FGD FlameSpec IR3 Series User manual

FlameSpec IR3 User Manual
Doc. No. F120V0020.07
4222 E. La Palma Ave, Anaheim, CA 92807 USA T: ([phone]
www.fg-detection.com · suppor[email protected]
FlameSpec IR3

Information
FlameSpec-IR3 Triple IR Flame Detector User Guide, October 2022
Copyright © Fire & Gas Detection Technologies Inc. All rights reserved.
The owner or authorized user of a valid copy of this manual may reproduce this publication for the
purpose of learning to use the specified equipment. No part of this publication may be reproduced or
transmitted for commercial purposes, such as selling copies of this publication or for providing paid for
support services.
The Fire & Gas Detection Technologies logo is a trademark of Fire & Gas Detection Technologies Inc.,
registered in the U.S. and other countries.
Every effort has been made to ensure that the information in this manual is accurate. However, Fire &
Gas Detection Technologies Inc. is not responsible for any inaccuracy or omission in this document. The
information in this document is subject to change without notice.
Legal Notice
Hardware, software or documentation is forbidden to reproduced, transmitted, transcribed, stored in a
retrieval system or translated into any language or computer language, in any form or by any means.
While great efforts have been made to assure the accuracy and clarity of this document, FIRE & GAS
DETECTION TECHNOLOGIES INC. assumes no liability resulting from any omissions in this document, or
from misuse of the information obtained herein. The information in this document has been carefully
checked and is believed to be entirely reliable with all of the necessary information included.
FIRE & GAS DETECTION TECHNOLOGIES INC. reserves the right to make changes to any products
described herein to improve reliability, function, or design, and reserves the right to revise this
document and make changes from time to time in content hereof with no obligation to notify any
persons of revisions or changes. FIRE & GAS DETECTION TECHNOLOGIES INC does not assume any
liability arising out of the application or any use of any product or circuit described herein; neither does
it convey license under its patent rights or the rights of others.

FlameSpec IR3 User Manual
Doc. No. F120V0020.07
For more information & technical support: ([phone] · [e-mail] iii
Table of Contents
1Introduction.................................................................................................................... 1
1.1 Features ..............................................................................................................................1
1.2 Model Number Description..................................................................................................2
1.3 Internal tests .......................................................................................................................2
1.4 Product Overview ................................................................................................................3
1.5 Accessories..........................................................................................................................4
2Installation ..................................................................................................................... 7
2.1 General Considerations........................................................................................................7
2.2 Preparations for Installation...............................................................................................10
2.3 Required Tools...................................................................................................................10
2.4 Certification Instructions....................................................................................................10
2.5 Mounting the Tilt Mount....................................................................................................11
2.6 Mounting the detector.......................................................................................................12
2.7 Electrical Wiring.................................................................................................................14
2.8 Current Output (0-20mA) Wiring ........................................................................................16
2.9 4 Wire Relay Connection ....................................................................................................18
2.10 RS-485 Communication Network........................................................................................19
2.11 Cabling Recommendations.................................................................................................19
2.12 Earth/Ground Regime ........................................................................................................19
3Configuration options ................................................................................................... 21
3.1 Sensitivity..........................................................................................................................22
3.2 Ultra-Fast Detection...........................................................................................................22
3.3 Alarm Delay.......................................................................................................................22
3.4 Alarm Latch .......................................................................................................................22
3.5 Enable Pre-Alarm 0-20mA ..................................................................................................22
3.6 Enable dirty window warning 0-20mA ................................................................................23
3.7 Auxiliary Relay...................................................................................................................23

FlameSpec IR3 User Manual
Doc. No. F120V0020.07
For more information & technical support: ([phone] · [e-mail] iv
3.8 Window Heater .................................................................................................................23
3.9 Modbus Address................................................................................................................23
3.10 Manual BIT –Alarm Output Test (Full loop test)..................................................................23
4Operation ..................................................................................................................... 24
4.1 Output Signals ...................................................................................................................24
4.2 Testing...............................................................................................................................25
4.3 Flame Simulator.................................................................................................................25
5Maintenance ................................................................................................................ 26
5.1 Cleaning Procedure............................................................................................................26
6Troubleshooting............................................................................................................ 27
7Servicing ....................................................................................................................... 28
8FGD Communicator Software ........................................................................................ 28
9Specifications................................................................................................................ 29
9.1 Fire Detection....................................................................................................................29
9.2 Electrical Specifications......................................................................................................29
9.3 Outputs .............................................................................................................................30
9.4 Mechanical Specifications ..................................................................................................30
9.5 Environmental Specifications .............................................................................................30
9.6 Product Labeling................................................................................................................31
9.7 Approvals ..........................................................................................................................33
9.8 Electromagnetic Compatibility ...........................................................................................33
10 Performance.............................................................................................................. 34
10.1 FLS-IR3-ASX1 (Standard mode)...........................................................................................34
10.2 False Alarm Immunity ........................................................................................................36
11 Ordering Information................................................................................................. 37
12 Warranty................................................................................................................... 38
Appendix A.......................................................................................................................... 39

