Fetco EXTRACTOR CBS-1131V+ Operating instructions

[phone] [phone] [e-mail] www.fetco.com
© 2008-2018 Food Equipment Technologies Company Part # P172 January 2018
FETCO®, EXTRACTOR® and V+ are trademarks or trade names of Food Equipment Technologies Company.
CBS-1100V+
™
Programming Guide
Models:
CBS-1131V+; CBS-1132V+
CBS-1151V+; CBS-1152V+

PROGRAMMING MENU LAYOUT CBS V+ Series
[A] PROGRAM [B] GENERAL [C] INPUTS [D] OUTPUTS [E] OTHER
Batch A1. to A7 B1.0 to B1.7 C1.0 to C1.3 D1.0 to D1.5 E1.0 to E1.8
| | | | |
A
10 PERMANENT | | | |
Position A10&A40 are permanent
|
| | | |
A
11 Brew Volume B1 Tank Temp C1 LLC Probe D1 Test Heater E1 Display Firmware
| | | | |
A12 Brew Time B2 [Brew at Temp] C2 B. Basket Sensor D2 Test Fill Valve E2 Sel. Brewer Model
| | | | |
A13 Prewet Percent B3 LLC Sensitivity C3 Tank water temp. D3 Test R. Brew Valve E3 Display Errors
| | | | |
A_4 Prewet Delay
(
onl
y
when prewet % >0%
)
B4 Temperature F/ C C4 Keypad Test D4 Test L. Brew Valve E4 Clear Errors
| | | |
A16 Drip Delay B5 Volume unit G or L D5 Screen Brightness E5 Reload Defaults
| | |
A20 Batch ACTIVATE? B6 Left Flow Rate E6 Save to USB
| | |
A
30 Batch
A
CTIVATE? B7 Right Flow Rate E7 Load through USB
| | |
A
40 PERMANENT B8 Slow Mains Flow E8 Demo Mode
|
A50 Batch ACTIVATE?
|
A60 Batch ACTIVATE?
|
A
70 Recipe Copy?
Use this chart to quickly locate and access programming topics.
The topics are in groups A-E in this guide.
“F” screen is Save and Exit
Check the user guide for more comprehensive details of the brewer settings.
User guides are located online at fetco.com in Service-Resources….or use our QR code
Scroll Across
(A
-F
)
Scroll Down
(
1-8
)

Popular Operator Control Settings Default Settings-(Factory Settings)
Parameter Name CBS-1131V+
CBS-1132V+ CBS-1151V+ CBS-1152V+
A11 Brew Volume 3 LTR 1.5 GAL
A12 Brew Time (Min:Sec) 4:00 4:00
A13 Prewet Percent 0% 0%
A14 Prewet Delay (Min:Sec)
This appears only when Prewet >0% 1:00 1:00
A16 Drip Delay (Min:Sec) 1:30 1:30
B1 Hot Water Tank Temp. 200 F 200 F
B2 Brew at Set Temperature “YES” [ON] “YES” [ON]
B3 LLC Sensitivity (See User Guide) “LOW” LOW”
B4 Temperature Scale F F
B5 Water Volume Scale Liters Gallons
B6 & B7 Brew Valve Flow Rate 1.55 LPM 3.40 LPM
FLOW rate is in Liters/Min even if brewer is in Gallons
A(20, 30&50,60) Batch Activate
[Batches on buttons 2&3 and 5&6 if dual] Yes-Active Yes-Active
Go to Parameter E5 to reset all settings to factory defaults.

