalak
rendelkezései szerint.
Leiter Forschung und Entwicklung
Manager Research and Development
Directeur de recherce et développement
Festool GmbH
Wertstr 20
D-73240 Wendlingen
Dr Johannes Steimel
EC-Declaration of Conformity: We declare at our sole
responsibility that this product is in conformity with
the following standards or standardised documents:
EN 50 144, EN 55 014, EN 61 000 in accordance with the
regulations 98/37/EC, 89/336/EEC
CE-Declaração de conformidade: Declaramos, sob
a nossa exclusiva responsabilidade, que este
produto corresponde às normas ou aos documentos
normativos citados a seguir:
EN 50 144, EN 55 014, EN 61 000 segundo as disposições
das directivas 98/37/CE, 89/336/CEE
CE-Déclaration de conformité communautaire Nous
déclarons sous notre propre responsabilité que ce
produit est conforme aux normes ou documents de
normalisation suivants: EN 50 144, EN 55 014, EN 61 000
conformément aux prescriptions des directives 98/37/CE,
89/336/CEE
Çàÿâëåíèå î êîíôîðìíîñòè ÑÅ. Ìû çàÿâëÿåì â
åäèíîëè÷íîé îòâåòñòâåííîñòè, ÷òî äàííîå èçäåëèå
ñîîòâåòñòâóåò òðåáîâàíèÿì ñëåäóþùèõ ñòàíäàðòîâ èëè
íîðìàòèâîâ EN 50 144, EN 55 014, EN 61 000 â ñîîòâåòñòâèè
ñ ïîñòàíîâëåíèÿìè äèðåêòèâ ÅÑ 98/37, ÅÝÑ 89/336.
CE-Declaración de conformidad. Declaramos bajo
nuestra exclusiva responsabilidad que este
producto corresponde a las siguientes normas o documentos
normalizados: EN 0 144, EN 014, EN 61 000 conforme a
las prescripciones estipuladas en las directrices 98/37/CE,
89/336/CEE.
Prohláení o souladu s normami CE. Prohlaujeme
na vlastní zodpovìdnost, e tento výrobek odpovídá
následují ím normám nebo normativním dokumentùm:
EN 50 144, EN 55 014, EN 61 000 v souladu s ustanoveními
smìrni 98/37/EHS, 89/336/EHS.
EF-konformitetserklæring: Vi erklærer at have alene
ansvaret for, at dette produkt er i overensstemmelse
med de følgende normer eller normative dokumenter:
EN 50 1 , EN 55 01 , EN 61 000 i henhold til bestemmelserne
af direktiverne 98/37/EF, 89/336/EØF.
Seen at Ideal Tools.

Festool GmbH
Postfach 1163
D-73236 Wendlingen
Wertstraße 20
D-73240 Wendlingen
)(07024) 804-0
Fax [phone]
http://www.festool.com
Seen at Ideal Tools.