FlameSpec IR3 User Manual
Doc. No. F120V0020.07
For more information & technical support: ([phone] · [e-mail] v
List of Figures
Figure 1 - Front view of the FLS-IR3...................................................................................................... 3
Figure 2 - Rear view of the FLS-IR3 ....................................................................................................... 3
Figure 3 - Tilt mount.............................................................................................................................. 4
Figure 4 - Weather Cover...................................................................................................................... 4
Figure 5 - Pole Mount ........................................................................................................................... 5
Figure 6 - Air Shield............................................................................................................................... 5
Figure 7 - Flame Simulator Kit............................................................................................................... 6
Figure 8 - FLS-FSIM-IR3 Flame Simulator Front View ........................................................................... 6
Figure 9 - Horizontal Field of View........................................................................................................ 8
Figure 10 - Vertical Field of View .......................................................................................................... 8
Figure 11: Tilt Mount Base - Plate View.............................................................................................. 12
Figure 12: Tilt mount base –Side View............................................................................................... 12
Figure 13 - Detector on Tilt Mount –Side View.................................................................................. 13
Figure 14 –Terminal View .................................................................................................................. 14
Figure 15 –Source 4-Wire Scheme..................................................................................................... 16
Figure 16 –Sink 4-Wire Scheme ......................................................................................................... 16
Figure 17 –Source 3-Wire Scheme..................................................................................................... 17
Figure 18 –Sink 3-Wire Scheme ......................................................................................................... 17
Figure 19 - 4 Wire Relay Connection................................................................................................... 18
Figure 20: RS-485 Networking ............................................................................................................ 19
List of Tables
Table 1: Terminal connections............................................................................................................ 15
Table 2: Detector Configuration Options............................................................................................ 21
Table 3: Sensitivity levels.................................................................................................................... 22
Table 4: Output Signals....................................................................................................................... 24

FlameSpec IR3 User Manual
F120V0020.07
For more information & technical support: ([phone] · [e-mail] 1
1Introduction
The FlameSpec-IR3 (FLS-IR3) will detect fires and explosions extremely quickly allowing
preventative action to be initiated rapidly to help minimize the consequences.
•Detection within 40 milliseconds of fireballs or explosions
•Standard fire is detected within 1.5s from 100 ft. (30m), 3.7s from 230 ft. (70m) and 7.1s
from 262 ft. (80m).
The FlameSpec-IR3 flame detector provides ultra-fast response, high performance and reliable detection
of all types of hydrocarbon fires (visible and non-visible). The detector responds to slow growing fires as
well as fast growing fire using improved Triple IR (IR3) technology. The detector operates in all weather
and light conditions with highest immunity to false alarms. The integral event recording in addition to
the proven superior capabilities of Triple IR (IR3) flame detection provide you with a very powerful
safety tool to protect personnel, plant and process.
The detector is certified for use in hazardous area locations; it may also be used in other areas not
classified as hazardous. The two cable/conduit entries either side of the lower part of the detector
housing are for connecting power and outputs to associated signaling equipment.
During normal operation, the flame detector performs self-tests of its optics, electronics and software.
These include a periodic BIT (Built-In-Test) in which the sensors and window cleanliness are tested.
1.1 Features
•Extreme sensitivity - up to 260ft (80m) for a 1ft2(0.1m2) n-heptane pan fire.
•Ultra-fast detection mode - detection within 40 milliseconds for fireballs or explosions.
•Option: Improved false alarm immunity in high CO2 applications, like aircraft hangars or helidecks.
•Option: Improved speed of response - (0.5s) for enclosed spare protection, like automotive applications
in compliance with NFPA 33 or printing presses and conveyors.
•Built-in-Test (BIT) - Automatic and manual self-test of window cleanliness and detector operation.
•Window heater to avoid condensation and icing.
•Tilt mounting bracket for accurate detector positioning.