HOW TO ENTER PROGRAMMING MODE TO ACCESS CONTROLS AND DIAGNOSTICS
1)Turn the brewer off by pressing the power switch.
2
)
Turn power switch “ON”
-The display will progress through startup screens.
Example:
Brewer and version code
-The STOP button will illuminate. As shown—right
3
)
-Quickl
y
press the STOP button
(
no need to hold
)
-Brewer is now in PROGAMMING MODE…
4)Press the STOP button to advance the menus
across the top A-F and back to START (“A”)
5)Press 1to enter menus for individual settings under letter
NOTE: Buttons li
g
ht up onl
y
when the
y
are available to make ad
j
ustment
Batch Settin
g
s
A
dvance through settings
The menu topics are numbered A1-A7; B1-B8 -etc…
-Press button 1to select recipe programming
Position name, topic & reference position show in display.
-Toggle buttons 2and 3to make changes.
-Then press button 1 to advance to next programming topic.
CBS-1132V+
v 1 . 0. 1744
BREW VOLUME
A11 3.00 L ±
First programming position
A11 is shown in example
CBS-1132V+
2
STOP
STOP
3
1
CBS-1132V+
1
2
STOP STOP
DISPLAY
Menu Topic
A
-F
Menu Position
1-7
Toggle Setting
UP or [YES] 3
Toggle Setting
DOWN or [NO]

To change recipes Illustration shows each recipe batch position
All recipe programming is made from the “A” screens
TO ACCESS BATCH RECIPES:
-Enter “A”-BATCH PRG
-Press button “A10” to scroll through the parameters
Press “STOP” to scroll across the other recipe buttons
Single brewer has 3 recipes. Twin brewer has 6 recipes
-All recipe settings are programmed from the “A” screen.
Each recipe button may be individually programmed.
Top recipe buttons (A10&A40) are permanent. Lower recipe buttons
(A20, A30&A50, A60 if dual can be hidden. To hide or deactivate a
button: toggle the BATCH ACT screen.
A11 screen sets the total brew volume
Note
: some water is retained in the used coffee grounds
-Scroll down (press button A10) to the next setting A12 to set brew time to
dispense the volume set in A11.
Note: goes to default setting if set too short for volume entered
- Press A10 button continue scrolling down through A13-A15 for all
recipes. (See user guide for detailed explanation of each parameter)
CBS-1132V+
A20
STOP STOP
A50
A30 A60
A
10
A40
BREW VOLUME
A11 3.00 L ±First programming position
A11 is shown in example
BREW TIME
A12 04:00 ±Second programming position
A12 is shown in this example
BATCH ACT
A20 YES –Toggle to NO to deactivate
or hide lower recipes

-After all brew recipes are set press STOP button to go to–GENERAL “B”
B1 is Tank Temperature
This controls the brew water temperature and the hot water service faucet
Toggle buttons A20 and A30 to make changes
Then press A10 to advance
B2 is Brew at Temperature
Default is YES. Brew will not start until
hot water tank temperature is at setpoint.
If Brew at Temp is set to “NO”-brew will start at any temperature above
77°C/170°F. Toggle buttons A20 & A30 to adjust
Then press A10 to advance
-Following the PROGRAMMING MENU LAYOUT chart shown on page 2
Complete your adjustments in the GENERAL –“B” parameter
- Settings found under BATCH PROGRAM “A” GENERAL “B include most
needed for start-up and operation.
-Always verify the model number (displayed when brewer first powered
ON). Model selection is found in E2
-Always SAVE & EXIT as shown in screen “F” or new settings will be lost.
Press A10 to advance though the settings to change or check settings
-then press STOP to continue scrolling across C-E positions
Tank Temp
B1 200F ±
First programming position “B1”
Is for hot water tank temperature
Brew @ Temp
B2 YES -
Brew pauses & will start when hot
water tank temp. is at setpoint