FlameSpec IR3 User Manual
F120V0020.07
For more information & technical support: ([phone] · [e-mail] 2
1.2 Model Number Description
The model numbers are defined as follows:
FLS-IR3 - A S X X
1
Standard
3
Like model 1, but recommended for Hangar, Helideck and
Petroleum Loading Racks
5
Like model 1 but with a fast response mode that is designed
for, but not limited to, automotive spray paint applications
where compliance with 0.5s response (per NFPA 33) is
needed.
1
M25
2
¾” NPT
1.2.1 Enhanced performance options
Option 3: Increased false alarm immunity in presence of hot CO2. Recommended for Hangar, Helideck
and Petroleum Loading Racks
Option 5: Design for, but not limited to, automotive spray paint applications where compliance with 0.5
s response (per NFPA 33) is needed
1.3 Internal tests
During normal operation, the flame detector performs self-tests of its optics, electronics and
software. These include a periodic BIT (Built-In-Test) in which the sensors and window
cleanliness are tested. Any detected fault is indicated as shown in Table 4 (in section 4.1). During
“Dirty Window” fault the detection sensitivity is significantly reduced, while “Fault” refers to
critical faults which totally prevent flame detection.

FlameSpec IR3 User Manual
F120V0020.07
For more information & technical support: ([phone] · [e-mail] 3
1.4 Product Overview
FIGURE 1-FRONT VIEW OF THE FLS-IR3
FIGURE 2-REAR VIEW OF THE FLS-IR3

FlameSpec IR3 User Manual
F120V0020.07
For more information & technical support: ([phone] · [e-mail] 4
1.5 Accessories
1.5.1 Mounting Bracket
The detector should be mounted using the
stainless-steel tilt mount part number FLS-TMO-
S01. This allows the detector to be securely
attached to a wall, pole or other solid surface
using appropriate fixings. See section2.5 and 2.6
for further details.
FIGURE 3-TILT MOUNT
1.5.2 Weather Cover
The weather cover P/N FLS-WCO-S01 protects
the detector from extreme weather conditions
such as heat, rain, and snow.
FIGURE 4-WEATHER COVER

FlameSpec IR3 User Manual
F120V0020.07
For more information & technical support: ([phone] · [e-mail] 5
1.5.3 Pole mount
The pole mount enables the detectors to be
installed with its tilt mount brackets. The pole
mount kit we supply are suitable for 2-inch or 3-
inch poles. Part number FLS-PMA-S23.
FIGURE 5-POLE MOUNT
1.5.4 Air shield
The air shield P/N FLS-ASD-S01 allows installation of
flame detectors in harsh weather conditions where
they may be exposed to dust, sand, and other
particulate matter. The connection point can be
mounted in the 3, 9 or 12 o’clock locations.
•Air pressure source: Clean, dry, and oil-free air
•Pressure: 2-3 bar /30-45 psi
•Fitting: 7/16”—20UNF-2A
•Operation temperature: -55°C to +85°C / -67°F
to +185°F
FIGURE 6-AIR SHIELD

FlameSpec IR3 User Manual
F120V0020.07
For more information & technical support: ([phone] · [e-mail] 6
1.5.5 Flame Simulator
The FLS-IR3 may be tested using the FLS-FSIM-
IR3-KIT. The FlameSpec flame simulator family
provides a fast and convenient means of
periodically testing the detector and control
system end-to-end. Maintenance costs can be
reduced as the detectors can be tested in situ
without needing a hot work permit.
FlameSpec Flame Simulators emit IR radiation in
a special electromagnetic radiation pattern which
simulates a fire to the detectors. The simulators
are lightweight, easy to use, with testing
distances of up to 23 ft. (7m) and capable of
more than 1000 activations between battery
charging. FlameSpec Flame Simulators are ATEX
approved for use in hazardous Zone 1, Zone 2,
Zone 21, Zone 22 areas.
Each simulator kit contains a carrying case,
simulator, carrying strap, battery charger, user
manual, Allen key and a tool for removing the
simulator rear cover.
FIGURE 7-FLAME SIMULATOR KIT
FIGURE 8-FLS-FSIM-IR3 FLAME SIMULATOR FRONT
VIEW

FlameSpec IR3 User Manual
F120V0020.07
For more information & technical support: ([phone] · [e-mail] 7
2Installation
This chapter does not attempt to cover all of the standard practices and codes of
installation. Rather, it emphasizes specific points of consideration and provides some
general rules for qualified personnel. You must always observe special safety
precautions.
2.1 General Considerations
This section includes important information.
•To help obtain optimal performance, the detector should be aimed toward the center of the
hazard or area to be monitored and protected ("detection zone") and have, to the extent
that is required, an unobstructed view of the protected area. Whenever possible, the
detector face should be tilted (aimed) down at an angle to prevent the accumulation of dust
and dirt.
•Do not start an installation until the performance target, system configuration, installation
location and coverage considerations have been defined by the responsible person.
To ensure optimal performance the following guidelines should be addressed:
Sensitivity
To determine the sensitivity level, the following issues should be considered:
•The size of the fire to be detected at the determined distance.
•The type of flammable fuel.
•Potential sources of false alarms that may be present (e.g., naked flames, hot process).
Spacing and Location
Consider the following factors when determining the number of detectors and their
locations in the protected area:
•The size and shape of the protected area
•The nature of the hazards, including materials stored or used and the protected objects
•The sensitivity of the detectors
•If there are any obstructed lines of sight
•The field of view of the detectors (See Figure 9 and Figure 10)

FlameSpec IR3 User Manual
F120V0020.07
For more information & technical support: ([phone] · [e-mail] 8
FIGURE 9-HORIZONTAL FIELD OF VIEW
FIGURE 10 -VERTICAL FIELD OF VIEW

FlameSpec IR3 User Manual
F120V0020.07
For more information & technical support: ([phone] · [e-mail] 9
Environment
•Environmental conditions including but not limited to dust, snow or rain can reduce the
detectors sensitivity and require additional consideration.
Hot Work
•Arc welding should not be performed within 12 ft. (3.5m) of the detector. It is
recommended that the system be inhibited during welding operations in situations
where the possibility of a false alarm cannot be tolerated.
•Gas welding requires a system inhibit, since the gas torch is an actual fire.
•Arc welding rods can contain organic binder materials in the flux that burn during the
welding operation and are detectable by the device.
•Welding rods with clay binders do not burn and should not be detected. However, a
system inhibit is always recommended, since the material being welded may be
contaminated with organic substances (paint, oil, etc.) that will burn and may be of the
size that should be detected.

FlameSpec IR3 User Manual
F120V0020.07
For more information & technical support: ([phone] · [e-mail] 10
2.2 Preparations for Installation
The installation must comply with national and local regulations and standards applicable to
flame detectors (e.g., NFPA 72) and all local and common engineering practices. It is
recommended to consult with the authority having jurisdiction.
Prior to installation:
•Make sure that you have all the components and tools required to complete the detector
installation readily available before beginning installation. In cases where you cannot
complete the installation in a single session, secure and seal the detectors and conduits
before leaving site.
•Use color-coded conductors or suitable wire markings or labels for the wiring. You may use
14 to 17 AWG (2.5mm2 to 1.0mm2) multi-strand wires for the site wiring. The selection of
wire gauge should be based on the number of detectors used on the same line and the
distance from the control unit, in compliance with specifications.
•Individually screen twisted pair cable is recommended for RS485 terminals.
•Use suitably rating wire for the application certification and temperatures.
2.3 Required Tools
The detector can be installed using the following tools:
Tool
Function
Hex. KEY 6 mm
Vertical alignment
Hex. KEY 10 mm
Horizontal alignment
Wrench 13 mm
Mounting the detector
Flat Screwdriver 6 mm
Ground screw connection
Flat screwdriver 3.5mm
Terminal connection
2.4 Certification Instructions
Warnings
•Do not open the detector, even when isolated, when flammable atmosphere present.
•The equipment may be used in hazardous areas with flammable gasses and vapors with
apparatus groups IIC, IIB and IIA and with temperature classes T1, T2, T3, T4 and T5. See
details of the explosion proof approvals in section 0.
•The equipment is certified for use in ambient temperatures in the range of -67°F to +167°F (-
55°C to +75°C) or -67°F to +185°F (-55°C to +85°C) and should not be used in temperatures
outside this range.