Batch Parameters –A-MENU and PROGRAMMING
Brewers are shipped with all recipe batch buttons enabled and set to the defaults shown in A1-A6.
These are full batches. Adjust settings of the individual recipes under batch PRG “A”
Position Name and default setting Range Comment
A.20,30
A.50,60 Batch Enabled or Disabled YES/NO The top batch on each side
cannot be disabled. (A10&A40)
A1
Brew Volume
3 liters CBS-1130V+
1.50 gal CBS-1150V+
CBS-1130V+
0.95 – 4.75 (Liters) To switch between gallons and
liters, go to position B5
CBS-1150V+
0.50-2.00 (Gallons)
A2 Brew Time (Min: Sec)
4:00 2:00 – 12:00 Factory default total brew is 5:30
(4:00 brew time+1:30 drip delay)
A3 Prewet Percent
0% 0.00 – 15.0% Percentage of total brew volume.
A4 Prewet Delay
00:00 (Min:Sec) 0:10 – 5:00 Prewet must be > 0% The time between end of prewet cycle and start of brew cycle.
A6 Drip Delay
1:30 (Min:Sec) 0:30 – 6:00 Minutes Brew switch continues to flash.

B-E Advanced Settings and Diagnostics
Batch Parameters – B-GENERAL settings
Position Name and default setting Range Comment
B1 Tank Temperature
93° C -or- 200°F 70° to 96°C 157° to 205°F NOTE: Equipment factory default is set for metric
B2 Brew at Temp. Setpoint
“YES” YES/NO Batch to start when at set
temperature: SEE USER GUIDE
B3 LLC Sensitivity
“LOW” LOW/HIGH High is only for low mineral or
R.O water SEE USER GUIDE
B4 Temperature Scale
“°F” Fahrenheit °F/°C NOTE: Changing will overwrite
user settings
B5 Volume Scale
L-(CBS-1130) G-(CBS-1150) Liters/Gallons
User adjustable CBS-1130V+ factory set in liters
CBS-1150V+ factory set in gallons
B6 LEFT brew valve flow rate
NOTE: flow rate only in liters per min CBS-1130 1.55L/0.40G
CBS-1150 3.40L/0.9G Adjusts the brew valve flow rate.
SEE USER GUIDE
B7 RIGHT brew valve flow rate
NOTE: flow rate only in liters per min CBS-1130 1.55LPM
CBS-1150 3.40LPM Adjusts the brew valve flow rate.
SEE USER GUIDE
B8 Mains low flow
“NO” NO/YES Trims fill system for low flow
from supply

Batch Parameters – C-INPUTS controls & conditions
Position Name and default setting Range Comment
C1 LLC Probe Continuity
Direct Read Reading of tank water resistivity in TDS Reading of tank water resistivity in TDS
C2 Brew Basket Sensor YES/NO YES or NO
C3 Tank Temp.
Direct Read Hot water tank temperature Hot water tank temperature
C4 Keyboard Test All buttons Checks buttons under
membrane cover
Batch Parameters – D-OUTPUTS settings
Position Name and default setting Range Comment
D1 Heater Test ON/OFF
10 seconds maximum ON time Energizes Heaters!
For diagnostics/service use only
D2 Fill Valve Test ON/OFF
10 seconds maximum ON time Tests Fill Valve
D3 Left Valve Test ON/OFF
10 seconds maximum ON time Tests Left Brew Valve
D4 Right Valve Test ON/OFF
10 seconds maximum ON time Tests Right Brew Valve
NOTE: If heater or valve are switched “ON” for testing they will automatically turn “OFF” in ten (10) seconds
D7 LCD Brightness
Default is 8 0-15 Adjust LCD screen brightness
only-Not for LEDs under buttons