FlameSpec IR3 User Manual
F120V0020.07
For more information & technical support: ([phone] · [e-mail] 11
•Installation shall be carried out in accordance with the applicable code of practice by
suitably trained personnel.
•Inspection and maintenance of this equipment shall be carried out by suitably trained
personnel in accordance with the applicable code of practice.
•If the equipment is likely to come into contact with corrosive and/or other harsh substances,
consult with the relevant technical persons to take suitable precautions to prevent the
detector from being adversely affected, thus ensuring that the type of protection is not
compromised.
•Harsh substances: For example, acidic liquids, gases, or solvents that may attack the
windows, metals, seals or polymeric materials.
•Suitable precautions: For example, regular checks as part of routine inspections or
establishing from the material’s data sheet that it is resistant to specific chemicals.
Specific conditions for use
•The equipment is not intended to be repaired by the user. Repair of this equipment shall be
carried out by the manufacturer in accordance with the applicable code of practice.
•The flame paths are not intended for repair. Contact the manufacturer if the flame paths are
damaged.
•Consult the manufacturer for genuine replacement cover and housing to connection box
fasteners. M6x1x18 Hexagonal Socket head fasteners with a minimum of ISO 4762 Grade A4
Class 80 are acceptable alternatives.
•One suitably certified stopping plug is supplied with the detector.
•The external earthing connection consists of cable lug with M5x10 stainless steel screw, the
terminals is suitable for connection of a wire of at least 4mm2 /12AWG.
The internal terminals are suitable for connection of a wire equal to or greater than the power
input wiring and at a minimum of 1mm2/ 17AWG conductor.
2.5 Mounting the Tilt Mount
The tilt mount enables the detector to be rotated up to 45 degrees (horizontal/vertical)
in all directions. The following installation instructions show how to use it to support the
detector from below (the preferred method).
To install the tilt mount:
1. Mount the tilt mount base (Figure 11: Tilt Mount Base - Plate View) to a solid
structure using four suitable fixings through the four 7mm (0.28") diameter
holes. Four captive screws with spring washers are provided in the tilt mount.

FlameSpec IR3 User Manual
F120V0020.07
For more information & technical support: ([phone] · [e-mail] 12
Figure 11: Tilt Mount Base - Plate View
Figure 12: Tilt mount base –Side View
2.6 Mounting the detector
Use the following steps to connect the detector to the tilt mount, referring to Figure 13:
•Place the detector, with its cable/conduit entries pointing down, on the holding plate of the
tilt mount (item 2).
•Secure the detector to the plate using the two hex screws and spring lock washers (items 3
and 4).
•Loosen the locking screws (Items 5 and 6) in such a way that enables you to rotate the
detector.

FlameSpec IR3 User Manual
F120V0020.07
For more information & technical support: ([phone] · [e-mail] 13
•Point the detector towards the detection area and make certain that the view of the area is
unobstructed.
•Secure the detector in that position by tightening the locking screws (Items 5 and 6) on the
tilt mount. (Make sure the detector is pointing in the correct direction).
The detector is now correctly mounted, aligned and ready for electrical connection. Please refer
to section 2.7 for wiring instructions, and section 3 for a description of the detector’s
configuration settings.
FIGURE 13 -DETECTOR ON TILT MOUNT –SIDE VIEW
ITEM
NO.
ITEM NAME
1
TILT MOUNT ASSEMBLY
2
HOLDING PLATE
3,4
MOUNTING HEX SCREWS M8 AND LOCK WASHERS
5
HEX SOCKET LOCKING SCREW M8
6
HEX SOCKET LOCKING SCREW M12
3, 4
1
6
2
5

FlameSpec IR3 User Manual
F120V0020.07
For more information & technical support: ([phone] · [e-mail] 14
2.7 Electrical Wiring
Warning
•The sensor module in the front half of the detector contains no serviceable components and
should never be opened. Opening will invalidate the warranty of the detector. The terminal
compartment at the back is the only part of the housing that should be opened by the user.
•The detector has 16 screw terminals as shown in the following figure and table:
FIGURE 14 –TERMINAL VIEW

FlameSpec IR3 User Manual
F120V0020.07
For more information & technical support: ([phone] · [e-mail] 15
TABLE 1: TERMINAL CONNECTIONS
Pin #
Function
Description
Ground
Ground (earth)
Connected to a screw on the housing exterior.
1
24 VDC (+)
Power supply (18-32 VDC)
2
24 VDC (-)
Power supply return (0V)
3
0-20mA+ (In)
This output is used for analog 0-20 mA current output
4
0-20mA- (out)
5
Fault Relay
A SPST contact relay, that is energized (closed) when the detector is in
normal operation and opens in case of fault.
6
Fault Relay COM
7
Alarm Relay (NO)
A normally open SPST contact relay, that is open in normal operation,
and closed when fire is detected. This relay can be configured to latch
as described in section (3.4).
8
Alarm Relay COM
11
24 VDC (+)
Power supply (18-32 VDC)
12
24 VDC (-)
Power supply return (0V)
13
Manual BIT activation
The manual BIT (built-in test) can be initiated by momentarily
connecting this terminal and one of the “24 VDC (-)” terminals (2 or 12).
See 3.10 Manual BIT –Alarm Output Test for more details.
14
Shield
This terminal should be left connected to the housing internal ground
screw.
15
RS-485 (+)
RS-485 Modbus communication (also used by the “FGD Communicator”
software)
16
RS-485 (-)
17
Auxiliary Relay NO
A normally open SPST contact relay, that is open in normal operation,
and closed according to the configuration used.
18
Auxiliary Relay COM