Use this formula to compensate for minor discrepancies in actual volume versus programmed volume
Measured Volume X
Current =New Use this formula to determine the new setting:
Enter new setting in B6 or B7 -See user guide.
Programmed Volume Setting Setting
Use theformulaabove to compensate and fine-tune brew volume. TIP:check flow from supply for fouled water filter
Brew valveflow ratesare in liter/min Enter the NewSetting value into B6/B7 and save as in the “F”screen.
HINT: Set lowerto increase volume, higher to decrease volume.
Use this to compensate for minor discrepancies in actual volume versus programmed volume.
E3-Error Codes
DO NOT CLEAR ERROR CODES UNTIL ERROR IS IDENTIFIED AND/OR CORRECTED Contact specialized personnel for error codes
Code Description Possible Cause Corrective Action
001 Software error-error on startup or
corrupted software Improper start-up or shutdown Restart , if still fault: reload software
050 Short-circuit in temperature probe Probe failure. Replace probe.
051 Open temperature probe. Bad probe connection, or probe failure.
Check all connections. Replace probe if necessary.
100 Initial Fill Error. Initial fill time took
longer than expected after power up. Water supply flow rate is too low. Watch for short potting during brew cycle. Investigate
cause of low flow rate. (Clogged water filter...)
101 Error on refill-. Tank did not refill within
expected time. Water supply flow rate is too low. Watch for short potting during brew cycle. Investigate
cause of low flow rate. (Clogged water filter…)
201 Heateropen, high limit thermostat
or Solid-State Relay (SSR) fault Failure of: heating element, SSR, high
Limit or low voltage Check and replace heating elements if necessary.
255 Touch pad error Keyboard contact longer than 2 min
Or faulty reassembly Restart , if still fault: reload software. If mechanical: replace membrane switch or control module
NO
BSKTInsert Brew Basket Brew basket must be in place
This is a SAFETY FEATURE Insert brew basket into brewer rails to enable brewer
Consult the user guide for your brewer for more complete information

Batch Parameters – E-OTHER software and code settings
Position Name and default setting Range Comment
E1 Display Firmware 1.0.1744 Displays current version
E2 Select Model CBS-1131
CBS-1132
CBS-1151
CBS-1152
NOTE: Will need reboot
COMPLETELY OVERWRITES ALL
USER SETTINGS
E3 Display Errors 1=Newest/6=Oldest
LAST six errors only See Error Code Chart for references
Resetting error codes should be after completing the service and factorydiagnostics and
correcting any brewer faults. Clear error codes by cycling the brewer “OFF” then “ON”.
E4 Reset Errors YES/NO NOTE: Always contact FETCO Technical Service for errors
[phone]
E5 (Reload) DEFAULTS Reset to default of
base model NOTE: COMPLETELY OVERWRITES
ALL USER SETTINGS
E6 USB Data Save Save data to USB
E7 Load From USB Will need reboot Plug in USB flash-drive device
E8 DEMO Mode
ON/OFF
Demonstrates the controls for
training. Brewer will not brew
when in demo mode.
Reset in E8 to “OFF” to exit

Batch Parameters F–HOW TO SAVE SETTINGS –EXIT & RETURN TO PROGAMMING
IMPORTANT! After programming, you MUST SAVE your settings before exiting programming
mode or changes will be lost.
Settings are saved from the “F” screen as shown below.
You may exit programming at any time.
After programmed settings are saved, the brewer exits PROGRAMMING mode and returns to
regular brew operations. Settings are saved only when brewer returns to OPERATING MODE
DO NOT attempt to save by rebooting (turning power OFF then ON). All changes made will be
discarded and brewer will remain in the existing default settings.
From any screen-Press
STOP button until the
EXIT (“F”) screen
appears
From the “F” screen
Press button 2to
toggle to show the
EXIT-YES screen
From EXIT-YES screen
Press button 1to
toggle to show the
SAVE screen
From SAVE screen
Press button 2to
toggle to show the
SAVE-YES screen
To SAVE and EXIT
Press button 1to
SAVE your changes
and to EXIT to
OPERATING MODE
EXIT
F YES –
1
2
STOP
STOP
A4
A5
3
A6
SAVE
F1 NO +
1
2
STOP
STOP
A4
A5
3
A6
Programming A-F
A - F
1
2
STOP
STOP
A4
A5
3
A6
EXIT
F NO +
1
2
STOP
STOP
A4
A5
3
A6
SAVE
F1 YES –
1
2
STOP
STOP
A4
A5
3
A6
